2005 MERCEDES-BENZ E WAGON Owner's Manual

120 Controls in detailLocking and unlockingIf the tailgate comes into contact with an
object while closing (e.g. luggage that has
been piled too high), the closing procedure
is stopped and the tailgate reopens
slightly.
iYou can also close the tailgate by hand.iTo prevent a possible inadvertent lock-
out, the tailgate will open automatically
if a SmartKey with KEYLESS-GO is rec-
ognized in the rear shelf or inside the
vehicle.
Warning!
G
Monitor the closing procedure carefully to
make sure no one is in danger of being in-
jured. To prevent possible personal injury,
always keep hands and fingers away from
the cargo compartment opening when clos-
ing the tailgate. Be especially careful when
small children are around. To stop the clos-
ing procedure, do one of the following:

press the tailgate closing switch1


press the Š button on the SmartKey
with KEYLESS-GO


pull the remote tailgate switch (on the
driver’s door)
Even with the SmartKey with KEYLESS-GO
removed from the vehicle, the tailgate clos-
ing switch can be operated. Therefore, do
not leave children unattended in the vehicle,
or with access to an unlocked vehicle. Unsu-
pervised use of vehicle equipment may
cause an accident and/or serious personal
injury.
Warning!
G
Only drive with the tailgate closed as,
among other dangers such as visibility
blockage, exhaust fumes may enter the
vehicle interior.iIf the vehicle was previously centrally
locked, the tailgate will lock automati-
cally after closing it.
To confirm locking all turn signal lamps
flash three times.

121 Controls in detail
Locking and unlocking
Closing the tailgate and locking the
vehicle from the outside (vehicles with
KEYLESS-GO*)
In vehicles with tailgate opening/closing
system* and KEYLESS-GO, you can close
the tailgate and lock the vehicle simulta-
neously from the outside using the
KEYLESS-GO locking/closing switch.
1KEYLESS-GO* locking/closing switch
Make sure you have SmartKey with
KEYLESS-GO with you.

Press switch 1 briefly.

All turn signal lamps flash three
times.


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.
If the tailgate comes into contact with an
object while closing (e.g. luggage that has
been piled too high), the closing procedure
is stopped and the tailgate reopens
slightly.
iYou can also close the tailgate by hand.iTo prevent a possible inadvertent lock-
out, the tailgate will open automatically
if a SmartKey with KEYLESS-GO is rec-
ognized in the rear shelf or inside the
vehicle.
Warning!
G
Monitor the closing procedure carefully to
make sure no one is in danger of being in-
jured. To prevent possible personal injury,
always keep hands and fingers away from
the cargo compartment opening when clos-
ing the tailgate. Be especially careful when
small children are around. To stop the clos-
ing procedure, do one of the following:

press the tailgate closing switch1


press the Š button on the SmartKey
with KEYLESS-GO


pull the remote tailgate switch (on the
driver’s door)
Even with the SmartKey with KEYLESS-GO
removed from the vehicle, the KEYLESS-GO
locking/closing switch can be operated.
Therefore, do not leave children unattended
in the vehicle, or with access to an unlocked
vehicle. Unsupervised use of vehicle equip-
ment may cause an accident and/or serious
personal injury.

122 Controls in detailLocking and unlockingAutomatic central locking
The doors and the tailgate automatically
lock when the ignition is switched on and
the wheels are turning at vehicle speeds of
approximately 9 mph (15 km / h) or more.
You can open a locked door from the in-
side. Open door only when conditions are
safe to do so.For more information on towing the vehi-
cle, see “Towing the vehicle” (
page 430).
You can deactivate the automatic locking
mode using the control system
(
page 174).
Locking and unlocking from the inside
You can lock or unlock the doors and the
tailgate from inside using the central lock-
ing switch. This can be useful, for example,
if you want to lock the vehicle before start-
ing to drive.
The fuel filler flap cannot be locked or un-
locked with the central locking switch.
Warning!
G
Only drive with the tailgate closed as,
among other dangers such as visibility
blockage, exhaust fumes may enter the ve-
hicle interior.
iThe doors unlock automatically after an
accident if the force of the impact ex-
ceeds a preset threshold.
The vehicle automatically locks when
the ignition is switched on and the
wheels are turning at vehicle speeds of
approximately 9 mph (15 km / h) or
more. You could therefore lock yourself
out when the vehicle

is pushed or towed


is on a test stand
Warning!
G
When leaving the vehicle, always remove the
SmartKey or the SmartKey with
KEYLESS-GO* from the starter switch, take
it with you, and lock the vehicle. Do not
leave children unattended in the vehicle, or
with access to an unlocked vehicle. Unsu-
pervised use of vehicle equipment may
cause an accident and / or serious personal
injury.

123 Controls in detail
Locking and unlocking
Depending on production date, your vehi-
cle is equipped with either switch design A
or B.
The switches are located in the center con-
sole.Switch design A1Central locking switch
2Central unlocking switch
Switch design B1Central locking switch
2Central unlocking switchLocking

Press central locking switch1.
If all doors are closed, the vehicle
locks.
Unlocking

Press central unlocking switch2.
The vehicle unlocks.
iYou can open a locked door from the
inside. Open door only when conditions
are safe to do so.
If the vehicle was previously centrally
locked using the SmartKey, it will not
unlock using the central unlocking
switch2.
If the vehicle was previously locked
with the central locking switch1

while in the selective remote con-
trol mode, only the front door
opened from the inside is unlocked.


while in the global remote control
mode, the vehicle is unlocked com-
pletely when a front door is opened
from the inside.

124 Controls in detailSeatsFor more information on seat adjustment,
see the “Getting started” section
(page 39).
Easy-entry / exit feature
This feature allows for easier entry into and
exit from the vehicle.
The easy-entry/exit feature can be activat-
ed or deactivated in the
Convenience
sub-
menu of the control system (
page 175).When exiting the vehicle, with the
easy-entry/exit feature activated and
depending on your selection, the steering
wheel tilts upwards and/or the driver’s
seat moves a few inches to the rear when
you:


remove the SmartKey from the starter
switch,
or


open the driver’s door with the
SmartKey in starter switch position 0
or 1 or the KEYLESS-GO* start/stop
button (
page 36) in position 1.
Warning!
G
You must make sure that no one can be-
come trapped or injured by the moving
steering wheel and driver’s seat when the
easy-entry / exit feature is activated.
To cancel seat / steering wheel movement,
do one of the following:

Press seat adjustment switch
(page 30).


Move steering column stalk
(page 41).


Press one of the memory buttons
(page 30).
The steering wheel and driver’s seat stop
moving.
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver's door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.

125 Controls in detailSeats
When entering the vehicle, with the
easy-entry/exit feature activated, the
steering wheel or, depending on your
selection, the steering wheel and driver’s
seat will return to their last set position or
a factory-set maximum forward position
when you:

close the driver’s door, and switch on
the ignition.
or


insert the SmartKey into the starter
switch or press KEYLESS-GO*
start/stop button once with driver’s
door closed.
iIf the current position for the steering
wheel is in the uppermost tilt position,
the steering wheel will no longer be
able to move upward when the
easy-entry/exit feature is activated.
If the current seat position falls into a
factory-set position range and the sys-
tem recognizes the current seat posi-
tion to be rearward enough for easy
entry and exit, the driver’s seat will not
move to the rear when the
easy-entry/exit feature is activated.
iFor safety reasons, the driver’s seat will
not return to its last set position with
the easy-entry/exit feature activated if
the system recognizes the last set posi-
tion as an extreme forward position.
Instead, the driver’s seat will remain at
or move to a factory-set maximum
forward position. To again fully return
the driver’s seat to your last set posi-
tion or to memory position, adjust the
seat to the desired position or press
and hold the respective memory
position switch (
page 139).

126 Controls in detailSeatsRemoving and installing front seat head restraints
For more information on head restraint
adjustment, see the “Getting started”
section (
page 40).
Front seat head restraintsRemoving front head restraints

Press switch1 upwards and hold until
the head restraint is fully extended.

Pull out head restraint.
Installing front head restraints:

Press switch1 upwards and hold for
about five seconds.

Push the head restraint down until it
engages.

Adjust head restraint to desired posi-
tion (
page 40).
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that the center of
the head restraint supports the back of the
head at eye level. This will reduce the poten-
tial for injury to the head and neck in the
event of an accident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.
Do not interchange head restraints from
front and rear seat.
iTilt the backrest to the rear for easier
removal and installation of the head re-
straints.

127 Controls in detailSeats
Rear seat head restraints
Folding head restraints back
The rear seat head restraints can be folded
backward for increased visibility.Folding head restraints back with switch
in the center console
1Head restraint release switch

Switch on the ignition (
page 34).

Press the symbol-side on rocker
switch1 to release the head re-
straints.
The head restraints will fold backward.Folding head restraints back manually
(rear outer seats)
1Release button

Push release button1 and fold the
head restraints backward.
Warning!
G
For safety reasons, always drive with the
rear head restraints in the upright position
when the rear seats are occupied.
Keep the area around head restraints clear
of articles (e.g. clothing) to not obstruct the
folding operation of the head restraints.
