2005 DODGE VIPER engine

Crankcase Emission Control System
Proper operation of this system depends on freedom
from plugging due to deposits. As vehicle mileage builds
up, the Crankcase Ventilation Valve orifice may accumu-
late deposits. If a valve is not working properly, replace it
with a new orifice. DO NOT ATTEMPT TO CLEAN THE
OLD ORIFICE!
Check the ventilation hose for indication of damage or
plugging deposits. Replace if necessary.
Air Cleaner Filter
Under normal driving conditions, replace the air filter at
the intervals shown on“Maintenance Schedule A”. If,
however, you drive the vehicle frequently under dusty or
severe conditions, the filter element should be inspected
periodically and replaced if necessary at the intervals
shown in“Maintenance Schedule B”.
WARNING!
The air cleaner can provide protection if the engine
backfires. Do not remove the air cleaner unless such
removal is necessary for repair or maintenance.
Make sure that no one is near the engine compart-
ment before starting the vehicle with the air cleaner
removed. Failure to do so can result in serious
personal injury.
Maintenance-Free Battery
The top of the MAINTENANCE-FREE battery is perma-
nently sealed. You will never have to add water, nor is
periodic maintenance required.
The battery is in a compartment inside the trunk on the
left side.
MAINTAINING YOUR VEHICLE 171
7

CAUTION!
It is essential when replacing the cables on the
battery that you attach the positive cable to the
positive post and the negative cable to the negative
post. Battery posts are marked positive (+) and
negative (-) and identified on the battery case. Cable
clamps should be tight on the terminal posts and
free of corrosion. Apply grease to post and clamps
after tightening. If using a“fast charger”while the
battery is in the vehicle, disconnect both vehicle
battery cables before connecting the charger to bat-
tery. Do not use a“fast charger”to provide starting
voltage.
Battery Save Feature
The Battery Save feature conserves battery power when
storing the vehicle up to 3 months without losing radio
and engine controller memory. This is an alternative to
disconnecting the battery.
NOTE:This vehicle is designed to sit in storage for up
to 30 days on a fully charged battery. If this vehicle is to
be stored for longer than 30 days the following is
recommended:
1. Disconnect the battery
2. Use the battery charger
3. Put the vehicle into Battery Save mode (3 month
charge).
174 MAINTAINING YOUR VEHICLE

NOTE:The exterior and interior lighting functions will
not work when the vehicle is in Battery Save Mode.
Exit Battery Save Mode by doing the following:
1. Press the driver’s door exterior handle to wake up the
vehicle.
2. If the door does not open (vehicle is armed) press the
remote keyless entry unlock button to unlock the vehicle.
3. Press the driver’s door exterior handle again to open
the door.
4. Cycle the Ignition to ON/RUN. If the ignition is NOT
cycled to ON/RUN, then the vehicle will re-enter Battery
Save Mode 45 seconds after the driver’s door is closed.Air Conditioner
Check the air conditioning system operation at the start
of the warm weather season.
NOTE:If air conditioning operation seems to be lower
than expected, check the front of the A/C condenser,
located in front of the radiator for dirt or insect accumu-
lation. Clean with a gentle water spray as required. Front
end fascia protectors may reduce air flow to the con-
denser and radiator, reducing A/C and engine cooling
performance.
176 MAINTAINING YOUR VEHICLE

Power Steering (Pump and Reservoir)
WARNING!
Fluid level should be checked with the engine off to
prevent injury from moving parts. Do not overfill.
Use only the manufacturer’s recommended fluid.
Refer to Recommended Fluids, Lubricants and
Genuine Parts for correct fluid type.
Check power steering fluid level at intervals as specified
in the maintenance schedules.
During scheduled maintenance, check the power steering
fluid level at the power steering fluid reservoir.The fluid should be checked HOT with the engine OFF.
Before removing the reservoir cap, wipe the outside of
the cap and reservoir so that no dirt can fall into the
reservoir.
Power Steering Fluid Reservoir
178 MAINTAINING YOUR VEHICLE

•Rubber bushings
•Starter bearing
•Throttle control cable
•Water pump bearings
Windshield Washers
The fluid reservoir in the right side engine compartment
should be checked for fluid level at regular intervals. Fill
the reservoir with windshield antifreeze (not radiator
antifreeze).
Exhaust System
The best protection against carbon monoxide entry into
the vehicle body is a properly maintained engine exhaust
system.
If you notice a change in the sound of the exhaust system;
or if exhaust fumes can be detected inside the vehicle; or
when the underside or side of the vehicle is damaged;have a competent mechanic inspect the complete exhaust
system and adjacent body areas for broken, damaged,
deteriorated, or mispositioned parts. Open seams or
loose connections could permit exhaust fumes to seep
into the passenger compartment. In addition, inspect the
exhaust system each time the vehicle is raised for lubri-
cation or oil change. Replace as required.
WARNING!
Exhaust gases can injure or kill. They contain carbon
monoxide which is colorless and odorless. Breathing
it can make you unconscious and can eventually
poison you.
182 MAINTAINING YOUR VEHICLE

Cooling System
Inspection
WARNING!
You or others can be badly burned by hot coolant or
steam from your radiator. If you see or hear steam
coming from under the hood, don’t open the hood
until the radiator has had time to cool. Never try to
open a cooling system pressure cap when the radia-
tor is hot.
Coolant Checks
Check engine coolant (antifreeze) protection every 12
months (before the onset of freezing weather, where
applicable). If coolant is dirty or rusty in appearance, the
system should be drained, flushed and refilled with fresh
coolant. Check the front of the radiator for any accumu-
lation of bugs, leaves, etc.
Check the coolant bottle tubing for condition and tight-
ness of connection at reserve tank and radiator. Inspect
the entire system for leaks.
NOTE:Check the front of the radiator for debris (leaves,
paper, etc.) regularly. A build up of such material could
lead to engine overheating.
Do not remove the cooling system pressure cap when the
cooling system is hot.
MAINTAINING YOUR VEHICLE 183
7

Cooling System—Drain, Flush and Refill
The cooling system should be drained, flushed and
refilled at the intervals shown on the Maintenance Sched-
ules.
If the solution is dirty and contains a considerable
amount of sediment, clean and flush with a reliable
cooling system cleaner. Follow with a thorough rinsing to
remove all deposits and chemicals. Discard old antifreeze
solution according to recommended procedure.
Selection Of Coolant
Use only the manufacturer’s recommended coolant. Re-
fer to the Recommended Fluids, Lubricants and Genuine
Parts section for the correct coolant type.
CAUTION!
•Mixing of coolants other than specified engine
coolant, may result in engine damage, and de-
crease corrosion protection. If a non-HOAT cool-
ant is introduced into the cooling system in an
emergency, it should be replaced with the speci-
fied coolant as soon as possible.
•Do not use plain water alone or alcohol base
antifreeze products. Do not use additional rust
inhibitors or antirust products, as they may not be
compatible with the radiator coolant and may
plug the radiator.
•This vehicle has not been designed for use with
Propylene Glycol based coolants. Use of Propy-
lene Glycol based coolants is not recommended.
184 MAINTAINING YOUR VEHICLE

Adding Coolant
When adding coolant, or refilling the system, a minimum
solution of 50% recommended HOAT ethylene glycol
engine coolant (antifreeze) and distilled water should be
used. Use higher concentrations (not to exceed 70%) if
temperatures below
34°F(
37°C) are anticipated.
Use only high purity water such as distilled or deionized
water when mixing the water / antifreeze solution. The
use of lower quality water will reduce the amount of
corrosion protection in the engine cooling system.
NOTE:It is the owner’s responsibility to maintain the
proper level of protection against freezing according to
the temperatures occurring in the area where the vehicle
is operated.WARNING!
Never add coolant to the radiator when the engine is
overheated. Do not loosen or remove pressure cap to
cool overheated engine. The coolant is under pres-
sure and severe scalding could result.
Cooling System Pressure Cap
The cap must be fully tightened to prevent loss of
coolant, and to insure that coolant will return to the
radiator from the coolant reserve tank.
The pressure cap should be inspected and cleaned if there
is any accumulation of foreign material on the sealing
surfaces.
MAINTAINING YOUR VEHICLE 185
