The control units for seat adjustment can be used to
set up to 8 individual seat positions for an
electrically adjustable seat. The seat positions can
be stored in memory and can be set again if
necessary using the memory keypad or by entering
a radio code.
Installation position
The control units for seat adjustment are located in
the floor area under the driver’s and passenger’s
seat.
The control unit can be used both for the driver’s
seat and for the passenger’s seat by assigning
a PIN code in the connecting plug.
The unlearned/uncoded control unit is thus coded
automatically for either the driver’s seat or
passenger’s seat installation position – depending
on the pin – when it is first connected to the seat.
This operation can only be performed once, but can
be released again by means of the diagnostic
function (in the Conditioning menu item).
Diagnosis
The following diagnostic functions are available
under the address words 36 Seat adjustment,
driver’s side and 06 Seat adjustment, passenger’s
side:
– Read measured-value blocks
–Coding
–Actuator test
–Adaptation
Control units for seat adjustment
326_115
