2005 INFINITI FX35 p1805

EC-616
[VQ35DE]
DTC P1805 BRAKE SWITCH
Revision: 2005 July 2005 FX
Specification data are reference values and are measured between each terminal and ground.
CAUTION:
Do not use ECM ground terminals when measuring input/output voltage. Doing so may result in dam-
age to the ECM's transistor. Use a ground other than ECM terminals, such as the ground.
Diagnostic ProcedureABS006X6
1. CHECK STOP LAMP SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Check the stop lamp when depressing and releasing the brake pedal.
OK or NG
OK >> GO TO 4.
NG >> GO TO 2.
2. CHECK STOP LAMP SWITCH POWER SUPPLY CIRCUIT
1. Disconnect stop lamp switch harness connector.
2. Check voltage between stop lamp switch terminal 1 and ground with CONSULT-II or tester.
OK or NG
OK >> GO TO 4.
NG >> GO TO 3.
TER-
MINAL NO. WIRE
COLOR ITEM CONDITION DATA (DC Voltage)
101 P/L Stop lamp switch [Ignition switch: OFF]

Brake pedal: Fully released
Approximately 0V
[Ignition switch: OFF]

Brake pedal: Slightly depressed BATTERY VOLTAGE
(11 - 14V)
Brake pedal Stop lamp
Fully released Not illuminated
Slightly depressed Illuminated
PBIB1605E
Voltage: Battery voltage
PBIB1184E

DTC P1805 BRAKE SWITCH EC-617
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2005 July 2005 FX
3. DETECT MALFUNCTIONING PART
Check the following.

10A fuse

Fuse block (J/B) connector E201

Harness for open and short between stop lamp switch and battery
>> Repair open circuit or short to ground or short to power in harness or connectors.
4. CHECK STOP LAMP SWITCH INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Disconnect stop lamp switch harness connector.
4. Check harness continuity between ECM terminal 101 and stop lamp switch terminal 2.
Refer to Wiring Diagram.
5. Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 6.
NG >> GO TO 5.
5. DETECT MALFUNCTIONING PART
Check the following.

Harness connectors E211, M41

Harness for open or short between ECM and stop lamp switch
>> Repair open circuit or short to ground or short to power in harness or connectors.
6. CHECK STOP LAMP SWITCH
Refer to EC-618, "
Component Inspection" .
OK or NG
OK >> GO TO 7.
NG >> Replace stop lamp switch.
7. CHECK INTERMITTENT INCIDENT
Refer to EC-163, "
TROUBLE DIAGNOSIS FOR INTERMITTENT INCIDENT" .
>> INSPECTION END
Continuity should exist.
PBIB1605E

EC-618
[VQ35DE]
DTC P1805 BRAKE SWITCH
Revision: 2005 July 2005 FX
Component InspectionABS006X7
STOP LAMP SWITCH
1. Disconnect stop lamp switch harness connector.
2. Check continuity between stop lamp switch terminals 1 and 2 under the following conditions.
3. If NG, adjust stop lamp switch installation, refer to BR-6, "
BRAKE PEDAL" , and perform step 2 again.
PBIB1605E
Conditions Continuity
Brake pedal: Fully released Should not exist.
Brake pedal: Slightly depressed Should exist.
PBIB1185E

EC-710
[VK45DE]
INDEX FOR DTC
Revision: 2005 July 2005 FX
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: When engine is running.
*5: The troubleshooting for this DTC needs CONSULT-II.
*6: When the fail-safe operations for both self-diagnoses occur at the same time, the MIL illuminates.
*7: Models with ICC. P1568 1568
ACC COMMAND VALUE*
7EC-1261
P1572 1572 ASCD BRAKE SW EC-1262 (Models with ICC)
EC-1271
(Models with ASCD)
P1574 1574 ASCD VHL SPD SEN EC-1279
(Models with ICC)
EC-1281
(Models with ASCD)
P1610 - P1615 1610 - 1615 NATS MALFUNCTION EC-744
P1706 1706 P-N POS SW/CIRCUITEC-1283
P1716 1716 TURBINE REV S/CIRC AT-141
P1720 1720 V/SP SEN(A/T OUT)EC-1288
P1730 1730 A/T INTERLOCK AT-145
P1752 1752 I/C SOLENOID/CIRCAT-150
P1754 1754 I/C SOLENOID FNCTNAT-152
P1757 1757 FR/B SOLENOID/CIRCAT-154
P1759 1759 FR/B SOLENOID FNCTAT-156
P1762 1762 D/C SOLENOID/CIRCAT-158
P1764 1764 D/C SOLENOID FNCTNAT-160
P1767 1767 HLR/C SOL/CIRCAT-162
P1769 1769 HLR/C SOL FNCTNAT-164
P1772 1772 LC/B SOLENOID/CIRCAT-166
P1774 1774 LC/B SOLENOID FNCTAT-168
P1780 1780 SHIFT SIG FNCTNEC-1290
P1800 1800 VIAS S/V CIRCEC-1292
P1805 1805 BRAKE SW/CIRCUITEC-1297
P2122 2122 APP SEN 1/CIRCEC-1302
P2123 2123 APP SEN 1/CIRCEC-1302
P2127 2127 APP SEN 2/CIRCEC-1309
P2128 2128 APP SEN 2/CIRCEC-1309
P2135 2135 TP SENSOREC-1316
P2138 2138 APP SENSOREC-1323
DTC*1
Items
(CONSULT-II screen terms) Reference page
CONSULT-II
GST*
2ECM*3

INDEX FOR DTC EC-711
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2005 July 2005 FX
Alphabetical IndexABS00E3W
NOTE:
If DTC U1000 or U1001 is displayed with other DTC, first perform the trouble diagnosis for DTC U1000,
U1001. Refer to EC-862, "
DTC U1000, U1001 CAN COMMUNICATION LINE" .
Items
(CONSULT-II screen terms) DTC*
1
Reference page
CONSULT-II
GST*
2ECM*3
A/T INTERLOCK P1730 1730 AT-145
A/T TCC S/V FNCTN P0744 0744AT-127
ACC COMMAND VALUE*7P1568 1568EC-1261
APP SEN 1/CIRC P2122 2122 EC-1302
APP SEN 1/CIRC P2123 2123EC-1302
APP SEN 2/CIRC P2127 2127EC-1309
APP SEN 2/CIRC P2128 2128EC-1309
APP SENSOR P2138 2138EC-1323
ASCD BRAKE SW P1572 1572 EC-1262 (Models with ICC)
EC-1271
(Models with ASCD)
ASCD SW P1564 1564 EC-1247
(Models with ICC)
EC-1254
(Models with ASCD)
ASCD VHL SPD SEN P1574 1574 EC-1279
(Models with ICC)
EC-1281
(Models with ASCD)
ATF TEMP SEN/CIRC P0710 0710 AT-136
BRAKE SW/CIRCUIT P1805 1805EC-1297
CAN COMM CIRCUIT U1000
1000*5EC-862
CAN COMM CIRCUIT U1001
1001*5EC-862
CKP SEN/CIRCUIT P0335 0335 EC-1036
CLOSED LOOP-B1 P1148 1148EC-1209
CLOSED LOOP-B2 P1168 1168EC-1209
CMP SEN/CIRC-B1 P0340 0340EC-1043
CTP LEARNING P1225 1225EC-1225
CTP LEARNING P1226 1226EC-1227
CYL 1 MISFIRE P0301 0301EC-1022
CYL 2 MISFIRE P0302 0302EC-1022
CYL 3 MISFIRE P0303 0303EC-1022
CYL 4 MISFIRE P0304 0304EC-1022
CYL 5 MISFIRE P0305 0305EC-1022
CYL 6 MISFIRE P0306 0306EC-1022
CYL 7 MISFIRE P0307 0307EC-1022
CYL 8 MISFIRE P0308 0308EC-1022
D/C SOLENOID FNCTN P1764 1764 AT-160
D/C SOLENOID/CIRC P1762 1762AT-158
ECM P0605 0605EC-1134
ECM BACK UP/CIRCUIT P1065 1065EC-1137
ECT SEN/CIRCUIT P0117 0117 EC-914
ECT SEN/CIRCUIT P0118 0118EC-914
ECT SENSOR P0125 0125EC-927

ON BOARD DIAGNOSTIC (OBD) SYSTEM EC-749
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2005 July 2005 FX
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: The trouble shooting for this DTC needs CONSULT-II.
*5: SRT code will not be set it the self-diagnostic result is NG.
*6: When the fail-safe operations for both self-diagnoses occur at the same time, the MIL illuminates.
*7: When engine is running, MIL may flash. For the details, refer to EC-761, "
MIL Flashing Without DTC" .
*8: When the ECM is in the mode of displaying SRT status, MIL may flash. For the details, refer to EC-754, "
How to Display SRT Status"
.
*9: Models with ICC. ACC COMMAND VALUE*
9P1568 1568 — — 1 —
EC-1261
ASCD BRAKE SW P1572 1572 — — 1 — EC-1262

(Models
with ICC) EC-1271

(Models
with ASCD)
ASCD VHL SPD SEN P1574 1574 — — 1 — EC-1279

(Models
with ICC) EC-1281

(Models
with ASCD)
NATS MALFUNCTION P1610 -
P1615 1610 - 1615 — — 2 —
EC-744
P-N POS SW/CIRCUIT P1706 1706 — — 2 ×EC-1283
TURBINE REV S/CIRC P1716 1716 — — 2 ×AT- 1 4 1
V/SP SEN(A/T OUT) P1720 1720 — — 2 — EC-1288
A/T INTERLOCK P1730 1730 — — 1×AT- 1 4 5
I/C SOLENOID/CIRC P1752 1752 — — 1 ×AT- 1 5 0
I/C SOLENOID FNCTN P1754 1754 — — 1 ×AT- 1 5 2
FR/B SOLENOID/CIRC P1757 1757 — — 1 ×AT- 1 5 4
FR/B SOLENOID FNCT P1759 1759 — — 1 ×AT- 1 5 6
D/C SOLENOID/CIRC P1762 1762 — — 1 ×AT- 1 5 8
D/C SOLENOID FNCTN P1764 1764 — — 1 ×AT- 1 6 0
HLR/C SOL/CIRC P1767 1767 — — 1 ×AT- 1 6 2
HLR/C SOL FNCTN P1769 1769 — — 1 ×AT- 1 6 4
LC/B SOLENOID/CIRC P1772 1772 — — 1 ×AT- 1 6 6
LC/B SOLENOID FNCT P1774 1774 — — 1 ×AT- 1 6 8
SHIFT SIG FNCTN P1780 1780 — — 2 — EC-1290
VIAS S/V CIRC P1800 1800 — — 2 —EC-1292
BRAKE SW/CIRCUIT P1805 1805 — — 2 —EC-1297
APP SEN 1/CIRC P2122 2122 — — 1×EC-1302
APP SEN 1/CIRC P2123 2123 — — 1 ×EC-1302
APP SEN 2/CIRC P2127 2127 — — 1 ×EC-1309
APP SEN 2/CIRC P2128 2128 — — 1 ×EC-1309
TP SENSOR P2135 2135 — — 1 ×EC-1316
APP SENSOR P2138 2138 — — 1 ×EC-1323
Items
(CONSULT-II screen terms) DTC*
1
SRT code
Test value/
Te s t l i m i t
(GST only) Trip MIL
Reference
page
CONSULT-II
GST*
2ECM*3

EC-798
[VK45DE]
TROUBLE DIAGNOSIS
Revision: 2005 July 2005 FX
2
P0031P0032 P0051 P0052 Heated oxygen sensor 1 heater

P0037 P0038 P0057 P0058 Heated oxygen sensor 2 heater

P0132 P0133 P0134 P0152 P0153 P0154 P1143 P1144 P1163 P1164 Heated oxygen sensor 1

P0138 P0139 P0158 P0159 P1146 P1147 P1166 P1167 Heated oxygen sensor 2

P0441 EVAP control system purge flow monitoring

P0444 P0445 P1444 EVAP canister purge volume control solenoid valve

P0447 P1446 EVAP canister vent control valve

P0451 P0452 P0453 EVAP control system pressure sensor

P0550 Power steering pressure sensor

P0710 P0720 P0740 P0744 P0745 P1716 P1720 P1730 P1752 P1754 P1757 P1759 P1762 P1764 P1767 P1769
P1772 P1774 A/T related sensors, solenoid valves and switches

P1065 ECM power supply

P 1111 P 11 3 6 I n ta k e v a l v e t i m i n g c o n t r o l s o l e n o i d v a l v e

P1122 Electric throttle control function

P1124 P1126 P1128 Electric throttle control actuator

P1140 P1145 Intake valve timing control position sensor

P1217 Engine over temperature (OVERHEAT)

P1805 Brake switch
3

P0011 P0021 Intake valve timing control

P0171 P0172 P0174 P0175 Fuel injection system function

P0300 - P0308 Misfire

P0420 P0430 Three way catalyst function

P0442 P0456 EVAP control system (SMALL LEAK, VERY SMALL LEAK)

P0455 EVAP control system (GROSS LEAK)

P0506 P0507 Idle speed control system

P1121 Electric throttle control actuator

P1148 P1168 Closed loop control

P1211 TCS control unit

P1212 TCS communication line

P1564 ICC steering switch/ASCD steering switch

P1568 ICC command value

P1572 ICC brake switch/ASCD brake switch

P1574 ICC vehicle speed sensor/ASCD vehicle speed sensor

P1780 Shift change signal

P1800 VIAS control solenoid valve
Priority Detected items (DTC)

DTC P1805 BRAKE SWITCH EC-1297
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2005 July 2005 FX
DTC P1805 BRAKE SWITCHPFP:25320
DescriptionABS007VH
Brake switch signal is applied to the ECM through the stop lamp switch when the brake pedal is depressed.
This signal is used mainly to decrease the engine speed when the vehicle is driving.
CONSULT-II Reference Value in Data Monitor ModeABS007VI
Specification data are reference values.
On Board Diagnosis LogicABS007VJ
The MIL will not light up for this diagnosis.
FAIL-SAFE MODE
When the malfunction is detected, ECM enters fail-safe mode.
DTC Confirmation ProcedureABS007VK
WITH CONSULT-II
1. Turn ignition switch ON.
2. Fully depress the brake pedal for at least 5 seconds.
3. Erase the DTC with CONSULT-II.
4. Select “DATA MONITOR” mode with CONSULT-II.
5. If 1st trip DTC is detected, go to EC-1299, "
Diagnostic Proce-
dure" .
WITH GST
Follow the procedure “WITH CONSULT-II” above.
MONITOR ITEM CONDITION SPECIFICATION
BRAKE SW

Ignition switch: ON Brake pedal: Fully released OFF
Brake pedal: Slightly depressed ON
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P1805
1805 Brake switch A brake switch signal is not sent to ECM for
extremely long time while the vehicle is driving.

Harness or connectors
(Stop lamp switch circuit is open or
shorted.)

Stop lamp switch
Engine operating condition in fail-safe mode
ECM controls the electric throttle control actuator by regulating the throttle opening to a small range.
Therefore, acceleration will be poor.
Vehicle condition Driving condition
When engine is idling Normal When accelerating Poor acceleration
SEF058Y
