2004 NISSAN 350Z Owner´s Manual

Your NISSAN vehicle is covered by the following
emission warranties.
For US:

Emission Defects Warranty

Emissions Performance Warranty
(See Warranty Information Booklet for de-
tails.)
For Canada:

Emission Control System Warranty
Details of these warranties may be found with
other vehicle warranties in your Warranty Infor-
mation Booklet that comes with your NISSAN
vehicle. If you did not receive a Warranty Infor-
mation Booklet, or it has become lost, you may
obtain a replacement by writing to:

Nissan North America, Inc.
Consumer Affairs Department
P.O. Box 191
Gardena, CA 90248-0191

Nissan Canada Inc.
5290 Orbitor Drive
Mississauga, Ontario, L4W 4Z5
If you believe that your vehicle has a defect
which could cause a crash or could cause
injury or death, you should immediately inform
the National Highway Traffic Safety Adminis-
tration
(NHTSA)
in addition to notifying
NISSAN.
If
NHTSA
receives similar complaints, it may
open an investigation, and if it finds that a
safety defect exists in a group of vehicles, it
may order a recall and remedy campaign.
However,NHTSA
cannot become involved
in individual problems between you, your
dealer, or NISSAN.
To contact
NHTSA
, you may call the Auto
Safety Hotline toll-free at (888) 327-4236.
You may also write to:NHTSA
, U.S. Depart-
ment of Transportation, Washington, D.C.
20590. You can also obtain other information
about motor vehicle safety from the Hotline.
You may notify NISSAN by contacting our Con-
sumer Affairs Department, toll-free, at 1-800-
NISSAN-1 (1-800-647-7261).Due to legal requirements in some states/
areas, your vehicle may be required to be in what
is called the “ready condition” for an
Inspection/Maintenance (I/M) test of the emis-
sion control system.
The vehicle is set to the “ready condition” when
it is driven through certain driving patterns.
Usually, the “ready condition” can be obtained
by ordinary usage of the vehicle.
If a powertrain system component is repaired or
the battery is disconnected, the vehicle may be
reset to a not “ready condition”. Before taking
the I/M test, drive the vehicle through the follow-
ing pattern to set the vehicle to the ready
condition. If you cannot or do not want to
perform the driving pattern, a NISSAN dealer
can conduct it for you.
WARNING
Always drive the vehicle in a safe and
prudent manner according to traffic
conditions, and obey all traffic laws.
1. Start the engine. Allow the engine to idle until
the engine coolant temperature gauge needle
points between the C and H (normal operat-
ing temperature).
EMISSIONCONTROL SYSTEM
WARRANTYREPORTING SAFETY DEFECTS
(US only)READINESS FOR INSPECTION/
MAINTENANCE (I/M) TEST (US
only)9-22
Technical and consumer information


04.5.17/Z33-D/V5.0


2. Accelerate the vehicle to 55 MPH (88 km/h),
then quickly release the accelerator pedal
completely and keep it released for at least 6
seconds.
3. Quickly depress the accelerator pedal for a
moment, then drive the vehicle at a speed of
53 to 60 MPH (86 to 96 km/h) for at least 5
minutes.
4. Stop the vehicle. Leave the engine running.
5. Accelerate the vehicle to 35 MPH (55 km/h)
and maintain the speed for 20 seconds.
6. Repeat steps 4 and 5 at least 3 times.
7. Accelerate the vehicle to 55 MPH (88 km/h)
and maintain the speed for at least 3 minutes.
8. Stop the vehicle. Place the automatic trans-
mission gear selector lever in the P (Park) or
N (Neutral) position or the manual transmis-
sion shift lever in the N position.
9. Turn the engine off.
10.Repeat steps 1 through 8 at least one more
time.
If step 1 through 7 is interrupted, repeat the
preceding step. Any safe driving mode is ac-
ceptable between steps. Do not stop the engine
until step 7 is completed.Your vehicle is equipped with a variety of com-
puters that monitor and control a number of
systems to optimize performance and help ser-
vice technicians with diagnosis and repair. De-
pending on the equipment on your vehicle, some
of the computers monitor emission control sys-
tems, braking systems and air bag systems, just
to name a few. Some data about vehicle opera-
tion may be stored in the computers for use
during servicing. Other data may be stored if a
crash event occurs. For example, air bag readi-
ness, air bag performance, and seat belt use by
the driver or passenger may be recorded, de-
pending on vehicle equipment. These types of
systems are sometimes called Event Data Re-
corders.
Special equipment can be used to access the
electronic data that may be stored in the vehi-
cle’s computers (sounds are not recorded).
NISSAN and NISSAN dealers have equipment
to access some of this data; others may also
have this equipment. The data may be retrieved
during routine vehicle servicing or for special
research. It might also be accessed with the
consent of the vehicle owner or lessee, in re-
sponse to a request by law enforcement, or as
otherwise required or permitted by law.
EVENT DATA RECORDERS
Technical and consumer information
9-23


04.5.17/Z33-D/V5.0


A genuine NISSAN Service Manual is the best
source of service and repair information for your
vehicle. Filled with wiring diagrams, illustrations
and step-by-step diagnostic and adjustment
procedures, this manual is the same one used by
the factory trained technicians working at
NISSAN dealerships. Also available are genuine
NISSAN Owner’s Manuals, and genuine
NISSAN Service and Owner’s Manuals for older
NISSAN models.For USA:
For current pricing and availability of genuine
NISSAN Service Manualsfor the 2000 model
year and later, contact:
Tweddle Litho Company
1-800-639-8841
www.nissan-techinfo.com
For current pricing and availability of genuine
NISSAN Service Manualsfor the 1999 model
year and prior, see a NISSAN dealer, or contact:
DDS Distribution Services, Ltd.
20770 Westwood Road
Strongsville, OH 44136
1-800-247-5321For current pricing and availability of genuine
NISSAN Owner’s Manualsfor the 2004
model year and prior, see a NISSAN dealer, or
contact:
DDS Distribution Services, Ltd.
20770 Westwood Road
Strongsville, OH 44136
1-800-247-5321
For Canada:
To purchase a copy of a genuine NISSAN
Service Manual or Owner’s Manual please con-
tact your nearest NISSAN dealer. For the phone
number and location of a NISSAN dealer in your
area call the NISSAN Information Center at
1-800-387-0122 and a bilingual
NISSAN representative will assist you.
Also available are Genuine NISSAN Service and
Owner’s Manuals for older NISSAN models.
IN THE EVENT OF A COLLISIONUnfortunately, accidents do occur. In this unlikely
event, there is some important information you
should know. Many insurance companies rou-
tinely authorize the use of non-genuine collision
parts in order to cut costs, among other reasons.
OWNER’S MANUAL/SERVICE
MANUAL ORDER INFORMATION9-24
Technical and consumer information


04.5.17/Z33-D/V5.0


Insist on the use of Genuine NISSAN
Collision Parts!If you want your vehicle to be restored using
parts made to NISSAN’s original exacting speci-
fications — if you want to help it to last and hold
its resale value, the solution is simple.Tell your
insurance agent and your repair shop to
only use Genuine NISSAN Collision Parts.
NISSAN does not warrant non-NISSAN parts,
nor does NISSAN’s warranty apply to damage
caused by a non-genuine part.
Using Genuine NISSAN Parts can help protect
your personal safety, preserve your warranty
protection and maintain the resale value of your
vehicle. And if your vehicle was leased, using
Genuine NISSAN Parts may prevent or limit
unnecessary excess wear and tear expenses at
the end of your lease.
NISSAN designs its hoods with crumple zones
to minimize the risk that the hood will penetrate
the windshield of your vehicle in an accident.
Non-genuine (imitation) parts may not provide
such built in safeguards. Also, non-genuine
parts often show premature wear, rust and cor-
rosion.Why should you take a chance?In over 40 states, the law says you must be
advised if non-genuine parts are used to repairyour vehicle. And some states have enacted
laws that restrict insurance companies from
authorizing the use of non-genuine collision
parts during the new vehicle warranty. These
laws help protect you, so you can take action to
protect yourself.
It’s your right!If you should need further information visit us at:
www.nissanusa.com.
Technical and consumer information
9-25


04.5.17/Z33-D/V5.0


MEMO9-26
Technical and consumer information


04.5.17/Z33-D/V5.0


10 Index
A
ABS (Anti-lock brake system)................................ 5-20
Air bag ON/OFF switch .......................................... 1-25
Air bag system
Front (See supplemental front air bag
system) .................................................................. 1-15
Side and curtain (See supplemental side air bag
and curtain side-impact air bag system) ...... 1-17
Air bag warning labels ............................................. 1-20
Air bag warning light .................................... 1-21, 2-14
Air cleaner housing filter.......................................... 8-18
Air conditioner
Air conditioner operation ..................................... 4-3
Air conditioner service ................................ 4-3, 4-6
Air conditioner specification label .................. 9-12
Air conditioning system refrigerant and lubricant
recommendations ......................................... 4-6, 9-6
Heater and air conditioner (automatic)............ 4-3
Alcohol, drugs and driving......................................... 5-5
Anchor point location, Top tether strap .............. 1-37
Antenna ........................................................................ 4-20
Anti-lock Brake System (ABS) .............................. 5-20
Anti-lock brake warning light.................................. 2-11
Appearance care
Exterior appearance care .................................... 7-2
Interior appearance care ..................................... 7-4
Audible reminders ..................................................... 2-17
Audio operation precautions ..................................... 4-7Audio system ................................................................ 4-6
Autochanger, Compact Disc (CD) ....................... 4-18
Automatic
Anti-glare inside mirror ...................................... 3-17
Automatic adjusting function
(front windows) ................................................... 2-37
Automatic passenger seatback tilt
function......................................................... 1-5, 3-22
Automatic transmission fluid (ATF) ................ 8-12
Driving with automatic transmission........ 5-6, 5-9
Transmission selector lever lock release ...... 5-12
Avoiding collision and rollover .................................. 5-5
B
Battery .......................................................................... 8-15
Battery saver system ......................................... 2-23
Battery replacement
Remote keyless entry system............................. 3-8
Before starting the engine ......................................... 5-8
Belts (See drive belts) ............................................. 8-17
Brake
Anti-lock brake system (ABS) ......................... 5-20
Brake and clutch fluid ....................................... 8-13
Brake booster ...................................................... 8-22
Brake fluid............................................................. 8-13
Brake pedal .......................................................... 8-21
Brake pedal check ............................................. 8-21
Brake system ....................................................... 5-20Parking brake check............................... 5-14, 8-21
Parking brake operation .................................... 5-14
Warning light ....................................................... 2-12
Break-in schedule ..................................................... 5-17
Brightness control, Instrument panel ................... 2-24
Bulbcheck/instrument panel.................................. 2-11
Bulbreplacement ...................................................... 8-25
C
Capacities and recommended fuel/lubricants...... 9-2
Car phone or CB radio............................................ 4-20
Cassette player (See audio system) .................... 4-17
Catalytic converter, Three way catalyst ................. 5-3
CD care and cleaning .............................................. 4-20
Child restraints ........................................................... 1-29
Installation on front passenger seat............... 1-31
Precautions on child restraints........................ 1-29
Top tether strap anchor point location ......... 1-37
Child safety ................................................................. 1-25
Chimes, Audible reminders..................................... 2-17
Circuit breaker, Fusible link .................................... 8-23
Cleaning exterior and interior .......................... 7-2, 7-4
Clock ............................................................................ 2-28
Closing the top .......................................................... 3-24
Clutch fluid.................................................................. 8-13
Coat hook.................................................................... 2-35
Cold weather driving ................................................ 5-24
Compact Disc (CD) changer operation .............. 4-18


04.5.17/Z33-D/V5.0


Compact Disc (CD) player (See audio
system) ......................................................................... 4-11
Compact spare tire ................................................... 8-36
Console box................................................................ 2-32
Controls, Heater and air conditioner controls
(automatic) ..................................................................... 4-3
Coolant
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Checking engine coolant level........................... 8-8
Corrosion protection ................................................... 7-5
Cruise control............................................................. 5-15
Cup holders ................................................................ 2-31
Curtain side-impact air bag system (See
supplemental side air bag and curtain air bag
system) ......................................................................... 1-17
D
Daytime running light system ................................. 2-23
Defroster switch, Rear window and outside mirror
defroster switch ......................................................... 2-21
Dimensions and weights ............................................ 9-9
Door open warning light .......................................... 2-12
Drive belts ................................................................... 8-17
Driving
Cold weather driving ......................................... 5-24
Driving with automatic transmission........ 5-6, 5-9
Driving with manual transmission .......... 5-7, 5-12
Precautions when starting and driving ............ 5-2E
Economy, Fuel............................................................ 5-17
Elapsed time ................................................................. 2-9
Emission control information label ........................ 9-11
Emission control system warranty......................... 9-22
Engine
Before starting the engine .................................. 5-8
Break-in schedule............................................... 5-17
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine coolant .................................... 8-9
Changing engine oil and filter ......................... 8-10
Checking engine coolant level........................... 8-8
Checking engine oil level ................................. 8-10
Coolant temperature gauge ............................... 2-5
Engine block heater ........................................... 5-25
Engine compartment check locations.............. 8-7
Engine cooling system ......................................... 8-8
Engine oil .............................................................. 8-10
Engine oil and oil filter recommendation......... 9-5
Engine oil viscosity ............................................... 9-5
Engine serial number ......................................... 9-11
Engine specifications ........................................... 9-8
If your vehicle overheats ...................................... 6-9
Oil pressure gauge ............................................... 2-6
Starting the engine ............................................... 5-8
Event data recorders ................................................ 9-23
Exhaust gas (Carbon monoxide).............................. 5-2
F
F.M.V.S.S. certification label................................... 9-11Filter
Air cleaner housing filter ................................... 8-18
Changing engine oil and filter ......................... 8-10
Flashers (See hazard warning flasher switch) ... 2-25
Flat tire............................................................................ 6-2
Flat tire, Low tire pressure warning system .......... 5-3
Floor mat cleaning ....................................................... 7-4
Fluid
Automatic transmission fluid (ATF) ................ 8-12
Brake and clutch fluid ....................................... 8-13
Brake fluid............................................................. 8-13
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Engine coolant ....................................................... 8-8
Engine oil .............................................................. 8-10
Power steering fluid ........................................... 8-13
Window washer fluid ......................................... 8-14
FM-AM radio with Compact Disc (CD) player .... 4-9
FM-AM-SAT radio with cassette player and
Compact Disc (CD) changer ................................. 4-13
Fuel
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Distance to empty ................................................. 2-9
filler cap................................................................. 3-13
filler lid ................................................................... 3-13
Fuel economy ...................................................... 5-17
Fuel octane rating ................................................. 9-3
Fuel recommendation ........................................... 9-3
Gauge ...................................................................... 2-6
Fuses ............................................................................ 8-22
Fusible links ................................................................ 8-23


04.5.17/Z33-D/V5.0

10-2

G
Garage door opener, HomeLink
Universal
Transceiver .................................................................. 2-39
Gas cap ....................................................................... 3-13
Gauge ............................................................................. 2-3
Engine coolant temperature gauge .................. 2-5
Engine oil pressure gauge .................................. 2-6
Fuel gauge .............................................................. 2-6
Odometer ................................................................ 2-4
Speedometer .......................................................... 2-4
Tachometer ............................................................. 2-5
Trip computer ......................................................... 2-8
Volt meter ................................................................ 2-7
General maintenance .................................................. 8-2
Golf bag stowing....................................................... 2-34
H
Hatch, Rear hatch........................................................ 3-9
Hazard warning flasher switch............................... 2-25
Head restraints ............................................................. 1-9
Headlights
Bulbreplacement ............................................... 8-26
Headlight switch ................................................. 2-23
Xenon headlights ................................................ 2-22
Heated seats .............................................................. 2-26
Heater
Engine coolant heater ....................................... 5-25
Heater and air conditioner (automatic)............ 4-3
HomeLink
Universal Transceiver ......................... 2-39
Hood release ................................................................ 3-9
Horn .............................................................................. 2-25How to stop alarm, Vehicle security .................... 2-18
I
Ignition switch ............................................................... 5-6
Automatic transmission models................ 5-6, 5-9
Key positions .......................................................... 5-7
Manual transmission models .................. 5-7, 5-12
Immobilizer system .................................................... 2-18
Indicator lights............................................................ 2-14
Inside
Automatic anti-glare mirror............................... 3-17
Mirror...................................................................... 3-16
Inspection/maintenance (I/M) test ........................ 9-22
Instrument brightness control ................................ 2-24
Instrument panel........................................................... 2-2
Interior light replacement......................................... 8-27
Interior lights ............................................................... 2-37
Interior trunk lid release ........................................... 3-12
J
Jump starting................................................................. 6-7
K
Keyless entry (See remote keyless entry
system) ........................................................................... 3-4
Keys................................................................................. 3-2L
Labels
Air bag warning labels ...................................... 1-20
Air conditioner specification label .................. 9-12
Emission control information label ................. 9-11
Engine serial number ......................................... 9-11
F.M.V.S.S. certification label ............................ 9-11
Tire and loading information label .................. 9-12
Vehicle identification number (VIN)................ 9-10
License plate, Installing front license plate......... 9-13
Light
Air bag warning light ......................................... 1-21
Bulbreplacement ............................................... 8-25
Headlight switch ................................................. 2-23
Headlights Bulbreplacement .......................... 8-26
Interior lights ........................................................ 2-37
Replacement ........................................................ 8-25
Vanity mirror light ................................................ 2-38
Warning/indicator lights and audible
reminders .................................................. 2-11, 2-14
Xenon headlights ................................................ 2-22
Lights, Exterior and interior light replacement ... 8-27
Loading information (See vehicle loading
information) ................................................................. 9-14
Lock
Door locks ............................................................... 3-2
Power door lock .................................................... 3-2
Rear floor box ...................................................... 2-33
Rear hatch lock...................................................... 3-9
Top latch lever ..................................................... 3-21
Trunk lid lock........................................................ 3-11
Low tire pressure warning light ............................. 2-13
Low tire pressure warning system ................. 5-3, 6-2


04.5.17/Z33-D/V5.0

10-3
