To replace the oil filter
The oil filter should be replaced at the time or mileage
specified on the scheduled maintenance chart.
You should be sure that any replacement filter used on
this vehicle is a high quality filter. The manufacturer 's
specifications for Genuine DaimlerChrysler oil filters
require that the filter be capable of withstanding a
pressure of 256 psi (1.8MPa). A Genuine DaimlerChrysler
oil filter is recommended as a replacement filter.
Follow the installation instructions printed on the filter.
Engine oil identification mark
Use only engine oils displaying the ILSAC certification
symbol on the front of the container.
M03A0150
ILSAC certification mark
(ªStarburstº symbol)
320 MAINTENANCE
CAPACITIES
Item Capacity Recommended Lubricants
Fuel (approximate) 62dm3(16.3 gal) Ð
Engine oil Oil pan 4dm3(4.2 qt) Engine oils displaying
ILSAC certification symbol
or conforming to the API
classification SL, SL/CF Oil filter 0.3dm
3(0.32 qt)
Power steering 1.2dm
3(1.3 qt) Diamond ATF
Automatic transaxle 4 Cyl.: 7.7dm3(8.2 qt)
6 Cyl.: 8.4dm3(8.9 qt)Diamond ATF SPIII
Manual transaxle 4 Cyl.: 2.2dm3(2.3 qt)
6 Cyl.: 2.8dm3(3.0 qt)Gear oil API classification
GL-4 SAE 75W-85W or
75W-90
Brakes and clutch As required Conforming to Brake fluid
DOT3 or DOT4
Transaxle linkage, Parking brake cable mechanism, hood
lock and hook, door latches, seat adjustersAs required Multipurpose grease NLGI
Grade 2
Engine coolant 4 Cyl.-M/T: *8.0L (8.5 qt)
-A/T: *7.9L (8.3 qt)
6 Cyl.-M/T: *9.2L (9.7 qt)
-A/T: *9.1L (9.6 qt)Long Life Antifreeze Coolant
or an equivalent
Refrigerant (air conditioning) 425g (15 oz) HFC-134a
Windshield washers 4 L (4.2 qt) Ð
*: Include 0.65 L (.69 qt.) in reserve tank.
378 SPECIFICATIONS
