2005 CHEVROLET CAVALIER Owners Manual

Storage Areas
Cupholder(s)
There are two cupholders located at the front of the
center console, in front of the shift lever. There are also
cupholders for the rear seat passengers located
under the center console lid. Open the center console
lid all the way to uncover the rear cupholders. There
may also be a large, removable cupholder inside of the
center console lid.
Center Console Storage Area
To open the center console, pull the lift lever up and the
lid back.
To close the center console, push the lid down until
it clicks.
Convenience Net
Your vehicle may have a convenience net. You will see
it inside the back wall of the trunk. Put small loads
behind the net. It can help keep them from falling over
during sharp turns or quick starts and stops.Unclip a corner of the convenience net to t larger
objects behind the net, then reclip it to secure them in
place. The net is not for larger, heavier loads. Store
them in the trunk as far forward as you can.
You can unhook the net so that it will lie at when you
are not using it.
Sunroof
The vehicle may have a
sunroof. With the ignition
in the ON position,
press and hold the rear of
the sunroof switch,
located on the headliner,
and the sunroof will
open to the vent position.
The sunshade must be
opened manually.
Press the sunroof switch twice and hold the rear of the
switch to open the sunroof and sunshade. Release
the switch to stop the sunroof.
Press and hold the front of the switch to close the
sunroof. The sunshade can only be closed by hand.
The sunroof cannot be opened or closed if the vehicle
has an electrical failure.
2-35

✍NOTES
2-36

Instrument Panel Overview...............................3-4
Hazard Warning Flashers................................3-6
Other Warning Devices...................................3-6
Horn.............................................................3-6
Tilt Wheel.....................................................3-6
Turn Signal/Multifunction Lever.........................3-7
Turn and Lane-Change Signals........................3-8
Headlamp High/Low-Beam Changer..................3-8
Flash-to-Pass.................................................3-8
Windshield Wipers..........................................3-9
Windshield Washer.......................................3-10
Cruise Control..............................................3-10
Exterior Lamps.............................................3-13
Headlamps on Reminder................................3-13
Daytime Running Lamps................................3-13
Fog Lamps..................................................3-15
Instrument Panel Brightness...........................3-15
Entry Lighting...............................................3-16
Front Reading Lamps....................................3-16
Map Lamps.................................................3-16
Battery Run-Down Protection..........................3-16
Accessory Power Outlets...............................3-16
Ashtrays and Cigarette Lighter........................3-17
Climate Controls............................................3-18
Climate Control System.................................3-18
Outlet Adjustment.........................................3-20Warning Lights, Gages, and Indicators............3-21
Instrument Panel Cluster................................3-22
Speedometer and Odometer...........................3-23
Trip Odometer..............................................3-23
Tachometer.................................................3-23
Safety Belt Reminder Light.............................3-24
Airbag Readiness Light..................................3-24
Charging System Light..................................3-25
Up-Shift Light...............................................3-26
Brake System Warning Light..........................3-26
Anti-Lock Brake System Warning Light.............3-27
Enhanced Traction System Warning Light.........3-28
Enhanced Traction System Active Light............3-29
Engine Coolant Temperature Gage..................3-29
Low Coolant Warning Light............................3-30
Malfunction Indicator Lamp.............................3-30
Oil Pressure Light.........................................3-33
Passlock
®Warning Light................................3-34
Highbeam On Light.......................................3-34
Check Gages Warning Light...........................3-34
Service Vehicle Soon Light............................3-35
Fuel Gage...................................................3-35
Section 3 Instrument Panel
3-1

Audio System(s).............................................3-36
Setting the Time for Radios without Radio
Data Systems (RDS)..................................3-36
Setting the Time for Radios with Radio Data
Systems (RDS).........................................3-36
AM-FM Radio...............................................3-37
Radio with CD (Base Level)...........................3-39
Radio with CD (Up Level)..............................3-44
Radio with CD (MP3)....................................3-54Personal Choice Radio Controls......................3-69
Theft-Deterrent Feature (Non RDS Radios).......3-69
Theft-Deterrent Feature (RDS Radios).............3-69
Radio Reception...........................................3-70
Care of Your CDs.........................................3-70
Care of Your CD Player................................3-70
Fixed Mast Antenna......................................3-71
XM™ Satellite Radio Antenna System.............3-71
Chime Level Adjustment................................3-71
Section 3 Instrument Panel
3-2

✍NOTES
3-3

Instrument Panel Overview
3-4

The main components of your instrument panel are the following:
A. Fog Lamp Button. SeeFog Lamps on page 3-15.
B. Instrument Panel Brightness Control. SeeInstrument
Panel Brightness on page 3-15.
C. Turn Signal/Multifunction Lever. SeeTurn
Signal/Multifunction Lever on page 3-7.
D. Instrument Panel Cluster. SeeInstrument Panel
Cluster on page 3-22.
E. Hazard Warning Flashers Switch. SeeHazard
Warning Flashers on page 3-6.
F. Ignition Switch. SeeIgnition Positions on page 2-16.
G. Windshield Wiper/Washer Controls. SeeWindshield
Wipers on page 3-9andWindshield Washer on
page 3-10.
H. Audio System. SeeAudio System(s) on page 3-36.
I. Climate Controls and Rear Window Defogger.
SeeClimate Control System on page 3-18.
J. Fuse Panel. SeeInstrument Panel Fuse Block on
page 5-82.K. Remote Trunk Release Button. See “Remote Trunk
Release” underTrunk on page 2-10.
L. Hood Release Lever. SeeHood Release on
page 5-10.
M. Tilt Steering Wheel Lever. SeeTilt Wheel on
page 3-6.
N. Accessory Power Outlet (If Equipped). See
Accessory Power Outlets on page 3-16. Cigarette
Lighter (If Equipped). SeeAshtrays and Cigarette
Lighter on page 3-17.
O. Parking Brake Lever. SeeParking Brake on
page 2-25.
P. Accessory Power Outlet. SeeAccessory Power
Outlets on page 3-16.
Q. Shift Lever. SeeAutomatic Transaxle Operation on
page 2-20andManual Transaxle Operation on
page 2-23.
3-5

Hazard Warning Flashers
Your hazard warning ashers let you warn others. They
also let police know you have a problem. Your front
and rear turn signal lamps will ash on and off.
The hazard warning asher
switch is located on the top
of the steering column.
Your hazard warning ashers work no matter what
position your key is in, and even if the key is not in.
Move the switch to the right to make the front and rear
turn signal lamps ash on and off. Move the switch
to the left to turn the ashers off.
When the hazard warning ashers are on, your turn
signals will not work. Make sure the hazard warning
asher switch is all the way to the left for normal
turn signal operation.
Other Warning Devices
If you carry reective triangles, you can set them up at
the side of the road about 300 feet (100 m) behind
your vehicle.
Horn
Press near or on the horn symbols on your steering
wheel pad to sound the horn.
Tilt Wheel
Your vehicle may have a tilt wheel which allows you to
adjust the steering wheel before you drive. You can
raise it to the highest level to give your legs more room
when you exit and enter the vehicle.
3-6
