DRIVING TIPS
468Check the condition of the battery and cables.
Cold temperatures reduce the capacity of any battery, so it
must be in top shape to provide enough power for winter
starting. Page 608
tells you how to visually inspect the battery.
Your Lexus dealer and most service stations will be pleased to
check the battery charge level.
Make sure the engine oil viscosity is suitable for the cold
weather.
See page 559 for recommended viscosity. Leaving a heavy
summer oil in your vehicle during winter months may cause
harder starting. If you are not sure about which oil to use, call
your Lexus dealer Ð they will be pleased to help. Check the electronic ignition system for loose
connections or obvious damage.
Keep the door locks from freezing.
Squirt
lock de±icer or glycerine into the locks to keep them from
freezing.
Use a washer fluid containing an antifreeze solution.
This product is available at your Lexus dealer and most auto
parts stores. Follow the manufacturer's directions for how
much to mix with water.
NOTICE
Do not use engine antifreeze or any other substitute because it may damage your vehicle's paint.

DRIVING TIPS
469
Do not use your parking brake when there is a possibility
it could freeze.
When
parking, put the transmission into ªPº and block the front
wheels. Do not use the parking brake, or snow or water
accumulated in and around the parking brake mechanism may
freeze the parking brake, making it hard to release.
Keep ice and snow from accumulating under the fenders.
Ice and snow built up under your fenders can make steering
difficult. During bad winter driving, stop and check under the
fenders occasionally.
Depending on where you are driving, we recommend you
carry some emergency equipment.
Some of the thi ngs you might put in the vehicle are tire chains,
window scraper, bag of sand or salt, flares, small shovel,
jumper cables, etc.
DINGHY TOWING
Your vehicle is not designed to be dinghy towed (with four
wheels on the ground) behind a motorhome.
NOTICE
Do not tow your vehicle with four wheels on the ground. This may cause serious damage to your vehicle.

DRIVING TIPS
470
TRAILER TOWING
Your vehicle is designed primarily as a passenger±and±load
carrying vehicle. Towing a trailer will have an adverse ef fect on
handling, performance, braking, durability and driving
economy (fuel consumption, etc.). Your safety and satisfaction
depend on the proper use of correct equipment and cautious
driving habits. For your safety and the safety of others, you
must not overload your vehicle or trailer. Lexus warranties do
not apply to damage or malfunction caused by towing a trailer
for commercial purposes. Ask your local Lexus dealer for
further details before towing.
CAUTION
When disconnecting a trailer, put the vehicle height in
the ªLOº (low) mode and push the ªHEIGHT CONTROL
OFFº switch to turn off the rear height control air
suspension. Otherwise, the vehicle height may be
changed in the automatic leveling function, resulting in
accident. For details see ªRear height control air
suspensionº on page 422.
Weight limits
Before towing, make sure the total trailer weight, gross
vehicle weight, gross axle weight and trailer tongue load
are all within the limits.
The total trailer weight and tongue load can be measured with
platform scales found at a highway weighing station, building
supply company, trucking company, junk yard, etc.

Certification label

DRIVING TIPS
471

Weight distributing hitch receiver
CAUTION
The maximum gross trailer weight (trailer weight plus
cargo weight) must never exceed 2948 kg (6500 lb.)
for vehicle with equipped.
If towing a trailer and cargo weighing over 907 kg
(2000 lb.), Lexus recommends to use a sway control
device with sufficient capacity. The combination of
the gross trailer weight added to the total weight of
the vehicle, occupants and vehicle cargo must never
exceed a total of 5443 kg (12000 lb.).
Exceeding the maximum weight of the trailer, the
vehicle, or the vehicle and trailer combination, can
cause an accident resulting in serious personal
injuries.
 Trailer hitch assemblies have different weight
capacities established by the hitch manufacturer.
Even though the vehicle may be physically capable of
towing a higher weight, the operator must determine
the maximum weight rating of the particular hitch
assembly and never exceed the maximum weight
rating specified for the trailer hitch. Exceeding the
maximum weight rating set by the trailer hitch
manufacturer can cause an accident resulting in
serious personal injuries.

Tongue load
Total trailer weight

100 = 10%
DRIVING TIPS
472
 The gross vehicle weight must not exceed the Gross
Vehicle Weight Rating (GVWR) indicated on the
Certification Label. The gross vehicle weight is the
sum weight of the unloaded vehicle, driver,
passengers, luggage, hitch and trailer tongue load.
It also includes the weight of any special equipment
installed on your vehicle.
 The load on either the front or rear axle resulting from
distribution of the gross vehicle weight on both axles
must not exceed the front and rear Gross Axle W eight
Ratings (GAWR) listed on the Certification Label.

Total trailer weight
Tongue load
 The trailer cargo load should be distributed so that
the tongue load is 10% of the total trailer weight, not
exceeding the maximum of 294 kg (650 lb.).
 Never load the trailer with more weight in the back
than in the front. About 60% of the trailer load should
be in the front half of the trailer and the remaining 40%
in the rear.

DRIVING TIPS
473
Hitches
If you wish to install a trailer hitch, you should consult with
your Lexus dealer.
 Use only a hitch recommended by the hitch manufacture
and the one which conforms to the total trailer weight
requirement.
 If you wish to install an aftermarket hitch, the hitch must be
bolted securely to the vehicle frame and installed according
to the hitch manufactures' instructions.
 The hitch ball and king pin should have a light coat of grease.
 Lexus recommends the ball mount assembly be removed
when not towing to prevent injury and to prevent damage in
the event of a rear end collision. After removing the ball
mount assembly, install the grommet to the hitch to prevent
entry of dirt and mud.

DRIVING TIPS
474
NOTICE
Do not use axle±mounted hitches as they can causedamage to the axle housing, wheel bearings, wheels ortires. Also, never install a hitch which may interfere with
the normal function of an Energy Absorbing Bumper.
Trailer ball
Follow these easy steps to properly determine the correct
trailer ball for your application:
1. Determine the correct trailer ball size for the trailer coupler.
Most couplers are stamped with the required trailer ball size.
The sizes you'll most likely find stamped on the coupler are:
Trailer Class
Typical Trailer Ball Size
III 2 in.
II 2 in.
I 1 7/8 in.
2. Select the appropriate trailer ball to match or exceed the
gross trailer weight rating of the trailer. The trailer ball load
rating should be printed on the top of the ball.

1Trailer ball load rating
2Ball diameter
3Shank length
4Shank diameter

DRIVING TIPS
475
3. When mounted in the ball mount, the threaded ball shank
must protrude beyond the bottom of the lock washer and nut
at least 2 threads. The trailer ball shank must be matched to
the ball mount hole diameter size.
NOTICE
Only use a ball mount attachment specified for the
Lexus GX470.
