2005 DODGE GRAND CARAVAN turn signal bulb

If either indicator flashes at a rapid rate, check for a
defective outside turn signal light bulb. If one of the
indicators fails to light when the lever is moved, it would
suggest that the indicator light is defective. Turn Signal Warning
If the vehicle electronics sense that the vehicle has
traveled at over 18 mph (29 km/h) for about one mile
with the turn signals on, a chime will sound to alert the
driver.
Headlight Low/High Beam Selector Switch
Pull the multifunction lever toward the steering wheel to
switch the headlights between HIGH and LOW beam.
Passing Light
You can signal another vehicle with your headlights by
lightly pulling the multifunction lever toward the steer-
ing wheel. This will cause the headlights to turn on at
high beam and remain on until the lever is released.
Turn Signal Switch UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139
3

3. Low Fuel Light
When the fuel level reaches approximately 3.0
gallons (11.0 liters) this light will turn on and
remain on until fuel is added.
4. Turn Signal Indicators
The arrow will flash with the exterior turn signal
when the turn signal lever is operated.
If the vehicle electronics sense that the vehicle has
traveled about one mile with the turn signals on, a chime
will sound to alert you to turn the signals off. If either
indicator flashes at a rapid rate, check for a defective
outside light bulb.
5. Liftgate Ajar
This light turns on if the liftgate is not com-
pletely closed. 6. Door Ajar Light
This light turns on if a door is not completely
closed.
7. Speedometer
Indicates vehicle speed.
8. Brake System Warning Light
This light monitors various brake functions,
including brake fluid level and parking brake
application. If the brake light turns on, it may
indicate that the parking brake is applied, there
is a low brake fluid level or there is a problem with the
anit-lock brake system.
The dual brake system provides a reserve braking capac-
ity in the event of a failure to a portion of the hydraulic
system. Failure of either half of the dual brake system is
indicated by the Brake Warning Light which will turn on
when the brake fluid level in the master cylinder has
dropped below a specified level. UNDERSTANDING YOUR INSTRUMENT PANEL 197
4

NOTE: You must apply the brakes before shifting from
Park.
19. Oil Pressure Warning Light
This light shows low engine oil pressure. The light
should turn on momentarily when the engine is
started. If the light turns on while driving, stop the
vehicle and shut off the engine as soon as possible. A
chime will sound for 4 minutes when this light turns on.
Do not operate the vehicle until the cause is corrected.
This light does not show how much oil is in the engine.
The engine oil level must be checked under the hood.
20. High Beam Light
This light shows that the headlights are on high
beam. Pull the turn signal lever towards the
steering wheel to switch the headlights from high or low
beam. 21. Malfunction Indicator Light
This light is part of an onboard diagnostic system
called OBD that monitors engine and automatic
transmission control systems. The light will illu-
minate when the key is in the ON position before engine
start. If the bulb does not come when turning the key
from OFF to ON, have the condition checked promptly.
Certain conditions such as a loose or missing gas cap,
poor fuel quality, etc. may illuminate the light after
engine start. The vehicle should be serviced if the light
stays on through several of your typical driving cycles. In
most situations the vehicle will drive normally and will
not require towing.
The Malfunction Indicator Light flashes to alert to serious
conditions that could lead to immediate loss of power or
severe catalytic converter damage. The vehicle should be
serviced as soon as possible if this occurs.202 UNDERSTANDING YOUR INSTRUMENT PANEL

▫ Steering Shaft Seal ....................391
▫ Steering Linkage ......................391
▫ Drive Shaft Universal Joints ..............391
▫ Body Lubrication .....................391
▫ Windshield Wiper Blades ................392
▫ Windshield And Rear Window Washers .....392
▫ Exhaust System ......................393
▫ Cooling System .......................394
▫ Hoses And Vacuum/Vapor Harnesses .......399
▫ Brakes .............................399
▫ Master Cylinder — ABS Brakes Brake
Fluid Level Check .....................401
▫ Fuel System Hoses ....................402 ▫ Automatic Transmission ................402
▫ Front And Rear Wheel Bearings ...........406
▫ Appearance Care And Protection
From Corrosion ......................406
▫ Cleaning The Instrument Panel And Underseat
Cup Holders ........................410

Integrated Power Module (IPM) ............412

Vehicle Storage ........................415

Replacement Light Bulbs .................415

Bulb Replacement ......................416
▫ Headlights ..........................416
▫ Front Park/Turn Signal And
Sidemarker Lights .....................418
▫ Front Fog Light ......................419372 MAINTAINING YOUR VEHICLE

NOTE: For lighted switches, see your dealer for replace-
ment instructions.
All of the interior bulbs are glass wedge base or glass
cartridge types. Aluminum base bulbs are not approved
and should not be used for replacement.
LIGHT BULBS — Exterior Bulb Number
Back-up, Tail, Stop, Turn Signal, & Sidemarker . . . 3057
Center High-Mounted Stop Light ............. 921
Fog Light — If Equipped .................. 9145
Front Side marker, Park/Turn Signal ........ 3457AK
Headlight ............................. 9007
License ................................ 168 BULB REPLACEMENT
Headlights
1. Remove the three screws securing the headlight mod-
ule.416 MAINTAINING YOUR VEHICLE

Front Park/Turn Signal and Sidemarker Lights
1. Remove the three screws securing the headlight mod-
ule.
2. Twist the turn signal socket to remove from the
headlight module and pull bulb from socket. 3. Replace bulb, reinstall socket and then reinstall the
headlight module.418 MAINTAINING YOUR VEHICLE

Front Fog Light
1. Reach behind the front fascia from under the vehicle.
2. Twist the front fog light bulb to remove from the fog
light housing.
3. Disconnect the electrical connector and replace the
bulb.
CAUTION!Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol. Rear Tail, Stop, Turn Signal, Side Marker and
Back-up Lights
1. Raise the liftgate.
2. Remove the two tail light assembly push-in type
fasteners, by prying under the fastener head with a large
flat screwdriver. MAINTAINING YOUR VEHICLE 419
7
