2005 DODGE GRAND CARAVAN key

To activate the system, open the sliding door and move
the child lock control, located near the door ’ s rear latch,
to the ON position.
When the child lock system is engaged the door can be
opened only by using the outside door handle, remote keyless entry transmitter, switches on the overhead con-
sole or the switches located on the trim panel just in front
of the power sliding door, even though the inside door
lock is in the unlocked position.
The power sliding door will operate from the switches
located on the trim panel just in front of the power sliding
door, regardless of the child lock lever position. To avoid
unintentional operation of the power sliding door from
the rear seats, press the button located in the overhead
console to disable the switches for the rear seat passen-
gers.
NOTE:
• The power sliding door switches will not operate if the
vehicle is in gear or the vehicle speed is above 0 mph
(0 km/h).
• The power sliding door will operate from the remote
keyless entry transmitter, if the vehicle is in Park,
regardless of the child lock lever position.Child Lock Control34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

LIFTGATE
NOTE: The key that is used to start the vehicle is also
used to lock or unlock the doors and open the liftgate.
To open the liftgate, insert the key into the lock and turn
to the right. On vehicles equipped with power locks the
liftgate can also be unlocked using the remote keyless
entry or by activating the power door lock switches
located on the front doors.
Once unlocked, on vehicles equipped with power locks,
the liftgate can be opened or closed without using the
key. To open the liftgate, depress the liftgate release
switch located on the underside of the license plate bar
and pull the liftgate open with one fluid motion. If the liftgate is locked and is not equipped with a
powered liftgate, pressing the button on the remote
keyless entry transmitter will result in the liftgate becom-
ing unlocked for 30 seconds allowing you to manually
access the liftgate area. Liftgate Release SwitchTHINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35
2

NOTE: On vehicles without power locks, the liftgate can
only be opened using the vehicle keys. The key must be
held in the unlocked position for the liftgate to open.
Power Liftgate — If Equipped
The power liftgate may be opened manually or by using
the button on the remote keyless entry transmitter. Press
the button on the remote keyless entry transmitter twice
within five seconds, to open the power liftgate. Once the
liftgate is fully open, pressing the button twice within
five seconds a second time will close the liftgate.
The power liftgate may also be opened by pressing the
button located on the overhead console.
When the remote keyless entry transmitter button is
pressed and the “ Lamp Flash ” feature is enabled, the tail
lights will flash to signal that the liftgate is opening or
closing. Power Liftgate Switch36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

2. Turn the ignition key to the RUN position (engine
does not need to be running), and wait for the Seat Belt
Warning Light to turn off.
3. Within 60 seconds, unbuckle and then re-buckle the
driver ’ s seat belt at least three times, ending with the seat
belt buckled.
4. Turn the ignition key to the OFF position. A single
chime will sound to signify that you have successfully
completed the programming.
The Enhanced Warning System (BeltAlert) can be reacti-
vated by repeating this procedure.
NOTE: Although the Enhanced Warning System
(BeltAlert) has been deactivated, the Seat Belt Warning
Light will continue to illuminate while the driver ’ s seat
belt remains unfastened. Seat Belts and Pregnant Women
We recommend that pregnant women use the seat belts
throughout their pregnancies. Keeping the mother safe is
the best way to keep the baby safe.
Pregnant women should wear the lap part of the belt
across the thighs and as snug across the hips as possible.
Keep the belt low so that it does not come across the
abdomen. That way the strong bones of the hips will take
the force if there is a collision.
Seat Belt Extender
If a seat belt is too short, even when fully extended and
when the adjustable upper shoulder belt anchorage (if
equipped) is in its lowest position, your dealer can
provide you with a seat belt extender. This extender
should be used only if the existing belt is not long
enough. When it is not required, remove the extender
and stow it.52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

• Knee Impact Bolster
• Driver Inflatable Knee Blocker
• Front Passenger Seat Occupant Classification System
(OCS) — If Equipped
Occupant Classification Module
Passenger Airbag Disabled (PAD) Indicator Light
Interconnecting Wiring
Bladder Assembly
Belt Tension Sensor
How The Airbag System Works
• The Occupant Restraint Controller (ORC) determines
if a frontal collision is severe enough to require the
airbags to inflate. Based on the level of collision
severity, the front control module determines the proper rate of inflation. The front airbag inflators are
designed to provide different rates of airbag inflation.
• The ORC may modify the rate of inflation based on the
occupant size provided by the Occupant Classification
Module.
• The ORC will not detect side, roll over, or rear impacts.
• The ORC monitors the readiness of the electronic parts
of the system whenever the ignition switch is in the
START or RUN positions. These include all of the
items listed above except the steering wheel and
column, instrument panel and passenger knee bol-
sters. If the key is in the OFF position, in the ACC
position, or not in the ignition, the airbags are not on
and will not inflate.
• Also, the ORC turns on the AIRBAG warn-
ing light and PAD indicator light in the
center of the instrument panel for 6 to 8
seconds for a self-check when the ignition is58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

UConnect ™ system. To select a phone from the list,
press the ’ Voice Recognition ’ button and say  Select  .
• The lower priority phone will only be used for the next
phone call. After that, the UConnect ™ system will
return to using the highest priority phone in the
vehicle.
UConnect ™ System Features
Barge In - Touch Tone Phone Inputs
You can use your UConnect ™ system to access a voice mail
system, an automated service, or any other phone number
that you can dial with any phone. When calling a number
with your UConnect ™ system that normally requires you to
enter in a touch-tone sequence on your cellular phone
keypad, you can push the ’ Voice Recognition ’ button and
say the sequence you wish to enter followed by  Send  . For
example, if required to enter your pin number, you can press
the ’ Voice Recognition ’ button and say  3746 Send  ,or
whatever you have made your pin. This method can also be used in instances where you are pressing a number on your
keypad to navigate through a menu structure or to enter a
number for a pager.
Barge In - Overriding Prompts
The ’ Voice Recognition ’ button can be used when you
wish to skip part of a prompt and issue your voice
recognition command immediately. For example, if a
prompt is playing  Would you like to pair a phone, clear
a  , you could press the ’ Voice Recognition ’ button and
say  Pair A Phone  to select that option without having to
listen to the rest of the voice prompt.
Language Selection
To change the language that the UConnect ™ system is
using, press the ’ Phone ’ button and say the name of the
language you wish to switch to (English, Espa ñ ol, or
Fran ç ais as equipped). After selecting one of the lan-
guages, all prompts and voice commands will be in the
selected language. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105
3

Turning Confirmation Prompts On/Off
Turning confirmation prompts off will stop the system
from confirming your choices (e.g. the UConnect ™ sys-
tem will not repeat a phone number before you dial it).
• Press the ’ Phone ’ button to begin.
• After the  Ready  prompt, say  Setup Confirmation  .
The UConnect ™ system will play the current confir-
mation prompt status and you will be given the choice
to change it.
Low Signal, Battery Strength, and Roam
Notification
The UConnect ™ system will provide notification to
inform you if your cellular phone is in roaming status,
has low signal strength, or has a low battery when you
are trying to place a phone call. Dialing Using the Cellular Phone Keypad
You can dial a phone number with your cellular phone
keypad and still use the UConnect ™ system. By dialing a
number with your paired Bluetooth ™ cellular phone, the
audio will be played through your vehicle ’ s stereo sys-
tem. The UConnect ™ system will work the same as if
you dialed the number using voice recognition.
Mute/Unmute
When you mute the UConnect ™ system, you will still be
able to hear the conversation coming from the other
party, but the other party will not be able to hear you. In
order to mute the UConnect ™ system press the ’ Voice
Recognition ’ button and say  Mute  . In order to unmute
the UConnect ™ system; press the ’ Voice Recognition ’
button and say  Unmute  .106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

LIGHTS
All of the lights, except the hazard warning lights, are
controlled by switches to the left of the steering column
on the instrument panel. Interior Lights
Interior lights are turned on when a door or liftgate is
opened, the keyless entry transmitter is activated, or
when the dimmer control is moved to the extreme top.
The interior lights will automatically turn off in about 15
minutes if any of the following occur.
• A door, sliding door or the liftgate is left open.
• Any overhead reading light is left on.
• If the dimmer control is in the extreme top position.
NOTE: The key must be out of the ignition switch or the
ignition switch must be in the OFF position for this
feature to operate.Headlight Switch134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
