2004 Peugeot Expert Owner's Manual

50 -
19-07-2004
51
-
19-07-2004
Access
ELECTRONIC ENGINE
IMMOBILISER
This locks the engine control system
as soon as the ignition has been
switched off and therefore prevents
starting of the vehicle by anyone who
does not have the key.
The ignition key has an electronic chip
which has a special code. When the
ignition is switched on, the code must
be recognised for the vehicle to start.
If the system does not function cor-
rectly , the electronic engine immobi-
liser warning light, situated in the cen-
tre of the fascia, lashes rapidly when
the ignition is switched on (2nd notch).
In this case your vehicle will not start.
Contact a PEUGEOT dealer as soon
as possible.
Conidential card
The conidential card contains the iden-
tiication code necessary for any work
carried out by a PEUGEOT dealer on
the electronic immobiliser system. This
code is hidden by a ilm, which should
be removed only if necessary.
Keep your card in a safe place,
never inside the vehicle. Make a careful note of the
number on each key. The
key number is coded on the
label attached to the key.
If the keys are lost, your
PEUGEOT dealer can rapidly supply
you with new keys.
The high frequency remote control is
a sensitive system; do not operate it
while it is in your pocket as there is
a possibility that it may unlock your
vehicle, without you being aware of
it.
The remote control does not operate
when the key is in the ignition, even
when the ignition is switched off,
except for reprogramming.
Driving with the doors locked may
make access to the passenger
compartment by the emergency
services more dificult in an
emergency.
As a safety precaution (with children
on board), remove the ignition key
when you leave the vehicle, even for
a short time.
Do not repeatedly press the button of
your remote control out of range of
your vehicle.
You run the risk of stopping it from
working and the remote control
would have to be reprogrammed. When purchasing a second-hand
vehicle:
- ensure that you are given the
conidential card;
- have the key codes memorised by a PEUGEOT dealer, to ensure that
the keys in your possession are
the only ones which can start the
vehicle.
Do not make any modiications to
the electronic engine immobiliser
system.

52 -
19-07-2004
53
-
19-07-2004
Access
FRONT DOORS AND SLIDING
SIDE DOOR
Opening the doors from outside
(front and side doors)
Opening the doors from inside
(front doors)
The front door opening controls
permit complete unlocking of the
vehicle. Locking / Unlocking from the
inside
Front door
To lock, lower button
A.
To unlock and open, lift button A and
pull the handle towards you.
The opening/closing control of one
of the front doors permits complete
unlocking/locking of the vehicle.
Sliding side door
The side door opening/closing control
only controls the door concerned.
To lock, push down button B.
To unlock and open, raise button B
and pull the handle towards the rear. Note:
the sliding side door can be
secured in the fully open position.
To release it, pull the handle irmly
towards the front and slide the door.
Side door child lock
This prevents opening of the side
door from the inside. F Turn the control a quarter turn
using the ignition key.

52 -
19-07-2004
53
-
19-07-2004
Access
HINGED REAR DOORS
Opening the doors from outside
To open, pull the rear right door
handle towards you and open the
rear left door by pulling the lever on
the inside. Locking / Unlocking from inside
(Van)
To unlock and open, pull the handle
towards you.
To open the other door, push
lever
A.
Note: when closing from the inside,
close the vehicle's left-hand door irst
ensuring that lever A is in the vertical
position then close the right-hand
door. Opening the hinged rear doors to
180°
To open the rear doors to 180°,
release the check strap
B towards
you when the door is partially open.
When closing the door, the check
strap hooks itself in place again
automatically.
Opening the doors from inside
Each opening control only unlocks
the door concerned.

54 -
19-07-2004
55
-
19-07-2004
Access
OPENING THE BONNET
Inside the vehicle : pull the handle
on the right-hand side, under the
fascia.
BONNET STRUT
Secure the strut to hold the bonnet
open.
Before closing the bonnet, replace
the strut in its housing.
To close
Lower the bonnet and release it at
the end of its travel. Check that the
bonnet is locked.
Outside the vehicle
: lift the catch
and raise the bonnet.

54 -
19-07-2004
55
-
19-07-2004
Access
FILLING WITH FUEL
The engine must be switched off
when illing with fuel. F Insert the key then turn it to the
left.
F Remove the cap.
An indication on the cap reminds you
which type of fuel to use.
When you ill your tank, do not
continue after the third cut-off of the
pump. This could cause your vehicle
to malfunction.
The capacity of the tank is
approximately 80 litres. F After illing the tank, lock the cap.
Low fuel level When the minimum
fuel level in the tank is
reached, this warning
light comes on.
You have enough fuel remaining
to drive for approximately 30 miles
(50 km). Ensure that the right-hand
sliding side door is not
opened while you are illing
with fuel.
The key cannot be removed
from the lock until the cap has been
replaced on the fuel tank.
If the tank is illed with fuel which
does not conform to your vehicle's
engine, it is essential that the fuel
tank is drained before the engine is
switched on.

56 -
19-07-2004
57
-
19-07-2004
Visibility
In good or rainy weather,
both day and night, the
front fog lamps and the rear
fog lamp are dazzling and
are prohibited.
Do not forget to switch them off when
they are no longer needed.
THE LIGHTS STALK
Front and rear lights
Selection is by turning ring A. The
status is conirmed by the indicator
light on the instrument panel.
Lights off
Side lights
Dipped / main beam
headlamps
Dipped / Main beam change
Pull the stalk fully towards you.
Lights on buzzer
With the ignition off, when the driver's
door is opened, a buzzer sounds if
you have left your lights on.
Front fog lamps and rear fog
lamp
Rotate the ring forwards to switch
on and backwards to switch off. The
status is conirmed by the indicator
light on the instrument panel.
Fog lamps off
Vehicles itted with a rear fog
lamp (ring B) Rear fog lamp
This operates with the dipped / main
beam headlamps. The front fog lamps operate with the
side lights, the dipped headlamps
and the main beam headlamps.
Front and rear fog
lamps (2nd notch of
the ring forwards).
Front fog lamps (irst notch
of the ring forwards)
Vehicles itted with front fog
lamps and a rear fog lamp (ring C)
Direction indicators (lashers)
Left: downwards.
Right: upwards.

56 -
19-07-2004
57
-
19-07-2004
Visibility
When using a car wash,
switch off the ignition or
check that the windscreen
wipers stalk is in position
0
-Off.
In winter, you are advised to wait until
the windscreen has been de-iced
fully before operating the windscreen
wipers stalk.
WINDSCREEN WIPER STALK
Front windscreen wiper
2 Fast wipe (heavy rain).
1 Normal wipe (moderate rain).
l Intermittent wipe.
0 Off.
â Single wipe
(press downwards). Operation
In position
1 or 2, when the vehicle
stops, the windscreen wiper changes
to a lower wiping speed, then
resumes its initial speed when the
vehicle starts again.
In the Intermittent position, the wiping
speed is proportional to the speed of
the vehicle. Windscreen wash
Pull the wiper stalk towards you.

The windscreen wash, then the
windscreen wipers, operate for a
speciied time.

58 -
19-07-2004
59
-
19-07-2004
Visibility
ELECTRIC WINDOWS
1 - Driver's electric window switch.
2 - Passenger's electric window switch.
SLIDING SIDE WINDOW
To open the window, pull control A
and push the window forwards.
To close the window, push it towards
the rear and press control B to lock
it.
Always remove the key
from the ignition when
leaving the vehicle, even
for a short time.
If an obstacle is detected
when operating the electric windows,
you must reverse the movement of
the window. To do this, press the
control concerned.
When the driver operates the
passenger electric window controls,
he must ensure that no one is
preventing correct closing of the
windows.
The driver must ensure that
passengers use the electric windows
correctly.
Be aware of children when operating
the windows.
Notes:
In the event of unwanted opening
of the window when closing (for
example, in the case of frost), press
the control until the window is fully
open, then pull it again until the
window closes. Continue to pull the
control for approximately one second
after closing.
Following reconnection of the battery,
in the event of a malfunction, release
the control and pull it again until the
window closes completely.
Continue to pull the control for
approximately one second after
closing.
Automatic operation
(driver's
side): F press or pull the switch fully.
One touch completely opens the
window.
You have two options:
Manual operation: F
press or pull the switch gently.
The window stops as soon as the
switch is released.
