2004 SUBARU IMPREZA WRX Owners Manual

Page 169 of 491

SUBARU IMPREZA WRX 2004 2.G Owners Manual 3-32
Instruments and controls
or down slightly and hold it during the lane change.
The turn signal indicator lights will flash in the direction
of the turn or lane change. The lever will return auto

Page 170 of 491

SUBARU IMPREZA WRX 2004 2.G Owners Manual 3-33
Instruments and controls
– CONTINUED  –
Illumination brightness control
(WRX-STi)
The brightness of the combination meter can be ad-
justed in five steps with the headlight switch either t

Page 171 of 491

SUBARU IMPREZA WRX 2004 2.G Owners Manual 3-34
Instruments and controls
the beam becomes.Parking light switch
The parking light switch operates regardless of the ig-
nition switch position.
By pushing the front end of this switch, followin

Page 172 of 491

SUBARU IMPREZA WRX 2004 2.G Owners Manual 3-35
Instruments and controls
– CONTINUED  –
Fog light switch (if equipped)
Pressing the fog lights operate only when the head-
lights are on low beam. Push the fog light switch to
turn the fog

Page 173 of 491

SUBARU IMPREZA WRX 2004 2.G Owners Manual 3-36
Instruments and controls
tempting to operate the wiper with the blades
frozen to the window glass could cause not
only the wiper blades to be damaged but also
the wiper motor to burn out. If th

Page 174 of 491

SUBARU IMPREZA WRX 2004 2.G Owners Manual 3-37
Instruments and controls
– CONTINUED  –
shield wiper blades” section (chapter 11) for re-
placement instructions. !Windshield wiper and washer switches
! Windshield wipers
1) OFF
2) : Int

Page 175 of 491

SUBARU IMPREZA WRX 2004 2.G Owners Manual 3-38
Instruments and controls
!
Mist (for a single wipe)
For a single wipe of the wipers, pull the lever toward
you. The wipers operate until you release the lever. !
Washer
To wash the windshield, p

Page 176 of 491

SUBARU IMPREZA WRX 2004 2.G Owners Manual 3-39
Instruments and controls
– CONTINUED  –
!Rear window wiper and washer switch  – Wagon
1) Rear wiper
2) Washer
! Rear wiper
The rear wiper offers intermittent operation only.
To turn the r
