2004 SATURN L-SERIES Owners Manual

The main components of the instrument panel are the
following:
A. Air Outlets. SeeOutlet Adjustment on page 3-24.
B. Turn Signal/Multifunction Lever. SeeTurn
Signal/Multifunction Lever on page 3-6.
C. Cruise Control (If Equipped). SeeCruise Control on
page 3-10.
D. Horn. SeeHorn on page 3-5.
E. Instrument Panel Cluster. SeeInstrument Panel
Cluster on page 3-26.
F. Windshield Wiper Lever. SeeWindshield Wiper
Lever on page 3-8.
G. Heated Seats (If Equipped). SeeHeated Seats on
page 1-5.
H. Fog Lamps (If Equipped). SeeInterior Lamps on
page 3-15.I. Hazard Warning Flasher Button. SeeHazard
Warning Flashers on page 3-4.
J. Traction Control. SeeTraction Control System (TCS)
Warning Light on page 3-32.
K. Audio System. SeeAudio System(s) on page 3-41.
L. Trunk Release Button/Dimmer Switch. See
Trunk/Liftgate on page 2-13/Interior Lamps on
page 3-15.
M. Hood Release. SeeHood Release on page 5-10.
N. Climate Control. SeeClimate Control System
on page 3-17.
O. Automatic Transaxle Shift Lever. SeeAutomatic
Transaxle Operation on page 2-23.
P. Power Windows. SeePower Windows on page 2-17.
Q. Glove Box. SeeGlove Box on page 2-41.
3-3
ProCarManuals.com

Hazard Warning Flashers
Your hazard warning ashers let you warn others. They
also let police know you have a problem. Your front
and rear turn signal lamps will ash on and off.The hazard warning
asher button is located
near the center of the
instrument panel.
Your hazard warning ashers work no matter what
position your key is in, and even if the key is not in.
Press the button to make the front and rear turn signal
lamps ash on and off. Press the button again to
turn the ashers off.
When the hazard warning ashers are on, your turn
signals will not work. Make sure the hazard warning
asher switch is all the way to the left for normal
turn signal operation.
3-4
ProCarManuals.com

Other Warning Devices
If you carry reective triangles, you can set one up at
the side of the road about 300 feet (100 m) behind your
vehicle.
Horn
You can sound the horn by pressing the center of your
steering wheel.
Tilt Wheel
Your vehicle may have a tilt wheel which allows you to
adjust the steering wheel before you drive. You can
raise it to the highest level to give your legs more room
when you exit and enter the vehicle.
The lever that allows you to tilt the steering wheel is
located on the left side of the steering column.To tilt the wheel, hold the
wheel and pull the lever.
Then, move the wheel to a
comfortable position and
release the lever to
lock the wheel in place.
3-5
ProCarManuals.com

Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes the following:
Turn and Lane-Change Signals
Headlamps
Headlamp High/Low-Beam Changer
Flash-to-Pass Feature
For additional information on the exterior lamps, see
Exterior Lamps on page 3-13.
Turn and Lane-Change Signals
The turn signal has two upward (for right) and two
downward (for left) positions. These positions allow you
to signal a turn or a lane change.
To signal a turn, move the lever all the way up or down.
When the turn is nished, the lever will return
automatically.
An arrow on the instrument
panel cluster will ash in
the direction of the
turn or lane change.
To signal a lane change, raise or lower the lever until
the arrow starts to ash. Hold it there until you complete
the lane change. The lever will return by itself when
you release it.
As you signal a turn or a lane change, if the arrows
ash rapidly, a signal bulb may be burned out and other
drivers won’t see your turn signal.
If a bulb is burned out, replace it to help avoid an
accident. If the arrows do not go on at all when you
signal a turn, check the fuse, seeFuses and Circuit
Breakers on page 5-92and for burned-out bulbs.
3-6
ProCarManuals.com

Headlamp High/Low-Beam Changer
To change the headlamps from low beam to high or high
beam to low, pull the turn signal lever all the way
towards you. Then release it.
When the high beams are
on, this light on the
instrument panel cluster
will also be on.
Flash-to-Pass
This feature lets you use your high-beam headlamps to
signal a driver in front of you that you want to pass.
To use it, pull the turn signal/multifunction lever toward
you until the high-beam headlamps come on, then
release the lever to turn them off.
Headlamps
The exterior lamp control is located in the middle of the
turn signal/multifunction lever.
O(Exterior Lamp Control):Turn the control with this
symbol on it to operate the exterior lamps.The exterior lamp control has the following four
positions:
AUTO (Automatic):Turn the control to this position to
put the headlamps in automatic mode. AUTO mode
will turn the exterior lamps on and off depending upon
how much light is available outside of the vehicle.
;(Parking Lamps):Turn the control to this position
to turn on the parking lamps together with the
following:
Sidemarker Lamps
Taillamps
License Plate Lamps
Instrument Panel Lights
53(Headlamps):Turning the control to this
position turns on the headlamps, together with the
previously listed lamps and lights.
Lamps On Reminder
If you open the driver’s door with the ignition off and the
lamps on, you will hear a warning chime.
3-7
ProCarManuals.com

Windshield Wiper Lever
The lever on the right side of the steering column
operates the windshield wipers.
8:Pull the lever down and release it for a single
wiping cycle. The lever will return to its original position.
For more cycles, hold the lever down before releasing it.
9:Put the lever in this position to turn off the wipers.
&:Put the lever in this position to set a delay
between wipes. Turn the band on the lever to set the
length of the delay (1, 2, or 3).
OO:Put the lever in this position for slow, steady
wiping cycles.
OOOO:Put the lever in this position for rapid
wiping cycles.
Be sure to clear ice and snow from the wiper blades
before using them. If they’re frozen to the windshield,
gently loosen or thaw them. If the blades do become
damaged, install new blades or blade inserts.
Heavy snow or ice can overload the wiper motor. A
circuit breaker will stop the motor until it cools down.
Clear away snow or ice to prevent an overload.
3-8
ProCarManuals.com

Windshield Washer
{CAUTION:
In freezing weather, do not use your washer
until the windshield is warmed. Otherwise the
washer uid can form ice on the windshield,
blocking your vision.
Pull the windshield wiper lever toward you to operate
the windshield wipers. Washer uid will squirt onto
the windshield and the wipers will run for a few cycles
to clear the windshield. For more wash cycles, pull
the lever toward you and hold it there.
Rear Window Wiper/Washer (Wagon)
There is a band on the wiper lever to operate the rear
wiper/washer.
9:Put the band in this position to turn off the rear
wiper.
Z:Put the band in this position to turn on the rear
wiper. This position will be slow, steady wiping cycles.
=(Wash):Hold the band in this position to spray
washer uid on the rear window. The rear wiper will also
come on. Release the band when enough uid has
been sprayed on the window. The rear wiper will stay
on until you turn the band to OFF.
3-9
ProCarManuals.com

Cruise Control
The buttons for the cruise control are located on the
steering wheel.
IO(Cruise On/Off):Push this button to turn the
system on and off.
IS(Resume/Accelerate):Push this button to
make the vehicle resume a previously set speed or to
accelerate when cruise is already active.
–(Set/Coast):Press this button to set the speed or to
decrease the speed when cruise is already active.With cruise control, you can maintain a speed of about
25 mph (40 km/h) or more without keeping your foot
on the accelerator. This can really help on long
trips. Cruise control does not work at speeds below
about 25 mph (40 km/h).
If you apply your brakes, the cruise control will shut off.
{CAUTION:
Cruise control can be dangerous where you
can not drive safely at a steady speed. So, do
not use your cruise control on winding roads
or in heavy traffic.
Cruise control can be dangerous on slippery
roads. On such roads, fast changes in tire
traction can cause needless wheel spinning,
and you could lose control. Do not use cruise
control on slippery roads.
If your vehicle is in cruise control when the traction
control system begins to limit wheel spin, the cruise
control will automatically disengage. SeeTraction
Control System (TCS) on page 4-9. When road
conditions allow you to safely use it again, you may turn
the cruise control back on.
3-10
