2005 BMW MOTORRAD K 1200 S weight

Technical data
Troubleshooting chart........ 132
Threaded fasteners . . . ........ 133
Engine ....................... 134
Riding specifications . ........ 136
Clutch ....................... 136
Transmission . . . .............. 136
Final drive . ................... 137
Running gear . . . .............. 137
Brakes ....................... 138
Wheels and tyres ............. 138
Electrics . . ................... 139
Frame ....................... 141
Dimensions .................. 141
Weights . . . ................... 142
9131zTechnical data

Number-plate light bulbIntegrated in rear lightFrameMain frame, typeComposite with internal-high-pressure forming
and extruded sections and chill castings
Type plate, location Frame cross-tube, rear
Vehicle identification number (VIN), location Frame side section, front rightDimensionsOverall motorcycle length 2182 mm
Maximum width 905 mm, Across mirrors
Maximum height 1211 mm, DIN unladen weight
Seat height, front 820 mm, Without rider
with OE Front seat, low: 790 mm, Without rider
Wheelbase in normal-load position 1571.64 mm, Full load of fuel, with
rider: 85 kg
Ground clearance 144 mm, In normal-load position, full load of
fuel, with rider: 85 kg
9141zTechnical data

WeightsUnladen weight248 kg, DIN unladen weight, ready for road
90 % load of fuel, without optional extras
Permissible gross weight 450 kg
Maximum payload 202 kg
9142zTechnical data

Details described or illus-
trated in this booklet may
differ from the motorcycle's
actual specification as pur-
chased, the accessories fit-
ted or the national-market
specification. No claims will
be entertained as a result of
such discrepancies.
Dimensions, weights, fuel
consumption and perform-
ance data are quoted to the
customary tolerances.
The right to modify designs,
equipment and accessories is
reserved.
Errors and omissions excep-
ted.
© 2005 BMW Motorrad
Not to be reproduced either
wholly or in part without writ-
ten permission from BMW
Motorrad, After Sales.
Printed in Germany.
