2005 DODGE VIPER windshield wipers

▫Multi-Function Control Lever..............74
▫Headlights, Parking Lights, Instrument Panel
Lights, And Front Fog Lights..............75
▫Daytime Running Lights.................76
▫Lights-On Reminder....................76
▫Headlight Time Delay...................76
▫Battery Saver Feature—Exterior Lights......76
▫Fog Lights...........................77
▫Turn Signals..........................77
▫Highbeam/Lowbeam Select Switch..........78▫Flash To Pass.........................78

Tilt Steering Column.....................78

Adjustable Pedals.......................79
▫Adjustable Left Foot Rest.................80

Windshield Wipers And Washers.............81
▫Windshield Washers....................82
▫Mist Function.........................82
▫Intermittent Wiper System................82
54 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

To adjust the left foot rest:
•Loosen the nut on the pedal using a 13 mm socket.
•Slide the pedal fore, aft and/or rotate up or down to
find a comfortable position.
•Retighten the nut, being careful not to overtighten.
WINDSHIELD WIPERS AND WASHERS
The wipers and washers are operated by a switch
in the right control lever. Move the control lever
up to select the desired wiper speed.
Windshield Wiper/Washer Control
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 81
3

Windshield Washers
To use the washer, pull the control lever toward you and
hold while spray is desired. If the lever is pulled while in
the delay range, the wiper will operate in low speed for
two wipe cycles after the lever is released, and then
resume the intermittent interval previously selected.
If the lever is pulled while in the OFF position, the wipers
will operate for two wipe cycles, then turn OFF.
Mist Function
Push down on the wiper control lever to activate a single
wipe to clear the windshield of road mist or spray from
a passing vehicle. The wiper blade will continue to wipe
until you release the stalk.
Intermittent Wiper System
Use the intermittent wiper when weather conditions
make a single wiping cycle with a variable pause be-
tween cycles desirable. Move the lever to the first detent
(DEL) position, then select the delay interval by turning
the end of the stalk. Rotate the end upward to decrease
the delay time and downward to increase it. The delay
can be regulated from one second between cycles to 15
seconds between cycles.
82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Defroster, Windshield...................... 51
Delay (Intermittent) Wipers................. 82
Diagnostic System, Onboard................ 161
Dimmer Control......................... 74
Dimmer Switch, Headlight.................. 78
Disposal
Antifreeze (Engine Coolant)............... 186
Door Locks............................. 13
Door Locks, Automatic.................... 15
Doors................................. 13
Drive Belts............................ 168
Driving
On Slippery Surfaces.................... 154
Electric Remote Mirrors.................... 68
Emergency Brake........................ 116
Emergency, In Case of
Freeing Vehicle When Stuck............... 155
Hazard Warning Flasher................. 148Jump Starting......................... 150
Overheating.......................... 148
Towing............................. 155
Emission Control System Maintenance......162,218
Engine............................... 160
Break-In Recommendations................ 50
Checking Oil Level..................... 164
Compartment......................... 160
Coolant (Antifreeze).................183,213
Cooling...........................90,183
Exhaust Gas Caution..................51,145
Fails to Start.......................... 112
Fuel Requirements..................142,212
Oil ...........................164,212,213
Oil Change Interval.................... 165
Oil Disposal.......................... 167
Oil Filter............................ 167
Oil Selection.......................166,212
Overheating........................90,148
INDEX 247
10

Wind Buffeting.......................... 26
Windows.............................. 24
Power............................... 24
Windshield Defroster...................... 51
Windshield Washers..................81,82,182
Windshield Wipers....................... 81
Wipers, Intermittent....................... 82
Wiring, Ignition......................... 170
INDEX 257
10
