142 Starting and drivingSteering wheel lockThe steering wheel lock is electronic. The
lock engages when the remote control is
removed from the ignition and unlocks when
the remote control is inserted. A click can be
heard when the steering wheel lock locks
and unlocks.
If the car is parked with one front wheel
touching the curb, for example, you may
need to turn the steering wheel slightly
when you insert the remote control to allow
the steering wheel lock to unlock. If you do
not succeed on first attempt you must
remove the remote control before trying
again. Turn the steering wheel and insert
the remote control into the ignition switch.
If the steering wheel lock does not disen-
gage it will not be possible to turn the remote
control in the ignition switch.
The following message is shown on the SID:If a fault arises affecting the steering wheel
lock, the following message will be
displayed on the SID:
If the steering wheel lock malfunctions while
the remote control is in the ignition switch,
this may prevent the removal of the remote
control or prevent the car from being
restarted once the engine has been
switched off.
If you have to leave the car, lock the car by
pressing down the lock buttons on the
doors. Lock the front left door from outside
with the traditional key (see page 42). The
car is now locked but the alarm is inactive.
Starting the engine
Steering wheel locked.
Pull out key, turn steering
wheel. Try again.
Steering lock malfunc.
Make a safe stop.
Contact Saab dealer.
WARNING
 When starting the engine:
- Sit down in the driver’s seat.
- Depress the clutch pedal fully. If the
gear lever is not in the neutral position,
the clutch pedal must be fully
depressed or the car will jump
forwards or backwards, which may
cause a crash.
- Never start the car from outside the
vehicle, e.g. through a window that is
down. This could lead to serious
personal injury.
 Cars with automatic transmission:
select position P to remove the ignition
key. The key can only be removed in
this gear position.
 Carbon monoxide (CO) is a colorless,
odorless, poisonous gas. Be alert to
the danger of CO – always open the
garage doors before starting the
engine in the garage.
 Do not rest or sleep in the car when
parked with the engine running. There
is a risk of depressing the accelerator
which could lead to engine damage.
 There is also a danger of CO poison-
ing if the exhaust system is leaking.
ProCarManuals.com

169 Starting and driving
Long-term parkingIf the car is not going to be used for some
time, e.g. three to four months, the following
steps are recommended:
 Drain the washer fluid reservoir and
hoses.
 Wash and wax the car. Clean the rubber
seals on the hood, trunk lid and doors,
and lubricate them with glycerol
(glycerine).
 After washing the car, dry the brake discs
to avoid corrosion by taking the car out on
the road and applying the brakes a few
times.
 Fill the fuel tank to prevent condensation
forming in it.
 Top up the coolant and check the anti-
freeze before the onset of winter. Park the car in a dry, covered and well-
ventilated building. Leave the parking
brake OFF!
Convertible: If the car is stored, the soft
top should be closed.
 If necessary, use wheel chocks and leave
the parking brake off.
 Disconnect the negative (–) battery lead.
If frost is likely to occur during the storage
period, remove the battery and store it in
a frost-free place.
 If it is not possible to stand the car on axle
stands, increase the tire pressure to
43 psi (3 bar).
Leave all the door windows open a crack
and cover the car with a non-plastic
tarpaulin – not one made of plastic which will
not breath.
ProCarManuals.com

183 Starting and driving
Driving with a loadThe handling characteristics are affected by
how the car is loaded.
 Place the heaviest load as far forward and
as low as possible in the trunk.
 Secure the load to the lashing eyes (see
page 137).
 Heavy loads mean that the car’s center of
gravity is further back. As a result, the car
will sway more during evasive steering.
 Never exceed the permissible load of the
roof box, even if there is room for more.
 Ensure that the tire pressure is correct –
slight overinflation is preferable to under-
inflation.
 The braking distance of a loaded car is
always greater. Keep your distance from
the vehicle in front.
 Do not exceed the car’s permissible
gross vehicle weight or axle load (see
page 268).
 Roof loads can negatively affect telecom-
munication.
For further information on tires see page
231.
Driving with the trunk lid
openAvoid driving with the trunk lid partly or fully
open, since exhaust fumes can be drawn
into the cabin.
If you must drive with the trunk lid open,
close all windows and the sunroof (if fitted)
and set the cabin fan to its highest speed
setting.
Driving in deep waterNOTICEDo not drive in puddles or water deeper
than 7 in. (20 cm) and do not drive faster
than 3–4 mph. Water can otherwise be
sucked into the engine. The engine will be
seriously damaged if water enters the
intake system.
ProCarManuals.com

184 Starting and drivingDriving at nightBear in mind the following points, especially
when driving at night:
 Nighttime driving requires your full
concentration
 Do not rush. Count on your journey taking
slightly longer.
 The number of drivers under the influence
of drugs is likely to be greater at night than
during the day.
 Do not stare at the headlights of oncom-
ing vehicles.
 Avoid driving at night if you have poor
eyesight. Night vision deteriorates with
age.
 Keep your car’s headlights, windows and
mirrors clean. Also, if you wear glasses,
make sure they are clean.
 Make sure you are well rested before
starting a long journey. Take a break every
other hour.
 Only eat light meals. Heavy meals have a
tendency to induce tiredness.
 Wild animals prefer to move at dusk and
dawn.
 Check the headlight levelling setting (see
page 91).
Towing the car
Front towing eye
WARNING
 Remember that the brake servo does
not operate when the engine is off.
Much greater pressure than normal
will therefore be required to operate
the brake pedal.
 Nor does the steering servo operate
when the engine is off. The steering
will therefore be much heavier than
usual.
 The towing vehicle should always be
heavier than the vehicle on tow.
 Never allow passengers to ride in the
car when it is on tow.
 Always seek professional help if the
car needs to be recovered.
 The ignition switch must be in the ON
position if the car is moved with the
engine not running.
 The steering wheel lock must be
disengaged before towing the car.
 The steering wheel lock disengages
when the remote control is inserted
into the ignition switch, if the battery
has sufficient charge.
WARNING
 Make sure that the towing eye is
screwed in tightly. It has a left-hand
thread!
 The towing eye is only designed for
towing the car on roads. It must not
be used to pull the car out of a ditch,
for example.
 Make sure that all bystanders keep a
suitable distance, in case the towing
eye or tow rope should snap. The
towing eye or tow rope could catapult
off and cause seriously injury.
 Never drive with the towing eye fitted
to the front bumper. Return it to its
designated storage space.
ProCarManuals.com

240 Car careLoading Your VehicleThis is an example of what your vehicle´s
Tire-Loading Information/Certification label
might look like. It is located on the B-pillar
and shows how much weight your vehicle
may properly carry. The label tells you the
proper size, and recommended inflation
pressures the the tires on your vehicle. It
also gives you important information about
the number of people that can be in your
vehicle and the total weight that you can
carry. This weight is called the Vehicle
Capacity Weight, and includes the weight of
all occupants, cargo and all nonfactory-
installed options.
Tire Terminology and DefinitionsAir Pressure: The amount of air inside the
tire pressing outward on each square inch of
the tire. Air pressure is expressed in pounds
per square inch (psi) or kilopascal (kPa).
Accessory Weight: This means the com-
bined weight of optional accessories, for
example, automatic transmission, power
steering, power brakes, power windows,
power seats, radio and air conditioning.
Aspect Ratio: The relationship of a tire´s
height to its width.
Belt: A rubber coated layer of cords that is
located between the plies and the tread.
Cords may be made from steel or other rein-
forcecing materials.
Bias Ply Tire: A pneumatic tire in which the
ply cords that extend to the beads are laid at
alternate angles substantially less than 90
degrees to the centerline of the tread.
Cold Inflation Pressure: The amount of air
pressure in a tire, measured in pounds per
square inch (psi) or kilopascal (kPa), before
a tire har built up heat from driving. See
“Inflation - Tire Pressure” on page 231.
Curb weight: This means the weight of a
motor vehicle with standard and optional
equipment including the maximum capacity
of fuel, oil and coolant, without passengers
and cargo.DOT Markings: A code molded into the
sidewall of a tire signifying that the tire is in
compliance with the U.S. Department of
Transportation motor vehicle safety stan-
dards. The DOT code includes the Tire
Identification Number (TIN), an alphanu-
meric designator which can also indentify
the tire manufacturer, production plant,
brand and date of production.
GVWR: Gross Vehicle Weight Rating see
“Loading Your Vehicle” on page 240.
GAWR FRT: Gross Axle Weight Rating for
the front axle, see “Loading Your Vehicle”
on page 269.
GAWR RR: Gross Axle Weight Rating for
the rear axle, see “Loading Your Vehicle” on
page 240.
Intended Outboard Sidewall: The side of
an asymmetrical tire that must always face
outward when mounted on a vehicle.
Kilopascal (kPa): The metric unit forair
pressure. There are 6.9 kPa to one psi.
Light Truck (LT-Metric) Tire: A tire used
on light duty trucks and some multipurpose
passenger vehicles.
Load Index: An assigned number ranging
from 1 to 279 that corresponds to the load
carrying capacity of a tire.
ProCarManuals.com

250 Car careWashingThe bodywork must be washed frequently.
When the car is new, the body should be
washed by hand using plain cold water and
a clean, soft brush through which the water
flows. Automatic carwashes should be
avoided when the car is new.
After 5–6 months the paintwork will have
hardened. To facilitate cleaning, a suitable
detergent can be added to the water, which
should be lukewarm.
Remove any bird droppings without delay,
as these can discolour the paintwork and
prove difficult to polish out. Lay a wad of wet
paper on the patch of dirt and leave it for a
minute or so. It will then be easy to wash off
the dirt.Use a soft cloth moistened with white spirit
to remove splashes of tar or asphalt. Do not
use strong cleaners, as these can dry out
the paintwork.
The underside of the car also needs wash-
ing regularly, and this should be done extra
thoroughly at the end of winter. Clean the
underside of the car by hand if the car is usu-
ally washed in an automatic car wash with-
out special facilities for underbody cleaning.
Never wash or leave the car to dry in the
sun, but wipe it dry with a chamois leather
immediately after washing to avoid smears
and streaks.Clean the inside of window glass using a
proprietary window cleaner. This is particu-
larly important when the car is new, as
upholstery and trim have a tendency to
sweat a little at first.
Keep the glass well polished, as this helps
to prevent misting.
Clean the outside of the windows with Saab
washer fluid. This is especially important if
the car has been washed in an automatic
car wash, as sometimes a wax treatment is
used that can contaminate the windshield
and impair the performance of the wipers.
NOTICEDo not use alcohol-based cleaners on the
plastic lenses of the front or rear lights, as
these can cause a crackling effect on the
lenses.
The door mirrors should be folded in
before the car enters an automatic car
wash.
ProCarManuals.com

284 IndexDriving in cold climates
___________ 175
Driving in deep water
____________ 183
Driving in hot climates ____________ 177
Driving techniques
______________ 173
Driving with a heavy load on hilly
roads
________________________ 155
Driving with a load
______________ 183
Driving with a roof load ___________ 182
Driving with the compact spare wheel
187
Driving with the trunk lid open
______ 183
EEDR
_________________________ 266
ESP, anti-skid system
____________ 165
Easy entry, Convertible ____________ 65
Economical motoring
____________ 173
Electric engine heater ____________ 174
Electric heating, front seats
___ 102
, 111
Electric windows
________________ 117
Electric windows, Convertible
_______ 69
Electrical system, technical data ____ 272
Electrically adjustable seats
________ 18
Electronic Stability Program (ESP)
__ 165
Electronic steering wheel lock
_____ 142
Emergency opening of the narrow
backrest
_____________________ 138
Emergency operation of the sunroof
_ 122
Engine bay, cleaning
____________ 249
Engine heater
__________________ 174
Engine immobilizer
_______________ 47Engine number
_________________ 278
Engine oil, checking
_____________ 196
Engine oil, grade
________________ 270
Engine oil, volume _______________ 271
Engine temperature gauge
_________ 80
Engine, description
______________ 193
Engine, technical data ____________ 270
Engines
_______________________ 271
Event Data Recorder
____________ 266
Extra electrical socket ____________ 126
FFacilitating entry to rear seat,
Convertible
____________________ 65
Factors affecting fuel consumption
__ 173
Filler cap
______________________ 148
Filling up ______________________ 147
Flat spots, tires
_________________ 232
Floor jack
_____________________ 246
Folding down the rear seat
________ 134
Front fog lights
__________________ 93
Front towing eye ________________ 184
Fuel gauge
_____________________ 81
Fuel grade _____________________ 271
Functions, car alarm
______________ 51
Fuse panel in luggage compartment
_225
Fuse table
_____________________ 224
Fuses
________________________ 222
GGDO, garage door opener
_________ 130
Gear selector indicator, automatic
transmission
___________________ 82
Gearbox number ________________ 278
General safety instructions,
Convertible
____________________ 54
Glove compartment
______________ 126
Glove compartment lighting
________ 219
HHandbrake
_____________________ 167
Hazard warning lights
_____________ 94
Head restraint, Convertible
_________ 66
Head restraints
__________________ 20
Headlight flasher _________________ 92
Headlight levelling ________________ 91
Headlights
______________________ 91
Heated door mirrors
_____________ 102
Hood
_________________________ 192
Horn __________________________ 116
Horn button
____________________ 116
IIf a tire goes flat
_________________ 237
Ignition switch
__________________ 140
Immobilizer
_____________________ 47
ProCarManuals.com

285 Index
Important considerations for driving
_ 144
Important information, petrol-engined
cars with catalytic converters
_____ 145
Indicator lights
___________________ 74
Inflation, tires __________________ 231
Instrument illumination, adjusting
____ 92
Interior lighting
_________________ 123
Interior lighting, Convertible
________ 70
Interior rearview mirror
___________ 129
Intermittent malfunctioning, central
locking
_______________________ 42
JJump starting
__________________ 187
KKey
___________________________ 40
Kick-down
_____________________ 155
LLATCH (child safety)
______________ 22
Labeling, tire sidewall ____________ 238
Labels and plates, location
________ 278
Lashing eyes
___________________ 137
Laying the car up
_______________ 169
Leather upholstery, cleaning
_______ 249Lighting in luggage compartment,
Convertible
____________________ 70
Limp-home
____________________ 144
Limp-home, automatic transmission
_156
Load carriers, roof
_______________ 182
Load indices, tires _______________ 239
Loading your vehicle _____________ 240
Load-through hatch ______________ 136
Locking a car with flat battery
_______ 43
Locks
__________________________ 40
Long-term parking
_______________ 169
Luggage compartment
___________ 134
Luggage compartment lighting
_ 124
, 138
Luggage compartment lighting,
Convertible
____________________ 70
Luggage compartment lighting,
changing
_____________________ 219
MMAXI fuses
____________________ 223
Main instrument panel
_____________ 74
Main/dipped beam
_______________ 92
Maintenance schedule ___________ 262
Manual climate control ____________ 98
Manual gear selection ____________ 158
Manual gearbox
________________ 152
Manual tripping of car alarm
________ 50
Materials used in the car, reclamation
255
Memory, driver’s seat
_____________ 19
Messages on SID, Convertible
______ 63Milometer
_______________________ 79
Mug holder ____________________ 124
NNew tires, buying
________________ 233
Night driving
___________________ 184
Number plate lighting, changing
____ 219
OORVR
________________________ 194
Oil capacity, engine
______________ 271
Opening handles
_________________ 40
Opening the soft top, Convertible
____ 56
Outside mirrors
_________________ 128
Owner assistance _______________ 264
PPanic function, car alarm
___________ 50
Park Brake Shift Lock
____________ 154
Park Brake Shift Lock, temporary
override
______________________ 156
Parking
_______________________ 167
Parking aid ____________________ 170
Parking brake __________________ 167
Parking on a hill _________________ 168
Pinch protection, electric windows
__ 118
ProCarManuals.com
