Knowing your vehicle
✽ ✽NOTICEThe transmitter will not work if any
of following occur:
- The ignition key is in ignition
switch.
- You exceed the operating distance limit (10 m).
- The battery in the transmitter is weak.
- Other vehicles or objects may be blocking the signal.
- The weather is extremely cold.
- The transmitter is close to a radio transmitter such as a radio station
or an airport which can interfere
with normal operation of the
transmitter.
When the transmitter does not work
correctly, open and close the door
with the ignition key. If you have a
problem with the transmitter, con-
tact an authorized Kia Dealer.
✽ ✽ NOTICEKeep the transmitter away from
water or any liquid. If the keyless
entry system is inoperative due to
exposure to water or liquids, it will
not be covered by your manufactur-
er vehicle warranty.
Operational distance may vary
depending upon the area the trans-
mitter is used in. For example, if the
vehicle is parked near police sta-
tions, government and public offices,
broadcasting stations, military instal-
lations, airports, or transmitting tow-
ers, etc.
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 5

Knowing your vehicle63
1
2
3
4
5
6
7
8
9
Battery replacementTransmitter uses a 3 volt lithium bat-
tery which will normally last for sev-
eral years. When replacement is
necessary, use the following proce-
dure.
1. Insert a slim tool into the slot andgently pry open the transmitter
center cover (
➀).
2. Replace the battery with new one. When replacing the battery, make
sure the battery positive “+” sym-
bol faces up as indicated in the
illustration.
3. Install the battery in the reverse order of removal.
✽ ✽NOTICE• The keyless entry system trans-
mitter is designed to give you
years of troublefree use, however
it can malfunction if exposed to
moisture or static electricity. If
you are unsure how to use your
transmitter or replace the battery,
contact an authorized Kia dealer.
• For replacement transmitters, see an Authorized Kia Dealer for
reprogramming.
MMSA3068
CAUTION
• Using the wrong battery can
cause the transmitter to mal-function. Be sure to use thecorrect battery.
 To avoid damaging the trans- mitter, don't drop it, get it wet,or expose it to heat or sun-light.
➀
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 6

Knowing your vehicle16
3
1
2
3
4
5
6
7
8
9
Window opening and closingThe driver’s door has a master power
window switch that controls all the
windows in the vehicle. To open or
close a window, press down or pull
up the front portion of the correspon-
ding switch.
Automatic power windowDepressing or pulling up the power
window switch momentarily to the
second detent position (
\b) com-
pletely lowers or lifts the window
even when the switch is released. To
stop the window at the desired posi-
tion while the window is in operation,
pull up or depress the switch
momentarily to the opposite direction
of the window movement.
If the battery has been discharged
or disconnected, the automatic
power window system must be reset
as follows:
1. Turn the ignition key to ON posi- tion.
2. Close each window and continue pulling up on each power window
switch for at least 0.5 second after
the window is completely closed. Automatic window reversal (When
window is closed by the automatic
power window)
If the upward movement of the win-
dow is blocked by an object or part of
the body, the window will detect the
resistance and will stop upward
movement. The window will then
lower approximately 15cm to allow
the object to be cleared.
1GHA2301
1GHA2300B1GHA2300A
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 16

Knowing your vehicle34
3
1
2
3
4
5
6
7
8
9
A driver position memory system is
provided to store and recall the seat
and outside mirror positions with a
simple button operation. By saving
the desired positions into the system
memory, different drivers can reposi-
tion the seat and outside mirror
based upon their driving preference. If battery is disconnected, the posi-
tion memory will be lost and the driv-
ing positions should be restored in
the system.
Storing positions into memory
using the buttons on the doorStoring driver
’s seat positions1. Shift the transaxle lever into P
while the ignition switch is ON.
2. Adjust the seat and outside rearview mirror to positions com-
fortable for the driver.
3. Press M button on the control panel.
4. Press one of the memory buttons (1 or 2) within 5 seconds after
pressing the M button. The sys-
tem will beep twice when memory
has been successfully stored.
The particular driver positions are
memorized in the button (1 or 2)
selected.
DRIVER POSITION MEMORY SYSTEM (IF EQUIPPED)
1GHA2201
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 34

363
1
2
3
4
5
6
7
8
9
Knowing your vehicle
Airbag system components The main components of your SRS
are:
To indicate that your vehicle is
equipped with airbags, the corre-
sponding airbag covers are
marked with “SRS AIRBAG”.
- Driver’ s airbag (see page 3- 63)
- Passenger’ s airbag(see page 3- 64)
- Side airbag (see page 3- 66)
- Curtain airbag (see page 3- 66)
 A diagnostic system that continual-
ly monitors the system operation.
 An indicator light to warn you of a
possible problem with the system.
 Emergency power backup in case
your car’ s electrical system is dis-
connected in a crash.
Driver’ s airbagThe driver’ s airbag is stored in the
center of the steering wheel.
CRUISE
ON/OFFCAN CE
L
COAST
SETRES
ACCEL
HLZ206
(Continued)
 If your vehicle has been sub-
jected to flood conditions (e.g.
soaked carpeting/standing
water on the floor of the vehi-
cle, etc.) or if your vehicle has
become flood damaged in any
way, do not attempt to start
the vehicle or put the key in
the ignition before discon-
necting the battery. This may
cause airbag deployment,
which could result in serious
personal injury or death. If
flooded conditions are sub-
jected to your vehicle, before
starting the vehicle, have the
vehicle towed to an authorized
Kia dealer for inspection and
necessary repairs.
2GHA2256
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 63

Knowing your vehicle80
3
1
2
3
4
5
6
7
8
9
Trunk room lampTrunk room lamp turns on when the
trunk is opened. It remains on until
the trunk is securely closed.
Inside the vehicleTo open the trunk from inside the
vehicle, make sure the trunk lid con-
trol button in the glove box is ON,
then pull trunk lid release switch (
➀)
on the drivers door panel.
If the trunk lid control button in the
glove box is OFF, the trunk can only
be opened with the vehicle master
key.
WARNING
- Exhaust
fumes
If you drive with the trunk lid
open, you will draw dangerous
exhaust fumes into your vehicle
causing serious injury or death
to vehicle occupants. Open
trunk lids can also dangerously
obscure rear view vision.
If you must drive with the trunk
lid open, keep the air vents open
so that additional outside air
comes into the vehicle.
1GHA2018
CAUTION
Make sure to close the trunk securely. If it remains openwhile engine is not running, itmay cause battery dischargebecause trunk room lampremains on.
1GHA2019
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 80

Knowing your vehicle98
3
1
2
3
4
5
6
7
8
9
✽ ✽
NOTICEClose the vanity mirror cover
securely and return the sunvisor to
its original position after use. If the
vanity mirror is not closed securely,
the lamp will stay on and could
result in battery discharge and pos-
sible sunvisor damage.
Power socket (if equipped)The power outlets are designed to
provide power for mobile telephones
or other devices designed to operate
with vehicle electrical systems. The
devices should draw less than 10
amps with the engine running.
2GHN33401GHA2234
Front (if equipped)Rear
2GHN3350
Center (if equipped)
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 98

399
1
2
3
4
5
6
7
8
9
Knowing your vehicle
✽ ✽NOTICE• Use when the engine is running.
• Only use the electric appliances
which are less than 12V and 10A
in electric capacity.
• Adjust the air-conditioner or heater to the lowest operation
level when you have to use the
power socket while using air-con-
ditioner or heater.
• Close the cover when not in use.
ClockDigital (if equipped)Whenever the battery terminals, A/V
CLOCK fuse, or Power Connect are
disconnected, you must reset the
time.
Press the Clock Control PUSH but-
ton in front of the monitor to access
the mode set buttons. Use these
buttons to adjust the time/date dis-
played on the monitor. 1. Press the MODE button (
➀).
2. Select the mode to be reset; hour (
➁), minute (
➂), month (
➃) and
date (
➄).
3. Reset the data using button  (
\b)
or button  (
➆) while the selected
mode blinks.
If the  (
\b) or  (
➆) button(s) are
pressed for more than 3 seconds,
the display will begin to change
rapidly. When the  (\b) or  (
➆)
button(s) are pressed then
released, the display will change
in single increments.
4. Press the SET (
➇) button when
the data is correctly set.
1GHA2110
➀
➆
➇
\b
➁
➂
➃
➄
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 99
