2005 DODGE VIPER jump start

WARNING!
Do not attempt to push or tow your vehicle to get it
started. Unburned fuel could enter the catalytic
converter and once the engine has started, ignite and
damage the converter and vehicle. If the vehicle has
a discharged battery, booster cables may be used to
obtain a start from a booster battery or the battery in
another vehicle. This type of start can be dangerous
if done improperly, so follow this procedure care-
fully. See section 6 of this manual for jump starting
instructions.
If the engine fails to start after you have followed the
“NORMAL STARTING”procedure, it may be flooded.
Push the accelerator pedal all the way to the floor and
hold it there while cranking the engine. This should clear
any excess fuel in case the engine is flooded.NOTE:To prevent damage to the starter, do not crank
the engine for more than 15 seconds at a time. Wait 10 to
15 seconds before trying again.
If the engine has been flooded, it may start to run, but not
have enough power to continue running when the start
button is released. If this occurs, continue cranking with
the accelerator pedal pushed all the way to the floor.
Release the accelerator pedal and the start button once
the engine is running smoothly.
If the engine shows no sign of starting after two 15
second periods of cranking with the accelerator pedal
held to the floor, the“NORMAL STARTING”procedure
should be repeated.
STARTING AND OPERATING 113
5

WHAT TO DO IN EMERGENCIES
CONTENTS

Hazard Warning Flasher..................148

If Your Engine Overheats.................148

Jump-Starting Procedures.................150

Driving On Slippery Surfaces..............154▫Traction............................154

Freeing A Stuck Vehicle..................155

Towing A Disabled Vehicle................155
6

JUMP-STARTING PROCEDURES
WARNING!
•Do not attempt to push or tow your vehicle to get
it started. Unburned fuel could enter the catalytic
converter and once the engine has started, ignite
and damage the converter and vehicle. If the
vehicle has a discharged battery, booster cables
may be used to obtain a start from a booster
battery or the battery in another vehicle. This type
of start can be dangerous if done improperly, so
follow this procedure carefully.
•Take care to avoid the radiator cooling fan and
accessory drive whenever the hood is raised. You
can be hurt by the moving components.
WARNING!
•Battery fluid is a corrosive acid solution; do not
allow battery fluid to contact eyes, skin or cloth-
ing. Don’t lean over battery when attaching
clamps or allow the clamps to touch each other. If
acid splashes in eyes or on skin, flush contami-
nated area immediately with large quantities of
water.
•A battery generates hydrogen gas that is flam-
mable and explosive. Keep flame or spark away
from the top of the battery. Do not use a booster
battery or any other booster source with an output
that exceeds 12 volts.
150 WHAT TO DO IN EMERGENCIES

The battery is located under the battery access panel
inside the trunk on the left side. Remote battery terminals
are located in the engine compartment for jump starting.NOTE:Remove the floor portion of the trunk carpet to
gain access to the battery.
1. Wear eye protection and remove any metal jewelry
such as watch bands or bracelets that might make an
inadvertent electrical contact.
2. When boost is provided by a battery in another
vehicle, park that vehicle within booster cable reach but
Battery Location
WHAT TO DO IN EMERGENCIES 151
6

without letting the vehicles touch. Set the parking brake,
place the transmission in neutral and turn the ignition
OFF for both vehicles.
3. Turn off the heater, radio and all unnecessary electrical
loads.
4. If you are jump starting your Viper, connect one end of
a jumper cable to the positive terminal of the booster
battery. Connect the other end of the same cable to the
remote battery positive terminal after removing the plas-
tic cover.
5. If you are jump starting another vehicle, connect one
end of a jumper cable to the remote battery positive
terminal post on the Power Distribution Center. Connect
the other end of the same cable to the positive terminal of
the discharged battery after removing the plastic cover.6. Connect the other cable, first to the negative terminal
of the booster battery and then to the ground (on the ear
of the Thermostat Housing) of your Viper as shown.
Make sure you have a good contact.
7. If you are jump starting another vehicle, connect one
end of a jumper cable to the ground (on the ear of the
Ground Connection
152 WHAT TO DO IN EMERGENCIES

Gas Caution.......................... 173
Jump Starting......................... 150
Keyless Transmitter Replacement............ 19
Bearings.............................. 194
Belt System, Six Point..................... 32
Belts, Drive............................ 168
Belts, Seat.............................. 26
Body Damage.......................... 195
Body Mechanism Lubrication............179,180
Body Mechanisms....................... 181
Boot, Convertible Top...................59,64
B-Pillar Location........................ 126
Brake, Parking.......................... 116
Brake System........................ 117,188
Anti-Lock............................ 117
Fluid Check.......................190,214
Hoses.............................. 189
Master Cylinder....................... 191
Warning Light......................... 91Break-In Recommendations, New Vehicle.....50,121
Bulb Replacement....................... 205
Bulbs, Light.........................204,205
Capacities, Antifreeze (Engine Coolant)........ 212
Capacities, Fluid........................ 212
Capacity, Cargo Weight................... 146
Caps, Filler
Power Steering........................ 178
Radiator (Coolant Pressure)............... 185
Car Washes............................ 197
Carbon Monoxide Warning...............51,145
Cargo Compartment
Capacity............................ 146
Carpeting............................. 196
Catalytic Converter...................... 168
CD Player............................95,98
CD Player Maintenance................... 103
Chains, Tire............................ 140
INDEX 245
10

Defroster, Windshield...................... 51
Delay (Intermittent) Wipers................. 82
Diagnostic System, Onboard................ 161
Dimmer Control......................... 74
Dimmer Switch, Headlight.................. 78
Disposal
Antifreeze (Engine Coolant)............... 186
Door Locks............................. 13
Door Locks, Automatic.................... 15
Doors................................. 13
Drive Belts............................ 168
Driving
On Slippery Surfaces.................... 154
Electric Remote Mirrors.................... 68
Emergency Brake........................ 116
Emergency, In Case of
Freeing Vehicle When Stuck............... 155
Hazard Warning Flasher................. 148Jump Starting......................... 150
Overheating.......................... 148
Towing............................. 155
Emission Control System Maintenance......162,218
Engine............................... 160
Break-In Recommendations................ 50
Checking Oil Level..................... 164
Compartment......................... 160
Coolant (Antifreeze).................183,213
Cooling...........................90,183
Exhaust Gas Caution..................51,145
Fails to Start.......................... 112
Fuel Requirements..................142,212
Oil ...........................164,212,213
Oil Change Interval.................... 165
Oil Disposal.......................... 167
Oil Filter............................ 167
Oil Selection.......................166,212
Overheating........................90,148
INDEX 247
10

Inside Rearview Mirror.................... 67
Instrument Cluster........................ 86
Instrument Panel and Controls............... 85
Instrument Panel Lens Cleaning............. 195
Interior and Instrument Lights..........See Lights
Interior Lighting......................... 74
Interior Lights........................... 74
Intermittent Wipers....................... 82
Introduction............................. 4
Jump Starting.......................... 150
Key-In Reminder......................... 12
Keyless Entry System...................... 15
Keys.................................. 11
Knee Bolster............................ 41
Lap/Shoulder Belts....................... 27
LATCH (Lower Anchors and Tether for CHildren) . 36Latches
Hood.............................71,180
Lead Free Gasoline...................... 142
Light Bulbs............................ 205
Lights...............................52,73
Airbag.............................44,91
Anti-Lock Warning...................... 87
Back-Up............................. 74
Brake Warning......................... 91
Bulb Replacement...................... 204
Daytime Running....................... 76
Dimmer Switch, Headlight..............74,78
Engine Temperature Warning.............. 90
Exterior Check......................... 52
Fog .............................75,77,90
Hazard Warning Flasher...............87,148
Headlight Switch....................... 75
Headlights.........................75,207
High Beam........................... 78
250 INDEX
