2005 MERCEDES-BENZ C WAGON display

141 Controls in detail
Control system
Setting locator lighting
With the locator lighting feature activated
and the exterior lamp switch in
positionU, the following lamps will
switch on when the vehicle is unlocked
with the SmartKey during darkness:

Parking lamps


Tail lamps


License plate lamps


Side marker lamps


Front fog lamps
The locator lighting switches off when the
driver’s door is opened.
If you do not open a door after unlocking
with the SmartKey the lamps will switch off
automatically after approximately
40 seconds.

Move the selection marker with
buttonæ orç to the
Lighting
submenu.

Press buttonj ork repeatedly
until the message
Surround lighting

appears in the multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to switch
the locator lighting function
On.

Turn the exterior lamp switch to
positionU when exiting the vehicle
(page 108).
The locator lighting feature is
activated.Setting night security illumination
(Headlamps delayed shut-off)
Use this function to set whether and how
long you would like the exterior lamps to
illuminate during darkness after exiting the
vehicle and all doors closed.
With the delayed shut-off feature activated
and the exterior lamp switch in
positionU before the engine is turned
off, the following lamps will switch on after
you have removed the SmartKey from the
starter switch:


Parking lamps


Tail lamps


License plate lamps


Side marker lamps


Front fog lamps
If you do not open a door after removing
the SmartKey from the starter switch, the
lamps will switch off automatically after
approximately 60 seconds.

142 Controls in detailControl system
Move the selection marker with
buttonæ orç to the
Lighting
submenu.

Press buttonj ork repeatedly
until the message
Hdlamp delay off

appears in the multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to select
the desired lamp-on period.
You can select:

0sec.
, the delayed shut-off feature
is deactivated.


15 sec.
, 30 sec.
, 45 sec.

or
60 sec.
, select the desired
lamp-on period.

Turn the exterior lamp switch to
positionU before turning off the
engine (
page 108).
The headlamps delayed shut-off
feature is activated.You can temporarily deactivate the
delayed shut-off feature:

Before exiting the vehicle, turn the
SmartKey in the starter switch to
position0.

Then turn it to position2 and back to
position0.
The delayed shut-off feature is
deactivated. It will reactivate as soon
as you reinsert the SmartKey in the
starter switch.
iYou can reactivate this function within
ten minutes by opening a door.

143 Controls in detail
Control system
Setting interior lighting delayed shut-off
Use this function to set whether and how
long you would like the interior lighting to
remain lit during darkness after you have
removed the SmartKey from the starter
switch.
Move the selection marker with
buttonæ orç to the
Lighting
submenu.

Press buttonj ork repeatedly
until the message
Int. light delay
off
appears in the multifunction
display.
The selection marker is on the current
setting.

Press buttonæ orç to select
the desired lamp-on time period.
You can select:

0 sec.
, the delayed shut-off feature
is deactivated.


5 sec.
10 sec.
, 15 sec.

or
20 sec.
, the interior lighting de-
layed shut-off feature is activated
with the desired lamp-on period.
Vehicle submenu
Access the
Vehicle
submenu via the
Settings
menu. Use the
Vehicle
submenu
to make general vehicle settings.
The following function is available:Setting automatic locking
Use this function to activate or deactivate
the automatic central locking. With the
automatic central locking system
activated, the vehicle is centrally locked at
vehicle speeds of approximately 9 mph
(15 km/h).

Move the selection marker with
buttonæ orç to the
Vehicle

submenu.

Press buttonj ork repeatedly
until the message
Automatic door lk.

appears in the multifunction display.
Function
Page
Setting automatic locking
143


145 Controls in detail
Control system

Move the selection marker with
buttonæ orç to the Convenience
submenu.

Press buttonj ork repeatedly
until the message
Easy-entry feature

appears in the multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to change
the easy-entry/exit setting.
The following settings are available for
the easy-entry/exit feature:Setting key-dependency
Use this function to set whether the
memory settings for the seats, the steering
wheel and the mirrors should be stored
separately for each SmartKey
(
page 105).

Move the selection marker with
buttonæ orç to the Convenience
submenu.

Press buttonj ork repeatedly
until the message
Key dependency

appears in the multifunction display.
The selection marker is on the current
setting.
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.
Off
The easy-entry/exit
feature is
deactivated
Steer. Column
Only the steering
column is moved
St.col.+seat
Both the steering
column and the seat
are moved


146 Controls in detailControl system
Press buttonæ orç to set
key-dependency
On or
Off
.
Setting parking position* for exterior
rear view mirror
Use the
Mirror set. parking aid
function
to select whether the passenger-side
exterior rear view mirror should be turned
downward during parking maneuvers when
reverse gearR is engaged. For additional
information, see “Activating exterior rear
view mirror parking position*”
(
page 163).

Move the selection marker with
buttonæ orç to the Convenience
submenu.

Press buttonj ork repeatedly
until the message
Mirror set.
parking aid
appears in the
multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to switch
function
On or
Off
.
Trip computer menu
Use the trip computer menu to call up
statistical data on your vehicle.
The following information is available:Function
Page
Fuel consumption statistics after
start
147
Fuel consumption statistics
since last reset
147
Calling up range
(distance to empty)
148


147 Controls in detail
Control system
Fuel consumption statistics after start
Press buttonÿ orè repeatedly
until the first function of the Trip
computer menu appears in the
multifunction display.

Press buttonj ork repeatedly
until the message
After start
appears
in the multifunction display.
1Distance driven since start
2Time elapsed since start
3Average speed since start
4Average fuel consumption since startFuel consumption since last reset

Press buttonÿ orè repeatedly
until the first function of the Trip
computer menu appears in the
multifunction display.

Press buttonj ork repeatedly
until the message
After reset
appears
in the multifunction display.
1Distance driven since last reset
2Time elapsed since last reset
3Average speed since last reset
4Average fuel consumption since last
reset
iAll statistics stored since the last
engine start will be reset approximately
four hours after the SmartKey in the
starter switch is turned to position0 or
removed from the starter switch.
Resetting will not occur if you turn the
SmartKey back to position1 or2
within this time period.

148 Controls in detailControl systemResetting fuel consumption statistics
Press buttonÿ orè repeatedly
until the first function of the Trip
computer menu appears in the
multifunction display.

Press buttonj ork repeatedly
until the reading that you want to reset
appears in the multifunction display.

Press and hold the reset button in the
instrument cluster (
page 116) until
the value is reset to0.Call up range (distance to empty)

Press buttonÿ orè repeatedly
until the first function of the Trip
computer menu appears in the
multifunction display.

Press buttonj ork repeatedly
until the message
Distance
appears in
the multifunction display.
The calculated range based on the
current fuel tank level appears in the
multifunction display.
TEL menu*Warning!
G
A driver’s attention to the road must always
be his/her primary focus when driving. For
your safety and the safety of others, we
recommend that you pull over to a safe
location and stop before placing or taking a
telephone call. If you choose to use the
telephone while driving, please use the
hands-free device and only use the
telephone when weather, road and traffic
conditions permit.
Some jurisdictions prohibit the driver from
using a cellular telephone while driving a
vehicle.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet
(approximately 14 m) every second.

149 Controls in detail
Control system
You can use the functions in the
TEL
menu
to operate your telephone, provided it is
connected to a hands-free system and
switched on.

Switch on the telephone and
COMAND*.

Press buttonÿ orè on the
steering wheel repeatedly until the
message
TEL
appears in the
multifunction display.
Which messages will appear in the
multifunction display depends on whether
your telephone is switched on or off:


If the telephone is off, the message PHONE OFF
appears in the multifunction
display.


If the telephone is on:
The telephone will then search for a
network. During this time the multi-
function display is empty.
As soon as the telephone has found a
network, the message
READY
appears
in the multifunction display.
This standby message indicates that your
telephone is ready for use and you can
operate it using the control system.Answering a call
When your telephone is ready to receive
calls, you can answer a call at any time. In
the multifunction display you will then see
the message:

Press buttons.
You have answered the call. The
duration of the call appears in the
multifunction display.
Never operate radio transmitters equipped
with a built-in or attached antenna (i.e. with-
out being connected to an external antenna)
from inside the vehicle while the engine is
running. Doing so could lead to a malfunc-
tion of the vehicle’s electronic system, pos-
sibly resulting in an accident and/or
personal injury.
