HEATER & COOLING UNIT ASSEMBLY
Revision: August 20072004 QX56
4. Remove the exhaust system. Refer to EX-3, "Removal and Installation" .
5. Disconnect the front heater hoses from the front heater core.
6. Disconnect the high/low pressure pipes from the front expansion valve.
7. Move the two front seats to the rearmost position on the seat track.
8. Remove the instrument panel and console panel. Refer to IP-10, "
INSTRUMENT PANEL ASSEMBLY" .
9. Remove the steering column. Refer to PS-10, "
Removal and Installation" .
10. Disconnect the instrument panel wire harness at the RH and LH in-line connector brackets, and the fuse
block (J/B) electrical connectors. Refer to PG-40, "
Harness Layout" .
11. Disconnect the steering member from each side of the vehicle body.
12. Remove the front heater and cooling unit assembly with it attached to the steering member, from the vehi-
cle.
CAUTION:
Use care not to damage the seats and interior trim panels when removing the front heater and
cooling unit assembly with it attached to the steering member.
13. Remove the front heater and cooling unit assembly from the steering member.
Installation
Installation is in the reverse order of removal.
CAUTION:

Replace the O-ring of the low-pressure pipe and high-pressure pipe with a new one, and apply
compressor oil to it when installing it.

After charging the refrigerant, check for leaks.
NOTE:

Fill the engine cooling system with the specified coolant mixture. Refer to MA-13, "REFILLING ENGINE
COOLANT" .

Recharge the A/C system. Refer to ATC-162, "Evacuating System and Charging Refrigerant" .
REAR HEATER AND COOLING UNIT ASSEMBLY
Removal
1. Discharge the refrigerant from the A/C system. Refer to ATC-162, "Discharging Refrigerant" .
2. Drain the coolant from the engine cooling system. Refer to MA-12, "
DRAINING ENGINE COOLANT" .
3. Disconnect the rear heater core hoses from the rear heater core.
4. Disconnect the rear A/C pipes from the rear expansion valve.
5. Remove the rear RH interior trim panel. Refer to EI-34,
"Removal and Installation" .
6. Disconnect the following electrical connectors:

Rear blower motor

Rear blower motor resistor

Rear air mix door motor
7. Disconnect the ducts from the rear heater and cooling unit
assembly.
8. Remove the rear heater and cooling unit assembly.
Installation
Installation is in the reverse order of removal.
CAUTION:

Replace the O-ring of the low-pressure pipe and high-pressure pipe with a new one, and apply
compressor oil to it when installing it.

After charging the refrigerant, check for leaks.
NOTE:

Fill the engine cooling system with the specified coolant mixture. Refer to MA-13, "REFILLING ENGINE
COOLANT" .

Recharge the A/C system. Refer to ATC-162, "Evacuating System and Charging Refrigerant" .
LJIA0021E

HEATER CORE
ATC-149
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: August 20072004 QX56
5. Remove the heater core.
NOTE:
If the in-cabin microfilters are contaminated from coolant leaking
from the heater core, replace the in-cabin microfilters with new
ones before installing the new heater core.
Installation
Installation is in the reverse order of removal.
REAR HEATER CORE
Removal
1. Partially drain the engine cooling system. Refer to MA-12, "DRAINING ENGINE COOLANT" .
2. Remove the rear RH interior trim panel. Refer to EI-34, "
Removal and Installation" .
3. Disconnect the rear heater hoses from the heater core.
4. Remove the rear heater core bracket.
5. Remove the heater core.
Installation
Installation is in the reverse order of removal.
LJIA0134E
LJIA0069E
LJIA0071E

REFRIGERANT LINES
ATC-171
C
D
E
F
G
H
I
K
L
MA
B
AT C
Revision: August 20072004 QX56
INSTALLATION
Installation is in the reverse order of removal.
Refer to ATC-164, "
Components" .
CAUTION:

Replace the O-ring of the high-pressure pipe with a new one, then apply compressor oil to it when
installing it.

After charging refrigerant, check for leaks.
Removal and Installation for Low-pressure PipeEJ S00 2DO
REMOVAL
1. Discharge the refrigerant. Refer to ATC-162, "HFC-134a (R-134a) Service Procedure" .
2. Remove the cowl top and the cowl top extension. Refer to EI-18, "
COWL TOP" .
3. Remove the low-pressure pipe. Refer to ATC-164, "
Components" .
CAUTION:
Cap or wrap the joint of the pipes with suitable material such as vinyl tape to avoid the entry of
contaminants.
INSTALLATION
Installation is in the reverse order of removal.
Refer to ATC-164, "
Components" .
CAUTION:

Replace the O-ring of the high/low-pressure pipe with a new one, then apply compressor oil to it
when installing it.

After charging refrigerant, check for leaks.
Removal and Installation for Rear High- and Low-pressure A/C and Heater Core
Pipes
EJS0060M
REMOVAL
1. Discharge the refrigerant. Refer to ATC-162, "HFC-134a (R-134a) Service Procedure" .
2. Drain the coolant from the engine cooling system. Refer to CO-8, "
Changing Engine Coolant" .
3. Disconnect the underfloor rear heater hoses (1 and 2) from the
rear heater pipes underneath the vehicle.

⇐: Front
4. Remove the rear high- and low-pressure pipes bolt (A) to dis-
connect the rear high- and low-pressure pipes from the under-
floor rear high- and low-pressure pipes underneath the vehicle.
CAUTION:
Cap or wrap the joint of the pipes with suitable material
such as vinyl tape to avoid the entry of air.
5. Remove the rear high- and low-pressure pipes nuts (B) under-
neath the vehicle.
NOTE:
The remaining steps are performed inside the rear luggage area of the vehicle.
6. Remove the luggage side finisher lower RH. Refer to EI-39, "
LUGGAGE FLOOR TRIM" .
7. Disconnect the rear heater core hoses (1 and 2) from the rear
heater core (3).

⇐: Front
WJIA2310E
WJIA2311E

ATC-172
REFRIGERANT LINES
Revision: August 20072004 QX56
8. Remove the rear high- and low-pressure pipes bracket bolt (A)
to release the bracket.

Rear blower motor (1)

⇐: Front
9. Remove the rear high- and low-pressure pipes bolt (A) to dis-
connect the rear high- and low-pressure pipes from the rear
expansion valve (1).

⇐: Front
CAUTION:
Cap or wrap the joint of the pipes with suitable material
such as vinyl tape to avoid the entry of air.
10. Disconnect the following electrical connectors:

Rear air mix door motor (1)

Rear blower motor resistor (2)

Rear blower motor (3)

⇐: Front
11. Disconnect the ducts from the rear heater and cooling unit assembly. Refer to ATC-157, "
Components" .
12. Remove the rear heater and cooling unit assembly.
CAUTION:
Cap or wrap the joint of the pipes with suitable material such as vinyl tape to avoid the entry of air.
13. Remove the rear high- and low-pressure A/C pipes.
INSTALLATION
Installation is in the reverse order of removal.
Refer to ATC-164, "
Components" .
CAUTION:

Replace the O-ring of the high/low-pressure pipe with a new one, then apply compressor oil to it
when installing it.

After charging refrigerant, check for leaks.
Removal and Installation for Underfloor Rear High- and Low-pressure A/C and
Heater Core Pipes
EJS0060N
REMOVAL
1. Drain the coolant from the engine cooling system. Refer to CO-8, "Changing Engine Coolant" .
2. Disconnect the battery negative terminal.
3. Disconnect the generator harness.
4. Discharge the refrigerant. Refer to ATC-162, "
HFC-134a (R-134a) Service Procedure" .
WJIA2312E
WJIA2313E
WJIA2314E

CO-1
ENGINE COOLING SYSTEM
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTION CO
A
CO
Revision: August 20072004 QX56 PRECAUTIONS .......................................................... 2
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 2
PREPARATION ........................................................... 3
Special Service Tools ............................................... 3
Commercial Service Tools ........................................ 3
OVERHEATING CAUSE ANALYSIS .......................... 4
Troubleshooting Chart .............................................. 4
COOLING SYSTEM .................................................... 6
Cooling Circuit .......................................................... 6
System Drawing ....................................................... 7
ENGINE COOLANT .................................................... 8
Inspection ................................................................. 8
LEVEL CHECK ..................................................... 8
CHECKING COOLING SYSTEM FOR LEAKS ..... 8
CHECKING RESERVOIR CAP ............................. 8
CHECKING RADIATOR CAP ................................ 8
Changing Engine Coolant ........................................ 8
DRAINING ENGINE COOLANT ........................... 8
REFILLING ENGINE COOLANT .......................... 9
FLUSHING COOLING SYSTEM ........................... 9
RADIATOR ................................................................ 10
Removal and Installation ........................................ 10
REMOVAL ........................................................... 10
INSTALLATION ................................................... 12
INSPECTION AFTER INSTALLATION ............... 12
Checking Radiator .................................................. 12ENGINE COOLING FAN ........................................... 13
Removal and Installation (Crankshaft Driven Type) ... 13
REMOVAL ........................................................... 13
INSPECTION AFTER REMOVAL ....................... 13
INSTALLATION ................................................... 13
INSPECTION AFTER INSTALLATION ................ 13
Removal and Installation (Motor Driven Type) ....... 14
REMOVAL ........................................................... 14
INSTALLATION ................................................... 14
WATER PUMP .......................................................... 15
Removal and Installation ........................................ 15
REMOVAL ........................................................... 15
INSPECTION AFTER REMOVAL ....................... 15
INSTALLATION ................................................... 15
INSPECTION AFTER INSTALLATION ................ 16
THERMOSTAT AND WATER PIPING ...................... 17
Removal and Installation ........................................ 17
REMOVAL ........................................................... 17
INSPECTION AFTER REMOVAL ....................... 18
INSTALLATION ................................................... 18
INSPECTION AFTER INSTALLATION ................ 18
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 19
Standard and Limit .................................................. 19
ENGINE COOLANT CAPACITY (APPROXI-
MATE) .................................................................. 19
THERMOSTAT .................................................... 19
RADIATOR .......................................................... 19

PREPARATION
CO-3
C
D
E
F
G
H
I
J
K
L
MA
CO
Revision: August 20072004 QX56
PREPARATIONPFP:00002
Special Service ToolsEBS00I4R
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Commercial Service ToolsEBS00I4S
Tool number
(Kent-Moore No.)
Tool nameDescription
EG17650301
(J-33984-A)
Radiator cap tester adapterAdapting radiator cap tester to radiator cap
and radiator filler neck
a: 28 (1.10) dia.
b: 31.4 (1.236) dia.
c: 41.3 (1.626) dia.
Unit: mm (in)
KV991J0010
(J-23688)
Engine coolant refractometerChecking concentration of ethylene glycol in
engine coolant
S-NT564
W BIA0539E
Tool nameDescription
Power toolLoosening bolts and nuts
Radiator cap tester Checking radiator and radiator cap
Coolant system tester adapter Adapting radiator cap tester to reservoir filler
neck
Coolant system tester adapter Adapting radiator cap tester to reservoir cap
PBIC0190E
PBIC1982E
W BIA0408E
W BIA0409E

CO-4Revision: August 2007
OVERHEATING CAUSE ANALYSIS
2004 QX56
OVERHEATING CAUSE ANALYSISPFP:00012
Troubleshooting ChartEBS00I4T
Symptom Check items
Cooling sys-
tem parts
malfunctionPoor heat transferWater pump malfunction Worn or loose drive belt
— Thermostat stuck closed —
Damaged finsDust contamination or
paper clogging
Physical damage
Clogged radiator cooling
tubeExcess foreign material
(rust, dirt, sand, etc.)
Water cut valve malfunctionExcess foreign material
(rust, dirt, sand, etc.), phys-
ical damage
Reduced air flowCooling fan does not oper-
ate
Fan assembly — High resistance to fan rota-
tion
Damaged fan blades
Damaged radiator shroud — — —
Improper engine coolant
mixture ratio—— —
Poor engine coolant quality — Engine coolant density —
Insufficient engine coolantEngine coolant leaksCooling hoseLoose clamp
Cracked hose
Water pump Poor sealing
Radiator capLoose
Poor sealing
RadiatorO-ring for damage, deterio-
ration or improper fitting
Cracked radiator tank
Cracked radiator core
Reservoir tank Cracked reservoir tank
Overflowing reservoir tankExhaust gas leaks into
cooling systemCylinder head deterioration
Cylinder head gasket dete-
rioration

CO-8Revision: August 2007
ENGINE COOLANT
2004 QX56
ENGINE COOLANTPFP:KQ100
InspectionEBS00I4W
LEVEL CHECK

Check if the engine coolant reservoir tank level is within MIN to
MAX level when engine is cool.

Adjust engine coolant level as necessary.
CHECKING COOLING SYSTEM FOR LEAKS
WAR NIN G:
Never remove the radiator or reservoir cap when the engine is hot. Serious burns could occur from
high-pressure engine coolant escaping from the radiator or reservoir.

To check for leakage, apply pressure to the cooling system at
the reservoir filler neck using suitable tool and Tool.
CAUTION:
Higher pressure than specified may cause radiator damage.
NOTE:
In case that engine coolant decreases, replenish cooling system
with engine coolant.

If any concerns are found, repair or replace damaged parts.
CHECKING RESERVOIR CAP

Check reservoir cap relief pressure using suitable tool and Tool.
NOTE:
Apply engine coolant to the cap seal.

Replace the reservoir cap if there is any damage in the nega-
tive-pressure valve, or if the open-valve pressure is outside of
the limit.
CHECKING RADIATOR CAP
Inspect the radiator cap.
NOTE:
Thoroughly wipe out the radiator filler neck to remove any waxy residue or foreign material.

Replace the cap if the metal plunger cannot be seen around the edge of the black rubber gasket.

Replace the cap if deposits of waxy residue or other foreign material are on the black rubber gasket or the
metal retainer.
Changing Engine CoolantEBS00I4X
Refer to MA-12, "Changing Engine Coolant" .
DRAINING ENGINE COOLANT
Refer to MA-12, "DRAINING ENGINE COOLANT" .
SM A41 2B
Tool number : EG17650301 (J-33984-A)
Leakage test pressure : 137 kPa (1.4 kg/cm, 20 psi)
WBIA0612E
Tool number : EG17650301 (J-33984-A)
Standard
: 95 - 125 kPa (0.97 - 1.28 kg/cm
2 , 14 - 18
psi)
WBIA0611E
