Removing the Spare Tire and Tools
The tools you will need are located in the storage
compartment at the rear of the vehicle, on the
passenger’s side.
To remove the tools, do the following:
1. Open the liftgate. SeeLiftgate on page 2-23for
more information.
2. Remove the convenience net, if equipped.
3. Open the jack storage compartment by lifting the
tab and pulling the cover off.A. Jack
B. Strap
C. Bracket
D. Wing NutE. Bag and Tools
F. Tire Bag and Cable
Storage for All-Wheel
Drive Vehicles
4. Remove the jack (A) and jacking tools (E) by
loosening and then removing the wing nut (D)
and bracket (C).
5. Separate the plastic pouch from the jack and
remove the jacking tools, including the folding
wrench and extension, from the pouch.
5-69

The tools you will be using include the jack (A),
extension (B), and folding wrench (C).
The compact spare tire is located under the rear of the
vehicle. SeeCompact Spare Tire on page 5-84for
more information about the compact spare.To remove the compact spare tire, do the following:
A. Hoist Shaft
B. Hoist Assembly
C. RetainerD. Compact Spare Tire
E. Extension (Chisel End)
F. Folding Wrench
1. Attach the folding wrench (F) to the extension (E)
and insert the chisel end on an angle through the
hole in the rear bumper and into the hoist shaft (A).
2. Turn the folding wrench counterclockwise to lower
the compact spare tire (D) to the ground. Continue
to turn the wrench so the compact spare tire
can be pulled out from under the vehicle.
5-70

3. Tilt the retainer at the end of the cable to remove
the compact spare tire, so it can be pulled up
through the wheel opening.
If your vehicle is an AWD vehicle, after removing
the compact spare tire, turn the wrench clockwise to
raise the cable back up. On an AWD vehicle, you
can not store a full-size tire under the vehicle.
It should be stowed inside the vehicle by the cable
provided. See “Storing the Flat Tire on an
All-Wheel-Drive Vehicle” underStoring a Flat or
Spare Tire and Tools on page 5-80for more
information.If you have a front-wheel-drive vehicle, the hoist is
used to store a full-size or a at road tire under
the vehicle. See “Storing the Flat Tire on an
Front-Wheel-Drive Vehicle” underStoring a Flat or
Spare Tire and Tools on page 5-80for more
information.
4. Remove the compact spare tire from the cable.
If the compact spare tire will not lower, check under the
vehicle to see if the tire is hanging loose and the
cable end and spring under the wheel plate are missing.
If so, the secondary latch system is engaged. See
Secondary Latch System on page 5-78.
To continue changing the at tire, seeRemoving the
Flat Tire and Installing the Spare Tire on page 5-72.
5-71

Removing the Flat Tire and
Installing the Spare Tire
If the wheel has a center cap, use the handle of the
folding wrench to pry it off. Then, with the other end of
the folding wrench, loosen the nuts.
If your vehicle has the plastic bolt-on wheel covers,
loosen the bolts completely using the folding wrench,
and remove the wheel cover.Once the center cap and/or wheel cover are removed,
use the following steps to remove the at tire and install
the spare tire.
1. Loosen the wheel nuts
using the folding
wrench, but do not
remove them. Turn the
handle
counterclockwise about
180 degrees, then
ip the handle back to
the starting position.
This avoids taking
the wrench off the lug
nut for each turn.
Notice:If your vehicle has wheel locks and you
use an impact wrench to remove the wheel nuts, you
could damage the lock nut or wheel lock key. Do
not use an impact wrench to remove the wheel nuts
if your vehicle has wheel locks.
Notice:If you use a jack to raise the vehicle
without positioning it correctly, you could damage
your vehicle. When raising your vehicle on a
jack, avoid contact with the rear axle control arms.
5-72

Notice:If you position the jack under the rocker
molding and attempt to raise the vehicle, you could
break the molding and/or cause other damage to
your vehicle. Always position the jack so that when
the jack head is raised, it will t rmly in the
notch located inboard from the rocker molding.
A. Front Location
B. Rear Location
2. Near each wheel, there is a notch (A and B) in the
vehicle’s frame, inboard of the rocker molding.
Position the jack and raise the jack head until it ts
rmly into the notch in the vehicle’s frame nearest
the at tire.3. Do not raise the vehicle yet.
4. Put the compact spare tire near you.
{CAUTION:
Getting under a vehicle when it is jacked up is
dangerous. If the vehicle slips off the jack you
could be badly injured or killed. Never get under
a vehicle when it is supported only by a jack.
{CAUTION:
Raising your vehicle with the jack improperly
positioned can damage the vehicle and even
make the vehicle fall. To help avoid personal
injury and vehicle damage, be sure to t the
jack lift head into the proper location before
raising the vehicle.
5-73

5. Attach the folding wrench (A) to the jack (B), and
turn the wrench clockwise to raise the jack head
approximately 3 inches (7.6 cm).6. Raise the vehicle by turning the folding wrench
clockwise in the jack. Raise the vehicle far enough
off the ground so there is enough room for the
compact spare tire to t under the wheel well.
5-74

7. Remove all the wheel nuts and take off the at tire.
{CAUTION:
Rust or dirt on the wheel, or on the parts to
which it is fastened, can make the wheel nuts
become loose after a time. The wheel could
come off and cause an accident. When you
change a wheel, remove any rust or dirt from
the places where the wheel attaches to the
vehicle. In an emergency, you can use a cloth
or a paper towel to do this; but be sure to use
a scraper or wire brush later, if you need to, to
get all the rust or dirt off.8. Remove any rust or dirt
from the wheel bolts,
mounting surfaces
and spare wheel.
{CAUTION:
Never use oil or grease on studs or nuts. If
you do, the nuts might come loose. Your wheel
could fall off, causing a serious accident.
5-75

9. Install the compact spare tire and put the wheel
nuts back on with the rounded end of the nuts
toward the wheel. Tighten each nut by hand until
the wheel is held against the hub.10. Lower the vehicle by attaching the folding wheel
wrench to the jack and turning the wrench
counterclockwise. Lower the jack completely.
