FEATURES OF YOUR HYUNDAI 1- 37
For the cigarette lighter to work, the key must be in the "ACC" position or the "ON" position.To use the cigarette lighter, push it all the way intoits socket. When the element has heated, thelighter will pop out to the "ready" position.Do not hold the cigarette lighter pressed in. Thiscan damage the heating element and create afire hazard.If it is necessary to replace the cigarette lighter,use only a genuine Hyundai replacement or itsapproved equivalent. CAUTION: Do not use electric accessories or equipmentother than the Hyundai genuine parts in thesocket. B430A01GK-AAT FRONT ASHTRAY The front ashtray may be opened by pushing and releasing the ashtray door at its top edge. To remove the ashtray in order to clean it, the metal ash receptacle should be lifted out from theashtray door. Do not attempt to remove the entireashtray door assembly or damage will result. Toreinstall it, place it in the proper position andpress it down in the ashtray door. The ashtraylamp will only illuminate when the exterior bodylights are switched on.
HGK146
B410A01A-AAT INSTRUMENT PANEL LIGHT CON- TROL (RHEOSTAT) The instrument panel lights can be made brighter or dimmer by turning the instrument panel lightcontrol knob. B420A02A-AAT CIGARETTE LIGHTERHGK134AHGK144

FEATURES OF YOUR HYUNDAI
1- 38 B340G01A-GAT HEADLIGHT LEVELING DEVICE SYS- TEM (If Installed) To adjust the headlight beam level according to the number of the passengers and the loadingweight in the luggage area, turn the beam level-ing switch.The higher the number of the switch position, thelower the headlight beam level. Always keep theheadlight beam at the proper leveling position, orheadlights may dazzle other road users.Listed below are the examples of proper switchsettings. For loading conditions other than thoselisted below, adjust the switch position so that thebeam level may be the nearest as the conditionobtained according to the list.
HGK157
B450A01GK-GAT DRINK HOLDER (If Installed)
HGK149
The drink holder is used for holding cups or cans. To use the passenger's drink holder, push thedrink holder. WARNING: Do not place objects other than cups or cansin the drink holder. Such objects can bethrown out in the event of a sudden stop or anaccident, possibly injuring the passengers inthe vehicle. Driver's
Passenger's
Switch
positionLoading condition
Driver only Driver + front passenger Full passengers (including driver)Full passengers (including driver) + full trunk loading (or light trailer loading)Driver + full trunk loading (or maximum trailer loading)
0 0 1 23
B460A01Y-AAT SUNROOF (If installed) Sun Shade
HGK029
Your HYUNDAI is equipped with a sliding sun- shade which you can manually adjust to let inlight with the sunroof closed, or to block sunlight.

FEATURES OF YOUR HYUNDAI
1- 42 B520A01A-AAT DAY/NIGHT INSIDE REARVIEW MIR- ROR
B520A01GK
Your Hyundai is equipped with a day/night inside rearview mirror. The "night" position is selectedby flipping the tab at the bottom of the mirrortoward you. In the "night" position, the glare ofheadlights of cars behind you is reduced. B520B01O-GAT DAY/NIGHT REAR VIEW MIRROR (Electric type) (If installed)
The electric type day/night inside rearview mirror automatically controls the glare of headlights ofthe car behind you. Adjust the rearview mirror tothe desired position.
B520B01GK
WARNING: Do not adjust or fold the outside rearviewmirrors while the vehicle is moving.This could result in loss of control, and anaccident which could cause death, seriousinjury or property damage.
Sensor
The outside rearview mirror heater is actuated in connection with the rear window defroster. Toheat the outside rearview mirror glass, push inthe switch for the rear window defroster. Therearview mirror glass will be heated for defrostingor defogging and will give you improved rearvision in inclement weather conditions. Push theswitch again to turn the heater off. The outsiderearview mirror heater automatically turns itselfoff after 15 minutes.
B510C01A-AAT FOLDING THE OUTSIDE REARVIEW MIRRORS
B510C01GK
To fold the outside rearview mirrors, push them towards the rear.The outside rearview mirrors can be folded rear-ward for parking in narrow areas.

FEATURES OF YOUR HYUNDAI 1- 43
B360A01F-AAT FRONT FOG LIGHT SWITCH (If Installed)
HGK142
To turn on the front fog lights, push the switch. They will light when the headlights are turned on. B360B01GK-GAT REAR FOG LIGHT SWITCH (If installed)HGK183
To turn on the rear fog lights, push the switch. They will come on when the headlights areturned on.
B530A01A-AAT PARKING BRAKE
HGK178
Always engage the parking brake before leaving the car. This also turns on the parking brakeindicator light when the key is in the "ON" or"START" position. Before driving away, be surethat the parking brake is fully released and theindicator light is off.
o To engage the parking brake, pull the lever up as far as possible.
o To release the parking brake, pull up the lever and press the thumb button. Then, while holding the button in, lower the brake lever.

FEATURES OF YOUR HYUNDAI
1- 44 B620A01S-AAT FRONT DOOR EDGE WARNING LIGHT A red light comes on when the front door is opened. The purpose of this light is to assist when you get in or out and also to warn passingvehicles.
B620A01GK2. Press the secondary latch lever up and lift the
hood.
3. Raise the hood by hand. When closing the hood, slowly close the hood and make sure it locks into place. WARNING:
o Always double check to be sure that the hood is firmly latched before driving away.If it is not latched, the hood could openwhile the vehicle is being driven, causinga total loss of visibility, which might resultin an accident.
o Do not move the vehicle with the hood in the raised position, as vision is obstructedand the hood could fall or be damaged.
B570A01GK-GAT HOOD RELEASE 1. Pull the release knob to unlatch the hood.
HGK106Hood Release Lever
HGK098
B550A01S-GAT HIGH-MOUNTED REAR STOP LIGHT In addition to the lower-mounted rear stoplights on either side of the car, the high mounted rearstoplight in the center of the rear window orinserted in the rear spoiler also lights when thebrakes are applied.
B550A01GK
A Type B Type C Type

DRIVING YOUR HYUNDAI
2- 2 C040A01A-AAT KEY POSITIONS WARNING: The engine should not be turned off or thekey removed from the ignition key cylinderwhile the vehicle is in motion. The steeringwheel is locked by removing the key.
C020A01A-AAT BEFORE STARTING THE ENGINEBefore you start the engine, you should always:
1. Look around the vehicle to be sure there are
no flat tires, puddles of oil, water or other indications of possible trouble.
2. After entering the car, check to be sure the parking brake is engaged.
3. Check that all windows, and lights are clean.
4. Check that the interior and exterior mirrors are clean and in position.
5. Check your seat, seatback and headrest to be sure they are in their proper positions.
6. Close all the doors.
7. Fasten your seat belt and be sure that all other occupants have fastened theirs.
8. Turn off all lights and accessories that are not needed.
9. When you turn the ignition switch to "ON", check that all appropriate warning lights areoperating and that you have sufficient fuel.
10. Check the operation of warning lights and all bulbs when key is in the "ON" position. o To start the engine, insert the ignition key and
turn it to the "START" position. Release it assoon as the engine starts. Do not hold the keyin the "START" position for more than 15seconds.
NOTE:For safety, the engine will not start if the shiftlever is not in "P" or "N" Position (AutomaticTransaxle).
C030A01A-GAT COMBINATION IGNITION SWITCH To Start the Engine
o If your Hyundai is equipped with a manual transaxle, place the shift lever in neutral and depress the clutch pedal fully.
o If your Hyundai has an automatic transaxle, place the shift lever in "P" (park). o "START"The engine is started in this position. It will crankuntil you release the key. NOTE: Do not hold the key in the "START" positionfor more than 15 seconds.
o "ON" When the key is in the "ON" position, the ignition is on and all accessories may be turned on. If theengine is not running, the key should not be leftin the "ON" position. This will discharge thebattery and may also damage the ignition sys-tem.
o "ACC" With the key in the "ACC" position, some electri-cal accessories (radio, etc.) may be operated.
o "LOCK" The key can be removed or inserted in thisposition.To protect against theft, the steering wheel locksby removing the key. NOTE: To unlocking the steering wheel, insert thekey, and then turn the steering wheel and keysimultaneously.
C040A01E
LOCK
ACC
ON
START

DRIVING YOUR HYUNDAI 2- 3
C050A01A-AAT STARTING WARNING: Never run the engine in a closed or poorlyventilated area any longer than is needed tomove your car in or out of the area. Thecarbon monoxide gas emitted is odorlessand can cause serious injury or death.
C050B01A-GAT Normal Conditions:The Starting Procedure:
1. Insert key, and fasten the seat belt.
2. Depress the clutch pedal fully and place the
gearshift lever (manual transaxle) in neutralor the selector lever (automatic transaxle) in"P" (park) position.
3. After turning the ignition key to the "ON" position, make certain all warning lights andgauges are functioning properly before start-ing the engine.
WARNING:Be sure that the clutch is fully depressedwhen starting a manual transaxle vehicle.Otherwise, there is the potential to causedamage to the vehicle or injury to someoneinside or outside the vehicle as a result of theforward or backward movement of the ve-hicle that will occur if the clutch is not de-pressed when the vehicle is started.
4. Turn the ignition key to the "Start" position and release it when the engine starts.
C070C01A-AAT To remove the ignition key
1. Turn the ignition key to the "ACC" position.
2. Simultaneously push and turn the ignition key
counterclockwise from the "ACC" position tothe "LOCK" position.
3. The key can be removed in the "LOCK" position.
C050A01E
LOCK
ON
STARTC070C01E
LOCK ACC
ON
START

DRIVING YOUR HYUNDAI
2- 6 C090B01A-AAT The function of each position is as follows: o P (Park): Use to hold the vehicle in place when parked orwhile starting the engine. Whenever parking thecar, apply the parking brake and shift the selectorlever to the "P" (Park) position. CAUTION: Never place the selector lever in the "P"(Park) position unless the vehicle is fullystopped. Failure to observe this caution willcause severe damage to the transaxle. C090C01A-AAT o R(Reverse): Use for backing up the vehicle. Bring the car to a complete stop before shifting the selector lever to"R" position. C090D02O-AAT o N (Neutral): In the "N" position, the transaxle is in neutral, which means that no gears are engaged. Theengine can be started with the shift lever in "N"position, although this is not recommended ex-cept if the engine stalls while the car is moving.
HGK174
C090A04Y-GAT AUTOMATIC TRANSAXLE The highly efficient Hyundai automatic transaxle has four forward speeds and one reverse speed.The individual speeds are selected automatical-ly, depending on the position of the speed selec-tor lever. The selector lever has 2 gates; the maingate and the manual gate. NOTE: For information on manual gate operation,refer to "Sports Mode". In the main gate, the selector lever has 4 posi- tions, and is equipped with a button to avoidinadvertent wrong selection. NOTE:
Depress the brake pedal and push the button when shifting.Push the button when shifting.The selector lever can be shifted freely.
The first few shifts on a new vehicle, or if the battery has been disconnected, may be some-what abrupt. This is a normal condition, andthe shifting sequence will adjust after shiftsare cycled a few times by the T.C.M (Trans-mission Control Module). CAUTION: Never shift into "R" or "P" position while thevehicle is moving.
The indicator lights in the instrument cluster indicate the selector lever position when theignition is switched "ON". During "D" or sportsmode operation, the gear currently in use dis-plays in the numeral indicator.
C090A02L
