2005 MERCEDES-BENZ G55AMG technical data

ContentsTechnical data.................................. 363
Parts service ...................................... 364
Warranty coverage ............................. 365
Loss of Service and Warranty
Information Booklet...................... 365
Identification labels............................ 366
Layout of poly-V-belt drive ................. 367
G 500 ........................................... 367
G 55 AMG..................................... 367
Engine ................................................ 368
Rims and tires .................................... 369
Rims and Tires............................. 370
Spare wheels................................ 371
Electrical system................................ 372
Main dimensions, vehicle weights
and ratings ......................................... 373
Main dimensions .......................... 373
Vehicle weights and ratings ......... 373Fuels, coolants, lubricants, etc. ......... 374
Capacities .................................... 374
Engine oils.................................... 375
Engine oil additives ...................... 376
Air conditioning refrigerant .......... 376
Brake fluid .................................... 376
Premium unleaded gasoline ......... 376
Fuel requirements ........................ 377
Gasoline additives ........................ 377
Coolants....................................... 378
Anticorrosion/antifreeze.............. 379
Windshield/rear window
washer system and headlamp
cleaning system ........................... 380
Technical terms............................... 381Index................................................. 387

15 Introduction
Where to find it
Where to find it
This Operator’s Manual is designed to pro-
vide comprehensive support information
for you, the vehicle operator. Each section
has its own reference color so you can find
information quickly.At a glance
Here you will find an overview of all the
controls that can be operated from the
driver’s seat.Getting started
Here you will find all the information you
need for your first drive. You should read
this section first if this is your first
Mercedes-Benz vehicle or if you are rent-
ing or borrowing this vehicle.Safety and Security
Here you will find descriptions of the safety
and security features of your vehicle.
Controls in detail
Here you will find detailed information
about the equipment installed on your ve-
hicle. This section expands on the “Getting
started” section and also describes techni-
cal innovations. If you are already familiar
with the basic functions of your vehicle,
this section will be of particular interest to
you.Operation
Here you will find all the information you
need for the proper operation of your vehi-
cle.Practical hints
This section provides fast assistance for
dealing with problems you may encounter.
Technical data
All important technical data for your vehi-
cle can be found in this section.Indexes
The glossary provides explanations of the
most important technical terms.
The table of contents and the index are de-
signed to help you find information quickly
and easily.
The following publications are part of your
vehicle documentation:

this Operator’s Manual


the Maintenance Booklet
Separate operating instructions will be
provided as required depending on the
equipment options installed in your vehi-
cle.

17 Introduction
Operating safety
Operating safety
Proper use of the vehicle
Proper use of the vehicle requires that you
are familiar with the following information
and rules:

the safety precautions in this manual


the “Technical data” section in this
manual


traffic rules and regulations


motor vehicle laws and safety stan-
dards
Warning!
G
Work improperly carried out on electronic
components and associated software could
cause them to cease functioning. Because
the vehicle’s electronic components are in-
terconnected, any modifications made may
produce an undesired effect on other sys-
tems. Electronic malfunctions could seri-
ously impair the operating safety of your
vehicle.
See an authorized Mercedes-Benz Light
Truck Center for repairs or modifications to
electronic components.
Other improper work or modifications on the
vehicle could also have a negative impact on
the operating safety of the vehicle.
Some safety systems only function while the
engine is running. You should therefore nev-
er turn off the engine while driving.
Warning!
G
Heavy blows against the vehicle underbody
or tires / wheels, for example when running
over an obstacle, road debris or a pothole,
may cause serious damage and impair the
operating safety of your vehicle. If you feel a
sudden significant vibration or ride distur-
bance, or you suspect that damage to your
vehicle has occurred, you should turn on
your hazard warning flashers, carefully slow
down, and drive with caution to an area
which is a safe distance from the road.
Inspect the vehicle underbody and
tires / wheels for possible damage. If the ve-
hicle appears unsafe, have it towed to the
nearest authorized Mercedes-Benz Light
Truck Center or other qualified maintenance
or repair facility for further inspection or re-
pairs.
Warning!
G
Various warning labels are attached to your
vehicle. These warning labels are intended
to make you and others aware of various
risks. You should not remove any of these
warning labels unless explicitly instructed to
do so by information on the label itself. Re-
moval of any of these labels may cause you
and others to be unaware of certain risks
which may result in an accident and/or per-
sonal injury.

240 OperationEngine compartmentChecking engine oil level with the
control system
When checking the oil level

the vehicle must be parked on level
ground


with the engine at operating tempera-
ture, the vehicle must have been sta-
tionary for at least five minutes with the
engine turned off


with the engine not at operating tem-
perature yet, the vehicle must have
been stationary for at least 30 minutes
with the engine turned off
To check the engine oil level via the
multifunction display, do the following:

Switch on the ignition (
page 35).
The standard display (
page 123) should
appear in the multifunction display.

Press buttonk orj on the
steering wheel until the following
message is seen in the multifunction
display:ENGINE OIL LEVEL
MEASURING NOW
MEASURE. CORRECT
ONLY IF VEH. LEVELOne of the following messages will
subsequently appear in the indicator:

ENGINE OIL LEVEL
OK


ADD 1.0 Qt. TO
REACH MAX. OIL LEVEL!(Canada:
1.0 LITER
)


ADD 1.5 Qts. TO
REACH MAX. OIL LEVEL!(Canada:
1.5 LITERS
)


ADD 2.0 Qts. TO
REACH MAX. OIL LEVEL!(Canada:
2.0 LITERS
)

If necessary, add engine oil.
For adding engine oil see (
page 243).
For more information on engine oil, see the
“Technical data” section (
page 374) and
(
page 375).iIf you want to interrupt the checking
procedure, press thek orj
button on the multifunction steering
wheel.

242 OperationEngine compartmentChecking engine oil level with the oil
dipstick
When checking the oil level the vehicle
must

be parked on level ground


be at normal operating temperature


have been stationary for at least five
minutes with the engine turned offTo check the engine oil level with the oil
dipstick, do the following:

Open the hood (
page 238).

Pull out oil dipstick1 (
page 243).

Wipe oil dipstick1 clean.

Fully insert oil dipstick1 into the
dipstick guide tube.

Pull out oil dipstick1 again after
approximately three seconds to obtain
accurate reading.
Oil dipstickThe oil level is correct when it is between
the lower (min) and upper (max) mark of
the oil dipstick.

If necessary, add engine oil.
For adding engine oil see (
page 243).
For more information on engine oil, see the
“Technical data” section (
page 374) and
(
page 375).
For more information on messages in the
multifunction display concerning engine
oil, see the “Practical hints” section
(page 309).
iThe engine oil level can be checked by
either the oil dipstick or via the multi-
function display in the instrument
cluster (
page 240). The amount of
engine oil needed is shown more
precisely in the multifunction display.
iThe filling quantity between the upper
and lower marks on the oil dipstick is
approximately 2.1 US qt. (2.0 l).

244 OperationEngine compartment
Screw oil filler cap2 back on filler
neck.
For more information on engine oil, see the
“Technical data” section (
page 374) and
(
page 375).
Transmission fluid level
The transmission fluid level does not need
to be checked. The transmission has a per-
manent supply of automatic transmission
fluid.
If you notice transmission fluid loss or gear
shifting malfunctions, have an authorized
Mercedes-Benz Light Truck Center check
the automatic transmission.Coolant level
The engine coolant is a mixture of water
and anticorrosion/antifreeze.
When checking the coolant level,

the vehicle must be parked on level
ground.


the engine must be cool. The coolant
level should reach the COLD LEVEL
mark in the reservoir.
!Excess oil must be siphoned or drained
off. It could cause damage to the
engine and catalytic converter not
covered by the Mercedes-Benz Limited
Warranty.
Warning!
G
In order to avoid any possibly serious burns:

Use extreme caution when opening the
hood if there are any signs of steam or
coolant leaking from the cooling system,
or if the coolant temperature display in-
dicates that the coolant is overheated.


Do not remove pressure cap on coolant
reservoir if coolant temperature is
above 158°F (70°C). Allow engine to
cool down before removing cap. The
coolant reservoir contains hot fluid and
is under pressure.


Using a rag, slowly open the cap approx-
imately
1/2turn to relieve excess pres-
sure. If opened immediately, scalding
hot fluid and steam will be blown out un-
der pressure.


Do not spill antifreeze on hot engine
parts. Antifreeze contains ethylene gly-
col which may burn if it comes into con-
tact with hot engine parts.


363 Technical data
Parts service
Warranty coverage
Identification labels
Layout of poly-V-belt drive
Engine
Rims and tires
Electrical system
Main dimensions, vehicle weights and ratings
Fuels, coolants, lubricants, etc.

364 Technical dataThe “Technical data” section provides the
necessary technical data for your vehicle.Parts service
All authorized Mercedes-Benz Light Truck
Centers maintain a stock of genuine
Mercedes-Benz parts required for mainte-
nance and repair work. In addition, strate-
gically located parts distribution centers
provide quick and reliable parts service.
More than 300 000 different parts for
Mercedes-Benz models are available.
Genuine Mercedes-Benz parts are subject-
ed to stringent quality inspections. Each
part has been specifically developed, man-
ufactured or selected for and adapted to
Mercedes-Benz vehicles.
Therefore, genuine Mercedes-Benz parts
should be installed.
!The use of non-genuine Mercedes-Benz
parts and accessories not authorized
by Mercedes-Benz could damage the
vehicle, which is not covered by the
Mercedes-Benz Limited Warranty, or
could compromise the vehicle’s dura-
bility or safety.
