2004 Lexus GX470 Audio System / LEXUS 2004 GX470 FROM AUG. 2004 THROUGH SEP. 2004 PROD. OWNER'S MANUAL (OM60B55U)

AUDIO
326After replacing the battery, check that the controller operates
properly. If
the controller still does not operate properly, contact
your Lexus dealer.
DVD player operation
The DVD player can play audio CDs, DVD video discs, CD
texts, dts-CDs, DVD audio discs and video CDs.
For appropriate discs for this player, see Audio/video system
operating hintsº on page 375.
The DVD player works when the ignition key is in the ACCº or
ONº position.
To turn on the DVD player, a disc must be loaded in the player.
To turn off the player, eject the disc.
(a) Inserting the disc
1. Push the center of the rear console box lid.

AUDIO
327
2. Push this button to open the cover.
3. Pull the lid forward.
4. Insert a disc with the label side backward and close the
lid.
The player is intended for the use with 12 cm (4.7 in.) discs only.
If the label faces forward, the disc cannot be played. In this
case, DISC CHECKº appears on the screen.
If a disc which is not playable is inserted, DISC CHECKº will
also appear on the screen. For appropriate discs for this
player, see Audio/video system operating hintsº on page 375.

AUDIO
328
The indicator light turns on while the disc is loaded.
The player will play the track or chapter, and it will play from the
beginning of the track or chapter again after it reaches the end.
CAUTION
To reduce the chance of injury in case of an accident or
a sudden stop, always keep the console box closed
while driving.
NOTICE
Never try to disassemble or oil any part of the DVD
player. Do not insert anything other than a disc into the
slot.
5. Close the cover and console box. (b) Ejecting the disc

AUDIO
329
Pull
the lid forward to open the DVD player. Push the disc
eject button to eject a disc.
NOTICE
Do not place anything on the opened cover. It could damage the cover.

AUDIO
330(c) Selecting the DVD mode

1Controller button2Mode selection screen
To select the DVD mode, push the DVDº button on the
controller.
You can also select the DVD mode on the mode selection
screen mentioned above.
DVDº appears on the screen.
The DVD Hint!º screen appears when the DVD mode is
first selected after you turn the ignition key to the ACCº
or ONº position.
Push the OKº switch when you read the message.

AUDIO
331
(d) DVD player operation switches
The DVD player can be operated with the controller
buttons directly.
The player can also be operated with the switches on the
screen.
To operate the switches on the screen, select the switch by the
joy stick and push the ENTº button. You cannot select the
switches on the screen by touching them directly.
When the switch is selected by the joy stick, the outline of the
switch
changes to blue. Push the ENTº button, and the switch
will be highlighted in green.

AUDIO
332(e) Turning the operation switches on and off
To turn on the operation switches, push the CURSORº
button on the controller.

AUDIO
333
22PY056
