2004 Peugeot 206 Dag Owner's Manual

102
14-06-2004
103
14-06-2004
YOUR 206 IN DETAIL
THE LIGHTS STALK
Front and rear lights
Selection is by turning ring A. Dipped/Main beam change
Pull the stalk towards you.
Note:
with the ignition off and the
automatic lighting function switched
off, when the driver's door is opened,
a buzzer sounds if you have left your
lights on.
Front fog lamps and rear fog lamp
Rotate the ring forwards to switch on
and backwards to switch off. The sta-
tus is conirmed by the indicator light
on the instrument panel. Vehicles itted with front fog
lamps and a rear fog lamp (ring C)
Side lights Dipped/main beam
headlampsAutomatic switching on
of lights Rear fog lamp Front fog lamps (irst rotation
of the ring forwards)
Front and rear fog
lamps (2nd rotation of
the ring forwards).
Note: to switch off the rear fog lamp
and the front fog lamps, turn the ring
backwards twice in succession.
Note: when the lights are switched
off automatically or when the dipped
headlamps are switched off manu-
ally, the front fog lamps, the rear fog
lamp and the side lights remain on
(turn the ring backwards to switch off
the front fog lamps. The side lights
then switch off).
Vehicles itted with a rear fog
lamp (ring B)
This only operates with the dipped/
main beam headlamps.
Note:
when the lights are switched
off automatically, the rear fog lamp
and the dipped headlamps remain
on (turn the ring backwards to switch
off the rear fog lamp. The dipped
headlamps and side lights then
switch off). The front fog lamps operate with
the side lights and the dipped head-
lamps.
When the main beam headlamps are
switched on, the front fog lamps are
switched off. They are switched on
again when the main beam head-
lamps are switched off.
Lights off

102
14-06-2004
103
14-06-2004
YOUR 206 IN DETAIL
"Follow me home" lighting
When you leave your vehicle, the
side lights and dipped headlamps
can be left on for approximately
30 seconds.
To do this:
- place the key in the STOP posi-
tion,
- place the lights stalk in the 0 posi-
tion,
- lash the headlamps,
- get out of the vehicle and lock it.AUTOMATIC SWITCHING ON
OF LIGHTS
The side lights and dipped beam
headlamps switch on automati-
cally if the light is poor and when the
windscreen wipers operate continu-
ously and switch off when the light
becomes bright enough or the wind-
screen wipers are switched off.
In foggy weather or in snow, the
brightness sensor can detect
suficient light, the lights will not
come on automatically.
This function is active when the vehi-
cle is supplied
to the customer.
To disarm or activate the function:
- Place the key in the accessories position (1st notch),
- Place the lights stalk in the AUTO/0
position,
- Press the end of the lights stalk for more than four seconds.
Do not cover the brightness sen-
sor, coupled with the rain sensor,
located in the centre of the wind-
screen, behind the interior mirror.
It is used for automatic switching
on of the lights.
Operating check
Activation
The activated function is accompa-
nied by an audible signal and a mes-
sage on the multifunction display.
Disarming
The disarmed function is accompa-
nied by an audible signal.
When the driver uses the manual
lighting controls, the function is tem-
porarily disarmed.
If the brightness sensor does not
function correctly, the lights come
on accompanied by an audible signal
and a message on the multifunction
display.
Contact a PEUGEOT dealer.
In good or rainy weather,
both day and night, the
front fog lamps and the
rear fog lamp are dazzling
and are prohibited.
Do not forget to switch them off
when they are no longer needed.
Direction indicators (lashers) Left: downwards.
Right: upwards.

102
14-06-2004
103
14-06-2004
YOUR 206 IN DETAIL
"Follow me home" lighting
When you leave your vehicle, the
side lights and dipped headlamps
can be left on for approximately
30 seconds.
To do this:
- place the key in the STOP posi-
tion,
- place the lights stalk in the 0 posi-
tion,
- lash the headlamps,
- get out of the vehicle and lock it.AUTOMATIC SWITCHING ON
OF LIGHTS
The side lights and dipped beam
headlamps switch on automati-
cally if the light is poor and when the
windscreen wipers operate continu-
ously and switch off when the light
becomes bright enough or the wind-
screen wipers are switched off.
In foggy weather or in snow, the
brightness sensor can detect
suficient light, the lights will not
come on automatically.
This function is active when the vehi-
cle is supplied
to the customer.
To disarm or activate the function:
- Place the key in the accessories position (1st notch),
- Place the lights stalk in the AUTO/0
position,
- Press the end of the lights stalk for more than four seconds.
Do not cover the brightness sen-
sor, coupled with the rain sensor,
located in the centre of the wind-
screen, behind the interior mirror.
It is used for automatic switching
on of the lights.
Operating check
Activation
The activated function is accompa-
nied by an audible signal and a mes-
sage on the multifunction display.
Disarming
The disarmed function is accompa-
nied by an audible signal.
When the driver uses the manual
lighting controls, the function is tem-
porarily disarmed.
If the brightness sensor does not
function correctly, the lights come
on accompanied by an audible signal
and a message on the multifunction
display.
Contact a PEUGEOT dealer.
In good or rainy weather,
both day and night, the
front fog lamps and the
rear fog lamp are dazzling
and are prohibited.
Do not forget to switch them off
when they are no longer needed.
Direction indicators (lashers) Left: downwards.
Right: upwards.

104
14-06-2004
105
14-06-2004
YOUR 206 IN DETAIL
WINDSCREEN WIPER STALK
Front windscreen wiper with
intermittent wipe
2 Fast wipe (heavy rain).
1 Normal wipe (moderate
rain).
l Intermittent wipe.
0 Off.
ê Single wipe (press
downwards).
In the Intermittent position, the wiping
speed is in proportion to the vehicle
speed. Front windscreen wiper with
automatic wipe
2
Fast wipe (heavy rain).
1 Normal wipe (moderate
rain).
AUTO Automatic wipe.
0 Off.
ê Single wipe (press
downwards).
In the AUTO position, the wiping
speed is in proportion to the intensity
of the rainfall. The command must be reactivated
each time the ignition is switched
back on:
- move the stalk to any position,
- then move it back to the required
position.
Windscreen and headlamp wash
Pull the windscreen wiper stalk to-
wards you. The windscreen wash
then the windscreen wipers operate
for a ixed period.
The windscreen wash and head-
lamp wash operate simultaneously
for two seconds, only if the head-
lamps are on.

104
14-06-2004
105
14-06-2004
YOUR 206 IN DETAIL
Automatic timed windscreen
wipers
In the AUTO position, the wind-
screen wipers operate automatically
and adapt their speed to the inten-
sity of the rainfall . Do not cover the rain sen-
sor located on the wind-
screen behind the interior
mirror.
When using an automatic car
wash, switch off the ignition or
check that the wiper stalk is not in
the automatic position.
In winter, it is advisable to wait
for the windscreen to completely
clear of ice before operating the
automatic wipe. Rear screen wiper
Rear screen washTurn ring
A to the irst notch
for intermittent wiping.
If the ignition is switched
off, it is necessary to reac-
tivate the control each
time. To do this, move the stalk to
any position, then move it back to the
required position .
Automatic rear screen wiper
When the windscreen wipers control
is activated and you engage reverse
gear, the rear screen wiper operates
intermittently.
Note: if you use a bicycle carrier,
consult a PEUGEOT dealer to have
this function deactivated or install a
speciic bicycle carrier approved by
PEUGEOT.
Turn ring A past the irst
notch; the screen wash then
the wiper operate for a ixed
period.
206 SW: the rear screen wiper and
rear screen wash functions are dis-
armed automatically when the rear
screen is open.
Operating check
Activation
When the function is activated, the
message
"Automatic wiping active"
appears on the multifunction display.
In the event of malfunction , the
driver is informed by an audible sig-
nal and the message "Auto wiper
fault" on the multifunction display.
In the event of malfunction in the
AUTO position, the windscreen wiper
will operate in intermittent mode.
Contact a PEUGEOT dealer.

106
14-06-2004
107
14-06-2004
YOUR 206 IN DETAIL
TRIP COMPUTER
Pressing the button on the end of the
wash/wipe stalk enables the follow-
ing data to be displayed:
Display B
- the range
- the distance travelled
- the average consumption
- the current consumption
- the average speed
Zero reset
Press the stalk for more than two
seconds.
Monochrome screen CT
- the 'vehicle' tab with:
• range, current consumption and
the distance still to be driven,
- tab '1' (route '1') with:
• the distance driven, the average consumption and the average
speed calculated over route "1"
- tab '2' (route '2') with the same fea-
tures.
It also permits access to the warning
log information.
Zero re-set
When the required route is displayed,
press the button for more than two
seconds.

106
14-06-2004
107
14-06-2004
YOUR 206 IN DETAIL
Range
This shows the distance that can still
be covered with the fuel remaining in
the tank.
Note: this igure may increase if
there is a change in the style of driv-
ing or the road surface, producing a
signiicant drop in current consump-
tion.
When the range is less than 20 miles
(30 km), three segments are dis-
played. After illing with fuel, the
range is displayed when it exceeds
62 miles (100 km).
If horizontal segments are displayed
for long periods instead of digits,
contact a PEUGEOT dealer.
Current consumption
This is the average quantity of fuel
consumed during the last few sec-
onds.
This function is displayed only when
the vehicle is travelling at a speed
greater than 20 mph (30 km/h).
Average consumption
This is the average fuel consump-
tion since the computer was last set
to zero.
Distance travelled
This indicates the distance travelled
since the computer was last set to
zero.
Distance remaining to be
travelled
This is the distance remaining to the
destination. It can either be calcu-
lated by the navigation if guidance
is activated, or entered by the user,
minus the distance covered since the
distance was entered.
Note: if digits are missing, dashes
are displayed in their place.
Average speed
This is the average speed calculated
since the computer was last set to
zero (with the ignition on).
The warning log
This summarises the active warning
messages by displaying them on the
multi-function display.
The routes
The routes "1" and ''2'' are independ-
ent but have identical application.
Route "1" for example allows you
to make daily calculations and route
"2" monthly calculations.

106
14-06-2004
107
14-06-2004
YOUR 206 IN DETAIL
TRIP COMPUTER
Pressing the button on the end of the
wash/wipe stalk enables the follow-
ing data to be displayed:
Display B
- the range
- the distance travelled
- the average consumption
- the current consumption
- the average speed
Zero reset
Press the stalk for more than two
seconds.
Monochrome screen CT
- the 'vehicle' tab with:
• range, current consumption and
the distance still to be driven,
- tab '1' (route '1') with:
• the distance driven, the average consumption and the average
speed calculated over route "1"
- tab '2' (route '2') with the same fea-
tures.
It also permits access to the warning
log information.
Zero re-set
When the required route is displayed,
press the button for more than two
seconds.
