96 Controls in detailLocking and unlockingOpening the doors from the inside
You can open a locked door from the in-
side. Open door only when conditions are
safe to do so.
1Locking knob
2Inside door handle
Pull on door handle2.
If door was locked, locking knob1
will move up.
Opening the trunk lid from the outside
A minimum height clearance of 6.3 ft
(1.90 m) is required to open the trunk lid.
The trunk lid lock is located in the rear li-
cense plate recess.
1Trunk lid lock
Press trunk lid lock1.
The trunk lid opens.
iIf you open a door, the side windows on
that side of the vehicle will lower
slightly. The windows close again when
you close the door.iIf the vehicle has previously been
locked from the outside with the
SmartKey, opening a door from the in-
side will trigger the anti-theft alarm sys-
tem.
To cancel the alarm, do one of the fol-
lowing:
With the SmartKey

Insert the SmartKey in the starter
switch.


Press button Œ or ‹ on the
SmartKey.
With KEYLESS-GO*


Grasp the outside door handle.


Press the KEYLESS-GO* start/stop
button.
!The trunk lid swings open upwards au-
tomatically. Always make sure that
there is sufficient overhead clearance.

97 Controls in detail
Locking and unlocking
The trunk can also be opened using the
SmartKey (
page 90) or from its inside in
an emergency, see “Trunk lid emergency
release” (
page 103).
Opening the trunk lid from the inside
You can open the trunk from the inside if
the vehicle is stationary.
A minimum height clearance of 6.3 ft
(1.90 m) is required to open the trunk lid.
The switch is located on the driver’s door.
1Indicator lamp
2Remote trunk lid release switch
Pull remote trunk lid release switch2
until trunk begins to open.
The trunk lid opens. The indicator
lamp1 comes on and remains lit until
the trunk is closed.The trunk can also be opened using the
SmartKey (
page 90) or from its inside in
an emergency, see “Trunk lid emergency
release” (
page 103). Vehicles with trunk lid opening/closing
system: To stop the opening proce-
dure, press buttonŠ. The trunk lid
stops moving.
iIf the trunk lid does not open, it is still
locked separately (if applicable)
(page 104).
Vehicles without KEYLESS-GO*: The
vehicle must be unlocked (
page 88).
Vehicles with KEYLESS-GO*: If the ve-
hicle was previously centrally locked,
the trunk lid will lock automatically af-
ter closing it (
page 98). The turn sig-
nal will flash three times to confirm
locking.
!The trunk lid swings open upwards au-
tomatically. Always make sure that
there is sufficient overhead clearance.iIf the trunk lid does not open, it is still
locked separately (if applicable)
(page 104).
If the vehicle was previously centrally
locked, the trunk lid will lock automati-
cally when closed (
page 98). The
turn signal will flash three times to con-
firm locking.

98 Controls in detailLocking and unlockingClosing the trunk lid
1Handle
Lower trunk lid by pulling firmly on
handle1.

Push the trunk lid closed from the out-
side with hands placed flat on trunk lid.
The power closing assist automatically en-
sures that the lid is pulled closed com-
pletely (
page 105).
Trunk lid opening / closing system*
You can open or close the trunk lid from
the inside if the vehicle is stationary.
Opening from the inside
A minimum height clearance of 6.3 ft
(1.90 m) is required to open the trunk lid.
The switch for opening and closing the
trunk is located on the driver’s door.
1Indicator lamp
2Remote trunk lid switch
Warning!
G
To prevent possible personal injury, always
keep hands and fingers away from the trunk
lid opening when closing the trunk. Be espe-
cially careful when small children are
around.Warning!
G
Only drive with the trunk closed as, among
other dangers such as visibility blockage,
exhaust fumes may enter the vehicle interi-
or.iDo not place the SmartKey in the open
trunk. You may lock yourself out.
Vehicles with KEYLESS-GO*: To pre-
vent a possible inadvertent lockout, the
trunk lid will open automatically if a
SmartKey with KEYLESS-GO is recog-
nized inside the vehicle or in the trunk.

99 Controls in detail
Locking and unlocking

Pull remote trunk lid switch2 until
trunk begins to open.
The trunk lid opens. The indicator
lamp1 comes on and remains lit until
the trunk is closed.The trunk can also be opened using the
SmartKey (
page 90) or from its inside in
an emergency, see “Trunk lid emergency
release” (
page 103).
Limiting opening height of trunk lid
The trunk lid opening height can be limited
when transporting goods on a roof rack
(e.g. presence of an MB sport luggage con-
tainer*). When activated, the trunk lid
opens to approximately the height of the
roof edge.
You can activate the limiting opening
height of trunk lid using the control system
(
page 153).
Closing from the inside

Press remote trunk lid switch2
(page 98) until the indicator lamp1
goes out and trunk lid is closed.
To interrupt the closing procedure:

Release remote trunk lid switch2.If the trunk lid comes into contact with an
object while closing (e.g. luggage that has
been piled too high) in the upper motion
sequence, the closing procedure is
stopped and the trunk reopens slightly.
!The trunk lid swings open upwards au-
tomatically. Always make sure that
there is sufficient overhead clearance.
To stop the opening procedure, press
or pull the remote trunk lid switch.iIf the trunk lid does not open, it is still
locked separately (if applicable)
(page 104).
If the vehicle was previously centrally
locked, the trunk lid will lock automati-
cally when closed (
page 98). The
turn signal will flash three times to con-
firm locking.
Warning!
G
Maintain sight of trunk area while operating
the door mounted switch. Monitor the clos-
ing procedure carefully to ensure that no
one is in danger of being injured.
To interrupt the closing procedure, release
the door mounted remote trunk lid switch.
Even with the SmartKey removed from the
starter switch or the SmartKey with
KEYLESS-GO* removed from the vehicle,
the remote trunk lid switch can be operated.
Therefore, do not leave children unattended
in the vehicle, or with access to an unlocked
vehicle. Unsupervised use of vehicle equip-
ment may cause an accident and/or serious
personal injury.

100 Controls in detailLocking and unlockingClosing the trunk lid from the outside
(vehicles without KEYLESS-GO*)
1Trunk lid closing switch
Press trunk lid closing switch1 brief-
ly.
The trunk lid closes.
If the trunk lid comes into contact with an
object while closing (e.g. luggage that has
been piled too high), the closing procedure
is stopped and the trunk reopens slightly.
Warning!
G
Monitor the closing procedure carefully to
ensure that no one is in danger of being in-
jured. To prevent possible personal injury,
always keep hands and fingers away from
the trunk opening when closing the trunk.
Be especially careful when small children
are around. To stop the closing procedure,
press the remote trunk lid switch (on the
driver's door), the trunk lid closing
switch1 or theŠ button on the
SmartKey.
When leaving the vehicle, always remove the
SmartKey from the starter switch, take the
SmartKey with you and lock your vehicle. Do
not leave children unattended in the vehicle,
or with access to an unlocked vehicle. Unsu-
pervised use of vehicle equipment may
cause an accident and/or serious personal
injury.
Warning!
G
Only drive with the trunk closed as, among
other dangers such as visibility blockage,
exhaust fumes may enter the vehicle interi-
or.iDo not place the SmartKey in the open
trunk. You may lock yourself out.

101 Controls in detail
Locking and unlocking
Closing the trunk lid from the outside
(vehicles with KEYLESS-GO*)
1Trunk lid closing switch
Make sure you have the SmartKey with
KEYLESS-GO with you.

Press trunk lid closing switch1 brief-
ly.
The trunk lid closes.
If the trunk lid comes into contact with an
object while closing (e.g. luggage that has
been piled too high), the closing procedure
is stopped and the trunk reopens slightly.
Warning!
G
Monitor the closing procedure carefully to
ensure that no one is in danger of being in-
jured. To prevent possible personal injury,
always keep hands and fingers away from
the trunk opening when closing the trunk.
Be especially careful when small children
are around. To stop the closing procedure,
press the trunk lid closing switch (on the
driver’s door), the trunk lid closing
switch
1
or the Š button on the
SmartKey.
When leaving the vehicle, always remove the
SmartKey from the starter switch, take the
SmartKey with KEYLESS-GO* with you, and
lock your vehicle. Do not leave children un-
attended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.
Warning!
G
Only drive with the trunk closed as, among
other dangers such as visibility blockage,
exhaust fumes may enter the vehicle interi-
or.iTo prevent a possible inadvertent lock-
out, the trunk lid will open automatical-
ly if a SmartKey with KEYLESS-GO is
recognized inside the vehicle or in the
trunk.

102 Controls in detailLocking and unlockingClosing the trunk lid and locking the ve-
hicle from the outside (vehicles with
KEYLESS-GO*)
On vehicles with trunk lid opening/closing
system and KEYLESS-GO, you can close
the trunk lid and lock the vehicle simulta-
neously.
1KEYLESS-GO locking/closing switch
Make sure you have the SmartKey with
KEYLESS-GO with you.

Press switch1 briefly.
The vehicle is locked and the trunk lid
closes automatically. The turn signals
flash three times to confirm locking.
Warning!
G
Monitor the closing procedure carefully to
ensure that no one is in danger of being in-
jured. To prevent possible personal injury,
always keep hands and fingers away from
the trunk opening when closing the trunk.
Be especially careful when small children
are around. To stop the closing procedure,
press the remote trunk lid switch (on the
driver’s door), the trunk lid closing
switch1, or the Š button on the
SmartKey.
When leaving the vehicle, always remove the
SmartKey from the starter switch, take the
SmartKey with KEYLESS-GO* with you, and
lock your vehicle. Do not leave children un-
attended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.
Warning!
G
Only drive with the trunk closed as, among
other dangers such as visibility blockage,
exhaust fumes may enter the vehicle interi-
or.iTo prevent a possible inadvertent lock-
out, the trunk lid will open automatical-
ly if a SmartKey with KEYLESS-GO is
recognized inside the vehicle or in the
trunk.

103 Controls in detail
Locking and unlocking
Trunk lid emergency release
The emergency release button is located
on the inside of the trunk lid.
1Emergency release button
Briefly press emergency release
button1.
The trunk unlocks and the trunk lid
opens.Illumination of the emergency release but-
ton:


The button will flash for 30 minutes af-
ter opening the trunk.


The button will flash for 60 minutes af-
ter closing the trunk.iThe emergency release button unlocks
and opens the trunk while the vehicle is
standing or driving.
The emergency release button does
not open the trunk lid if the vehicle bat-
tery is discharged or disconnected.
iIf the emergency release button is
pressed and the vehicle was centrally
locked, the exterior lamps will flash and
the alarm will sound as the trunk lid
opens:
To cancel the alarm, do one of the fol-
lowing:
With the SmartKey

Insert the SmartKey in the starter
switch.


Press button Œ or ‹ button
on the SmartKey.
With KEYLESS-GO*


Grasp the outside door handle.


Press the KEYLESS-GO* start/stop
button.
