Seat belt not fastened warning light* When the ignition is swit-
ched on, this indicator light comes on if the driver has not fastened hisseat belt. Above 12 mph (20 kmh), this warning light flashes for two minutes accom-panied by an audible signal which
becomes progressively louder. Oncethe two minutes have elapsed, thewarning light remains on until the dri-ver fastens his seat belt.
Battery charge warning light
This indicates one of the following:
- faulty operation of the charging circuit,
- slack battery or starter terminals,
- a cut or slack alternator belt,
- an alternator failure.
Consult a PEUGEOT dealer.
Engine diagnostics warning light This comes on for a few
seconds each time the ignition is switched on. If it comes on with the engine run- ning, this indicates incorrect opera-tion of the injection, ignition or emis-
sion control system. There is a riskof damage to the catalytic converter(petrol engine only).
Consult a PEUGEOT dealer.
* According to destination. Water in diesel filter indicator*
There is a risk of damage to theinjection system.
Consult a PEUGEOT dealer as soon as possible.
Passenger air bag disarmed warninglight*
If the passenger air bag is disarmed, the warning light comes on whenthe ignition is switched on and itremains on.
Always consult a PEUGEOT dealer if the warning light flashes.
Low fuel levelwarning light
When this light first comes on, youhave enough fuel to drive approxi-
mately 30 miles (50 km) (The tank
capacity is approximately 55 litresfor petrol engines and 60 litres forDiesel engines). Diesel engine pre-heat warning light
Wait until the warning light goes out before starting the engine. If the temperature is high enough, the warning light comes on for less
than one second. You can start theengine without waiting.
INSTRUMENTS AND CONTROLS
30
Electronic stability control system(ESP/ASR) warninglight
This comes on for a few secondseach time the ignition is switched on.
Contact a PEUGEOT dealer if the ESP/ASR switch indicator lightflashes and this warning lightremains on or comes on while theengine is running and the vehicle ismoving. While the engine is running and the vehicle is moving, it flashes if thesystem is activated. It comes on permanently when it is disarmed.
