2004 KIA Opirus headrest

Knowing your vehicle18
3
1
2
3
4
5
6
7
8
9
Driver’s seat
➀
Seat adjustment, forward / back-
ward/height (see page 3- 20)
➁
Seatback recliner (see page 3- 22)
➂
Seat heater switch (see page 3- 22)
➃
Lumbar support (see page 3- 23)
➄
Driver position memory system
(see page 3- 24)


Headrest adjustment (headrest
can not be adjusted by a switch)(see page 3- 24)
Front passenger seat
\b
Seat adjustment, forward / back-
ward (see page 3- 25)
➆
Seatback recliner (see page 3- 26)
➇
Seat heater switch (see page 3- 27)


Headrest adjustment (headrest
can not be adjusted by a switch)(see page 3- 28)
Rear seat
\f
Seat heater switch (left) (see page 3- 31)
➉
Seat heater switch (right)(see page 3- 31)


Headrest adjustment (see page 3- 32)
SEAT
ESP
2GHN2025
No Function
No Function
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 18

Knowing your vehicle24
3
1
2
3
4
5
6
7
8
9
Driver position memory system
(if equipped)A driver position memory system is
provided to store and recall the seat
and outside mirror positions with a
simple button operation. By saving
the desired positions into the system
memory, different drivers can reposi-
tion the seat and outside mirror
based upon their driving preference.
See page 3-34 for detail information.
Headrest adjustmentAdjusting forward and backward
The headrest may be adjusted for-
ward to three different positions by
pulling the headrest forward. To
adjust the headrest backward, pull it
fully forward to the farthest position
and release it. Adjust the headrest so
that it properly supports the head
and neck. Adjusting the height up and down
The headrest not only provides com-
fort for the driver and passengers,
but also helps to protect the head
and neck in the event of a collision.
To raise the headrest, pull it up to the
desired position (
➀). To lower the
headrest, push and hold the release
button (
➁) on the headrest support
and lower the headrest to the desired
position (➂). For best protection,
adjust the headrest so its center is as
high as your ears. Also adjust the
headrest so its distance from the
head is as wide as your fist.
2GHA2243
1GHA2245
1GHA2246
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 24

325
1
2
3
4
5
6
7
8
9
Knowing your vehicle
Removal
To remove the headrest, raise it as
far as it can go then press the
release lever (
➀) while pulling
upward (
➁).
Adjusting the front passenger
seatForward/backward position
adjustmentPush the control knob forward or
backward to move the seat to the
desired position. Release the knob
and the seat will lock in the selected
position.
Adjust the seat before driving, and
make sure the seat is locked secure-
ly by trying to move forward and
backward without using the control
knob. If the seat moves, it is not
locked properly.
1GHA2247
WARNING
To reduce the risk of head and
neck injuries, do not drive the
vehicle with the headrest
removed or improperly posi-
tioned.
Do not adjust the driver ’s head-
rest while driving.
1GHA2248
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 25

Headrest adjustmentAdjusting forward and backward
The headrest may be adjusted for-
ward to three different positions by
pulling the headrest forward. To
adjust the headrest backward, pull it
fully forward to the farthest position
and release it. Adjust the headrest so
that it properly supports the head
and neck.Adjusting the height up and down
The headrest not only provides com-
fort for the driver and passengers,
but also helps to protect the head
and neck in the event of a collision.
To raise the headrest, pull it up to the
desired position (
➀). To lower the
headrest, push and hold the release
button (
➁) on the headrest support
and lower the headrest to the desired
position (➂). For best protection,
adjust the headrest so its center is as
high as your ears. Also adjust the
headrest so its distance from the
head is as wide as your fist.
Knowing your vehicle28
3
1
2
3
4
5
6
7
8
9
1GHA2246
1GHA2245
WARNING
Passengers should use extreme
caution when using seat warm-
ers due to the possibility of
excess heating or burns. In par-
ticular, the following types of
passengers should exercise
extreme care:
1. Infants, children, elderly or
handicapped persons, or hos-
pital outpatients
2. Persons with sensitive skin or those that burn easily
3. Fatigued individuals
4. Intoxicated individuals
5. Individuals taking medication that can cause drowsiness or
sleepiness (sleeping pills,
cold tablets, etc.)
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 28

329
1
2
3
4
5
6
7
8
9
Knowing your vehicle
Removal
To remove the headrest, raise it as
far as it can go then press the
release button (
➀) while pulling
upward (
➁).
WARNING
To reduce the risk of head and
neck injuries, do not drive the
vehicle with the headrest
removed or improperly posi-
tioned.
1GHA2247
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 29

Knowing your vehicle30
3
1
2
3
4
5
6
7
8
9
Rear seatFull flat seatTo allow the rear seat passenger to
support their legs while the front
passenger seat is in a reclined posi-
tion, the front passenger seatback
can be reclined nearly flat.
1. Remove the headrest (refer to
page 3-29).
2. Using the control switch, move the front passenger seat to the far-
thest forward position.
3. Using the control switch, recline the seatback as far as it can go to
allow the rear seat passenger to
support their legs in the reclined
position.
ArmrestThe armrest is located in the center
of the rear seat. Pull the armrest
down from the seatback.
You will find a storage cover and cup
holders (if equipped).
2GHN2237
1GHA2252
WARNING
Do not allow a rear seat passen-
ger to use the full flat seat fea-
ture and recline while the vehi-
cle is in motion. Severe injury
or death could occur.
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 30

Knowing your vehicle32
3
1
2
3
4
5
6
7
8
9
Headrest adjustmentAdjusting forward and backward
The headrest may be adjusted for-
ward to three different positions by
pulling the headrest forward. To
adjust the headrest backward, pull it
fully forward to the farthest position
and release it. Adjust the headrest so
that it properly supports the head
and neck. Adjusting the height up and down
The headrest not only provides com-
fort for the driver and passengers,
but also helps to protect the head
and neck in the event of a collision.
To raise the headrest, pull it up to the
desired position (
➀). To lower the
headrest, push and hold the release
button (
➁) on the headrest support
and lower the headrest to the desired
position (➂). For best protection,
adjust the headrest so its center is as
high as your ears. Also adjust the
headrest so its distance from the
head is as wide as your fist. Removal
To remove the headrest, raise it as
far as it can go then press the
release lever (
➀) while pulling
upward (
➁).
1GHA2254
1GHA2255
1GHA2253
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 32

333
1
2
3
4
5
6
7
8
9
Knowing your vehicle
Storing long/narrow cargo withtrunk closed (if equipped)Pull the armrest down using the
strap provided on the armrest. Pull
the cover down while pushing the
release lever down. Additional cargo
space is provided to accommodate
long/narrow cargo (skis, poles, lum-
ber, etc.) not able to fit properly in the
trunk when closed.
WARNING
To reduce the risk of head and
neck injuries, do not drive the
vehicle with the headrest
removed or improperly posi-
tioned.
1GHA2108
CAUTION
 Make sure the engine is off,
the transaxle is in P and theparking brake is appliedwhenever loading or unload-ing cargo. Vehicle may move ifshift lever is inadvertentlymoved to another position.
 Be careful when loading cargo
through the rear passengerseats to prevent damage tothe vehicle interior.
 When cargo is loaded through
the rear passenger seats,ensure the cargo is properlysecured to prevent it frommoving while driving.Unsecured cargo in the pas-senger compartment cancause damage to the vehicleor injury to it’ s occupants.
Opirus-ENG (CAN) 3.qxd 7/8/03 1:56 PM Page 33
