2005 DODGE STRATUS COUPE rear view mirror

Interior
1. Seat belt!p. 68
Adjustable seat belt shoulder anchor (for front
seats)!p. 732. Remote trunk lid release!p. 37
3. Power window switch!p. 44
4. Window lock switch!p. 45
5. Electric remote-controlled outside mirror
switch!p. 190
6. Power door lock switch!p. 34
7. Sun visor!p. 211
8. Sunroof switch (for vehicles with sunroof)!p. 46
Dome light (for vehicles without sunroof)!p. 131
9. Inside day/night rearview mirror!p. 179
Electrochromic inside rearview mirror (if so equipped)
!p. 180
Dome light (for vehicles with sunroof)
10. Vanity mirror!p. 212
11. Glove compartment!p. 216
12. Cup holder (for rear seat)!p. 214
13. Rear seat!p. 66
14. Center console with lid!p. 217
15. Supplemental restraint system-side air bag!p. 89
(for front seats, if so equipped)
16. Cup holder (for front seats)!p. 214
17. Front seat!p. 57
18. Ash receptacle receiver.
INTRODUCTION 7
1

Outside
1. Engine compartment!p. 259
Engine hood!p. 422. Windshield wiper and washer!p. 128
3. Sunroof (if so equipped)!p. 46
4. Outside rear-view mirrors!p. 190
5. Whip antenna!p. 221
6. Front turn signal lights and parking lights
!p. 122, 297
7. Fog lights (if so equipped)!p. 122
8. Headlights!p. 122, 295
9. Front side marker lights!p. 300
10. Tire inflation pressure!p. 340
Changing tires!p. 270
Tire rotation!p. 347
Tire chains!p. 348
Wheel covers (if so equipped)!p. 268
11. Locking and unlocking!p. 26
Keyless entry system (if so equipped)!p. 29
12. High-mounted stop lights!p. 302
13. Trunk lid!p. 35
14. License plate lights!p. 303
15. Back up lights!p. 294
16. Stop and tail lights!p. 294
17. Rear turn signal and tail lights!p. 294
18. Rear side-marker lights!p. 294
19. Fuel filler!p. 39
8 INTRODUCTION

REAR PERSONAL LIGHTS
ON - The light illuminates
OFF - The light illuminates when a door is opened and
goes out when it is closed.
HORN SWITCH
Pressing on or around themark on the steering wheel,
causes the horn to honk.
GARAGE DOOR OPENER (IF SO EQUIPPED)
The HomeLinkyUniversal Transceiver replaces up to
three remote controls that operate devices such as garage
door openers, motorized gates, or home lighting. It
triggers these devices at the push of a button, located on
your Electrochromic inside rearview mirror (if so
E19A1270E23A0020T
134 INSTRUMENTS AND CONTROLS

NGear positions........................158
NDriving speed
(Vehicles with automatic transaxle).........159
NHolding on an upgrade.................159
NTransaxle reset mode...................160
mAutomatic transaxle Autostick
(if so equipped)
........................160
NSelector lever operation.................161
NIndicator lights.......................163
NSelector positions (Main gate).............164
NSelector positions Manual gate Autostick.....165
NHolding on an upgrade.................167
NTransaxle reset mode...................168
mManual transaxle (if so equipped)..........168
NTo start.............................169
NProper shift points.....................169NRecommended downshifting speed.........171
NDriving precautions....................171
mParking brake.........................171
mBrake pedal...........................173
mPower brakes.........................174
mBrake pad wear alarm...................174
mAnti-lock braking (ABS) system
(if so equipped)
........................175
NGeneral driving hints
(standard/anti-lock brakes)...............175
mSteering wheel tilt lock lever..............177
mPower steering........................178
mInside Day/Night rearview mirrors.........179
NElectrochromic inside rearview mirror
(if so equipped.......................180
NElectrochromic mirror operation
(if so equipped).......................181
144 STARTING AND DRIVING

INSIDE DAY/NIGHT REARVIEW MIRRORS
WARNING!
²Do not attempt to adjust the rearview mirrors
while driving. This can be dangerous.
²Your passenger's side mirror is convex. The ob-
jects you see in the mirror will look smaller and
farther away than they actually are. Do not use
this mirror to estimate the distance of following
vehicles when changing lanes.
Adjust the inside mirror to maximize the view through
the rear window. Make this adjustment while the day/
night knob (A) is in the daytime position (1). To reduce
glare from other vehicle's headlights, switch the lever to
the night position (2).
I08A0620
STARTING AND DRIVING 179
5

Electrochromic inside rearview mirror (if so
equipped)
When the ignition key is in the ªACCº or ªONº position,
the green indicator (A) should be illuminated. If not,
press the display switch (C) for more than 6 seconds, less
than 9 seconds, until the indicator illuminates. Now the
mirror automatically dims to the proper level to mini-
mize glare from lights behind you after dark.
I08A0630I08A0640
180 STARTING AND DRIVING

If the ªCALº is not displayed, but compass calibration is
required, press and hold the display switch for 12 sec-
onds, or until ªCALº is displayed. With ªCALº dis-
played, drive the vehicle in a circle at less than 5mph
(8km/h) or less until the ªCALº goes off.
Cleaning of the mirror
When cleaning the mirror, use a paper towel or similar
material dampened with glass cleaner. Do not spray glass
cleaner directly on the mirror as that may cause the liquid
cleaner to enter the mirror housing.
Electric remote-controlled outside mirrors
The outside rearview mirrors can be adjusted when the
ignition key is in the ªONº or ªACCº position.
Place the lever (A) to the same side as the mirror whose
adjustment is desired:
L - Left outside mirror adjustment
R - Right outside mirror adjustment
I08B2160
190 STARTING AND DRIVING

Headlight flasher (high/low beam)........ 123
Switch............................. 122
Heater............................... 238
High beam indicator..................109,114
High-mounted stoplights
Bulb capacity........................ 293
Homelink Transmitter................... 134
Horn switch........................... 134
Ignition switch......................... 151
Indicator and warning light............... 109
Inside day/night rearview mirrors.......... 179
Instrument cluster...................... 108
Instrument panel light dimmer control....... 127
Intermittent Wipers..................... 129
Jack
Jacking points........................ 270
Jacking up the car..................... 270
Storage............................. 266
Key reminder chime..................... 152
Keyless entry system..................... 29Keys..............................23,152
Labeling............................. 372
Lap Belts.............................. 87
Lights
Bulb chart........................... 293
Dome light/Reading light............... 131
Headlights.......................... 122
Reading lamps....................... 133
Low-fuel warning light................109,115
Luggage hooks......................... 217
Malfunction Indicator Light............... 314
Manual, Service........................ 385
Manual transaxle
Oil ................................ 331
Possible driving speed................. 171
Shift points (recommended speed)........ 169
Meters............................... 108
Mirrors
Vanity mirror........................ 213
Mopar Parts........................315,383
INDEX 393
