BR-22
FRONT DISC BRAKE
Revision: 2005 July 2005 FX

Do not reuse drained brake fluid.
1. Install disc rotor.
2. Install caliper assembly to the vehicle, and tighten bolts to the specified torque.
CAUTION:
When attaching caliper assembly to the vehicle, wipe any
oil off knuckle spindle, washers and caliper assembly
attachment surfaces.
3. Install brake hose to brake caliper assembly, and tighten union bolt to the specified torque.
CAUTION:

Do not reuse copper washers for union bolt.

Attach brake hose to caliper assembly together with
union bolt and washers.
4. Refill new brake fluid and bleed air. Refer to BR-10, "
Bleeding Brake System" .
5. Attach tires to the vehicle.
Disassembly and Assembly of Brake Caliper AssemblyAFS001S1
DISASSEMBLY
1. Remove sliding pin bolt, and then remove the pad, shim, shim cover, and pad retainer from the torque member.
2. Remove sliding pins and sliding pin boots from torque member.
3. Place a wooden block as shown in the figure, and blow air from union bolt mounting hole to remove pistons and piston boots.
CAUTION:
Do not get your fingers caught in piston.
SFIA1205E
SFIA1204E
MAA0272D

BR-28
REAR DISC BRAKE
Revision: 2005 July 2005 FX
INSTALLATION
CAUTION:

Refill with new brake fluid “DOT 3”.

Do not reuse drained brake fluid.
1. Install disc rotor.
2. Install caliper assembly to the vehicle, and tighten bolts to the specified torque. CAUTION:
Before installing caliper assembly to the vehicle, wipe off oil and grease on washer seats on axle
assembly and mounting surface of caliper assembly.
3. Install brake hose to caliper assembly and tighten union bolt to the specified torque.
CAUTION:

Do not reuse copper washer for union bolt.

Securely attach brake hose to protrusion on caliper assembly.
4. Refill new brake fluid and bleed air. Refer to BR-10, "
Bleeding Brake System" .
5. Install tires to the vehicle.
Disassembly and Assembly of Brake Caliper AssemblyAFS001NE
DISASSEMBLY
1. Remove sliding pin bolt, and then remove pad, shim, shim cover, and pad retainer from torque member and cylinder.
2. Remove sliding pin boot from torque member.
3. As shown in the figure, using a flat-bladed screwdriver, remove retaining ring from cylinder body.
4. Place a wooden block as shown in the figure, and blow air from union bolt mounting hole to remove pistons and piston boots.
CAUTION:
Do not get your fingers caught in piston.
5. Using a flat-bladed screwdriver, remove piston seals from cylin- der body.
CAUTION:
Be careful not to damage cylinder inner wall.
SBR028A
BRD0041D
SFIA0999E

CO-28
[VQ35DE]
WATER OUTLET AND WATER PIPING
Revision: 2005 July 2005 FX
WATER OUTLET AND WATER PIPINGPFP:11060
ComponentsABS00E82
Removal and InstallationABS007ZU
REMOVAL
1. Remove front engine undercover with power tool.
2. Drain engine coolant from radiator drain plug at the bottom of radiator, and from water drain plug at the front of cylinder block. Refer to CO-11, "
Changing Engine Coolant" and CO-22, "WATER PUMP" .
CAUTION:

Perform this step when the engine is cold.

Do not spill engine coolant on drive belts.
3. Remove engine cover with power tool. Refer to EM-19, "
INTAKE MANIFOLD COLLECTOR" .
4. Remove air duct (inlet), air duct and air cleaner case assembly. Refer to EM-17, "
AIR CLEANER AND AIR
DUCT" .
5. Remove radiator hose (upper) and heater hose.
6. Remove the following parts, when remove water outlet.

A/T fluid charging pipe; Refer to AT- 2 7 0 , "TRANSMISSION ASSEMBLY" .

Intake manifold collectors (upper and lower). Refer to EM-19, "INTAKE MANIFOLD COLLECTOR" .

Rocker cover (right bank). Refer to EM-51, "ROCKER COVER" .
7. Remove engine coolant temperature sensor as necessary. CAUTION:
Be careful not to damage engine coolant temperature sensor.
8. Remove water outlet, heater pipe, water bypass hoses and water pipe.
1. Harness bracket 2. Water hose 3. Water bypass hose
4. Engine coolant temperature sensor 5. Gasket 6. Water outlet
7. Heater hose 8. Water pipe 9. Radiator hose (upper)
10. Heater pipe 11. Washer 12. O-ring
SBIA0484E

CO-42
[VK45DE]
RADIATOR
Revision: 2005 July 2005 FX

Install blind plug to avoid leakage of A/T fluid.
7. Remove radiator shroud (lower).

While pressing left and right pawls in direction indicated by
arrows, pull radiator shroud (lower) rearwards to remove.
8. Lift up and remove radiator shroud.
9. Remove washer tank mounting bolts.
10. Rotate two radiator upper mount brackets 90 degrees in the direction as shown in the figure, and remove them.
PBIC1532E
PBIC1535E
PBIC1534E
PBIC1533E

EM-36
[VQ35DE]
OIL PAN AND OIL STRAINER
Revision: 2005 July 2005 FX
Removal and Installation (AWD Model)ABS00E3Q
REMOVAL
CAUTION:
To avoid the danger of being scalded, never drain engine oil when the engine is hot.
NOTE:
To remove oil pan (lower) only, take step 5, then step 24. Removal of step 1, hood assembly (step 2) and step
4 are unnecessary.
1. Remove front tire.
2. Remove hood assembly. Refer to BL-13, "
HOOD" .
3. Remove front and rear engine undercover with power tool.
4. Remove front cross bar with power tool. Refer to FSU-6, "
FRONT SUSPENSION ASSEMBLY" .
5. Drain engine oil. Refer to LU-9, "
Changing Engine Oil" .
CAUTION:

Perform this step when the engine is cold.

Do not spill engine oil on drive belts.
6. Drain engine coolant. Refer to CO-11, "
Changing Engine Coolant" .
CAUTION:

Perform this step when the engine is cold.

Do not spill engine coolant on drive belts.
7. Remove engine cover with power tool. Refer to EM-19, "
INTAKE MANIFOLD COLLECTOR" .
8. Remove air hose from air duct to mass air flow sensor side and electric throttle control actuator side. Refer to EM-17, "
AIR CLEANER AND AIR DUCT" .
9. Remove drive belts. Refer to EM-15, "
DRIVE BELTS" .
10. Remove front drive shaft (LH and RH) and side shaft. Refer to FAX-12, "
FRONT DRIVE SHAFT" .
11. Remove side shaft. Refer to FFD-12, "
FRONT FINAL DRIVE ASSEMBLY" .
12. Removal engine rear lower slinger, and install engine rear slinger [SST: 10006 31U00 ( — )] to sling engine assembly for positioning. Refer to EM-8, "
Special Service Tools" .
13. Remove front suspension member. Refer to Refer to FSU-17, "
FRONT SUSPENSION MEMBER" .
14. Remove engine mounting bracket, engine mounting bracket (lower) and insulator. Refer to EM-112,
"ENGINE ASSEMBLY" .
15. Remove front propeller shaft. Refer to PR-4, "
FRONT PROPELLER SHAFT" .
16. Remove oil filter and oil filter bracket. Refer to LU-12, "
OIL FILTER BRACKET (AWD)" .
17. Remove alternator stay. Refer to SC-23, "
CHARGING SYSTEM" .
18. Remove idler pulley and bracket. Refer to EM-15, "
DRIVE BELTS" .
19. Disconnect oil cooler water hoses, and remove oil cooler water pipe mounting bolt. Refer to LU-14, "
OIL
COOLER" .
20. Disconnect A/T fluid cooler hoses, and remove A/T fluid cooler tube. Refer to AT- 2 7 0 , "
TRANSMISSION
ASSEMBLY" .
21. Remove front final drive assembly. Refer to FFD-12, "
FRONT FINAL DRIVE ASSEMBLY" .
22. Remove starter motor. Refer to SC-10, "
STARTING SYSTEM" .
23. Remove crankshaft position sensor (POS).
1. Oil pan gasket (rear) 2. Oil pan (upper) 3. O-ring
4. Oil pan gasket (front) 5. Oil filter 6. Connector bolt
7. Oil cooler 8. O-ring 9. Relief valve
10. Oil filter bracket 11. Oil filter bracket gasket 12. Oil strainer
13. Drain plug 14. Drain plug washer 15. Oil pan (lower)
16. Rear plate 17. Crankshaft position sensor (POS) 18 O-ring (small)
19. O-ring (large) 20. Axle pipe
Slinger bolts: : 28.0 N·m (2.9 kg-m, 21 ft-lb)

PRECAUTIONS GI-5
C
D E
F
G H
I
J
K L
M B
GI
Revision: 2005 July 2005 FX

Before jacking up the vehicle, apply wheel chocks or other tire
blocks to the wheels to prevent the vehicle from moving. After
jacking up the vehicle, support the vehicle weight with safety
stands at the points designated for proper lifting before working
on the vehicle.
These operations should be done on a level surface.

When removing a heavy component such as the engine or tran-
saxle/transmission, be careful not to lose your balance and drop
them. Also, do not allow them to strike adjacent parts, especially
the brake tubes and master cylinder.

Before starting repairs which do not require battery power:
Turn off ignition switch.
Disconnect the negative battery terminal.

If the battery terminals are disconnected, recorded memory of
radio and each control unit is erased.

To prevent serious burns:
Avoid contact with hot metal parts.
Do not remove the radiator cap when the engine is hot.

Dispose of drained oil or the solvent used for cleaning parts in
an appropriate manner.

Do not attempt to top off the fuel tank after the fuel pump nozzle
shuts off automatically.
Continued refueling may cause fuel overflow, resulting in fuel
spray and possibly a fire.

Clean all disassembled parts in the designated liquid or solvent
prior to inspection or assembly.

Replace oil seals, gaskets, packings, O-rings, locking washers, cotter pins, self-locking nuts, etc. with new
ones.

Replace inner and outer races of tapered roller bearings and needle bearings as a set.

Arrange the disassembled parts in accordance with their assembled locations and sequence.

Do not touch the terminals of electrical components which use microcomputers (such as ECM).
Static electricity may damage internal electronic components.

After disconnecting vacuum or air hoses, attach a tag to indicate the proper connection.

Use only the fluids and lubricants specified in this manual.

Use approved bonding agent, sealants or their equivalents when required.

Use hand tools, power tools (disassembly only) and recom-
mended special tools where specified for safe and efficient ser-
vice repairs.

When repairing the fuel, oil, water, vacuum or exhaust systems,
check all affected lines for leaks.
SGI231
SEF289H
SGI233
PBIC0190E

GI-10
HOW TO USE THIS MANUAL
Revision: 2005 July 2005 FX
ComponentsAAS000GW

THE LARGE ILLUSTRATIONS are exploded views (see the following) and contain tightening torques,
lubrication points, section number of the PARTS CATALOG (e.g. SEC. 440) and other information neces-
sary to perform repairs.
The illustrations should be used in reference to service matters only. When ordering parts, refer to the
appropriate PARTS CATALOG .
Components shown in an illustration may be identified by a circled number. When this style of illustration
is used, the text description of the components will follow the illustration.
SYMBOLS
1. Union bolt 2. Copper washer 3. Brake hose
4. Cap 5. Bleed valve 6. Sliding pin bolt
7. Piston seal 8. Piston 9. Piston boot
10. Cylinder body 11. Sliding pin 12. Torque member mounting bolt
13. Washer 14. Sliding pin boot 15. Bushing
16. Torque member 17. Inner shim cover 18. Inner shim
19. Inner pad 20. Pad retainer 21. Pad wear sensor
22. Outer pad 23. Outer shim 24. Outer shim cover 1: PBC (Poly Butyl Cuprysil) grease
or silicone-based grease 2: Rubber grease : Brake fluid
Refer to GI section for additional symbol definitions.
SFIA2959E
SAIA0749E

IDX-4
ALPHABETICAL INDEX
ECTS - Wiring diagram ...................... EC-210, EC-916
Electric sunroof .................................................. RF-10
Electric throttle control actuator ........ EC-424, EC-426,
EC-1148
, EC-1150
Electric throttle control actuator (VK45DE) ..... EM-178
Electric throttle control actuator (VQ35DE) ....... EM-19
Electrical load signal circuit .............. EC-679, EC-1369
Electrical unit ..................................................... PG-76
Electrical units location ...................................... PG-70
Electronic ignition (EI) system ............. EC-33, EC-724
Engine control module (ECM) .......... EC-402, EC-1134
Engine control system diagram ....................... EC-721
Engine control system diagram and chart ......... EC-30
Engine coolant temperature sensor (ECTS) ... EC-208,
EC-220
, EC-914, EC-927
Engine coolant(VK45DE) .................................. CO-37
Engine coolant(VQ35DE) ................................. CO-11
Engine oil filter replacement ............................. MA-26
Engine oil filter replacement(VQ35DE) ............. MA-19
Engine oil precautions .......................................... GI-8
Engine oil replacement(VQ35DE) ..................... MA-18
Engine oil(VK45DE) ........................................... LU-25
Engine oil(VQ35DE) ............................................ LU-7
Engine removal(VK45DE) ............................... EM-240
Engine removal(VQ35DE) .............................. EM-112
Engine room cover(VK45DE) ......................... EM-172
ETC1 - Wiring diagram .................... EC-427, EC-1151
ETC2 - Wiring diagram .................... EC-434, EC-1158
ETC3 - Wiring diagram .................... EC-438, EC-1162
EVAP canister ...................................... EC-42, EC-733
EVAP canister purge volume control solenoid valve ....
EC-336
, EC-1069, EC-1233
EVAP canister vent control valve ...... EC-343, EC-568,
EC-1076
, EC-1241
EVAP control system (small leak) diagnosis .. EC-327,
EC-367
, EC-1061, EC-1108
EVAP control system pressure sensor ........... EC-350,
EC-353
, EC-359, EC-1083, EC-1086, EC-1092
EVAP control system purge flow monitoring diagnosis
EC-322
, EC-1056
EVAP vapor lines inspection ................. MA-21, MA-28
Evaporative emission (EVAP) system . EC-39, EC-730
Evaporator ..................................................... ATC-156
Exhaust manifold(VK45DE) ............................ EM-182
Exhaust manifold(VQ35DE) .............................. EM-26
Exhaust system ................................................... EX-3
Exhaust system inspection ..................... EX-3, MA-29
Expansion valve ............................................. ATC-157
F
F/FOG - Wiring diagram ..................................... LT-81
F/PUMP - Wiring diagram ................ EC-669, EC-1359
Final drive pre-inspection .................. FFD-20, RFD-17
Final drive removal and installation .. FFD-12, FFD-14,
RFD-14
Floor trim ............................................................. EI-39
Flow charts ......................................................... GI-27
Fluid temperature sensor (A/T) ........................ AT-136
Fluorescent leak detector ............................. ATC-158
Fog lamp, front ................................................... LT-79
Front axle ............................................ FAX-4, FAX-10
Front brake solenoid valve ................. AT-154, AT-156
Front bumper ...................................................... EI-14
Front door ............................. BL-153, BL-157, GW-76
Front fog lamp .................................................... LT-79
Front passenger air bag .................................. SRS-39
Front seat belt ...................................................... SB-3
Front seat belt pre-tensioner ..... SB-2, SRS-3, SRS-44
Front suspension .............................................. FSU-6
Front washer ...................................................... WW-4
Front wiper ......................................................... WW-4
FTTS - Wiring diagram .... EC-269, EC-274, EC-1006,
EC-1011
Fuel cut control (at no load high engine speed) EC-34,
EC-725
Fuel filter replacement ......................................... FL-4
Fuel gauge ............................................................ DI-5
Fuel injection system (Bank 1) .......... EC-986, EC-995
Fuel injection system (Bank 2) .......... EC-986, EC-995
Fuel injector and fuel tube(VK45DE) .............. EM-192
Fuel injector and fuel tube(VQ35DE) ................ EM-45
Fuel level sensor EC-385, EC-387, EC-389, EC-1117,
EC-1119
, EC-1121
Fuel line inspection .................................. FL-3, MA-25
Fuel line inspection(VQ35DE) .......................... MA-17
Fuel precautions .......................................... GI-6, GI-7
Fuel pressure check ........................... EC-99, EC-789
Fuel pressure release ......................... EC-99, EC-789
Fuel pump ....................................... EC-668, EC-1358
Fuel pump and gauge .......................................... FL-4
Fuel system ......................................................... FL-3
Fuel tank ............................................................ FL-10
Fuel tank temperature sensor .......... EC-267, EC-273,
EC-1004
, EC-1010
Fuel tank vacuum relief valve ............. EC-42, EC-733
FUELB1 - Wiring diagram .. EC-250, EC-260, EC-988,
EC-997
FUELB2 - Wiring diagram .. EC-251, EC-261, EC-989,
EC-998
Fuse .................................................................. PG-17
Fuse and fusible link box .................................. PG-83
Fusible link ........................................................ PG-17
G
Gauges ................................................................. DI-5
Glass ...................................... GW-11, GW-76, GW-80
Glove box lamp ................................... LT-156, LT-202
Grille - See Exterior ............................................ EI-22
Ground distribution ........................................... PG-31
H
H/AIM - Wiring diagram ..................................... LT-75
H/LAMP - Wiring diagram .................................. LT-11
Harness connector ............................................ PG-74
Harness layout .................................................. PG-46
