2005 DODGE STRATUS Owners Manual

Operating Tips (Manual A/C Control Only)
UNDERSTANDING YOUR INSTRUMENT PANEL 137
4

Outside Air Intake
Make sure the air intake, directly in front of the wind-
shield, is free of ice, slush, snow or other obstructions
such as leaves. Leaves collected in the air-intake plenum
may reduce air flow and plug the plenum water drains.
Air Intake
138 UNDERSTANDING YOUR INSTRUMENT PANEL

STARTING AND OPERATING
CONTENTS

Starting Procedures....................142
▫Automatic Transaxle...................142
▫Manual Transaxle.....................142
▫Normal Starting......................142
▫Extreme Cold Weather (Below -20°F Or -29°C) . 144
▫If Engine Fails To Start.................144
▫After Starting........................145

Battery And Engine Block Heaters—
If Equipped
..........................145

Automatic Transaxle....................145
▫Brake/Transmission Interlock.............145▫Automatic Transaxle Ignition Interlock
System.............................147
▫Four Speed Automatic Transaxle..........147
▫Reset Mode.........................147
▫Gear Ranges For Four Speed Automatic
Transaxle...........................148

Parking Brake.........................150

Brake System.........................151
▫Anti-Lock Brake System (ABS)—If Equipped . 152

Power Steering........................153

Traction Control—If Equipped...........153

Tire Safety Information..................154
5

▫Tire Markings........................154
▫Tire Identification Number (TIN)..........158
▫Tire Loading And Tire Pressure...........159

Ti re s—General Information...............163
▫Tire Pressure.........................163
▫Tire Inflation Pressures.................164
▫Radial-Ply Tires......................166
▫Compact Spare Tire—If Equipped.........166
▫Limited Use Spare—If Equipped.........167
▫Tire Spinning........................167
▫Tread Wear Indicators..................168
▫Replacement Tires.....................169
▫Alignment And Balance.................170

Tire Chains...........................170

Snow Tires...........................170

Tire Rotation Recommendations...........171

AutoStick—If Equipped................172
▫AutoStick Operation...................172
▫AutoStick General Information............173

Fuel Requirements.....................173
▫Spark Knock.........................173
▫Reformulated Gasoline.................174
▫Gasoline/Oxygenate Blends..............174
▫MMT In Gasoline.....................175
▫Materials Added To Fuel................175
▫Fuel System Cautions..................175
▫Carbon Monoxide Warnings..............176

Adding Fuel..........................176
▫Fuel Filler Cap (Gas Cap)...............176

Vehicle Loading.......................178

Trailer Towing........................178
▫Towing Requirements..................179
140 STARTING AND OPERATING

Flexible Fuel–(2.7L Engines With Automatic
Transmission Only)
.....................180
▫E-85 General Information................180
▫Ethanol Fuel (E-85)....................180
▫Fuel Requirements....................181
▫Selection Of Engine Oil.................181▫Starting............................183
▫Cruising Range.......................183
▫Replacement Parts.....................183
▫Maintenance.........................183
STARTING AND OPERATING 141
5

STARTING PROCEDURES
Before starting your vehicle, adjust your seat, adjust both
inside and outside mirrors, and fasten your seat belts.
CAUTION!
Long periods of engine idling, especially at high
engine speeds can cause excessive exhaust tempera-
tures which can damage your vehicle. Do not leave
your vehicle unattended with the engine running.
WARNING!
Do not leave children or animals inside parked
vehicles in hot weather. Interior heat build up may
cause serious injury or death.
Automatic Transaxle
The gear selector must be in the NEUTRAL or PARK
position before you can start the engine. Apply the brakes
before shifting to any driving gear.
Manual Transaxle
Fully apply the parking brake, press the clutch pedal to
the floor and place the gear selector in NEUTRAL before
starting the engine.
Normal Starting
Normal Starting of either a cold or a warm engine does
not require pumping or depressing the accelerator pedal.
Simply turn the key to the“START’”position and release
when the engine starts. If the engine has not started
within 3 seconds, slightly depress the accelerator pedal
while continuing to crank. If the engine fails to start
within 15 seconds, turn the key to the“OFF”position,
wait 10 to 15 seconds, then repeat the normal starting
procedure.
142 STARTING AND OPERATING

WARNING!
Never pour fuel or other flammable liquid into the
throttle body air inlet opening in an attempt to start
the vehicle. This could result in flash fire causing
serious personal injury.
CAUTION!
Do not attempt to push or tow your vehicle to get it
started. Vehicles equipped with an automatic trans-
axle cannot be started this way. Unburned fuel could
enter the catalytic converter and once the engine has
started, ignite and damage the converter and vehicle.
If the vehicle has a discharged battery, booster cables
may be used to obtain a start from another vehicle.
This type of start can be dangerous if done improp-
erly, so follow the procedure carefully. See section 6
of this manual for jump starting instructions.
Ignition Key Positions
STARTING AND OPERATING 143
5

Extreme Cold Weather (below -20°For-29°C)
To insure reliable starting at these temperatures, use of an
externally powered electric engine block heater and
battery blanket heater package (available from your
dealer) is recommended.
If Engine Fails to Start
If the engine fails to start after you have followed the
“NORMAL STARTING”or“EXTREME COLD
WEATHER”procedures, it may be flooded. Push the
accelerator pedal all the way to the floor and hold it there
while cranking the engine. This should clear any excess
fuel in case the engine is flooded.
CAUTION!
To prevent damage to the starter, do not crank the
engine for more than 15 seconds at a time. Wait 10 to
15 seconds before trying again.
If the engine has been flooded, it may start to run, but not
have enough power to continue running when the key is
released. If this occurs, continue cranking with the accel-
erator pedal pushed all the way to the floor. Release the
accelerator pedal and the key once the engine is running
smoothly.
If the engine shows no sign of starting after two 15
second periods of cranking with the accelerator pedal
held to the floor, the“NORMAL STARTING”or“EX-
TREME COLD WEATHER”procedure should be re-
peated.
144 STARTING AND OPERATING
