2004 YAMAHA BREEZE stop start

4-5
EBU00053
Handlebar switches
EBU11580
Engine stop switch “ENG. STOP”
Make sure that the engine stop switch is in the
“RUN” position before starting the engine. The
engine stop switch controls ignition and can be
used at all times to stop the engine, especially in
an emergency. The engine will not start or run
when the engine stop switch is turned to “OFF”.
EBU00056
Start switch “START”
The starter motor cranks the engine when this
switch is pushed.
cC
See starting instructions prior to starting
engine (see page 6-3 for details).
w
q
e
1. Engine stop switch “ENG. STOP”
2. Light switch “LIGHTS”
3. Start switch “START”
1. Coupe-circuit du moteur “ENG. STOP”
2. Contacteur d’éclairage “LIGHTS”
3. Contacteur de démarreur “START”
1. Interruptor de paro del motor “ENG. STOP”
2. Interruptor de luces “LIGHTS”
3. Interruptor de arranque “START”
5VJ-9-61-04 3/17/03 4:47 PM Page 6

4-6
FBU00053
Contacteurs au guidon
FBU11580
Coupe-circuit du moteur “ENG. STOP”
S’assurer que le coupe-circuit du moteur est
placé sur “RUN” avant de mettre le moteur en
marche. Le coupe-circuit du moteur contrôle
l’allumage et peut à tout moment servir à couper
le moteur. Il est particulièrement utile en cas
d’urgence. Le moteur ne se met pas en marche
ou ne tourne pas quand son coupe-circuit est sur
“OFF”.
FBU00056
Contacteur du démarreur “START”
Pour mettre le moteur en marche, enfoncer le
contacteur du démarreur.
fF
Il convient de lire les instructions de démar-
rage avant de mettre le moteur en marche
(voir page 6-4).
SBU00053
Interruptores del manillar
SBU11580
Interruptor de parada del motor “ENG.
STOP”
Asegúrese de que el interruptor de parada del
motor esté en la posición “RUN” antes de arrancar
el motor. El interruptor de parada del motor con-
trola el encendido y puede utilizarse para parar el
motor en cualquier momento, especialmente en
casos de emergencia. Cuando se gira el interrup-
tor de parada a la posición “OFF”, el motor no
puede ser puesto en marcha ni funcionar.
SBU00056
Interruptor de arranque “START”
Cuando se pulsa este interruptor, el motor de
arranque hace que gire el motor principal.
yY
Antes de poner en marcha el motor, ver ins-
trucciones de arranque (para más detalles
ver página 6-4).
5VJ-9-61-04 3/17/03 4:47 PM Page 7

4-7
NOTE:
If the starter switch is pushed with the main
switch “ON” and the engine stop switch “OFF”,
the starter motor will be activated but the engine
will not start. To start the engine, be sure to
position the engine stop switch at “RUN”.
EBU12860
Light switch “LIGHTS”
Set the switch to the “LO” position to switch on
the low beam and the taillight.
Set the switch to the “HI” position to switch on
the high beam and the taillight.
Set the switch to the “OFF” position to switch off
all the lights.
NOTE:
The headlight and the taillight can be turned on
only when the engine is started.
5VJ-9-61-04 3/17/03 4:47 PM Page 8

6-3
EBU00510
Starting a cold engine
w
Always make sure all control cables work
smoothly before you begin riding in cold
weather. If the control cables are frozen or
do not work smoothly, you could be unable
to control the ATV, which could lead to an
accident or collision.
1. Set the parking brake.
2. Turn the fuel cock to “ON”.
3. Turn the main switch to “ON” and the engine
stop switch to “RUN”.
4. Shift the drive select lever to neutral.
5VJ-9-61-06 3/17/03 4:51 PM Page 4

7-39
With the engine idling, return the starter knob to
the closed position and shift the drive select
lever into the forward position. Then release the
parking brake. Apply the throttle slowly and
smoothly. The centrifugal clutch will engage and
you will start to accelerate. If the throttle is
applied too abruptly, the front wheels may lift off
the ground resulting in a loss of directional con-
trol. Avoid higher speeds until you are thorough-
ly familiar with the operation of your ATV.
When slowing down or stopping, release the
throttle and apply the brakes smoothly and
evenly. Improper use of the brakes can cause
the tires to lose traction, reducing control and
increasing the possibility of an accident.
5VJ-9-61-07 3/14/03 11:53 PM Page 40

7-53
If your ATV has stalled or stopped and you
believe you can continue up the hill, restart care-
fully to make sure you do not lift the front wheels
which could cause you to lose control. If you are
unable to continue up the hill, dismount the ATV
on the uphill side. Physically turn the ATV
around and then descend the hill.
If you start to roll backwards, DO NOT use the
rear brake to stop. The ATV could easily tip over
backwards. Instead, dismount the ATV immedi-
ately on the uphill side.
5VJ-9-61-07 3/14/03 11:53 PM Page 54

7-77
8If your ATV starts to slide sideways:
Steer in the direction of the slide if you have
the room.
Applying the brakes or accelerating is not rec-
ommended until you have corrected the slide.
(See pages 7-71–7-73.)
8If your ATV can’t make it up a hill you are try-
ing to climb:
Turn the ATV around if you still have forward
speed. If not, stop, dismount on the uphill side
of the ATV and physically turn the ATV
around. If the ATV starts to slip backwards
DO NOT USE THE REAR BRAKE - the ATV
may tip over on top of you. Dismount the ATV
on the uphill side. (See pages 7-45–7-55.)
5VJ-9-61-07 3/14/03 11:53 PM Page 78

8-25
cC
Be sure no foreign material enters the
crankcase.
6. Start the engine and warm up for a few min-
utes. While warming up, check for oil leakage.
If oil leakage is found, stop the engine imme-
diately and check for the cause.
7. Check the oil level.Recommended oil:
See page 10-2
Oil quantity:
Total amount:
0.6 L (0.53 Imp qt, 0.63 US qt)
5VJ-9-61-08 3/17/03 4:52 PM Page 8-26
