2005 MERCEDES-BENZ C WAGON Owner's Manual

95 Controls in detail
Locking and unlocking
Automatic central locking
The doors and the tailgate automatically
lock when the ignition is switched on and
the wheels are turning at vehicle speeds of
approximately 9 mph (15 km/h) or more.
You can open a locked door from the
inside. Open door only when conditions
are safe to do so.
You can deactivate the automatic locking
using the control system, see “Setting au-
tomatic locking” (
page 143).
Warning!
G
To prevent possible personal injury, always
keep hands and fingers away from the tail-
gate opening when closing the tailgate. Be
especially careful when small children are
around.
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you and lock your vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. Unsuper-
vised use of vehicle equipment may cause
an accident and/or serious personal injury.Warning!
G
Only drive with the tailgate closed as
exhaust fumes may enter the vehicle
interior.
iDo not place the SmartKey in the open
cargo compartment. You may lock
yourself out.iIf the vehicle was previously centrally
locked, the tailgate lid will lock auto-
matically when closed. The turn signals
will flash three times to confirm lock-
ing.
iThe doors unlock automatically after an
accident if the force of the impact
exceeds a preset threshold.
To prevent the vehicle door locks from
locking, deactivate the automatic
central locking when the vehicle

is pushed or towed


is on a test stand

96 Controls in detailLocking and unlockingLocking and unlocking from the inside
You can lock or unlock the doors and the
tailgate from inside using the central lock-
ing or unlocking switch. This can be useful,
for example, if you want to lock the vehicle
before starting to drive.
You cannot lock or unlock the fuel filler flap
with the central locking or unlocking
switch.The switches are located in the center
console.
1Central locking switch
2Central unlocking switchLocking

Press central locking switch1.
If all doors are closed, the vehicle
locks.
Unlocking

Press central unlocking switch2.
The vehicle unlocks.
Warning!
G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. Unsuper-
vised use of vehicle equipment may cause
an accident and/or serious personal injury.
iYou can open a locked door from the
inside. Open door only when conditions
are safe to do so.
If the vehicle was previously centrally
locked using the SmartKey, it will not
unlock using the central unlocking
switch2.
If the vehicle was previously locked
with the central locking switch1

while in the selective remote con-
trol mode, only the door opened
from the inside is unlocked.


while in the global remote control
mode, the vehicle is unlocked
completely when a door is opened
from the inside.

97 Controls in detail
Seats
Seats
For information on seat adjustment, see
“Adjusting” (
page 35).
Easy-entry/exit feature*
This feature allows for easier entry into and
exit from the vehicle.
The easy-entry/exit feature can be
activated or deactivated in the Convenience
submenu of the control
system (
page 144).When exiting the vehicle, with the
easy-entry/exit feature activated and
depending on your selection, the steering
wheel tilts upwards and/or the driver’s
seat moves a few inches to the rear when
you:


remove the SmartKey from the starter
switch,
or


open the driver’s door with the
SmartKey in starter switch position0
or1.
Warning!
G
You must make sure no one can become
trapped or injured by the moving steering
wheel and driver’s seat when the
easy-entry/exit feature is activated.
To cancel seat/steering wheel movement,
do one of the following:

Press seat adjustment switch*
(page 30).


Move steering column stalk*
(page 40).


Press memory position switch*
(page 106).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.

98 Controls in detailSeats
When entering the vehicle, with the
easy-entry/exit feature activated, the
steering wheel or, depending on your
selection, the steering wheel and driver’s
seat will return to their last set position or
a factory-set maximum forward position
when you:

close the driver’s door with the ignition
switched on


insert the SmartKey into the starter
switch with the driver’s door closed.
iIf the current position for the steering
wheel is in the uppermost tilt position,
the steering wheel will no longer be
able to move upward when the
easy-entry/exit feature is activated.
If the current seat position falls into a
factory-set position range and the
system recognizes the current seat
position to be rearward enough for
easy entry and exit, the driver’s seat
will not move to the rear when the
easy-entry/ exit feature is activated.
iFor safety reasons, the driver’s seat will
not return to its last set position with
the easy-entry/exit feature activated if
the system recognizes the last set posi-
tion as an extreme forward position.
Instead, the driver’s seat will remain at
or move to a factory-set maximum
forward position. To again fully return
the driver’s seat to your last set posi-
tion or to memory position, adjust the
seat to the desired position or press
and hold the respective memory
position switch* (
page 106).

99 Controls in detail
Seats
Removing and installing front seat head restraints
For information on head restraint
adjustment, see “Seats” (
page 35).Front seat head restraints, manual seat
1Release button
Removing front seat head restraints

Pull head restraint to its highest
position.

Push release button1 and pull out
head restraint.
Installing front seat head restraints

Insert head restraint and push it down
until it engages.

Push release button1 and adjust
head restraint to desired position.
iAdjust the head restraint in such a way
that it is as close to the head as
possible.Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that the center of
the head restraint supports the back of the
head at eye level. This will reduce the poten-
tial for injury to the head and neck in the
event of an accident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.
Do not interchange head restraints from
front and rear seat.iTilt the backrest to the rear for easier
removal and installation of the head
restraints.

100 Controls in detailSeatsFront seat head restraints, power seat*
1Head restraint switch
Switch on ignition (
page 33).
Removing front seat head restraints

Press switch1 upwards and hold until
head restraint is fully extended.

Pull out head restraint.Installing front seat head restraints

Press switch1 upwards and hold for
about five seconds.

Push head restraint down until it
engages.

Adjust head restraint to desired
position (
page 38).
Rear seat head restraintsHead restraint height (rear outer seats)
1Release button
Raising:

Manually adjust the height of the head
restraint by pulling it upward.
If the head restraint is fully retracted,
push release button1 and pull the
head restraint out.
Lowering:

To lower the head restraint, push
release button1 and push down on
the head restraint.
Warning!
G
For safety reasons, always drive with the
rear head restraints in the upright position
when the rear seats are occupied.
Keep the area around head restraints clear
of articles (e.g. clothing) to not obstruct the
folding operation of the head restraints.

101 Controls in detailSeats
Folding head restraints back
The rear seat head restraints can be folded
backward for increased visibility.
1Release button
Push release button1.
The head restraints will fold backward.Placing head restraints upright

Pull the head restraint forward until it
locks into position.
iAdjust the head restraint in such a way
that it is as close to the head as
possible.Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that the center of
the head restraint supports the back of the
head at eye level. This will reduce the poten-
tial for injury to the head and neck in the
event of an accident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are
intended to help reduce injuries during an
accident.
Warning!
G
Make sure the head restraints engage when
placing them upright. Otherwise their
protective function cannot be assured.

102 Controls in detailSeatsHead restraint tilt (rear outer seats)
Two different head restraint angle
positions are available.
Press the release button (
page 101)
and tilt the head restraint to the
desired position.
Removing and installing rear seat head
restraints (rear outer seats)
1Release button
Removing rear seat head restraints

Fold back head restraint (
page 101).

Pull head restraint to its highest
position.

Push release button1 and pull out
head restraint.
Installing rear seat head restraints

Insert head restraint and push it down
until it engages.

Push button1 and adjust head
restraint to desired position.
iAdjust the head restraint in such a way
that it is as close to the head as
possible.iThe rear center seat head restraint
cannot be removed.
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that the center of
the head restraint supports the back of the
head at eye level. This will reduce the poten-
tial for injury to the head and neck in the
event of an accident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.
Do not interchange head restraints from
front and rear seat.
