2004 MAZDA MODEL MX-5 MIATA Owners Manual

3-27
Knowing Your Mazda
Doors and Locks
Form No. 8S15-EA-03G
4. Unlock the top latches and the side latches on the hardtop.
5. Align the rear deck latches with the rear deck studs and set the hardtop
squarely onto the body. 6. Slide the hardtop forward while
pressing down on the rear deck latches
to lock the latches, and then verify that
they are secure by attempting to lift the
rear of the hardtop.
Top latch assembly
Slide latch assembly
Rear deck stud
Hardtop Rear deck latch
Rear deck latch
• Be careful not to strike the body
with any of the protruding hardtop
latches.
• The rear defogger grid and the
defogger cord could be damaged
when removing or installing the top.
Make sure the rear defogger grid
isn
’t folded and the defogger cord
isn ’t caught between the vehicle ’s
body and the top.
Rear deck latch
CAUTION
J07S_8S15-EA-03G_Edition2.book Page 27 Thursday, August 21, 2003 10:04 AM

3-28
Knowing Your Mazda
Doors and Locks
Form No. 8S15-EA-03G
7. Push each top latch up with the palm of your hand until the lock buttons click
and the latches are locked.
8. Push each side latch down with the palm of your hand until the lock
buttons click and the latches are
locked. 9. Reconnect the rear window defroster
coupler.

Detachable Hardtop Appearance
Care
Refer to detachable hardtop maintenance
(page 8-46) for information on detachable
hardtop appearance care.
After installation, verify that all latches
are secure. Operating the vehicle with
unlocked latches may cause hardtop
damage or loss.
Side latch
CAUTION
NOTE
If the top rattles even when all latches
are secure, drive slowly and contact an
Authorized Mazda Dealer for
inspection.
Rear window defroster coupler
J07S_8S15-EA-03G_Edition2.book Page 28 Thursday, August 21, 2003 10:04 AM

3-29
Knowing Your Mazda
Form No. 8S15-EA-03G
Security System
The optional immobilizer system allows
the engine to start only with a key the
system recognizes.
If someone attempts to start the engine
with an unrecognized key, the engine will
not start, thereby helping to prevent the
theft of your vehicle.
Immobilizer System*
•Changes or modifications not
expressly approved by the party
responsible for compliance could
void the user
’s authority to operate
the equipment.
• To avoid damage to the key, do not:

Drop the key.
 Get the key wet.
 Expose the key to any kind of
magnetic field.
 Expose the key to high
temperatures on places such as
the dashboard or hood, under
direct sunlight.
CAUTION
•When starting the engine do not
allow the following, as the engine
may not start due to the electronic
signal from the ignition key not
being transmitted correctly.

A key ring rests on the key grip.
 Metal parts of other keys or
metal objects touch the key grip.
 Spare keys or keys for other
vehicles equipped with an
immobilizer system touch or
come near the key grip.
 Devices for electronic purchases,
or security passage touch or
come near the key.
CAUTION
*Some models.
J07S_8S15-EA-03G_Edition2.book Page 29 Thursday, August 21, 2003 10:04 AM

3-30
Knowing Your Mazda
Security System
Form No. 8S15-EA-03G

Immobilizer System Warning
Light
If the immobilizer system is working
properly, the light will come on when the
ignition switch is turned to the ON or
START position. The light will go out
when confirmation by the immobilizer
system is completed.
If the light flashes rapidly, fails to come
on, or comes on and stays on, it indicates
a system malfunction. If any of these
occur, contact an Authorized Mazda
Dealer as soon as possible.
NOTE
• (U.S.A.)

This device complies with part 15
of the FCC Rules. Operation is
subject to the following two
conditions: (1) This device may not
cause harmful interference, and (2)
this device must accept any
interference received, including
interference that may cause
undesired operation.
• (CANADA)

This device complies with RSS-210
of Industry CANADA. Operation is
subject to the following two
conditions: (1) this device may not
cause interference, and (2) this
device must accept any interference,
including interference that may
cause undesired operation of the
device.
J07S_8S15-EA-03G_Edition2.book Page 30 Thursday, August 21, 2003 10:04 AM

3-31
Knowing Your Mazda
Security System
Form No. 8S15-EA-03G

Maintenance
If you have a problem with the
immobilizer system or the key, consult an
Authorized Mazda Dealer.

Modification and Add-On
Equipment
Mazda cannot guarantee the immobilizer
system
’s operation if the system has been
modified or if any add-on equipment has
been installed to it.
NOTE
• If the warning light comes on and
stays on when the ignition switch is
turned to the ON position, the
engine will not start.
• Signals from a TV or radio station,
or from a transceiver or a mobile
telephone, could interfere with your
immobilizer system. If you are
using the proper key and your
engine fails to start, check the
warning light. If it is flashing,
remove the ignition key and wait 2
seconds or more, then reinsert it and
try starting the engine again. If it
doesn
’t start after 3 or more tries,
contact an Authorized Mazda
Dealer.
• If the warning light flashes
continuously while you are driving,
don’
t shut off the engine. Go to an
Authorized Mazda Dealer and have
it checked. If you shut off the
engine while the light is flashing
you won ’t be able to restart it.
NOTE
• The keys carry a unique electronic
code. For this reason, and to assure
your safety, replacement keys
require some waiting time to obtain.
They are only available through an
Authorized Mazda Dealer.
• Always keep a replacement key, in
case one is lost. If a key is lost,
contact an Authorized Mazda
Dealer as soon as possible.
• If you lose a key, an Authorized
Mazda Dealer will reset the
electronic codes of your remaining
keys and immobilizer system.
Starting the vehicle with a key that
has not been reset is not possible.
To avoid damage to your vehicle, do
not modify the system or install any
add-on equipment to it.
CAUTION
J07S_8S15-EA-03G_Edition2.book Page 31 Thursday, August 21, 2003 10:04 AM

3-32
Knowing Your Mazda
Form No. 8S15-EA-03G
Mirrors

Outside Mirrors
Check the mirrors
’ angles before driving.
Power control mirror
The ignition switch must be in the ACC or
ON position.
To a d j u s t :
1. Move the selector switch to the left or right to choose the mirror.
2. Depress the mirror switch in the appropriate direction. Folding the mirror
Fold the outside mirror rearward until it is
flush with the vehicle.Mirrors
Convex Mirror (Passenger Side):
Changing lanes without taking into
account the actual distance of the
vehicle in the convex mirror is
dangerous. You could have a serious
accident. What you see in the convex
mirror is closer than it appears. Be
sure to look over your shoulder or to
check your inside mirror before
changing lanes.
WARNING
Outside mirror
Selector switch
Mirror switch
Driving with Mirrors Folded In:
Driving with the outside mirrors
folded in is dangerous. Your rear view
will be restricted, and you could have
an accident. Always return the
outside mirrors to the driving position
before you start driving.
WARNING
J07S_8S15-EA-03G_Edition2.book Page 32 Thursday, August 21, 2003 10:04 AM

3-33
Knowing Your Mazda
Mirrors
Form No. 8S15-EA-03G

Rearview Mirror (With Day/
Night Function)
Before driving, adjust the rearview mirror
to center on the scene through the rear
window.
Do this with the day/night lever in the day
position.
Push the lever forward for day driving.
Pull it back to reduce glare from
headlights.
Day/Night lever
Day Night
Blocked View:
Cargo stacked higher than the
seatbacks is dangerous. It can block
your view in the rearview mirror,
which might cause you to hit another
car when changing lanes. Don ’t stack
things higher than the seatbacks.
Objects in the Storage Area:
Putting heavy or sharp objects in the
top storage area is dangerous.
During a sudden stop or collision,
they can become projectiles that
might hit and injure passengers.
Don ’t place heavy or sharp objects in
the top storage area.
Standing in a Moving Vehicle:
Standing in the vehicle, or sitting on
the convertible top storage area or
center console when it ’s moving is a
dangerous way to ride. During a
sudden maneuver or collision you
could be seriously injured or even
killed.
Sit in the seat with the seat belt on
when the vehicle is moving.
WARNING
J07S_8S15-EA-03G_Edition2.book Page 33 Thursday, August 21, 2003 10:04 AM

3-34
Form No. 8S15-EA-03G
J07S_8S15-EA-03G_Edition2.book Page 34 Thursday, August 21, 2003 10:04 AM
