2004 Peugeot 307 SW Owner's Manual

76
15-03-2004
77
15-03-2004
YOUR 307 SW IN DETAIL
5. Air intake Pressing button 5 permits re-
circulation of the interior air.
Recirculation, indicated by
illumination of the indicator
light, prevents exterior odours and
smoke from entering the passenger
compartment.
Used simultaneously with the air
conditioning, recirculation enables
cooling performance to be improved.
Used in a humid climate, recircu-
lation may result in misting of the
windows.
As soon as possible, switch button 5
to the outside air position, to prevent
deterioration of the air quality. The
indicator light switches off. 6. Demisting the rear screen and
the mirrors
With the engine running,
pressing the button once
demists the rear screen and
the mirrors.
This switches off automatically after
approximately twelve minutes.
Pressing again activates demisting
for a further twelve minutes.
It is possible to stop demisting by
pressing the button again before the
end of the twelve minutes.
Important precaution
Operate the air conditioning system
for 5 to 10 minutes, once or twice a
month, to keep it in perfect working
order.
If the system does not produce
cold air, do not use it and contact a
PEUGEOT dealer.
4. Air low adjustment
Turn the control from posi-
tion 1 to position 4 to obtain
an air low suficient to en-
sure your comfort.

78
15-03-2004
79
15-03-2004
AUTOMATIC AIR CONDITIONING
Automatic operation
2. Automatic comfort programmePress the AUTO button. The
system automatically adjusts
the atmosphere inside the
vehicle in accordance with
the value that you have chosen. To
do this, it controls the temperature,
the low, the distribution and the
intake of air as well as the air con-
ditioning. Note:
for your comfort, when the
engine is switched off, the settings are
retained until the engine is switched
on again, if the temperature in the
passenger compartment has not al-
tered signiicantly; otherwise, opera-
tion resumes in automatic mode.
3. Automatic visibility programme
In some cases, the automat-
ic comfort programme may
not be suficient for de-icing
or demisting of the windows
(humidity, several passengers, ice
etc.). Select this programme to clear
the windows quickly.
To exit this programme and return to
the automatic comfort programme,
press the AUTO button.
Manual operation
If you wish, you can make a different
choice from that offered by the sys-
tem by changing a setting. The other
functions will still be controlled auto-
matically. Pressing the AUTO button
returns the system to completely au-
tomatic operation.
1. Temperature adjustment
The value indicated on the
display corresponds to a
level of comfort and not to
a temperature in degrees
Celsius or Fahrenheit.
Press the arrows 1 (up and down) to
change this value. A setting around
21 enables a comfortable tempera-
ture to be obtained.
YOUR 307 SW IN DETAIL

78
15-03-2004
79
15-03-2004
4. Air conditioningPress this button to stop air
cooling. The symbol ECO is
displayed. Automatic opera-
tion of the air conditioning is
resumed when the button is pressed
again. The symbol A/C is displayed.
Note
It is quite normal that the condensa-
tion created by the air conditioning
results in a low of water under the
vehicle when it is stationary.
To prevent condensation on the
inside of the vehicle in cold or wet
weather, you are advised to avoid
using the ECO mode.
5. Air distribution Pressing this button several
times in succession enables
the air low to be directed in
turn towards:
- the windscreen (de-icing or demisting),
- the windscreen and the footwells,
- the footwells,
- the centre and side vents and the footwells,
- the centre and side vents. 6. Air low
The low of air can be
increased or reduced
by pressing buttons +
or - respectively.
7. Air intake 8. Switching the system off
The OFF button switches
off all the functions of the
system.
Temperature-related comfort
is no longer guaranteed but a slight
low of air is maintained to prevent
condensation and to renew the air.
Pressing the OFF, AUTO , or vis-
ibility button again reactivates the
system with the values set before it
was switched off.
Note: if you wish to cut off the low
of air completely, press the air intake
button 7.
9. Demisting the rear screen and the mirrors
Press this button to demist
the rear screen and the mir-
rors. Demisting switches off
automatically. It is possible
to stop operation of the demisting
before it is switched off automatically
by pressing the button again.
Important precaution
Operate the air conditioning for 5 to
10 minutes, once or twice a month, to
keep it in good working order.
If the system does not produce cold
air, do not use it and contact your
PEUGEOT dealer.
Press this button for recir-
culation of the interior air.
Recirculation, shown on the
display, enables the passen-
ger compartment to be isolated from
exterior odours and smoke.
Avoid prolonged recirculation of inte-
rior air. To do this, press the button
again to resume automatic manage-
ment of the intake of air.
Note: To prevent condensation on
the inside of the vehicle in cold or wet
weather, you are advised to avoid us-
ing this mode.
YOUR 307 SW IN DETAIL

80
15-03-2004
81
15-03-2004
YOUR 307 SW IN DETAILFRONT SEATS
1 - Forwards/backwards
adjustment
Lift the control and slide the seat
forwards or backwards.
2 - Seat back angle adjustment
Push the handle towards the rear.
3 - Driver's or passenger's seat height adjustment
Pull the handle upwards or push it
downwards as many times as neces-
sary to obtain the required position.
4 - Armrests
These can be folded down and are
removable.
To remove them, press the button
located between the armrest and the
side of the seat and pull it.

80
15-03-2004
81
15-03-2004
YOUR 307 SW IN DETAIL
5 - Head restraint height and angle adjustment
To raise or lower the restraint, pull it
forwards, sliding it at the same time. Active seat back
(front seat)
This possesses a device to prevent
'whiplash'.
When there is an impact from the
rear, the action of the body on the
seat back forces the head restraint
forwards and upwards, preventing
the head being thrown backwards.
6 - Storage drawers
There is a storage drawer under
each front seat.
- To open it, lift it and pull.
- To take it out, open it to its full extent, press the ends of the slides and lift
it, then remove it completely.
- To put it back in place, at the end of its travel, press the top of the
drawer to secure it.
Do not place heavy objects in the
drawers.
Under the front passenger seat, the
layout of the loor allows for storage
of a irst aid kit and a warning triangle
(small version).
7 - "Aircraft" style table
There is an 'aircraft' style table, itted
with a can holder, at the rear of each
front seat. Never drive with the head
restraints removed; they
should be in place and
correctly adjusted.REAR HEAD RESTRAINTS
These have a high position for when
they are in use and a low position for
when they are stored.
The head restraints are
also remov-
able.
To remove them, pull upwards as
far as the stop, then press the lug
(side seat) or on the two lugs (centre
seat).
The adjustment is correct when
the upper edge of the head re-
straint is level with the top of
the head.
To remove the head restraint, place it
almost in the top position, lift the lug
using a coin and pull it.
To put it back in position, locate the
stems of the restraint in the holes,
taking care to keep them in line with
the seat back.

80
15-03-2004
81
15-03-2004
YOUR 307 SW IN DETAIL
5 - Head restraint height and angle adjustment
To raise or lower the restraint, pull it
forwards, sliding it at the same time. Active seat back
(front seat)
This possesses a device to prevent
'whiplash'.
When there is an impact from the
rear, the action of the body on the
seat back forces the head restraint
forwards and upwards, preventing
the head being thrown backwards.
6 - Storage drawers
There is a storage drawer under
each front seat.
- To open it, lift it and pull.
- To take it out, open it to its full extent, press the ends of the slides and lift
it, then remove it completely.
- To put it back in place, at the end of its travel, press the top of the
drawer to secure it.
Do not place heavy objects in the
drawers.
Under the front passenger seat, the
layout of the loor allows for storage
of a irst aid kit and a warning triangle
(small version).
7 - "Aircraft" style table
There is an 'aircraft' style table, itted
with a can holder, at the rear of each
front seat. Never drive with the head
restraints removed; they
should be in place and
correctly adjusted.REAR HEAD RESTRAINTS
These have a high position for when
they are in use and a low position for
when they are stored.
The head restraints are
also remov-
able.
To remove them, pull upwards as
far as the stop, then press the lug
(side seat) or on the two lugs (centre
seat).
The adjustment is correct when
the upper edge of the head re-
straint is level with the top of
the head.
To remove the head restraint, place it
almost in the top position, lift the lug
using a coin and pull it.
To put it back in position, locate the
stems of the restraint in the holes,
taking care to keep them in line with
the seat back.

82
15-03-2004
83
15-03-2004
YOUR 307 SW IN DETAIL
REAR SEATS
Forwards-backwards adjustment*
Lift the bar A and slide the seat
forwards or backwards.
From the 3rd row, you can pull the
strap B and slide the seat forwards
or backwards.
This manoeuvre makes it easier for
passengers to exit the 3rd row, when
the 2nd row seat is folded.
Seat back angle adjustment
Pull one strap C (two straps for each
side seat, one for the centre seat)
and adjust to the required angle.
Release the strap to lock.
To adjust the angle of the seat from
the 3rd row or the boot, pull the strap
C at the rear of the seat.
Note: the additional seat can be an-
gled and folded by means of a single
strap C at the rear of the seat on the
right or on the left. Folding a side seat:
access to the 3rd row:
Place the head restraint in the low
position.
Push the seat back fully
using bar
A .
Fold the seat back onto the cushion
using the strap C.
Note: you can lock the seat back
in this position (e.g. for removal) by
pressing down on it.
Push control D upwards to release
the rear feet.
Place the seat in the "folded" position.
exit from the 3rd row or folding
from the boot:
Place the head restraint in the low
position.
Push the seat back fully using the
strap B. Fold the seat back onto the cushion
using the strap
C.
Note: you can lock the seat back
in this position (for removal) by
pressing down on it.
Push the control D upwards to
release the rear feet.
Place the seat in the folded position.
While driving attach the retaining
strap (contained in the storage
pocket of a front seat):
- on the 2nd row: on one side, to the carrying handle G and on
the other side, to the grab han-
dle,
- on the 3rd row: on one side, to the carrying handle G and on
the other side, to the rear arm-
rest grab handle.
* Except additional seat.

82
15-03-2004
83
15-03-2004
YOUR 307 SW IN DETAIL
Centre seat table position
Place the head restraint in the low
position.
Fold the seat back onto the cushion
using the strap C.
You now have a small table with four
can holders, two pen holders and a
document holder. Folding the centre seat
Place the head restraint in the low
position.
Push the seat back fully
using the
bar A or the strap B.
Fold the seat back onto the cushion
using the strap C.
Note: you can lock the seat back
in this position (for removal) by
pressing down on it.
Push control D upwards to release
the rear feet.
Place the seat in the folded position.
While driving, attach the retaining
strap (contained in the storage
pocket of one of the front seats)
on one side to the carrying han-
dle G and on the other side, to the
grab handle. Folding an additional seat
Place the head restraint in the low
position.
Pull the strap
C (at the rear of the
seat to the right or to the left) back-
wards then press on the seat back to
release it, while continuing to pull the
strap.
Fold the seat back onto the seat
cushion.
Note: you can lock the seat back
in this position (for removal) by
pressing down on it.
Push the two levers E upwards to
unlock the rear feet.
Place the seat in the folded position.
While driving, attach the retaining
strap (contained in the storage
pocket of the additional seat) on
one side to the carrying handle G
and on the other side, to the rear
armrest grab handle.
