2005 INFINITI QX4 warning

TROUBLE DIAGNOSIS FOR SYSTEM
TF-115
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: October 20052005 QX56
3. CHECK GROUND CIRCUIT
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Disconnect ATP switch harness connector.
3. Check continuity between ATP switch harness connector F55
terminal 9 (B) and ground.
Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 4.
NG >> Repair open circuit or short to ground or short to power
in harness or connectors.
4. CHECK ATP SWITCH
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Disconnect ATP switch harness connector.
3. Remove ATP switch. Refer to TF-22, "
Location of Electrical Parts" .
4. Push and release ATP switch and check continuity between ATP
switch terminals 8 and 9.
OK or NG
OK >> GO TO 5.
NG >> Replace ATP switch. Refer to TF-22, "
Location of Elec-
trical Parts" .
5. CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to TF-36, "
Transfer Control Unit Input/Output Signal Ref-
erence Values" .
OK or NG
OK >> GO TO 6.
NG >> Check transfer control unit pin terminals for damage or loose connection with harness connector.
If any items are damaged, repair or replace damaged parts.
6. CHECK ATP WARNING LAMP
1. Turn ignition switch “ON”. (Do not start engine.)
2. Move A/T selector lever to "P" position.
3. Set 4WD shift switch from "4H" to "4LO" or "4LO" to "4H".
Does ATP warning lamp turn ON while switching?
YES >> GO TO TF-125, "ATP Warning Lamp Turns ON" .
NO >> Inspection End.
COMPONENT INSPECTION
1. Turn ignition switch “OFF”. (Stay for at least 5 second.)
2. Disconnect ATP switch harness connector.
3. Remove ATP switch. Refer to TF-22, "
Location of Electrical Parts" . Continuity should exist.
SDIA2394E
Terminal Condition Continuity
8 - 9Push ATP switch Yes
Release ATP switch No
SDIA2757E

TROUBLE DIAGNOSIS FOR SYMPTOMS
TF-121
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: October 20052005 QX56
4WD Warning Lamp Does Not Turn ONEDS002HN
SYMPTOM:
4WD warning lamp does not turn ON when turning ignition switch to “ON”.
DIAGNOSTIC PROCEDURE
1. CHECK TRANSFER CONTROL UNIT POWER SUPPLY CIRCUIT
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Connect transfer control unit harness connector.
3. Check voltage between transfer control unit harness connector
terminals and ground.
4. Turn ignition switch “ON”. (Do not start engine.)
5. Check voltage between transfer control unit harness connector
terminals and ground.
OK or NG
OK >> GO TO 4.
NG >> Check the following. If any items are damaged, repair or replace damaged parts.

10A fuses No. 26 located in fuse and fusible link box and No. 59 located in the fuse and relay
box. Refer to PG-4, "
POWER SUPPLY ROUTING CIRCUIT" .

20A fuse No. 53 located in the IPDM E/R. Refer to PG-4, "POWER SUPPLY ROUTING CIR-
CUIT" .

Harness for short or open between battery and transfer control unit harness connector termi-
nals 47.

Harness for short or open between battery and transfer control unit harness connector terminal
29.

Harness for short or open between battery and transfer shut off relay harness connector E69
terminal 1 (G), and 3 (G).

Harness for short or open between transfer shut off relay harness connector E69 terminal 2
(SB) and transfer control unit harness connector terminal 30.

Harness for short or open between transfer shut off relay harness connector E69 terminal 5 (Y/
R) and transfer control unit harness connector terminals 16 (Y/R) and 22 (Y/R).

Battery and ignition switch. Refer to PG-4, "POWER SUPPLY ROUTING CIRCUIT" .

Transfer shut off relay. Refer to TF-57, "COMPONENT INSPECTION" .
Connector Terminal (Wire color) Voltage (Approx.)
E14216 (Y/R) - Ground
0V 22 (Y/R) - Ground
E14329 (L/W) - Ground
30 (SB) - Ground
Battery voltage
47 (W) - Ground
WDIA0165E
Connector Terminal (Wire color) Voltage (Approx.)
E14216 (Y/R) - Ground
Battery voltage 22 (Y/R) - Ground
E14329 (L/W) - Ground
30 (SB) - Ground 0V
47 (W) - Ground Battery voltage
WDIA0166E

TROUBLE DIAGNOSIS FOR SYMPTOMS
TF-123
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: October 20052005 QX56
4. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND COMBINATION METER
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Disconnect transfer control unit harness connector and combination meter harness connector.
3. Check continuity between the following terminals.
–Transfer control unit harness connector E142 terminal 5 (W/B)
and combination meter harness connector M24 terminal 34 (W/
B).
Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 5.
NG >> Repair or replace damaged parts.
5. CHECK INDICATOR LAMP CIRCUIT
1. Connect combination meter harness connector.
2. Disconnect transfer control unit harness connector.
3. Turn ignition switch “ON”. (Do not start engine.)
4. Ground the following terminal using suitable wiring.
–Transfer control unit harness connector E142 terminal 5 (W/B)
and ground.
Does 4WD warning lamp turn on?
OK >> GO TO 6.
NG >> Replace combination meter. Refer to IP-13, "
Combina-
tion Meter" .
6. SYMPTOM CHECK
Check again.
OK or NG
OK >> Inspection End.
NG >> GO TO 7.
7. CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to TF-36, "
Transfer Control Unit Input/Output Signal Ref-
erence Values" .
OK or NG
OK >> Inspection End.
NG >> Check transfer control unit pin terminals for damage or loose connection with harness connector.
If any items are damaged, repair or replace damaged parts.
4WD Shift Indicator Lamp or 4LO Indicator Lamp Does Not ChangeEDS002HO
SYMPTOM:
4WD shift indicator lamp or 4LO indicator lamp does not change when switching 4WD shift switch.Continuity should exist.
WDIA0154E
SDIA2774E

TROUBLE DIAGNOSIS FOR SYMPTOMS
TF-125
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: October 20052005 QX56
9. CHECK SYSTEM FOR ACTUATOR POSITION SWITCH
Perform trouble diagnosis for actuator position switch system. Refer to TF-77, "
Actuator Position Switch" .
OK or NG
OK >> GO TO 10.
NG >> Repair or replace damaged parts.
10. SYMPTOM CHECK
Check again.
OK or NG
OK >> Inspection End.
NG >> GO TO 11.
11 . CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to TF-36, "
Transfer Control Unit Input/Output Signal Ref-
erence Values" .
OK or NG
OK >> GO TO 12.
NG >> Check transfer control unit pin terminals for damage or loose connection with harness connector.
If any items are damaged, repair or replace damaged parts.
12. CHECK TRANSFER INNER PARTS
1. Disassemble transfer assembly. Refer to TF-144, "
Disassembly and Assembly" .
2. Check transfer inner parts.
OK or NG
OK >> Inspection End.
NG >> Repair or replace damaged parts.
ATP Warning Lamp Turns ONEDS002HP
SYMPTOM:
ATP warning lamp turns ON when 4WD shift switch from “4H” to “4LO” or “4LO” to “4H” with A/T
selector lever “N” to “P” position.
DIAGNOSTIC PROCEDURE
1. CHECK SYSTEM FOR CAN COMMUNICATION LINE
Perform self-diagnosis. Refer to TF-50, "
Self-diagnostic Procedure" .
Do the self-diagnostic results indicate CAN communication?
YES >> Perform trouble diagnosis for CAN communication line. Refer to TF-113, "CAN Communication
Line" .
NO >> GO TO 2.
2. CHECK SYSTEM FOR 4WD SHIFT SWITCH
Perform trouble diagnosis for 4WD shift switch system. Refer to TF-62, "
4WD Shift Switch" .
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3. CHECK SYSTEM FOR PNP SWITCH SIGNAL
Perform trouble diagnosis for PNP switch signal system. Refer to TF-69, "
PNP Switch Signal (TCM)" .
OK or NG
OK >> GO TO 4.
NG >> Repair or replace damaged parts.

TF-126
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: October 20052005 QX56
4. CHECK SYSTEM FOR ATP SWITCH
Perform trouble diagnosis for ATP switch system. Refer to TF-113, "
AT P S w i t c h" .
OK or NG
OK >> GO TO 5.
NG >> Repair or replace damaged parts.
5. CHECK HARNESS BETWEEN TRANSFER CONTROL UNIT AND COMBINATION METER
1. Turn ignition switch “OFF”. (Stay for at least 5 seconds.)
2. Disconnect transfer control unit harness connector and combination meter harness connector.
3. Check continuity between the following terminals.
–Transfer control unit harness connector E142 terminal 15 (L/B)
and combination meter harness connector M24 terminal 6 (L/B).
–Transfer control unit harness connector E143 terminal 40 (L)
and combination meter harness connector M24 terminal 7 (R/B).
Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 6.
NG >> Repair or replace damaged parts.
6. CHECK ATP WARNING LAMP CIRCUIT
1. A/T selector lever in "P" position.
2. Connect combination meter harness connector and transfer control unit harness connector.
3. Disconnect ATP switch harness connector.
4. Ground the following terminal using suitable wiring.
–ATP switch harness connector F55 terminal 8 (L/Y) and ground.
5. Turn ignition switch “ON”. (Do not start engine.)
Does indicator lamp turn on?
OK >> GO TO 7.
NG >> Replace combination meter. Refer to IP-13, "
Combina-
tion Meter" . Continuity should exist.
WDIA0149E
40 to 7: Continuity should not exist.
7 to 40: Continuity should exist.
WDIA0150E
SDIA2769E

TF-128
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: October 20052005 QX56
5. CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to TF-36, "
Transfer Control Unit Input/Output Signal Ref-
erence Values" .
OK or NG
OK >> GO TO 6.
NG >> Check transfer control unit pin terminals for damage or loose connection with harness connector.
If any items are damaged, repair or replace damaged parts.
6. CHECK TRANSFER INNER PARTS
1. Disassemble transfer assembly. Refer to TF-144, "
Disassembly and Assembly" .
2. Check transfer inner parts.
OK or NG
OK >> Inspection End.
NG >> Repair or replace damaged parts.
4WD Warning Lamp Flashes RapidlyEDS002HR
SYMPTOM:
While driving, 4WD warning lamp flashes rapidly.
NOTE:
Rapid flashing: 2 times/second
DIAGNOSTIC PROCEDURE
1. CHECK TIRE
Check the following.

Tire pressure

Wear condition

Longitudinal tire size (There is no difference between longitudinal tires.)
OK or NG
OK >> GO TO 2.
NG >> Repair or replace damaged parts.
2. CHECK 4WD WARNING LAMP
Stop the vehicle and allow it to idle for a short period of time.
Does flashing stop?
YES >> Inspection End.
NO >> GO TO 3.
3. CHECK TRANSFER FLUID TEMPERATURE
Perform trouble diagnosis for transfer fluid temperature system. Refer to TF-102, "
Transfer Fluid Temperature"
.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace damaged parts.
4. SYMPTOM CHECK
Check again.
OK or NG
OK >> Inspection End.
NG >> GO TO 5.

TROUBLE DIAGNOSIS FOR SYMPTOMS
TF-129
C
E
F
G
H
I
J
K
L
MA
B
TF
Revision: October 20052005 QX56
5. CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to TF-36, "
Transfer Control Unit Input/Output Signal Ref-
erence Values" .
OK or NG
OK >> Inspection End.
NG >> Check transfer control unit pin terminals for damage or loose connection with harness connector.
If any items are damaged, repair or replace damaged parts.
4WD Warning Lamp Flashes SlowlyEDS002HS
SYMPTOM:
While driving, 4WD warning lamp flashes slowly. (When continuing to flash until turning ignition
switch OFF.)
NOTE:
Slow flashing: 1 time/2 seconds
DIAGNOSTIC PROCEDURE
1. CHECK TIRE
Check the following.

Tire pressure

Wear condition

Longitudinal tire size (There is no difference between longitudinal tires.)
OK or NG
OK >> GO TO 2.
NG >> Repair or replace damaged parts.
2. CHECK TRANSFER FLUID TEMPERATURE
Perform trouble diagnosis for transfer fluid temperature system. Refer to TF-102, "
Transfer Fluid Temperature"
.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3. CHECK CLUTCH PRESSURE SWITCH
Perform trouble diagnosis for clutch pressure switch system. Refer to TF-105, "
Clutch Pressure Switch" .
OK or NG
OK >> GO TO 4.
NG >> Repair or replace damaged parts.
4. SYMPTOM CHECK
Check again.
OK or NG
OK >> Inspection End.
NG >> GO TO 5.
5. CHECK TRANSFER CONTROL UNIT
Check transfer control unit input/output signal. Refer to TF-36, "
Transfer Control Unit Input/Output Signal Ref-
erence Values" .
OK or NG
OK >> Inspection End.
NG >> Check transfer control unit pin terminals for damage or loose connection with harness connector.
If any items are damaged, repair or replace damaged parts.

WT-1
ROAD WHEELS & TIRES
E SUSPENSION
CONTENTS
C
D
F
G
H
I
J
K
L
M
SECTION WT
A
B
WT
Revision: October 20052005 QX56 PRECAUTIONS .......................................................... 2
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 2
PREPARATION ........................................................... 3
Special Service Tool ................................................. 3
Commercial Service Tools ........................................ 3
NOISE, VIBRATION, AND HARSHNESS (NVH)
TROUBLESHOOTING ................................................ 4
NVH Troubleshooting Chart ..................................... 4
WHEEL ....................................................................... 5
Inspection ................................................................. 5
WHEEL AND TIRE ASSEMBLY ................................. 6
Balancing Wheels .................................................... 6
REMOVAL ............................................................. 6
WHEEL BALANCE ADJUSTMENT ...................... 6
Rotation .................................................................... 7
LOW TIRE PRESSURE WARNING SYSTEM ............ 8
System Components ................................................ 8
System Description .................................................. 8
TRANSMITTER ..................................................... 8
REMOTE KEYLESS ENTRY RECEIVER ............. 8
BCM (BODY CONTROL MODULE) ...................... 9
WARNING LAMP AND BUZZER .......................... 9
DISPLAY UNIT ...................................................... 9
CAN COMMUNICATION .......................................... 10
System Description ................................................ 10
TROUBLE DIAGNOSES ...........................................11
Wiring Diagram .......................................................11
BCM Input/Output Signal Standard ........................ 13
ID Registration Procedure ...................................... 14
ID REGISTRATION WITH TRANSMITTER
ACTIVATION TOOL ............................................ 14
ID REGISTRATION WITHOUT TRANSMITTER
ACTIVATION TOOL ............................................ 15
Transmitter Wake Up Operation ............................. 16
WITH TRANSMITTER ACTIVATION TOOL ........ 16
CONSULT-II Function (BCM) ................................. 17
Self-Diagnosis ........................................................ 18DESCRIPTION .................................................... 18
FUNCTION .......................................................... 18
CONSULT-II ......................................................... 18
How to Perform Trouble Diagnosis for Quick and
Accurate Repair ...................................................... 20
INTRODUCTION ................................................. 20
WORK FLOW ...................................................... 20
Preliminary Check .................................................. 21
Malfunction Code/Symptom Chart .......................... 22
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC
ITEMS ........................................................................ 24
Inspection 1: Transmitter or Control Unit (BCM) ..... 24
MALFUNCTION CODE NO. 21, 22, 23 OR 24 ... 24
Inspection 2: Transmitter - 1 ................................... 24
MALFUNCTION CODE NO. 31, 32, 33, 34, 41,
42, 43, 44, 45, 46, 47 OR 48 ............................... 24
Inspection 3: Transmitter - 2 ................................... 25
MALFUNCTION CODE NO. 35, 36, 37 OR 38 ... 25
Inspection 4: Vehicle Speed Signal ........................ 26
MALFUNCTION CODE NO. 52 ........................... 26
TROUBLE DIAGNOSIS FOR SYMPTOMS .............. 27
Inspection 1: Warning Lamp Does Not Come On
When Ignition Switch Is Turned On ........................ 27
Inspection 2: Warning Lamp Stays On When Ignition
Switch Is Turned On ............................................... 27
Inspection 3: Warning Lamp Flashes When Ignition
Switch Is Turned On ............................................... 29
Inspection 4: Hazard Warning Lamp Flashes When
Ignition Switch Is Turned On .................................. 30
Inspection 5: “TIRE PRESSURE” Information In
Display Unit Does Not Exist .................................... 31
Inspection 6: ID Registration Cannot Be Completed ... 31
REMOVAL AND INSTALLATION ............................. 32
Transmitter (Pressure Sensor) ............................... 32
REMOVAL ........................................................... 32
INSTALLATION ................................................... 32
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 34
Road Wheel ............................................................ 34
Tire ......................................................................... 34
