2005 DODGE RAM 2500 DIESEL check transmission fluid

reserve fuel capacity, which corresponds to approxi-
mately 8% of tank volume. This reserve capacity was put
in place to prevent the likelihood of customers running
out of fuel when operating at maximum load conditions
in areas where there aren’t many gas stations. (See page
130 for more information.)
Ram fuel tank volumes are as follows:
•34 gallons - 2500/3500 short box models
•35 gallons - 2500/3500 long box models
28. Transmission Oil Temperature Warning Light
(Automatic Transmissions Only)
This light indicates that there is excessive trans-
mission fluid temperature that might occur
with severe usage such as trailer towing. It may
also occur when operating the vehicle in a high
torque converter slip condition, such as 4-wheel-drive
operation (e.g. snow plowing, off- road operation). If thislight comes on, stop the vehicle and run the engine at idle
or faster, with the transmission in NEUTRAL until the
light goes off.
29. Check Gages
This light illuminates when the Voltmeter, Engine
Oil Pressure or Engine Coolant Temperature
gages indicate a reading either too high or too low.
Examine the gages carefully, and follow the instructions
above for each indicated problem.
NOTE:When the ignition switch is turned to OFF, the
Fuel Gage, Voltmeter, Oil Pressure and Engine Coolant
Temperature gages may not show accurate readings.
When the engine is not running, turn the ignition switch
to ON to obtain accurate readings.
UNDERSTANDING YOUR INSTRUMENT PANEL 169
4

Transfer Case — If Equipped
Fluid Level Check
This fluid level can be checked by removing the filler
plug. The fluid level should be to the bottom edge of the
filler plug hole with the vehicle in a level position.
Lubricant Selection
Refer to Recommended Fluids, Lubricants and Genuine
Parts for the correct lubricant type.
Manual Transmission — If Equipped
Fluid Level Check
This fluid level can be checked by removing the filler
plug. If the level of the lubricant is more than 1/4” below
the bottom of the filler hole while the vehicle is on level
ground, enough lubricant should be added to bring the
level to the bottom of the filler hole.
Lubricant Selection for 6-Speed Manual
Transmission — If Equipped
If it becomes necessary to add fluid or change the fluid,
be sure to use the same lubricant or equivalent. Refer to
Recommended Fluids, Lubricants and Genuine Parts for
the correct lubricant type.
Automatic Transmission
Fluid Level Check
The fluid level should be checked when the engine is
fully warmed up and the fluid in the transmission is at
normal operating temperature. Operation of the trans-
mission with an improper fluid level will greatly reduce
the life of the transmission and of the fluid. Check the
fluid level whenever the vehicle is serviced.
370 MAINTAINING YOUR VEHICLE

Procedure For Checking Fluid Level
To properly check the automatic transmission fluid level,
the following procedure must be used:
1. The vehicle must be on level ground.
2. The engine should be running at curb idle speed for a
minimum of 60 seconds.
3. Fully apply parking brake.
4. Place the gear selector briefly in each gear position
ending with the lever in N (Neutral).
5. Remove the dipstick and determine if the fluid is hot
or warm. Hot fluid is approximately 180°F (82°C) which
is the normal operating temperature after the vehicle has
been driven at least 15 miles. The fluid can not be
comfortably held between the finger tips. Warm is when
fluid is between 85° - 125°F (29° - 52°C).6. Wipe the dipstick clean and reinsert until seated.
Remove dipstick and note reading.
a. If the fluid is hot, the reading should be in the
crosshatched area marked “OK”.
b. If the fluid is warm, the reading should be between
the two holes. If the fluid level indicates low, add
sufficient fluid to bring to the proper level.
Fluid is added through the dipstick tube.
NOTE:To prevent dirt and water from entering the
transmission after checking or replenishing fluid, make
certain that the dipstick cap is properly seated.
Selection Of Lubricant
Refer to Recommended Fluids, Lubricants and Genuine
Parts for the correct lubricant type. It is important that the
transmission fluid be maintained at the prescribed level
using the recommended fluid.
MAINTAINING YOUR VEHICLE 371
7

Once a Month
•Check tire pressure and look for unusual wear or
damage.
•Inspect the batteries and clean and tighten the termi-
nals as required.
•Check the fluid levels of coolant reservoir, brake
master cylinder, and transmission and transfer case (if
equipped), add as needed.
•Check Filter Minder™. Replace air cleaner filter
element if necessary.
•Check all lights and all other electrical items for correct
operation.At Each Oil Change
•Change the engine oil filter.
•Inspect the exhaust system.
•Inspect the brake hoses.
•Inspect the CV joints (if equipped) and front suspen-
sion components.
•Check the automatic transmission fluid level.
•Check the manual transmission fluid level.
•Check the coolant level, hoses, and clamps.
404 MAINTENANCE SCHEDULES
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Miles 22,500 26,250 30,000 33,750 37,500
(Kilometers) (36 000) (42 000) (48 000) (54 000) (60 000)
Change engine oil and engine oil filter. X X X
Lubricate Front Drive Shaft Fitting (2500/3500, 4X4). X X X X X
Rotate tires. X X X
Lubricate outer tie rod ends 2500/3500 (4X4) models only. X X X
Inspect drive belt, replace as required. X
Inspect fan hub.X
Inspect damper.X
Inspect water pump weep hole for blockage. X
Replace fuel filter element. Clean the water in fuel sensor. X
Change rear axle fluid. X
Change front axle fluid (4X4). X
Check transfer case fluid level (4X4). X
Drain and refill automatic transmission fluid. Replace filter
and adjust bands (48RE only).X
SCHEDULE “B” 407
8
M
A
I
N
T
E
N
A
N
C
E
S
C
H
E
D
U
L
E
S

Air Cleaner, Engine (Engine Air Cleaner Filter) . 349,375
Air Conditioner Maintenance............... 355
Air Conditioning Refrigerant.............355,356
Air Conditioning System................207,355
Air Conditioning System, Zone Control........ 211
Air Filter.............................. 349
Air Pressure, Tires....................269,276
Airbag..............................45,51
Airbag Light.........................70,163
Airbag On/Off Switch..................... 51
Airbag, Side............................ 54
Alarm..............................29,166
Alignment and Balance................... 276
Alterations/Modifications, Vehicle............. 8
Antifreeze (Engine Coolant)................ 363
Capacities........................... 397
Anti-Lock Warning Light...............164,259
Anti-Theft System.....................29,166
Appearance Care........................ 379Ashtray............................... 144
Automatic Transmission................... 370
Adding Fluid......................... 371
Fluid and Filter Changes................. 372
Fluid Level Check...................... 370
Fluid Type........................371,399
Shift Indicator........................ 166
Shifting............................. 237
Special Additives...................... 373
Axle Fluid.......................291,369,399
Axle Lubrication.....................291,369
Ball Joints............................. 357
Battery............................... 354
Blanket..........................232,355
Emergency Starting..................... 327
Bearings.............................. 373
Belts, Drive............................ 348
Belts, Seat.............................. 34
432 INDEX

Exterior Lighting........................ 116
Fan .................................. 365
Filters
Engine Oil.....................343,346,398
Flashers
Turn Signal.......................... 118
Flat Tire Stowage.....................317,326
Fluid, Brake........................... 399
Fluid Capacities......................... 397
Fluid Level Checks
Brake............................... 367
Manual Transmission................... 370
Power Steering........................ 356
Transfer Case......................... 370
Fog Lights.......................... 117,396
Fold Flat Load Floor..................... 148
Four Wheel Drive....................... 243
Four-Way Hazard Flasher.................. 314Freeing A Stuck Vehicle................... 331
Front Axle..........................358,369
Fuel..............................281,315
Diesel.........................281,315,398
Gauge.............................. 168
Requirements......................... 281
Specifications......................... 284
Tank Capacity........................ 397
Fuses................................ 383
Garage Door Opener..................... 134
Gauges............................... 169
Coolant Temperature.................... 165
Fuel................................ 168
Oil Pressure.......................... 164
Speedometer......................... 164
Tachometer.......................... 163
Voltmeter............................ 162
Gear Ranges........................... 237
436 INDEX

Low Washer Fluid..................... 168
Passing............................. 119
Seat Belt Reminder..................... 163
Service...........................384,385
Side Marker.......................... 396
Transfer Case......................... 247
Transmission Warning................169,298
Turn Signal.................. 118,163,385,389
Warning (Instrument Cluster Description)..... 162
Limited-Slip Differential................254,369
Loading Vehicle......................... 286
Tires ............................... 264
Locks................................. 16
Child Protection........................ 21
Door................................ 16
Ignition.............................. 14
Keys................................ 11
Power Door........................... 17
Steering Wheel......................... 14Lower Anchors and Tether for CHildren (LATCH) . 60
Lubricants............................. 373
Lubrication, Body....................... 358
Lug Nuts............................. 322
Lumbar Support........................ 109
Maintenance........................... 340
Maintenance Procedures................... 343
Maintenance Schedule.................... 402
ScheduleA......................... 416
Manual, Service......................... 429
Manual Transmission..................241,370
Fluid Level Check...................... 370
Lubricant Selection..................... 399
Mirrors................................ 78
Automatic Dimming..................... 79
Electric Powered....................... 80
Outside.............................. 79
Rearview............................. 78
INDEX 439
