2004 INFINITI FX35 relay

GW-102
REAR WINDOW DEFOGGER
Revision: 2004 November 2004 FX35/FX45
Rear Window Defogger Circuit CheckAIS004RC
1. CHECK POWER SUPPLY CIRCUIT 1
1. Turn ignition switch OFF.
2. Disconnect rear window defogger connector.
3. Turn ignition switch ON.
4. Check voltage between rear window defogger connector and
ground.
OK or NG
OK >> GO TO 2.
NG >> GO TO 3.
2. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between rear window defogger connector
D114 terminal 2 and ground.
OK or NG
OK >> Check filament. Refer to GW-107, "Filament Check"

If filament is OK, check condition of harness and con-
nector.

If filament is NG, repair filament.
NG >> Repair or replace harness between rear window defog-
ger and ground.
3. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Remove rear window defogger relay.
3. Check continuity between rear window defogger relay connector
E13 terminal 5, 7 and rear window defogger connector D104 ter-
minal 1.
OK or NG
OK >> Check condition of harness and connector.
NG >> Repair or replace harness rear window defogger relay
and condenser.
ConnectorTerminal (Wire color)
ConditionVoltage (V)
(Approx.)
(+) (–)
D104 1(W) GroundRear window defogger
switch ON. Battery voltage
Rear window defogger
switch OFF.0
PIIA9347E
2 (B) − Ground : Continuity should exist.
PIIA9348E
5 (B) – 1 (W) : Continuity should exist.
7 (B) – 1 (W) : Continuity should exist.
PIIA9349E

REAR WINDOW DEFOGGER
GW-103
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: 2004 November 2004 FX35/FX45
Door Mirror Defogger Power Supply Circuit CheckAIS004RD
1. CHECK FUSE

Check 15A fuse [No.8, located in fuse block (J/B)]
NOTE:
Refer to GW-86, "
Component Parts and Harness Connector Location" .
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown out, be sure to eliminate cause of malfunction before installing new fuse. Refer to
PG-3, "
POWER SUPPLY ROUTING CIRCUIT" .
2. CHECK POWER SUPPLY CIRCUIT 1
1. Turn ignition switch ON.
2. Check voltage between fuse block (J/B) connector and ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness between rear window defog-
ger relay and fuse block (J/B).
3. CHECK POWER SUPPLY CIRCUIT 2
Check voltage between fuse block (J/B) connector and ground.
OK or NG
OK >> GO TO 4.
NG >> Replace fuse block (J/B).
4. CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect fuse block (J/B) and door mirror connector.
3. Check continuity between fuse block (J/B) connector M2 termi-
nal 5B and door mirror connector D2 (driver side) or D32 (pas-
senger side) terminal 1.
OK or NG
OK >> GO TO 5.
NG >> Repair or replace harness between fuse block (J/B) and
malfunction door mirror connector.
ConnectorTerminal (Wire color)
ConditionVoltage (V)
(Approx.)
(+) (–)
E201 2C (B) GroundRear window defogger
switch ON Battery voltage
Rear window defogger
switch OFF0
PIIA2388E
ConnectorTerminal (Wire color)
ConditionVoltage (V)
(Approx.)
(+) (–)
M2 5B (L) GroundRear window defogger
switch ON Battery voltage
Rear window defogger
switch OFF0
PIIA2386E
5B (L) – 1 (L) : Continuity should exist.
PIIA6213E

IDX-7
A
C
D
E
F
G
H
I
J
K
L B
IDX
ALPHABETICAL INDEX
Propeller shaft ..................................................... PR-6
Propeller shaft on vehicle service ........................ PR-6
Propeller shaft vibration ....................................... PR-6
PS/SEN - Wiring diagram ................ EC-397, EC-1053
R
R/VIEW - Wiring diagram ................................... DI-84
Radiator(VK45DE) ............................................. CO-39
Radiator(VQ35DE) ............................................ CO-14
Rear axle ........................................................... RAX-5
Rear bumper ........................................................ EI-18
Rear combination lamp removal and installation ..........
LT-147
Rear door ............................................ BL-148, GW-80
Rear seat ......................................................... SE-107
Rear suspension ............................................... RSU-5
Rear view monitor ............................................... DI-81
Rear washer .................................................... WW-35
Rear window defogger ...................................... GW-86
Rear wiper ....................................................... WW-35
Refrigerant connection precaution ..................... ATC-8
Refrigerant discharging evacuating charging ATC-137
Refrigerant general precaution .......................... ATC-7
Refrigerant lines ............................................ ATC-137
Refrigerant pressure sensor ........... EC-609, EC-1287,
ATC-90
, ATC-155
Refrigeration cycle ........................................... ATC-21
Removal and installation (A/T) ........... AT-266, AT-269
Removal and installation (Transfer) .................... TF-43
Revolution sensor (A/T) ...................... AT-116, AT-260
Ring gear diff. inspection ................................. RFD-13
Rocker cover(VK45DE) ................................... EM-193
Rocker cover(VQ35DE) ..................................... EM-51
Room lamp - See Interior lamp ......................... LT-157
ROOM/L - Wiring diagram ................................ LT-164
RP/SEN - Wiring diagram ................ EC-610, EC-1288
S
Seal - See Exterior .............................................. EI-28
SEAT - Wiring diagram ...................................... SE-95
Seat belt inspection ............................................. SB-8
Seat belt pre-tensioner disposal ...................... SRS-49
Seat belt, front ..................................................... SB-4
Seat, rear ......................................................... SE-107
Self-diagnosis (Transfer) .................................... TF-21
SEN/PW - Wiring diagram ............... EC-490, EC-1157
SHIFT - Wiring diagram ................................... AT-236
Shift change signal ........................................ EC-1218
Shift lock system .............................................. AT-235
Shift schedule .................................................. AT-348
Shock absorber (rear) ....................................... RSU-9
Side air bag (satellite) sensor .......................... SRS-46
Side bearing preload diff. ................................. RFD-20
Side curtain air bag .......................................... SRS-43
Side flange installation diff. .............................. RFD-10
Side trim .............................................................. EI-37
SMJ (super multiple junction) ............................ PG-79
Spark plug replacement .................................... MA-26
Spark plug replacement(VQ35DE) ................... MA-19
Spark plug(VK45DE) ...................................... EM-186
Spark plug(VQ35DE) ........................................ EM-43
Specification value ............................. EC-131, EC-780
Speedometer ........................................................ DI-4
Spiral cable ..................................................... SRS-38
Spot lamp .......................................................... LT-184
SROOF - Wiring diagram ..................... BL-167, RF-14
SRS - See Supplemental Restraint System ..... SRS-5
SRS Trouble diagnoses .................................... SRS-7
Stabilizer bar (rear) ......................................... RSU-16
Stall test (A/T) .................................................... AT-51
Standardized relay ............................................. PG-81
START - Wiring diagram .................................... SC-11
Starter ................................................................ SC-10
Starting system .................................................. SC-10
Steering gear and linkage inspection ................ MA-35
Steering linkage ................................................. PS-19
Steering wheel and column ................... PS-10, PS-12
Steering wheel turning force .............................. PS-10
Step lamp .......................................................... LT-124
Stop lamp .......................................................... LT-116
Stop lamp switch .............................. EC-550, EC-1220
STOP/L - Wiring diagram .................................. LT-118
Sun roof, electric ................................................ RF-10
Sunload sensor ............................. ATC-110, ATC-119
Sunroof .................................................. RF-10, RF-25
Supplemental Restraint System ....................... SRS-5
Suspension ....................................................... MA-36
Symbols and abbreviations ...................... GI-10, GI-23
T
Tachometer ........................................................... DI-4
TCM circuit diagram ........................................... AT-50
TCM inspection table ......................................... AT-90
Thermostat(VK45DE) ....................................... CO-51
Thermostat(VQ35DE) ....................................... CO-26
Three way catalyst function (Bank 1) . EC-316, EC-971
Three way catalyst function (Bank 2) . EC-316, EC-971
Three way catalyst precautions ............................ GI-6
Three way catalyst(VK45DE) .......................... EM-178
Three way catalyst(VQ35DE) ........................... EM-26
Throttle control motor ....................... EC-428, EC-1090
Throttle control motor relay .............. EC-423, EC-1085
Throttle position sensor (TPS) .......... EC-190, EC-284,
EC-485
, EC-487, EC-569, EC-848, EC-942, EC-1152,
EC-1154
, EC-1239
Tie-rod ............................................................... PS-19
Timing chain(VK45DE) ................................... EM-196
Timing chain(VQ35DE) ..................................... EM-63
Tire rotation ............................................. WT-6, MA-34
Tooth contact diff. ........................................... RFD-24
Top tether strap child restraint ........................... SB-12
Torque converter installation AT-267, AT-268, AT-272
Torque convertor clutch solenoid valve AT-123, AT-125
TPS1 - Wiring diagram ...................... EC-286, EC-944
TPS2 - Wiring diagram ...................... EC-192, EC-850

LAN-1
LAN SYSTEM
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION LAN
A
B
LAN
Revision: 2004 November 2004 FX35/FX45
LAN SYSTEM
CAN
PRECAUTIONS .......................................................... 4
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 4
Precautions When Using CONSULT-II ..................... 4
CHECK POINTS FOR USING CONSULT-II ......... 4
Precautions For Trouble Diagnosis .......................... 4
CAN SYSTEM ....................................................... 4
Precautions For Harness Repair .............................. 5
CAN SYSTEM ....................................................... 5
CAN COMMUNICATION ............................................ 6
System Description .................................................. 6
CAN Communication Unit ........................................ 6
TYPE 1/TYPE2 ..................................................... 6
TYPE 3 .................................................................. 9
TYPE 4/TYPE5 ................................................... 13
TYPE 6 ................................................................ 16
CAN SYSTEM (TYPE 1) ........................................... 21
System Description ................................................ 21
Component Parts and Harness Connector Location ... 21
Wiring Diagram - CAN - ......................................... 22
Work Flow .............................................................. 24
CHECK SHEET ................................................... 26
CHECK SHEET RESULTS (EXAMPLE) ............. 28
Circuit Check Between TCM and Data Link Con-
nector ..................................................................... 41
Circuit Check Between Data Link Connector and
Unified Meter and A/C Amp. .................................. 41
Circuit Check Between Unified Meter and A/C Amp.
and ABS Actuator and Electric Unit (Control Unit) ... 42
ECM Circuit Check ................................................. 42
TCM Circuit Check ................................................. 43
Display Unit Circuit Check ...................................... 43
Data Link Connector Circuit Check ........................ 44
BCM Circuit Check ................................................. 44
Steering Angle Sensor Circuit Check ..................... 45
Unified Meter and A/C Amp. Circuit Check ............ 45
ABS Actuator and Electric Unit (Control Unit) Circuit
Check ..................................................................... 46IPDM E/R Circuit Check ......................................... 46
CAN Communication Circuit Check ........................ 47
IPDM E/R Ignition Relay Circuit Check .................. 51
Component Inspection ............................................ 51
ECM/IPDM E/R INTERNAL CIRCUIT INSPEC-
TION .................................................................... 51
CAN SYSTEM (TYPE 2) ........................................... 52
System Description ................................................. 52
Component Parts and Harness Connector Location ... 52
Wiring Diagram - CAN - .......................................... 53
Work Flow ............................................................... 55
CHECK SHEET ................................................... 57
CHECK SHEET RESULTS (EXAMPLE) ............. 59
Circuit Check Between TCM and Data Link Con-
nector ...................................................................... 74
Circuit Check Between Data Link Connector and
Unified Meter and A/C Amp. ................................... 74
Circuit Check Between Unified Meter and A/C Amp.
and ABS Actuator and Electric Unit (Control Unit) ... 75
Circuit Check Between ABS Actuator and Electric
Unit (Control Unit) and Driver Seat Control Unit ..... 76
ECM Circuit Check ................................................. 76
TCM Circuit Check ................................................. 77
Display Unit Circuit Check ...................................... 77
Data Link Connector Circuit Check ........................ 78
BCM Circuit Check ................................................. 78
Steering Angle Sensor Circuit Check ..................... 79
Unified Meter and A/C Amp. Circuit Check ............ 79
ABS Actuator and Electric Unit (Control Unit) Circuit
Check ..................................................................... 80
Driver Seat Control Unit Circuit Check ................... 80
IPDM E/R Circuit Check ......................................... 81
CAN Communication Circuit Check ........................ 82
IPDM E/R Ignition Relay Circuit Check .................. 86
Component Inspection ............................................ 86
ECM/IPDM E/R INTERNAL CIRCUIT INSPEC-
TION .................................................................... 86
CAN SYSTEM (TYPE 3) ........................................... 87
System Description ................................................. 87
Component Parts and Harness Connector Location ... 87

LAN-2Revision: 2004 November 2004 FX35/FX45Schematic ............................................................... 88
Wiring Diagram - CAN - .......................................... 89
Work Flow ............................................................... 92
CHECK SHEET ................................................... 94
CHECK SHEET RESULTS (EXAMPLE) ............. 97
Circuit Check Between TCM and Data Link Con-
nector ....................................................................116
Circuit Check Between Data Link Connector and
Unified Meter and A/C Amp. .................................117
Circuit Check Between Unified Meter and A/C Amp.
and ABS Actuator and Electric Unit (Control Unit) .117
Circuit Check Between ABS Actuator and Electric
Unit (Control Unit) and Driver Seat Control Unit ...118
ECM Circuit Check ...............................................119
TCM Circuit Check ...............................................119
Display Control Unit Circuit Check ........................120
Low Tire Pressure Warning Control Unit Circuit
Check ...................................................................120
ICC Unit Circuit Check ..........................................121
Intelligent Key Unit Circuit Check .........................121
Data Link Connector Circuit Check .......................122
BCM Circuit Check ...............................................122
Steering Angle Sensor Circuit Check ...................123
Unified Meter and A/C Amp. Circuit Check ...........123
ICC Sensor Circuit Check .....................................124
ABS Actuator and Electric Unit (Control Unit) Circuit
Check ...................................................................124
Driver Seat Control Unit Circuit Check .................125
IPDM E/R Circuit Check .......................................126
CAN Communication Circuit Check ......................127
IPDM E/R Ignition Relay Circuit Check .................132
Component Inspection ..........................................132
ECM/IPDM E/R INTERNAL CIRCUIT INSPEC-
TION ..................................................................132
CAN SYSTEM (TYPE 4) .........................................133
System Description ...............................................133
Component Parts and Harness Connector Location .133
Schematic .............................................................134
Wiring Diagram - CAN - ........................................135
Work Flow .............................................................138
CHECK SHEET .................................................140
CHECK SHEET RESULTS (EXAMPLE) ...........142
Circuit Check Between TCM and Data Link Con-
nector ....................................................................156
Circuit Check Between Data Link Connector and
Unified Meter and A/C Amp. .................................156
Circuit Check Between Unified Meter and A/C Amp.
and ABS Actuator and Electric Unit (Control Unit) .157
ECM Circuit Check ...............................................157
TCM Circuit Check ...............................................158
Display Unit Circuit Check ....................................158
AWD Control Unit Circuit Check ...........................159
Data Link Connector Circuit Check .......................159
BCM Circuit Check ...............................................160
Steering Angle Sensor Circuit Check ...................160
Unified Meter and A/C Amp. Circuit Check ...........161
ABS Actuator and Electric Unit (Control Unit) Circuit
Check ...................................................................161
IPDM E/R Circuit Check .......................................162CAN Communication Circuit Check ......................163
IPDM E/R Ignition Relay Circuit Check .................166
Component Inspection ..........................................166
ECM/IPDM E/R INTERNAL CIRCUIT INSPEC-
TION ..................................................................166
CAN SYSTEM (TYPE 5) ..........................................167
System Description ...............................................167
Component Parts and Harness Connector Location .167
Schematic .............................................................168
Wiring Diagram - CAN - ........................................169
Work Flow .............................................................172
CHECK SHEET .................................................174
CHECK SHEET RESULTS (EXAMPLE) ............176
Circuit Check Between TCM and Data Link Con-
nector ....................................................................192
Circuit Check Between Data Link Connector and
Unified Meter and A/C Amp. .................................192
Circuit Check Between Unified Meter and A/C Amp.
and ABS Actuator and Electric Unit (Control Unit) .193
Circuit Check Between ABS Actuator and Electric
Unit (Control Unit) and Driver Seat Control Unit ...194
ECM Circuit Check ................................................194
TCM Circuit Check ................................................195
Display Unit Circuit Check ....................................195
AWD Control Unit Circuit Check ...........................196
Data Link Connector Circuit Check .......................196
BCM Circuit Check ................................................197
Steering Angle Sensor Circuit Check ....................197
Unified Meter and A/C Amp. Circuit Check ...........198
ABS Actuator and Electric Unit (Control Unit) Circuit
Check ....................................................................198
Driver Seat Control Unit Circuit Check ..................199
IPDM E/R Circuit Check ........................................200
CAN Communication Circuit Check ......................200
IPDM E/R Ignition Relay Circuit Check .................205
Component Inspection ..........................................205
ECM/IPDM E/R INTERNAL CIRCUIT INSPEC-
TION ..................................................................205
CAN SYSTEM (TYPE 6) ..........................................206
System Description ...............................................206
Component Parts and Harness Connector Location .206
Schematic .............................................................207
Wiring Diagram - CAN - ........................................208
Work Flow .............................................................211
CHECK SHEET .................................................213
CHECK SHEET RESULTS (EXAMPLE) ............216
Circuit Check Between TCM and Data Link Con-
nector ....................................................................237
Circuit Check Between Data Link Connector and
Unified Meter and A/C Amp. .................................238
Circuit Check Between Unified Meter and A/C Amp.
and ABS Actuator and Electric Unit (Control Unit) .238
Circuit Check Between ABS Actuator and Electric
Unit (Control Unit) and Driver Seat Control Unit ...239
ECM Circuit Check ................................................240
TCM Circuit Check ................................................240
Display Control Unit Circuit Check ........................241
Low Tire Pressure Warning Control Unit Circuit
Check ....................................................................241

LAN-3
C
D
E
F
G
H
I
J
L
MA
B
LAN
Revision: 2004 November 2004 FX35/FX45AWD Control Unit Circuit Check ........................... 242
ICC Unit Circuit Check ......................................... 242
Intelligent Key Unit Circuit Check ......................... 243
Data Link Connector Circuit Check ...................... 243
BCM Circuit Check ............................................... 244
Steering Angle Sensor Circuit Check ................... 244
Unified Meter and A/C Amp. Circuit Check .......... 245
ICC Sensor Circuit Check .................................... 245
ABS Actuator and Electric Unit (Control Unit) Circuit Check ...................................................................246
Driver Seat Control Unit Circuit Check .................246
IPDM E/R Circuit Check .......................................247
CAN Communication Circuit Check ......................248
IPDM E/R Ignition Relay Circuit Check ................253
Component Inspection ..........................................253
ECM/IPDM E/R INTERNAL CIRCUIT INSPEC-
TION ..................................................................253

LAN-40
[CAN]
CAN SYSTEM (TYPE 1)
Revision: 2004 November 2004 FX35/FX45
Case 13
Check CAN communication circuit. Refer to LAN-47, "CAN Communication Circuit Check" .
Case 14
Check IPDM E/R ignition relay circuit continuously sticks “OFF”. Refer to LAN-51, "IPDM E/R Ignition Relay
Circuit Check" .
PKIA7940E
PKIA7942E

CAN SYSTEM (TYPE 1)
LAN-41
[CAN]
C
D
E
F
G
H
I
J
L
MA
B
LAN
Revision: 2004 November 2004 FX35/FX45
Case 15
Check IPDM E/R ignition relay circuit continuously sticks “ON”. Refer to LAN-51, "IPDM E/R Ignition Relay Cir-
cuit Check" .
Circuit Check Between TCM and Data Link ConnectorAKS00BZB
1. CHECK HARNESS FOR OPEN CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect the negative battery terminal.
3. Disconnect ECM connector and harness connector M82.
4. Check continuity between harness connector M82 terminals
14H (L), 15H (R) and data link connector M5 terminals 6 (L), 14
(R).
OK or NG
OK >> Connect all the connectors and diagnose again. Refer to
LAN-24, "
Work Flow" .
NG >> Repair harness.
Circuit Check Between Data Link Connector and Unified Meter and A/C Amp.AKS00BZC
1. CHECK HARNESS FOR OPEN CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect the negative battery terminal.
3. Disconnect ECM connector and unified meter and A/C amp. connector.
4. Check continuity between data link connector M5 terminals 6
(L), 14 (R) and unified meter and A/C amp. harness connector
M55 terminals 1 (L), 11 (R).
OK or NG
OK >> Connect all the connectors and diagnose again. Refer to
LAN-24, "
Work Flow" .
NG >> Repair harness.
PKIA7941E
14H (L) - 6 (L) : Continuity should exist.
15H (R) - 14 (R) : Continuity should exist.
SKIA6861E
6 (L) - 1 (L) : Continuity should exist.
14 (R) - 11 (R) : Continuity should exist.
SKIA6862E
