2004 Lexus GX470 Audio System / LEXUS 2004 GX470 FROM SEP. 2004 PROD. OWNER'S MANUAL (OM60B57U)

STARTING AND DRIVING
438
This device complies with Part 15 of the FCC Rules. Opera-
tion is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.

STARTING AND DRIVING
439
NOTICE:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide rea-
sonable protection against harmful interference in a residen-
tial installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful in-
terference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interfer-
ence to radio or television reception, which can be deter-
mined by turning the equipment off and on, the user is en-
couraged to try to correct the interference by one or more of
the following measures:
 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and re-
ceiver.
 Connect the equipment into an outlet on a circuit dif ferent
from that to which the receiver is connected.
 Consult the dealer or an experienced radio/TV technician
for help.
FCC WARNING:
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user's authority to operate the equipment.

STARTING AND DRIVING
440For vehicles sold in Canada
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this de-
vice must accept any interference, including interference
that may cause undesired operation of the device.

STARTING AND DRIVING
441
Replacing tires and wheels
When replacing the wheels, be sure to install air pressure
sensors on the wheels.
There are 3 ways to set up the air pressure sensors:
(a) Remove the sensor from the old wheel and install it to the
new wheel.
(b) Keep the same wheel with air pressure sensor and replace
only the tire.
(c) Use a new wheel and sensor.
You have to register an ID code for a new sensor. Up to 2 sets
of codes can be registered. As one ID for the originally installed
sensor is registered at MAINº of the selector switch, use the
2ndº position to register an ID for the new sensor.
You do not need to re-register the ID code for any other
replacements. For the use of the originally installed tires, put
the selector switch at MAINº and for the use of tires set
purchased later, put the switch at 2ndº. For the sensor
selector switch, see page 442.CAUTION
 Have the tires, wheels or sensors replaced and ID
codes registered by a Lexus dealer. If you need
sensors, purchase from a Lexus dealer.
 The use of non-genuine wheels will cause the air
pressure sensors to transmit the electronic code in
different manner, resulting in the failure of the
system.

STARTING AND DRIVING
442
Selector switch

1Main position22nd position
The selector switch is located in the lower part of the
driver's side instrument panel.
The ID code is given in the sensor. To activate the air
pressure warning system, it is necessary to register the ID
code of the sensor on the selector switch in the vehicle.2 sets of ID codes can be registered. The code of the tires
originally installed on the vehicle is registered on the switch at
MAINº. Have a new tires set with new air pressure sensors
registered at 2ndº by Lexus dealer.
ID codes should be registered by Lexus dealer. Once
registered,
change the setting position each time you purchase
tires and wheels. Re-registration is not required.
When purchasing new tires, consult your Lexus dealer.

STARTING AND DRIVING
443
CAUTION
When the tires whose ID code is registered at MAINº
are used, the system does not work properly with the
selector switch set at 2ndº. If the tires whose ID code
is registered at 2ndº are stored nearby, the system will
detect their tire pressure (and vice versa).
BRAKE PAD WEAR LIMITINDICATORS
The brake pad wear limit indicators on your disc brakes
give a warning noise when the brake pads are worn to the
extent that replacement is required.
If you hear a squealing or scraping noise while driving, have the
brake pads checked and replaced by your Lexus dealer as
soon as possible. Expensive rotor damage can result if the
pads are not replaced when needed.

STARTING AND DRIVING
444
LIMITED-SLIP DIFFERENTIAL
Your Lexus is equipped with a limited-slip center differential
(transfer).
If one wheel Ð either front or rear Ð begins to spin, the transfer
(limited-slip center differential) is designed to aid traction by
automatically transmitting driving force to the wheels on the
other drive axle. It transmits driving force to the front wheels
if a rear wheel spins, and to the rear wheels if a front wheel
spins.
CAUTION
Do not start or run the engine while your vehicle is
supported by a jack. The vehicle could be driven off the
jack and could pose a danger or result in serious injury.
NOTICE
Use only a spare tire of the same size, construction and
load capacity as the original tires on your Lexusbecause damage to the limited-slip differential couldpossibly occur with another tire type.

STARTING AND DRIVING
445
