STARTING AND DRIVING
398
(e) Parking

1Brake pedal
2Parking brake lever
3Pº (Park) position
1. Bring the vehicle to a complete stop.
2. Apply the parking brake fully.
3. With the brake pedal held down with your foot, shift the
selector lever to the Pº position.
CAUTION
While the vehicle is moving, never attempt to move the
selector lever into Pº under any circumstances.
Serious mechanical damage and loss of vehicle control
may result.
(f) Good driving practice
 If the transmission repeatedly shifts up and down between
the fourth and overdrive gears when climbing a gentle slope,
shift the selector lever to the 4º position. Be sure to shift the
selector lever to the Dº position after climbing the slope.

STARTING AND DRIVING
399

When towing a trailer, in order to maintain efficient engine
braking and electrical charging performance, do not use
overdrive.
CAUTION
Always keep your foot on the brake pedal while stopped
with the engine running. This prevents the vehicle from
creeping.
NOTICE
Always use the brake pedal or parking brake to hold the
vehicle on an upgrade. Do not attempt to hold the vehicle using the accelerator pedal, as this can causethe transmission to overheat.

STARTING AND DRIVING
400
(g) If you cannot shift the selector lever
If you cannot shift the selector lever even though the brake
pedal is depressed, use the shift lock override button. For
instructions, see If you cannot shift automatic transmission
selector leverº on page 512.
(h) Driving in second start mode
In the second start mode, the transmission system shifts up
from second gear. Use this mode when starting your vehicle
in sand, mud, ice or snow.
To set the second start mode, push the 2nd STRTº switch. In
the second start mode, the 2nd STRTº indicator light comes
on. To cancel the second start mode, push the 2nd STRTº
switch once again.
FOUR-WHEEL DRIVE SYSTEM
(a) Four-wheel drive control
Use the four-wheel drive control lever and center
differential lock button to select the following transfer and
center differential modes.
The Hº and Lº position of the four-wheel drive control lever
provides either lock or unlock mode of the center differential
depending on the center differential lock button position.
Use the center differential lock system if your wheels get stuck
in a ditch, or when you are driving on a slippery or bumpy
surface. When the center differential is locked, the vehicle
stability control system is automatically turned off and the
center dif ferential lock and VSC OFFº indicator lights come on
because the function that controls engine performance
interferes with the process of freeing your wheels.

STARTING AND DRIVING
401
NOTICE
As soon as the center differential lock switch is turnedon, the VSC OFFº indicator light comes on. After thewheels are out of the ditch or off the slippery or bumpysurface, turn the center differential lock switch off.Make sure the center differential lock indicator light andvehicle stability control system off indicator light turnoff.
Hº (high speed position, center differential unlocked):
Lever at Hº, center differential lock button left out
Use this for normal driving on all types of roads, from dry
hard-surfaced roads to wet, icy or snow-covered roads. This
position gives greater economy, quietest ride, least wear and
better vehicle control.
Hº (high speed position, center differential locked): Lever
at Hº, center differential lock button pushed in
Use this for greater traction when you experience a loss of
power, such as wheel slipping, in the center differential unlock
mode.
Nº (neutral position): Lever at Nº
No power is delivered to the wheels. The vehicle must be
stopped. Lº (low speed position, center differential unlocked):
Lever at Lº, center differential lock button left out
Use this for maximum power and traction. Use this for climbing
or descending steep hills, off-road driving, and hard pulling in
sand or mud.
In this mode, the braking feeling that occurs when the wheels
are negotiating a sharp corner is further reduced than in the Lº
(low position, center differential locked) mode.
Lº (low speed position, center differential locked):
Lever
at Lº, center differential lock button pushed in
Use this for maximum power and traction. Use this for hard
pulling in si tuations the vehicle cannot negotiate even in the Lº
(low speed position, center differential unlocked) mode. Also,
using this mode when driving down steep of f-road inclines will
help contribute to increased vehicle stability.

STARTING AND DRIVING
402The indicator light tells when the differential lock is engaged.
Note that the differential is not still locked as long as the
indicator light remains off.
When
the operation is not completed, the indicator blinks. If the
indicator light does not go off when you push out the center
differential lock switch, drive straight ahead while accelerating
or decelerating, or drive in reverse.
The center differential lock system operation is not completed
within 5 seconds while the cruise control system is set, cancel
the cruise control system. To cancel the cruise control system,
see Cruise controlº on page 408. If the indicator light does not go off when you push out the
center differential lock button, drive straight ahead while
accelerating or decelerating, or drive in reverse.
See (b) Shifting procedureº for further instructions.
Advice for driving on slippery roads in Lº (low speed
position) mode
If you shift the four-wheel drive control lever to Lº, the
automatic transmission lever to 2º when you drive in steep
off-road areas, the output of the brake can be controlled
effectively by the active traction control system, which assists
the driver to control the driving power of 4 wheels.
Use the Lº position of the automatic transmission lever for
maximum power and traction when your wheels get stuck or
when you drive down a steep incline. In the following cases,
the out put of the brake can be controlled by the active traction
control
system if the engine speed is under 3000 rpm (normally
engine speed is under 3000 rpm when the wheels get unstuck).
 The four-wheel drive control lever in the Lº position and the
automatic transmission lever in the Lº position or the
automatic transmission lever in the Dº or 2º with the
transmission downshifting to the first gear.
 The four-wheel drive control lever in the Lº position and the
automatic transmission lever in the Rº position
(As for the automatic transmission lever positions, see
Automatic transmissionº on page 392.)

STARTING AND DRIVING
403
(b) Shifting procedure
To shift between unlock and lock modes in Hº, push the
center differential lock button.
To shift between unlock and lock modes in Lº, push the
center differential lock button.
To shift between Hº and Lº, stop the vehicle, put the
transmission into Nº and move the four-wheel drive control
lever.CAUTION
Never move the four-wheel drive control lever if wheels
are slipping. Stop the slipping or spinning before
shifting.
NOTICE
For normal driving on dry and hard surface roads, unlock the center differential. To prevent damage to thecenter differential lock system, do not push the centerdifferential lock button when the vehicle is cornering or
when its wheels are spinning freely off the ground. If the
indicator light does not go off when unlocking the center differential, drive straight ahead while
accelerating or decelerating, or drive in reverse.

STARTING AND DRIVING
404
REAR VIEW MONITOR SYSTEM
The rear view monitor system assists the driver by
displaying an image of the rear of the vehicle while
backing up. The displayed image on the screen is a
horizontally reversed mirror image of the inside rear view
mirror.
To display the rear view image on the screen, place the
selector lever in the Rº position when the ignition switch
is in the ONº position.
If you move the selector lever out of the Rº position, the screen
returns to the previous screen. Operating another function of
the navigation system will display another screen.
The rear view monitor system is a supplemental device
intended to assist back up. When backing up, be sure to check
behind and all around the vehicle visually.
CAUTION
 Never depend on the rear view monitor system
entirely when backing up. Always make sure your
intended path is clear.
Use caution just as you would when backing up any
vehicle.
 Never back up while looking only at the screen. The
image on the screen is different from actual
conditions. Depicted distances between objects and
flat surfaces will differ from actual distances. If you
back up w hile looking only at the screen, you may hit
a vehicle, a person or an object. When backing up, be
sure to check behind and all around the vehicle
visually and with mirrors before proceeding.
 Do not use the system when the back door is not
completely closed.
 If the back of the vehicle is hit, the position and
mounting angle of the camera may change. Be sure
to have the camera's position and mounting angle
checked at your Lexus dealer.
 If the temperature changes rapidly, such as when hot
water is poured on the vehicle in cold weather, the
system may not operate normally.

STARTING AND DRIVING
405
If the camera lens becomes dirty, it cannot transmit
a clear image. If water droplets, snow, or mud adhere
to the lens, rinse with water and wipe with a soft cloth.
If the lens is extremely dirty, wash it with a mild
cleanser and rinse.
 The displayed image may become darker and moving
images may be slightly distorted when the system is
cold. When backing up, be sure to check behind and
all around the vehicle visually and with mirror before
proceeding.AREA DISPLAYED ON SCREEN
Image is displayed approximately level on screen.
