2005 INFINITI FX35 Window systems

AUDIO AV-39
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2005 July 2005 FX
FOR RADIO ONLY
NOTE:
1. The cause is a reduction in the receiving sensitivity of the window antenna.
2. This is noise resulting from variations in field strength, such as fading noise and multi-path noise, or exter- nal noise from trains and other sources. It is not a malfunction.

Fading noise: This noise occurs because of variations in the field strength in a narrow range due to moun-
tains or buildings blocking the signal.

Multi-path noise: This noise results from the waves sent directly from the broadcast station arriving at the
antenna at a different time from the waves which reflect off of mountains or buildings.
FOR CASSETTE PLAYER ONLY
FOR CD ONLY
Symptom Possible cause
No sound

Antenna feeder check (For open or short). Refer to AV-54, "Location of Antenna" .

Window antenna check. Refer to AV-54, "CHECK ELEMENT" .
If above systems are OK, replace audio unit.
Noisy

Antenna feeder check (For open or short). Refer to AV-54, "Location of Antenna" .

Antenna amp. check. Refer to AV-53, "Antenna Amp. Inspection" .

Window antenna check. Refer to AV-54, "CHECK ELEMENT" .

Noise prevention parts check.

Each electrical equipment check.

Wire harness of each piece of electrical equipment check.
If above systems are OK, replace antenna amp.
Selected radio stations stored in memory are
deleted.

Replace audio unit.
Symptom Possible cause
Cassette tape cannot be inserted.

Audio unit. Refer to AV-47, "Removal and Installation of Audio Unit" .

Cassette tape.
Cassette tape cannot be ejected.
Auto reverse does not work, or the tape direction changes
in the middle of play.

Audio unit. Refer to AV-47, "Removal and Installation of Audio Unit" .
There is much noise.
The sound is not clear.
Sound fluctuates/tape speed not correct
No sound.
Symptom Possible cause
CD cannot be inserted.

Audio unit. Refer to AV-47, "Removal and Installation of Audio Unit" .
CD cannot be ejected.
The CD cannot be played.
The sound skips, stops suddenly, or is distorted.

BCS-8
BCM (BODY CONTROL MODULE)
Revision: 2005 July 2005 FX
SYSTEMS CONTROLLED BY BCM DIRECTLY
NOTE:
Power supply only. No system control.
SYSTEMS CONTROLLED BY BCM AND IPDM E/R
SYSTEMS CONTROLLED BY BCM AND COMBINATION METER
SYSTEMS CONTROLLED BY BCM AND INTELLIGENT KEY UNIT
System Reference
Power door lock BL-21, "
POWER DOOR LOCK SYSTEM"
Remote keyless entryBL-56, "REMOTE KEYLESS ENTRY SYSTEM"
Power window NOTEGW-15, "POWER WINDOW SYSTEM"
Sunroof NOTERF-10, "SUNROOF"
Room lamp timerLT-159, "INTERIOR ROOM LAMP"
Warning chimeDI-58, "WARNING CHIME"
Rear wiperWW-38, "REAR WIPER AND WASHER SYSTEM"
Low tire pressure warning systemWT-7, "LOW TIRE PRESSURE WARNING SYSTEM"
System Reference
Panic alarm BL-56, "
REMOTE KEYLESS ENTRY SYSTEM"
Theft warningBL-186, "VEHICLE SECURITY (THEFT WARNING) SYSTEM"
IVIS (NATS)BL-213, "IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-NATS)"
Headlamp
LT- 7 , "HEADLAMP - XENON TYPE -"

LT- 3 9 , "DAYTIME LIGHT SYSTEM"
Auto light systemLT- 5 5 , "AUTO LIGHT SYSTEM"

Parking, license plate and tail lamps

Battery saver control LT-129, "PARKING, LICENSE PLATE AND TAIL LAMPS"
Front fog lamp
LT- 7 9 , "FRONT FOG LAMP"
Front wiperWW-4, "FRONT WIPER AND WASHER SYSTEM"
Rear window defoggerGW-86, "REAR WINDOW DEFOGGER"
System Reference
Warning chime DI-58, "
WARNING CHIME"
Turn signal and hazard warning lampsLT- 9 1 , "TURN SIGNAL AND HAZARD WARNING LAMPS"
Daytime running lightLT- 3 9 , "DAYTIME LIGHT SYSTEM"
System Reference
Intelligent Key BL-89, "
INTELLIGENT KEY SYSTEM"

BCS-14
BCM (BODY CONTROL MODULE)
Revision: 2005 July 2005 FX
4. Select the desired part to be diagnosed on the “SELECT TEST
ITEM” screen.
ITEMS OF EACH PART
NOTE:
CONSULT-II displays systems equipped in the vehicle.
× :Applicable
NOTE:
*1: This item is displayed, but should not be used.
*2: This item is displayed, but does not function.
PKIA5226E
System and item CONSULT-II display Diagnostic test mode (Inspection by part)
WORK
SUPPORT SELF
−
DIAG
RESULTS DATA
MONI-
TOR CAN
DIAG SUP-
PORT
MNTR ACTIVE
TEST ECU
PA R T
NUM- BER CON-
FIGU-
RATION
BCM BCM ×× × ×
×
*1
Power door lock system DOOR LOCK ×××
Rear window defogger REAR DEFOGGER ××
Warning chime BUZZER ××
Room lamp timer INT LAMP ×××
Headlamp HEAD LAMP ×××
Wiper WIPER ×××
Turn signal lamp
Hazard lamp FLASHER
××
Blower fan switch signal
A/C switch signal AIR CONDITONER
×
Intelligent Key system INTELLIGENT KEY ×
Combination switch COMB SW ×
IVIS IMMU ××
Room lamp battery saver BATTERY SAVER ×× ×
Trunk lid TRUNK
*2××
Vehicle security system THEFT ALM ×××
Retained power control RETAINED PWR ×××
Oil pressure switch SIGNAL BUFFER ××
Low tire pressure warning
system AIR PRESSURE
MONITOR ×××
Panic system PANIC ALARM ×

REMOTE KEYLESS ENTRY SYSTEM BL-59
C
D E
F
G H
J
K L
M A
B
BL
Revision: 2005 July 2005 FX
Refer to AV- 6 0 , "SETTING SCREEN" . (without navigation system)
Refer to AV- 9 4 , "
Vehicle Electronic Systems" . (with navigation system)
Panic Alarm Operation
When key switch is OFF (when ignition key is not inserted in key cylinder), BCM turns on and off horn and
headlamp intermittently with input of PANIC ALARM signal from key fob.
The alarm automatically turns off after 25 seconds or when BCM receives any signal from key fob.
Panic alarm operation mode can be changed using “PANIC ALARM SET” mode in “WORK SUPPORT”.
Refer to BL-68, "
Work Support" .
For detailed description, refer to BL-186, "
VEHICLE SECURITY (THEFT WARNING) SYSTEM" .
Keyless Power Window Down (Open) Operation
When key fob unlock switch is turned ON with ignition switch OFF, and key fob unlock switch is detected to be
on continuously for 3 seconds, the driver's door and passenger's door power windows are simultaneously
opened.
Power window is operated to open and the operation continues as long as the key fob unlock switch is
pressed.
Keyless power window down operation mode can be changed using “PW DOWN SET” mode in “WORK SUP-
PORT”. Refer to BL-68, "
Work Support"
Room Lamp and Ignition Key Ring Illumination Operation
When the following conditions come:

condition of interior lamp switch is DOOR position;

door switch OFF (when all the doors are closed);
Remote keyless entry system turns on interior lamp (for 30 seconds) with input of UNLOCK signal from key
fob. For detailed description, refer to LT- 1 5 9 , "
INTERIOR ROOM LAMP" .
CAN Communication System DescriptionAIS004MC
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN Communication UnitAIS004RM
Refer to LAN-30, "CAN COMMUNICATION" .

BL-68
REMOTE KEYLESS ENTRY SYSTEM
Revision: 2005 July 2005 FX
Work Support
*: Perform this mode always in the state of C mode. Refer to BL-58, "Hazard and Horn Reminder" .
HORN CHIRP SET*
*: Perform this mode always in the state of C mode. Refer to BL-58, "Hazard and Horn Reminder" .
This mode can be changed also on the display.
Refer to AV-60, "
SETTING SCREEN" . (without navigation system)
Refer to AV-94, "
Vehicle Electronic Systems" . (with navigation system)
HAZARD LAMP BACK SET*
*: Perform this mode always in the state of C mode. Refer to BL-58, "Hazard and Horn Reminder" .
This mode can be changed also on the display.
Refer to AV-60, "
SETTING SCREEN" . (without navigation system)
Refer to AV-94, "
Vehicle Electronic Systems" . (with navigation system)
HORN This test is able to check panic alarm and horn reminder operations.
The horn activate for 0.5 seconds after “ON” on CONSULT-II screen is touched.
DOOR LOCK This test is able to check door lock actuator operation.

The all door lock actuator are locked when “ALL LOCK” on CONSULT-II screen is touched.

The all door lock actuator are unlocked when “ALL UNLOCK” on CONSULT-II screen is touched.

The door lock actuator (driver side) is unlocked when “DR UNLOCK” on CONSULT-II screen is
touched.

The all door lock actuator (except driver side) are unlocked when “OTHER UNLOCK” on CON-
SULT-II screen is touched.
TRUNK/BACK DOOR This is displayed even when it is not equipped. Test Item Description
Test Item Description
HORN CHIRP SET* Horn reminder mode can be changed in this mode. The horn reminder mode will be
changed when “CHANGE SETT” on CONSULT-II screen is touched.
HAZARD LAMP SET* Hazard reminder mode can be changed in this mode. The hazard reminder mode will be
changed when “CHANGE SETT” on CONSULT-II screen is touched.
MULTI ANSWER BACK SET Hazard and horn reminder mode can be changed in this mode. The hazard and horn
reminder mode will be changed when “CHANGE SETT” on CONSULT-II screen is touched.
AUTO LOCK SET Auto locking function mode can be changed in this mode. The function mode will be
changed when “CHANGE SETT” on CONSULT-II screen is touched.
PANIC ALRM SET Panic alarm operation mode can be changed in this mode. The operation mode will be
changed when “CHANGE SETT” on CONSULT-II screen is touched.
PW DOWN SET Keyless power window down (open) operation mode can be changed in this mode. The
operation mode will be changed when“CHANGE SETT” on CONSULT-II screen is touched.
Horn chirp function ON OFF
MODE1 MODE2 MODE3 MODE4
Hazard lamp operation mode Nothing Unlock only Lock only Lock and Unlock

BL-204
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: 2005 July 2005 FX
Trouble Diagnosis Symptom ChartAIS004P3
*1: Make sure the system is in the armed phase. Procedure
Diagnostic procedure Refer to page
Symptom
1 Vehicle security
system cannot be
set by ···· Door switch Diagnostic Procedure 1 (Check door, hood and back door switch)
BL-205
Lock / unlock switch Diagnostic Procedure 6 (Check door lock / unlock switch)BL-212
Door outside key Diagnostic Procedure 3 (Check door key cylinder switch)BL-212
Key fob Check remote keyless entry. BL-56
Intelligent Key Check Intelligent Key.BL-89
— If the above systems are “OK”, replace BCM.BCS-16
Security indicator does not turn “ON”. Diagnostic Procedure 2 (Check security indicator lamp)
BL-211If the above systems are “OK”, replace BCM.BCS-16
2 *1 Vehicle secu-
rity system does
not alarm when
···· Any door is opened. Diagnostic Procedure 1 (Check door, hood and back door switch)
BL-205If the above systems are “OK”, replace BCM.BCS-16
3 Vehicle security
alarm does not
activate. Horn alarm
Diagnostic Procedure 4 (Check vehicle security horn alarm)
BL-212
Check horn function. BL-83
If the above systems are “OK”, replace BCM.BCS-16
Head lamp alarm Diagnostic Procedure 5 (Check head lamp alarm)
BL-212If the above systems are “OK”, replace BCM.BCS-16
4 Vehicle security
system cannot be
canceled by ···· Door outside key
Diagnostic Procedure 3 (Check door key cylinder switch)
BL-212
If the above systems are “OK”, check power window main switch. EI-34
Key fob Check remote keyless entry function.
BL-57If the above systems are “OK”, replace BCM.BCS-16
Intelligent Key Check Intelligent Key
BL-91If the above systems are “OK”, replace BCM.BCS-16

BASIC SERVICE PROCEDURE EC-97
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2005 July 2005 FX
OPERATION PROCEDURE
1. Make sure that accelerator pedal is fully released.
2. Turn ignition switch ON.
3. Turn ignition switch OFF wait at least 10 seconds. Make sure that throttle valve moves during above 10 seconds by confirming the operating sound.
Idle Air Volume LearningABS006KG
DESCRIPTION
Idle Air Volume Learning is an operation to learn the idle air volume that keeps each engine within the specific
range. It must be performed under any of the following conditions:

Each time electric throttle control actuator or ECM is replaced.

Idle speed or ignition timing is out of specification.
PREPARATION
Before performing Idle Air Volume Learning, make sure that all of the following conditions are satisfied.
Learning will be cancelled if any of the following conditions are missed for even a moment.

Battery voltage: More than 12.9V (At idle)

Engine coolant temperature: 70 - 100 °C (158 - 212 °F)

Park/neutral position switch: ON

Electric load switch: OFF
(Air conditioner, headlamp, rear window defogger)
On vehicles equipped with daytime light systems, if the parking brake is applied before the engine
is started the headlamp will not be illuminated.

Steering wheel: Neutral (Straight-ahead position)

Vehicle speed: Stopped

Transmission: Warmed-up
For models with CONSULT-II, drive vehicle until “ATF TEMP SE 1” in “DATA MONITOR” mode of “A/T”
system indicates less than 0.9V.
For models without CONSULT-II, drive vehicle for 10 minutes.
OPERATION PROCEDURE
With CONSULT-II
1. Perform EC-96, "Accelerator Pedal Released Position Learning" .
2. Perform EC-96, "
Throttle Valve Closed Position Learning" .
3. Start engine and warm it up to normal operating temperature.
4. Check that all items listed under the topic PREPARATION (previously mentioned) are in good order.
5. Select “IDLE AIR VOL LEARN” in “WORK SUPPORT” mode.
SEF217Z

BASIC SERVICE PROCEDURE EC-787
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2005 July 2005 FX
OPERATION PROCEDURE
1. Make sure that accelerator pedal is fully released.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds. Make sure that throttle valve moves during above 10 seconds by confirming the operating sound.
Idle Air Volume LearningABS00E4I
DESCRIPTION
Idle Air Volume Learning is an operation to learn the idle air volume that keeps each engine within the specific
range. It must be performed under any of the following conditions:

Each time electric throttle control actuator or ECM is replaced.

Idle speed or ignition timing is out of specification.
PREPARATION
Before performing Idle Air Volume Learning, make sure that all of the following conditions are satisfied.
Learning will be cancelled if any of the following conditions are missed for even a moment.

Battery voltage: More than 12.9V (At idle)

Engine coolant temperature: 70 - 99 °C (158 - 210 °F)

PNP switch: ON

Electric load switch: OFF
(Air conditioner, headlamp, rear window defogger)
On vehicles equipped with daytime light systems, if the parking brake is applied before the engine
is started the headlamp will not be illuminated.

Steering wheel: Neutral (Straight-ahead position)

Vehicle speed: Stopped

Transmission: Warmed-up
For models with CONSULT-II, drive vehicle until “ATF TEMP SE 1” in “DATA MONITOR” mode of “A/T”
system indicates less than 0.9V.
For models without CONSULT-II, drive vehicle for 10 minutes.
OPERATION PROCEDURE
With CONSULT-II
1. Perform EC-786, "Accelerator Pedal Released Position Learning" .
2. Perform EC-786, "
Throttle Valve Closed Position Learning" .
3. Start engine and warm it up to normal operating temperature.
4. Check that all items listed under the topic PREPARATION (previously mentioned) are in good order.
5. Select “IDLE AIR VOL LEARN” in “WORK SUPPORT” mode.
SEF217Z
