7. Remove timing chain tensioner (primary) with the following pro-
cedure.
a. Pull the lever down and release plunger stopper tab.

Plunger stopper tab can be pushed up to release (coaxial
structure with lever).
b. Insert stopper pin into the tensioner body hole to hold lever and
keep the plunger stopper tab released.
NOTE:
An Allen wrench [2.5 mm (0.098 in)] is used for a stopper pin as
an example.
c. Insert plunger into the tensioner body by pressing timing chain
slack guide.
d. Keep slack guide pressed and hold plunger in by pushing stopper pin deeper through lever and into the
tensioner body hole.
e. Turn crankshaft pulley approximately 20° clockwise so that tim-
ing chain on the timing chain tensioner (primary) side is loose.
f. Remove mounting bolts and timing chain tensioner (primary).
CAUTION:
Be careful not to drop mounting bolts inside chain case.
8. Remove three water pump fixing bolts. Secure a gap between
water pump gear and timing chain, by turning crankshaft pulley
counterclockwise until timing chain looseness on water pump
sprocket becomes maximum.
PBIC2112E
PBIC0848E
PBIC2113E
PBIC1193E

CO-24
[VQ35DE]
WATER PUMP
Revision: 2004 November 2004 FX35/FX45
9. Screw M8 bolts [pitch: 1.25 mm (0.049 in) length: approx. 50
mm (1.97 in)] into water pumps upper and lower mounting bolt
holes until they reach timing chain case. Then, alternately
tighten each bolt for a half turn, and pull out water pump.
CAUTION:

Pull straight out while preventing vane from contacting
socket in installation area.

Remove water pump without causing sprocket to contact
timing chain.
10. Remove M8 bolts and O-rings from water pump.
CAUTION:
Do not disassembly water pump.
INSPECTION AFTER REMOVAL

Check for badly rusted or corroded water pump body assembly.

Check for rough operation due to excessive end play.

If anything is found, replace water pump.
