IN CASE OF AN EMERGENCY
304B: If no steam is coming from your engine:
Leave the engine running and turn off the air conditioning.
Check the following.

Is the cooling fan operating?
 Is the coolant in the acceptable range?
CAUTION
When the engine is running, keep hands and clothing
away from the moving fan and engine drive belt.
 Do not attempt to remove the radiator cap when the
engine and radiator are hot. Serious injury could
result from scalding hot fluid and steam blown out
under pressure.
If the cooling fan is not operating or the coolant is not in the
acceptable range, turn off the engine and call your Lexus
dealer.
If both conditions are O.K., after the engine coolant
temperature has cooled to normal, continue driving your
vehicle.
If the engine coolant temperature does not cool down, or your
vehicle overheats again, have it checked as soon as possible
by your Lexus dealer.
IF YOU HAVE A FLAT TIRE
1. Reduce your speed gradually, keeping a straight
line. Move cautiously off the road to a safe place
— well away from the traffic. Avoid stopping on the
center divider of a highway. Park on a level spot with
firm ground.
2. Stop the engine and turn on your emergency
flashers.
3. F i r m l y s e t t h e p a r k i n g b r a k e a n d p u t t h e
transmission in “P”.
4. Have everyone get out of the vehicle on the side
away from traffic.
5. Read the following instructions thoroughly.

IN CASE OF AN EMERGENCY
305
CAUTION
When jacking, be sure to observe the following
to reduce the possibility of personal injury:
Follow jacking instructions.
 Do not put any part of your body under a
vehicle supported by a jack. Otherwise,
personal injury may occur.
 Do not start or run the engine while your
vehicle is supported by the jack.
 Stop the vehicle on a level firm ground, firmly
set the parking brake and put the
transmission in “P”. Block the wheel
diagonally opposite to the one being changed
if necessary.
 Make sure to set the jack properly in the jack
point. Raising the vehicle with jack
improperly positioned will damage the vehicle
or may allow the vehicle to fall off the jack
and cause personal injury.
Never get under the vehicle when the vehicle
is supported by the jack alone.
 Use the jack only for lifting your vehicle
during wheel changing.
 Do not raise the vehicle with someone in the
vehicle.
 When raising the vehicle, do not place any
objects on top of or underneath the jack.
 Raise the vehicle only high enough to remove
and change the tire.
NOTICE
Do not continue driving with a deflated tire.
Driving even a short distance can damage a tire
and wheel beyond repair.

IN CASE OF AN EMERGENCY
306
1. Lift up the deck board and hang the deck board
hook on the right hinge of the trunk lid.
Make sure the board does not fall down.
When closing the board, replace the hook in its
original position.1 Spare tire 2 Jack handle 3 Wrench
4 Jack 5 Towing eyelet
2. Get the jack, wrench and spare tire.
To prepare yourself for an emergency, you should
familiarize yourself with the use of the jack and each
tool, and their storage locations. The jack handle and
wrench are attached at the reverse side of the cover.

IN CASE OF AN EMERGENCY
307
1 Joint
2When removing the jack, turn the joint by hand
in the “contract” direction until the jack is free.
3When storing, turn the joint by hand in the
“expand” direction until the jack is firmly secured
to prevent it from flying forward during a collision
or sudden braking.
To remove the spare tire:
1Remove the spare tire cover.
2Loosen the bolt and remove it.
When storing the spare tire, place it with the inner
side of the wheel facing up. Then bolt the tire in place
and install the spare tire cover to prevent the tire from
flying forward during a collision or sudden braking.

IN CASE OF AN EMERGENCY
308
3. Block the wheel diagonally opposite the flat tire
to keep the vehicle from rolling when it is jacked
up.
When blocking the wheel, place a wheel block in front
of one of the front wheels or behind one of the rear
wheels.4. Loosen all the wheel nuts.
Always loosen the wheel nuts before raising the
vehicle.
Turn the wheel nuts counterclockwise to loosen them.
To get maximum leverage, fit the wrench to the nut
so that the handle is on the right side, as shown
above. Grab the wrench near the end of the handle
and pull up on the handle. Be careful that the wrench
does not slip off the nut.

IN CASE OF AN EMERGENCY
309
Do not remove the nuts yet — just unscrew them
about one−half turn.
CAUTION
Never use oil or grease on the bolts or nuts.
The nuts may loose and the wheels may fall off,
which could cause a serious accident.
5. Position the jack at the jack points as shown.
Rotate the load rest 90  from storage position to
lifting position.
Make sure the jack is positioned on a level and solid
surface.

IN CASE OF AN EMERGENCY
310
6. After making sure no one is in the vehicle, raise
it high enough so that the spare tire can be
installed.
Allow for the fact that you need more ground
clearance when putting on the spare tire than when
removing the flat tire.
To raise the vehicle, insert the jack handle into the
jack (it is a loose fit) and turn it clockwise. As the
jack touches the vehicle and begins to lift,
double−check that it is properly positioned.
CAUTION
Never get under the vehicle when the vehicle
is supported by the jack alone.

IN CASE OF AN EMERGENCY
311
7. Remove the wheel nuts and remove the flat tire.
Lift the flat tire straight off and put it aside.Before putting on the wheel, remove any corrosion
on the mounting surfaces with a wire brush or such.
Installation of wheels without good metal−to−metal
contact at the mounting surface can cause wheel nuts
to loosen and eventually cause a wheel to come off
while driving.
