GW-78
FRONT DOOR GLASS AND REGULATOR
Revision: 2004 November 2004 FX35/FX45
Inspection after Removal
Check the regulator assembly for the following. If a malfunction is
detected, replace or grease it.
Wire wear
Regulator deformation
Grease condition for each sliding part
The arrows in the figure show the application points of the body
grease.
Disassembly and assemblyAIS006NV
REGULATOR ASSEMBLY
Disassembly
Remove the power window motor and guide rail from the module
assembly.
Assembly
Assemble in the reverse order of disassembly.
Inspection after InstallationAIS006NW
SETTING OF LIMIT SWITCH
Setting of Limit Switch
If any of the following work has been done, set the limit switch (integrated in the motor).
Removal and installation of the motor from the regulator.
Operate the regulators as a unit.
Installation of the new glass.
Installation of the new glass run.
Resetting
After installing each component to the vehicle, follow the steps below.
1. Raise the glass to the top position.
2. While pressing and holding the reset switch, lower the glass to
the bottom position.
3. Release the reset switch, and check the reset switch returns to
the original position, and then raise the glass to the top position.
CAUTION:
Do not operate the glass automatically to raise the glass to
the top position.
FITTING INSPECTION
Make sure the glass is securely fit into the glass run groove.
PIIA4730E
PIIA4731E
PIIA4732E
GW-82
REAR DOOR GLASS AND REGULATOR
Revision: 2004 November 2004 FX35/FX45
10. Remove the power window motor mounting bolts and nuts, and
remove the regulator from the panel.
11. Disconnect the connector for the regulator assembly.
Installation
Install in the reverse order of removal.
Inspection after Removal
Check the regulator assembly for the following. If a malfunction is
detected, replace or grease it.
Gear wear
Regulator deformation
Spring damage
Grease condition for each sliding part
The arrows in the figure show the application points of the body
grease.
Disassembly and assemblyAIS006NY
REGULATOR ASSEMBLY
Disassembly
Remove the power window motor from the regulator assembly.
Assembly
Assemble in the reverse order of disassembly.
Inspection after InstallationAIS006NZ
SETTING OF LIMIT SWITCH (WITH ANTI-PINCH SYSTEM ONLY)
If any of the following work has been done, set the limit switch (integrated in the motor).
Removal and installation of the motor from the regulator.
Operate the regulators as a unit.
Installation of the new glass.
Installation of the new glass run.
Resetting
After installing each component to the vehicle, follow the steps below.
1. Raise the glass to the top position.
2. While pressing and holding the reset switch, lower the glass to
the bottom position.
3. Release the reset switch, and check the reset switch returns to
the original position, and then raise the glass to the top position.
CAUTION:
Do not operate the glass automatically to raise the glass to
the top position.
PIIA4736E
PIIA4935E
PIIA4737E
