Door mirror defogger RH does not operate. 1. Passenger side door mirror defogger circuit checkGW-93
Rear window defogger switch does not light, and rear win-
dow defogger is not shown on the display, but the rear win-
dow defogger operates. 1. Rear window defogger signal checkGW-94
Symptom Diagnoses / Service procedure Refer to page

GW-90
REAR WINDOW DEFOGGER
Revision: October 20052005 QX56
3. CHECK REAR WINDOW DEFOGGER GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between rear window defogger connector D604 terminal - and ground.
OK or NG
OK >> Check filament. Refer to GW-94, "Filament Check" .

If filament is OK.
Check the condition of the harness and the connector.

If filament is NG.
Repair filament.
NG >> Repair or replace harness.
4. CHECK REAR WINDOW DEFOGGER RELAY OUTPUT SIGNAL
1. Turn ignition switch ON.
2. Check voltage between IPDM E/R connector E124 terminal 60 and ground.
OK or NG
OK >> Replace IPDM E/R. Refer to PG-28, "Removal and
Installation of IPDM E/R" .
NG >> Repair or replace harness.
Door Mirror Defogger Power Supply Circuit CheckEIS005Z0
1. CHECK FUSE
Check if any of the following fuses for fuse block (J/B) are blown.
NOTE:
Refer to GW-77, "
Component Parts and Harness Connector Location" .
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. Refer to
GW-77, "
Component Parts and Harness Connector Location" . - (B) - Ground : Continuity should exist.
LIIA0409E
ConnectorTerminal (Wire color)
ConditionVoltage (V)
(Approx.)
(+) (–)
E124 60 (B) GroundRear window defogger
switch ON. Battery voltage
Rear window defogger
switch OFF.0
WIIA0525E
COMPONENT PARTS AMPERE FUSE NO.
IPDM E/R 15A 43

REAR WINDOW DEFOGGER
GW-91
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: October 20052005 QX56
2. CHECK DOOR MIRROR DEFOGGER POWER SUPPLY CIRCUIT 2
Check voltage between IPDM E/R connector and ground.
OK or NG
OK >> GO TO 3.
NG >> Replace IPDM E/R. Refer to PG-28, "
Removal and
Installation of IPDM E/R" .
3. CHECK DOOR MIRROR DEFOGGER CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R and door mirror LH or RH.
3. Check continuity between IPDM E/R connector E120 terminal 23 and door mirror connector D4 (LH) or
D107 (RH) terminal 10.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness.
4. CHECK DOOR MIRROR DEFOGGER GROUND CIRCUIT
Check continuity between each door mirror connector D4 (LH) or D107 (RH) terminal 11 and ground.
OK or NG
OK >> GO TO 5.
NG >> Repair or replace harness.
ConnectorTerminal (Wire color)
ConditionVoltage (V)
(Approx.)
(+) (–)
E12023
(GR/W)GroundRear window defogger
switch ON Battery voltage
Rear window defogger
switch OFF0
LIIA0977E
23 (GR/W) - 10 (GR/W) : Continuity should exist.
LIIA1453E
11 (B) - Ground : Continuity should exist.
LIIA1454E

GW-92
REAR WINDOW DEFOGGER
Revision: October 20052005 QX56
5. CHECK DOOR MIRROR DEFOGGER
Check continuity between each door mirror terminals 10 and 11.
OK or NG
OK >> Check the condition of the harness and the connector.
NG >> Replace malfunctioning door mirror LH or RH. Refer to
GW-97, "
Door Mirror Assembly" .
Door Mirror LH Defogger Circuit CheckEIS005Z1
1. CHECK DOOR MIRROR DEFOGGER POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect door mirror LH.
3. Turn ignition switch ON.
4. Check voltage between door mirror LH connector and ground.
OK or NG
OK >> GO TO 2.
NG >> Repair or replace harness.
2. CHECK DOOR MIRROR DEFOGGER GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between door mirror LH connector D4 terminal
11 and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness.10 - 11 : Continuity should exist.
LIIA2305E
ConnectorTerminal (Wire color)
ConditionVoltage (V)
(Approx.)
(+) (–)
D410
(GR/W)GroundRear window defogger
switch ON Battery voltage
Rear window defogger
switch OFF0
LIIA1456E
11 (B) - Ground : Continuity should exist.
LIIA1458E

REAR WINDOW DEFOGGER
GW-93
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: October 20052005 QX56
3. CHECK DOOR MIRROR DEFOGGER
Check continuity between door mirror LH terminals 10 and 11.
OK or NG
OK >> Repair or replace harness.
NG >> Replace door mirror LH. Refer to GW-97, "
Door Mirror
Assembly" .
Door Mirror RH Defogger Circuit CheckEIS005Z2
1. CHECK DOOR MIRROR DEFOGGER POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect door mirror RH.
3. Turn ignition switch ON.
4. Check voltage between door mirror RH connector and ground.
OK or NG
OK >> GO TO 2.
NG >> Repair or replace harness.
2. CHECK DOOR MIRROR DEFOGGER GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between door mirror RH connector D107 terminal 11 and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness.10 - 11 : Continuity should exist.
LIIA2305E
ConnectorTerminal (Wire color)
ConditionVoltage (V)
(Approx.)
(+) (–)
D107 10 (GR/W) GroundRear window defogger
switch ON Battery voltage
Rear window defogger
switch OFF0
LIIA1456E
11 (B) - Ground : Continuity should exist.
LIIA1458E

GW-94
REAR WINDOW DEFOGGER
Revision: October 20052005 QX56
3. CHECK DOOR MIRROR DEFOGGER
Check continuity between door mirror RH terminals 10 and 11.
OK or NG
OK >> Repair or replace harness.
NG >> Replace door mirror RH. Refer to GW-97, "
Door Mirror
Assembly" .
Rear Window Defogger Signal CheckEIS005Z3
1. CHECK AV COMMUNICATION LINE
AV communication line check is executed. Refer to BCS-8, "
CAN Communication System Description" .
OK or NG
OK >> GO TO 2.
NG >> Replace display control unit. Refer to AV- 1 5 8 , "
Removal and Installation of Display Unit" .
2. CHECK CAN COMMUNICATION LINE
CAN communication line check is executed. Refer to LAN-5, "
CAN COMMUNICATION" .
OK or NG
OK >> Check the condition of the harness and the connector.
NG >> In addition, it is necessary to check CAN communication line. Refer to LAN-5, "
CAN COMMUNI-
CATION" .
Filament CheckEIS005Z4
1. When measuring voltage, wrap tin foil around the top of the neg-
ative probe.Then press the foil against the wire with your finger.
2. Attach probe circuit tester (in Volt range) to middle portion of
each filament.10 - 11 : Continuity should exist.
LIIA2305E
Is rear window defogger displayed on the display?
SEL122R
SEL263

DOOR MIRROR
GW-97
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: October 20052005 QX56
DOOR MIRRORPFP:96301
Door Mirror AssemblyEIS004VG
REMOVAL
NOTE:
Be careful not to damage the mirror bodies.
1. Remove the front door sash cover. Refer to AV- 4 6 , "
Removal and Installation of Front Tweeter" .
2. Remove the door mirror harness connector.
3. Remove the door mirror mounting nuts, and remove the door mirror assembly.
INSTALLATION
Installation is in the reverse order of removal.
Door Mirror GlassEIS004VH
REMOVAL
1. Set mirror assembly mirror glass upward.
2. Apply protective tape to mirror housing.
3. Insert a screwdriver at notch and gently pry mirror glass and
holder from mirror holder bracket.
4. Disconnect two electrical connectors from mirror glass and
holder.
LIIA1570E
LIIA1591E

GW-98
DOOR MIRROR
Revision: October 20052005 QX56
INSTALLATION
1. Set mirror holder bracket and mirror glass and holder in the hor-
izontal position.
2. Connect two electrical connectors to the back of the mirror
holder.
3. Align mirror glass and holder with mirror holder bracket and
push mirror glass and holder onto mirror holder bracket.
4. Rotate mirror to ensure proper installation.
LIIA1592E
