Be sure no foreign material enters the
crankcase.
6. Start the engine and warm up for a few min-
utes. While warming up, check for oil leakage.
If oil leakage is found, stop the engine imme-
diately and check for the cause.
7. Check the oil level.Recommended oil:
See page 10-2
Oil quantity:
Total amount:
0.6 L (0.53 Imp qt, 0.63 US qt)
5VJ-9-61-08 3/17/03 4:52 PM Page 8-26
Page 253 of 350
8-31
EBU00959
Engine and V-belt case air filter element
cleaning
Both air filter elements should be cleaned at the
specified intervals in the periodic maintenance
chart.
Engine air filter element
NOTE:
There is a check hose at the bottom of the air fil-
ter case. If dust or water collects in this hose,
empty the hose and clean the air filter element
and air filter case.
1. Remove the seat.
2. Remove the breather hose and then loosen
the clamp screw.
3. Remove the air filter case cover.
q
w
e
q
1. Check hose1. Flexible de contrôle1. Manguito de comprobación
1. Air filter case cover
2. Breather hose 3. Clamp
1. Cache du boîtier de filtre à air
2. Reniflard 3. Bride
1. Tapa de la caja del filtro de aire
2. Tubo de ventilación 3. Abrazadera
5VJ-9-61-08 3/17/03 4:52 PM Page 8-32
Page 259 of 350
8-37
NOTE:
The air filter element should be cleaned every
20–40 hours. It should be cleaned and lubricat-
ed more often if the machine is operated in
extremely dusty areas. Each time air filter ele-
ment maintenance is performed, check the air
inlet to the air filter case for obstructions. Check
the air filter case rubber joint to the carburetor
and manifold fittings for an airtight seal. Tighten
all fittings securely to avoid the possibility of
unfiltered air entering the engine.
cC
Never operate the engine with the air filter
element removed. This will allow unfiltered
air to enter, causing rapid engine wear and
possible engine damage. Additionally, opera-
tion without the air filter element will affect
carburetor jetting with subsequent poor per-
formance and possible engine overheating.
5VJ-9-61-08 3/17/03 4:52 PM Page 8-38
Page 317 of 350

8-95
EBU00440
Troubleshooting chart
1. Fuel
Check if there is
fuel in the fuel
tank.
2. Compression
Use electric starter
to see if there is
compression.
3. Ignition
Remove plug and
check electrodes.
WetWipe clean with dry
cloth.
DryAttach plug cap and
ground to chassis.Use electric
starter.Spark weak.
Spark good.Ignition system normal.
No spark.
Ask a Yamaha dealer to inspect.
Adjust plug gap or
replace plug.
There is compresson.Compression normal.
Ask a Yamaha dealer to inspect.No compression.
There is fuel.Turn the fuel
cock to “OFF”.
Remove the
fuel hose from
the fuel cock.
Some fuel.Turn the fuel
cock to “RES”.Restart engine.
No fuel.Supply fuel.
4. Battery
Use electric
starter.
Engine turns
over quickly.Battery good.
Engine turns
over slowly.Check fluid, recharge,
check connections.
Check fuel flow.
Water or dirt
mixed in fuel.
Turn the fuel
cock to “ON”.No fuel.Fuel cock clogged.
