You’ll f ind many saf ety
recommendations throughout this
section, and throughout this manual.
Therecommendationsonthispage
are the ones we consider to be the
most important.
A seat belt is your best protection in
all types of collisions. Airbags are
designed to supplement seat belts,
not replace them. So even though
your vehicle is equipped with airbags,
make sure you and your passenger
always wear your seat belts, and
wear them properly (see page ).
Since all children are saf est in the
back seat of a vehicle, and your
vehicle does not have a back seat, we
recommend that you do not carry a
child passenger. If an older child must ride in this
vehicle, f ollow all child saf ety
instructions and warnings in this
manual (see pages ).
While airbags can save lives, they
can cause serious or fatal injuries to
occupants who sit too close to them,
or are not properly restrained.
Inf ants, young children, and short
adults are at the greatest risk. Be
sure to f ollow all instructions and
warnings in this manual.
Alcohol and driving don’t mix. Even
one drink can reduce your ability to
respond to changing conditions, and
your reaction time gets worse with
every additional drink. So don’t drink
and drive, and don’t let your f riends
drink and drive, either.Excessive speed is a major f actor in
crash injuries and deaths. Generally,
the higher the speed, the greater the
risk, but serious injuries can also
occur at lower speeds. Never drive
f aster than is saf e f or current
conditions, regardless of the
maximum speed posted.
Having a tire blowout or a
mechanical f ailure can be extremely
hazardous. To reduce the possibility
of such problems, check your tire
pressures and condition f requently,
and perform all regularly scheduled
maintenance (see page ).
14 25 37
127
Important Saf ety Precautions
Always Wear Your Seat Belt
Your Vehicle is Not
Recommended f or Child
PassengersBe Aware of Airbag Hazards
Don’t Drink and DriveControl Your Speed
K eep Your Vehicle in Saf e
Condition
Due t o t he passenger’s airbag hazard,
you should never carry an inf ant in arear-f acing child seat in t his vehicle.
8

For saf ety, you should check the
condition of your seat belts regularly.
Honda provides a lif etime warranty
on seat belts f or U.S. models. See
your
booklet f or details.
The tensioners are designed to
activate primarily in f rontal collisions,
andtheyshouldactivateinany
collision severe enough to cause
airbag inflation.
However, the tensioners can be
activated during a collision in which
the f ront airbags do not deploy. In
this case, the airbags would not be
needed, but the additional restraint
could be helpf ul.
When the tensioners are activated,
the seat belts will remain tight until
they are unbuckled in the normal
manner.
For added protection, the seat belts
are equipped with automatic seat
belt tensioners. When activated, the
tensioners immediately tighten the
beltstohelpholdthedriveranda
passenger in place. Pull each belt out f ully and look f or
f rays, cuts, burns, and wear. Check
that the latches work smoothly and
the belts retract easily. Any belt that
is not in good condition or not
working properly will not provide
good protection and should be
replaced as soon as possible.
If a seat belt is worn during a crash,
it must be replaced by your dealer. A
belt that has been worn during a
crash may not provide the same level
of protection in a subsequent crash.
Honda Warranty Inf ormation
CONT INUED
Additional Inf ormation About Your Seat Belts
Seat Belt Maintenance
A utomatic Seat Belt T ensioners
Driver and Passenger Saf ety
19

Your vehicle’s exhaust contains
carbon monoxide gas. You should
have no problem with carbon
monoxide entering the vehicle in
normal driving if you maintain your
vehicle properly.With the hatch open, airflow can pull
exhaust gas into your vehicle’s
interior and create a hazardous
condition. If you must drive with the
hatch open, open all the windows,
and set the heating/climate control
system as shown below.
If you must sit in your parked vehicle,
even in an unconf ined area, with the
engine running, adjust the heating/
climate control system as f ollows:
Select the f resh air mode.
Select the mode.
Turn the f an on high speed.
Set the temperature control to a
comfortable setting.
High levels of carbon monoxide can
collect rapidly in enclosed areas,
such as a garage. Do not run the
engine with the garage door closed.
Even with the door open, run the
engine only long enough to move the
vehicle out of the garage.
The vehicle is raised f or an oil
change.
You notice a change in the sound
of the exhaust.
The vehicle was in an accident
that may have damaged the
underside.
Have the exhaust system inspected
f or leaks whenever:
1.
2.
3.
4.
Carbon Monoxide Hazard
38
Carbon monoxide gas is toxic.
Breathing it can cause
unconsciousness and even kill
you.
Avoid any enclosed areas or
activities that expose you to
carbon monoxide.

Î
ÎThe heating and air conditioning
systems in your vehicle provide a
comf ortable driving environment in
all weather conditions.
The standard audio system has
many f eatures. This section de-
scribes those f eatures and how to
use them.
Your vehicle has an anti-theft audio
system that requires a code number
to enable it. ...............
Vents, Heating, and A/C . 74
..............................
ECON Button .75
.
To Cool or Heat Automatically . 78
............................
Playing the Radio .80
..............................
Radio Reception .83
....................................
Playing a CD .85
.....................................
CD Changer .87
......................
Protecting Your CDs .87
...........
CD Player Error Messages . 88
.......
CD Changer Error Messages . 89
...................
Radio Thef t Protection . 90
............................
Setting the Clock .91
Air conditioning is standard on
vehicles with automatic transmission
(CVT) and standard on most manual
transmissions.
Features
Features
73

On vehicles with automatic
transmission (CVT), see page f or
Automatic Climate Control and
Manual Operations inf ormation.
You can manually select the f an
speed by pressing the f an control
button ( / or ). The
fanspeedisshownbybarsinthe
display.
Turning this dial clockwise increases
the temperature of the airflow.Switch to recirculation mode when
driving through dusty or smoky
conditions, then return to fresh air
mode.
This button turns the rear window
def ogger of f and on (see page ).
Press the mode control button to
select the vents the air flows from.
Some air will f low f rom the
dashboard corner vents in all modes.
Air flows from the center
and corner vents in the dashboard. ThesystemshouldbeleftinFresh
Air mode under almost all conditions.
Keeping the system in Recirculation
mode, can cause the windows to f og
up.
If the A/C is on when this button is
pressed, the auto idle stop works
only if the outside temperature is
above 41°F (5°C). If thecoolingprovidedinECON
mode is not adequate, press the Auto
button (see page ).
When the recirculation indicator is
on, air f rom the vehicle’s interior is
sent throughout the system again.
When the indicator is off, air is
brought in f rom the outside of the
vehicle (fresh air mode).
The outside air intakes f or the
heating and cooling system are at
the base of the windshield. Keep this
area clear of leaves and other debris.
78
58
78
CONT INUED
Vents, Heating, and A/C
Fan Control
T emperature Control Dial
Rear Window Def ogger Button
ECON Button Mode Control Button
Recirculation Button
Features
75

The f low-through ventilation system
draws in outside air, circulates it
through the interior, then exhausts it
through vents near the rear window.
On vehicles with automatic
transmission (CVT), make sure the
display shows A/C OFF.
The heater uses engine coolant to
warm the air. If the engine is cold, it
will be several minutes bef ore you
f eel warm air coming through the
system.Select and Fresh Air mode.
Set the f an to the desired speed.
Adjust the warmth of the air with
the temperature control dial.
Airf low is divided between
the vents in the dashboard and the
f loor vents.
Airf low is divided between
the f loor vents and the def roster
vents at the base of the windshield.
Air f lows f rom the def roster
vents at the base of the windshield.
When mode is selected, the
auto idle stop f unction will not
activate. you can
cool it down more rapidly by partially
opening the windows, turning on the
AUTO, and setting the fan to
maximum speed in Fresh Air mode. Air conditioning places an extra load
on the engine. Watch the engine
coolant temperature gauge (see page ). If it moves near the red zone,
turn of f the A/C until the gauge
reads normally.
Air f lows f rom the f loor
vents. Set the temperature to the lower
limit.
Select and Fresh Air mode.
Set the f an to the desired speed.
When you select or ,
the system automatically switches to
Fresh Air mode and turns on the
A/C (on climate control model only). Turn on the ECON mode by
pressing the ECON button. The
display shows A/C ON. Press the
ECON button again to turn the
ECON mode off.
Make sure the temperature is set
to maximum cool.
Select .
If the outside air is humid, select
Recirculation mode. If the outside
air is dry, select Fresh Air mode.
Set the f an to the desired speed.
1.
2.
3. 1.
2.
3. 49
1.
2.
3.
4.
5.
If the interior is very warm,
On vehicles with automatic
transmission (CVT)
Vents, Heating, and A/C
Ventilation
Using the Heater Using the A /C in ECON Mode
76

Air conditioning, as it cools, removes
moisture from the air. When used in
combination with the heater, it
makes the interior warm and dry.
This setting is suitable f or all driving
conditions whenever the outside
temperature is above 32°F (0°C).Select . The system
automatically switches to Fresh
Air mode. On vehicles with
climate control, the system also
turns on the A/C. The A/C
indicator will not come on, if it was
off to start with.
Select .
Set the f an and temperature
controls to the maximum level.
For your saf ety, make sure you have
a clear view through all the windows
bef ore driving.
To remove f og f rom the inside of the
windows:
Set the f an to the desired speed.
Select , the system
automatically switches to Fresh
Air mode. On vehicles with
climate control, the system also
turns on the A/C. The A/C indicator will not come on, if it was
off to start with.
Adjust the temperature control
dial so the airflow feels warm.
Select to help clear the
rear window.
When mode is selected, the
auto idle stop f unction will not
activate.
When you switch to another mode
f rom , the A/C stays on.
Press the ECON button to turn it of f .
When you turn of f by
pressing the button again, the
system returns to its former settings.
Turn the fan on.
Turn on the air conditioning.
Select and Fresh Air mode.
Adjust the temperature control
dial to your pref erence.
To clear the windows f aster, you can
close the dashboard corner vents by
rotating the wheel next to them. This
will send more warm air to the
windshield def roster vents. Once the
windshield is clear, select the Fresh
Air mode to avoid f ogging the
windows.
1.
2.
3.
4.
1.
2.
3.
1.
2. 3.
4.
On vehicles with climate control
Vents, Heating, and A/C
T o Remove Exterior Frost or Ice
From the Windows
T o Def og and Def rost To Dehumidif y the Interior
Features
77

The Automatic Climate Control
system can adjust the f an speed and
airflow levels to maintain the interior
temperature you select.Press the Auto button.
Set the desired temperature by
turning the Temperature Control
dial. You will see AUTO in the
system’s display.
When the system is in f ully
automatic mode, the auto idle stop
f unction will not be activated.
The system automatically selects the
proper mix of conditioned and/or
heated air to raise or lower the
interior temperature to the
temperature you selected. If you set the temperature to its
lower limit or its highest limit, the
system runs at f ull cooling or heating
only. It does not regulate the interior
temperature.
In cold weather, the fan will not
come on automatically until the
heater starts to develop warm air.
You can manually select various
functions of the automatic climate
controlsystemwhenitisinAUTO.
All other f eatures remain
automatically controlled.
Making any manual selection causes
thewordAUTOinthedisplaytogo
out.
To shut of f the system completely,
turn off the fan and turn the
temperature control dial all the way
to the left.
If you press OFF, the Climate
Control system shuts of f completely.
Keep the system completely of f
f or short periods only.
To keep stale air and mustiness
f rom collecting, you should have
the f an running at all times.
1.
2.
On vehicles with manual transmission
On vehicles with automatic
transmission (CVT)
On vehicles with automatictransmission (CVT) On vehicles with automatictransmission (CVT) On vehicles with automatic
transmission (CVT)
Vents, Heating, and A/C
T o Cool or Heat A utomatically
Using A utomatic Climate Control
Manual OperationTo Turn Everything Of f
78
