2005 BMW MOTORRAD K 1200 S torque

Maintenance - general
instructionsThe 'Maintenance' chapter
describes work involving the
replacement of wear parts
that can be performed with
minimum effort.
If special tightening torques
are to be taken into account
for assembly, these are also
listed.
Threaded fasteners for which
a suitable tool is included in
the toolkit are marked ac-
cordingly.
If you are interested in inform-
ation on more extensive work,
we recommend the repair
manual on CD-ROM which
applies to your particular mo-
torcycle. You can obtain a
copy from your authorised
BMW Motorrad dealer.
Toolkit1Screwdriver with revers-
ible blade
2 Torx wrench, T25
3 Screwdriver, small
The toolkit supplied with
the motorcycle is under-
neath the seat.Contents, supplement-
ary kit
OA
The supplementary kit is
available as an optional ac-
cessory. Please consult your authorised BMW Motorrad
dealer.
Overview, supple-
mentary kit1
Screwdriver blade
2 Socket wrench, w/f 17
3 Spark plug socket span-
ner
4 Open-ended spanner,
w/f 17
5 TORX wrenches, T40,
T45, T50
792zMaintenance

Raise the front of the mo-
torcycle until the front wheel
can rotate freely. It is advis-
able to use the BMW Motor-
rad front wheel stand to lift
the motorcycle.
Fitting the front wheel stand
( 109)The left axle clamping
screw locates the
threaded bush in the front
suspension. If the threaded
bush is not correctly aligned
the gap between the ABS
sensor ring and the ABS
sensor will not be correct and this can cause the ABS to
malfunction or allow the ABS
sensor to be damaged.
in order to ensure that the
threaded bush remains cor-
rectly aligned, do not slacken
or remove the left axle camp-
ing screw.
Remove right-hand axle
clamping screw 6.
Remove quick-release
axle 7, holding the wheel as
you do so.
BMW Motorrad provides
an adapter for removing
the quick-release axle. This
adapter can be combined
with a commercially available
w/f 22 open-end or ring span-
ner. The BMW special tool
number is 36 3 691 and the
adapter is available from your
authorised BMW Motorrad
dealer. Lower the front wheel to the
ground between the front
forks.
Roll the front wheel forward
to remove.
Do not damage the ABS
sensor when rolling the
front wheel in or out between
the forks.
Installing front wheel
Threaded fasteners not
tightened to the spe-
cified torque can work loose
or their threads can suffer
damage.
7103zMaintenance

Always have the security of
the fasteners checked by a
specialist workshop, prefer-
ably an authorised BMW Mo-
torrad dealer.There is a risk of
damaging parts of the
front brake, particularly the
BMW Integral ABS, in the
course of the procedure
described below.
Take care not to damage the
brake system, in particular the
ABS sensor with cable and
the ABS sensor ring.
The front wheel must be
installed right way round
to rotate in the correct direc-
tion.
Note the direction-of-rotation
arrows on the tyre or the
wheel rim. Roll the front wheel into
position between the front
forks.
Do not damage the ABS
sensor when rolling the
front wheel in or out between
the forks. Raise the front wheel, install
quick-release axle
7and
tighten to specified tighten-
ing torque.
Quick-release axle in
threaded bush
50 Nm
Tighten right-hand axle
clamping screw 6to the
appropriate tightening
torque.
Clamping screw for quick-
release axle in wheel carrier
19 Nm
Remove the front wheel
stand.
7104zMaintenance

Lower the rear wheel to the
ground.
Roll the rear wheel out to-
ward the rear.
If you are using a BMW Mo-
torrad rear wheel stand: re-
install the retaining disc.Installing rear wheel
Threaded fasteners not
tightened to the spe-
cified torque can work loose
or their threads can suffer
damage.
Always have the security of
the fasteners checked by a
specialist workshop, prefer- ably an authorised BMW Mo-
torrad dealer.
If you are using a BMW Mo-
torrad rear wheel stand: re-
move the retaining disc.
Roll the rear wheel into po-
sition at the rear-wheel ad-
apter.
Seat the rear wheel on the
rear-wheel adapter.
If you are using a BMW Mo-
torrad rear wheel stand: re-
install the retaining disc. Install studs
5and tighten to
the specified torque in diag-
onally opposite sequence.
Rear wheel to wheel flange
60 Nm
Turn the end silencer to its
initial position.
7107zMaintenance

Threaded fastenersActivityType of threaded connection Tightening
torquesFront wheel
Front brake caliper, wheel carrier
installedM8 x 32 -10.9
30 Nm (Left)
M8 x 32 -10.9 30 Nm (Right)
Clamping screw for quick-release
axle in wheel carrier M8 x 30
19 Nm
Quick-release axle in threaded
bush M24 x 1.5
50 Nm
Rear wheel
Silencer to rear footrest, right M8 x 30 28 Nm
Silencer to manifold M8 - 10.9 self-locking, Optimoly TA 35 Nm
Rear wheel to wheel flange M10 x 43 x 1.25 60 Nm
M10 x 40 x 1.25 60 Nm
9133zTechnical data

EngineType
Type, engineTransversely mounted, four-cylinder
four-stroke in-line engine tilted 55° forward,
with four valves per cylinder, two overhead
camshafts with cam followers; liquid cooled,
with electronic fuel injection, integrated
six-speed cassette gearbox, dry-sump
lubrication.
Technical data
Effective displacement 1157 cm
3
Cylinder bore79 mm
Piston stroke 59 mm
Compression ratio 13 : 1
Nominal output 123 kW, At engine rpm: 10250 min
-1
with OE Power reduction:74 kW, At engine rpm: 7000 min
-1
with OE Power reduction:79 kW, At engine rpm: 8750 min
-1
Max. torque130 Nm, At engine rpm: 8250 min
-1
Maximum permissible engine speed11000 min
-1
Idle speed1150
±50
min
-1
