2004 FIAT CROMA CD player

67
RADIO WITH COMPACT DISC
AND MP3 CD PLAYERRADIO WITH
COMPACT DISC PLAYER
MENU
Functions of button 12 (MENU-PRESET SCAN)
To activate the menu function, briefly press button 12
(MENU-PRESET SCAN). The display shows the word
“MENU”.
To scroll the menu functions use buttons 3 (
N) or 6
(
O). To change the setting of the function selected,
use buttons 7 (
÷) or 5 (˜).
The display will show the current status of the
function selected.
The functions controlled by the menu are the
following:
❒PRESET/USER/CLASSIC/ROCK/JAZZ (turning
on/off and choosing predefined equalizer
adjustments);
❒USER EQ SETTINGS (equalizer setting, only if USER
equalizer setting has been selected);
❒REGIONAL MODE (regional programmes);
❒CD DISPLAY (CD data display);
❒MP3 DISPLAY (MP3 CD data display);
❒CDC DISPLAY (CD Changer data display, if
installed); MP3 Info function (directory data info)
Press briefly button 8 (6-MP3
|) to display the name
of the current directory: the display will show the
name of the currently selected directory for about
5 seconds. Then the previously selected CD mode
will be displayed again.
If button 8 (6-MP3
|) is pressed again during
directory name displaying, the name of the MP3
track being played will be displayed twice for about
5 seconds. Then the previously selected CD mode
will be displayed again.

68
RADIO WITH COMPACT DISC
AND MP3 CD PLAYERRADIO WITH
COMPACT DISC PLAYER
❒SENSITIVITY (tuning sensitivity);
❒SVC SETTING (automatic volume control in
relation to speed);
❒CD NAMING FUNCTION (allocation of CD
names, only with CD or CD Changer selected);
❒VOICE SETTINGS (Telephone volume, if installed);
❒HICUT FUNCTION (Treble reduction);
❒IGNITION TIMER (System power off mode);
To exit the menu function, press button 12 (MENU-
PRESET SCAN) again.
PRESET /USER / CLASSIC / ROCK / JAZZ
function (equalizer on/off)
The integrated equalizer can be turned on or off. With
the equalizer off, it is possible to change the sound
settings only adjusting the bass (“BASS”) and treble
tones (“TREBLE”), while activating the function makes
it possible to adjust the sound curves.
To turn the equalizer off, select “PRESET” with button
7 (
÷) or 5 (˜).To turn the equalizer on,select one of the following
with button 7 (
÷) or 5 (˜):
❒“USER” (adjustment of the 7 equalizer bands that
can be changed by the user);
❒“CLASSIC” (predefined equalizer adjustment for
best playing of classic music);
❒“ROCK” (predefined equalizer adjustment for best
playing of rock and pop);
❒“JAZZ” (predefined equalizer adjustment for best
playing of jazz).
After selecting the last adjustment set in the Menu
using buttons 3 (
N) or 6 (O), use button 7 (÷) or
5 (
˜) to change it.
When one of the equalizer settings is on, the display
shows “EQ”.

69
RADIO WITH COMPACT DISC
AND MP3 CD PLAYERRADIO WITH
COMPACT DISC PLAYER
USER EQ SETTINGS function
(equalizer settings only if USER is selected)
To set a personal equalizer adjustment,use button 7
(
÷) or 5 (˜) to select “USER EQ SETTINGS”.
To change the equalizer settings,use button 7 (
÷)
or 5 (
˜). The display shows a graph with 7 bars,
where each bar represents a frequency for the left or
right channel. Choose the bar to be adjusted using
button 7 (
÷) or 5 (˜); the bar chosen starts to
flash and it is possible to adjust it using button 3 (
N)
or 6 (
O).
To store the new settings,press button 12 (MENU-
PRESET SCAN) again. The display still shows “USER
EQ SETTINGS”.
REGIONAL MODE function
(regional broadcast reception)
Certain national broadcasters,at determinate times of
the day, transmit regional programmes which differ
from region to region. This function makes it possible
to tune in only on local stations (regional). Therefore,
if a regional programme is heard and you wish to stay
tuned to it, the function must be activated.
To turn the function on/off use button
7 (
÷) or 5 (˜).The display will show the current status of the
function:
❒“REGIONAL MODE: ON” (function on);
❒“REGIONAL MODE: OFF” (function off).
If the function is off and a regional programme is tuned
that works in a determinate area and the car enters a
different area, the regional station of the new area is
received.
IMPORTANT When the function is off (“REGIONAL
MODE: OFF”)and the AF function is on (alternative
frequencies) the radio automatically tunes to the
frequency of the station selected with the strongest
signal.
CD DISPLAY function (CD data display)
With this function it is possible to choose the
information shown on the display, when listening to a
Compact Disc.
After choosing “CD” in the menu using buttons 3 (
N)
or 6 (
O) the display shows “CD DISPLAY”. To change
the setting use buttons 7 (
÷) or 5 (˜).
The display shows the setting among the two possible:
❒“TIME” (time elapsed from start of track);
❒“NAME” (CD name).

70
RADIO WITH COMPACT DISC
AND MP3 CD PLAYERRADIO WITH
COMPACT DISC PLAYER
MP3 DISPLAY function (MP3 CD data display)
With this function it is possible to choose the
information shown on the display, when listening to a
MP3 CD.
This function can be chosen only if a MP3 CD is
inserted.In this case the display will show “MP3
DISPLAY”. To change the function use buttons 7
(
÷) or 5 (˜).
The display shows the setting among the four possible:
❒“DIR” (directory name);
❒“TRACK” (track name).
❒“TIME” (time elapsed from start of track);
❒“NAME” (CD name).
CDC DISPLAY function
(CD Changer data display) (if installed)
This function can be chosen only if a CD Changer is
connected.In this case the display will show “CDC
DISPLAY”.
To change the function use buttons 7 (
÷) or 5
(
˜).
The display shows the setting among the three
possible:
❒“TIME” (time elapsed from start of track);
❒“CD NR” (CD number);
❒“NAME” (CD name).SENSITIVITY function
(tuner sensitivity adjustment)
With this function it is possible to change the
sensitivity of automatic station searching. When low
sensitivity is set “SENSITIVITY: LOCAL” only stations
with excellent reception are sought;when high
sensitivity is set “SENSITIVITY: DISTANCE” all
stations are sought. Therefore, if the car is in an area
with a considerable number of stations and you want
to choose only those with a strong signal, set to low
sensitivity “SENSITIVITY: LOCAL”.
To set the sensitivity, use button 7 (
÷) or 5 (˜).
The display will show the current status of the
function:
❒“SENSITIVITY: LOCAL” (low sensitivity);
❒“SENSITIVITY: DISTANCE” (high sensitivity).

71
RADIO WITH COMPACT DISC
AND MP3 CD PLAYERRADIO WITH
COMPACT DISC PLAYER
SVC SETTING function
(volume changing with speed)
The SVC function makes it possible to automatically
adapt the volume level to the speed of the car,
increasing it as the speed increases to maintain the
ratio with the noise level in the passenger
compartment.
To turn the function on/off use button 7 (
÷) or 5
(
˜). The display will show the current status of the
function:
❒“SVC SETTING: ON” (function on);
❒“SVC SETTING: OFF” (function off).
CD NAMING function
(allocating a name to a CD)
Use the CD NAME function to give a name (max.
name length = 8 characters) to max. 30 CDs.
This function can be selected only if in Compact Disc
or CD Changer mode. To turn this function on, use
button 7 (
÷) or 5 (˜): the display shows “CD
NAMING FUNCTION”. If the CD already has a name,
this will be shown on the display, if not, eight dashes
will be shown. If storage is no longer available for a
new name, the display will show the first name stored.To change the name or give a name to the new CD
press button 7 (
÷) or 5 (˜). Press the buttons
again to choose the position of the character to be
changed. Press buttons 3 (
N) or 6 (O) to choose or
change the character.
To store the name, press button 12 (MENU-PRESET
SCAN) again. The display will show “CD NAME”.
To clear a name, turn the function on and press
button 16 (2-CLR) for about 5 seconds. The system
beeps and the display shows “ONE NAME DELETED”
for about 2 seconds. At this point the procedure can
be started to give a new name.
To clear all the names, turn the function on and keep
button 16 (2-CLR) pressed for over 8 seconds. The
set gives two beeps and the display shows “ALL
NAMES DELETED” for about 2 seconds. At this point
it is possible to start the name allocation procedure.

72
RADIO WITH COMPACT DISC
AND MP3 CD PLAYERRADIO WITH
COMPACT DISC PLAYER
VOICE SETTINGS function
(telephone volume adjustment)
With this function it is possible to adjust (setting from
1 to 66) or cut off (OFF setting) the telephone sound.
To turn the function on/off use button 7 (
÷) or 5
(
˜).
To adjust, turn the button/knob 19 (ON/OFF
VOLUME).
The display will show the current status of the
function:
❒“VOICE VOLUME 23”: function on with volume
setting 23
❒“VOICE FUNCTION OFF”: function off.
HICUT function (treble reduction)
Using this function it is possible to reduce the treble
tones, in accordance with the signal transmitted.
To turn the function on/off, use button
7 (
÷) or 5 (˜).
The display will show the current status of the
function:
❒“HICUT FUNCTION: ON” (function on);
❒“HICUT FUNCTION: OFF” (function off).IGNITION TIMER function
(system power off mode)
This function enables to switch off the sound system
according to two different modes. To turn this
function on/off, use buttons 7 (
÷) or 5 (˜).
The display will show the chosen mode:
❒“00 MIN”: deactivation dependent on ignition key.
Sound system will switch off automatically when
turning the ignition key to STOP;
❒“20 MIN”: deactivation independent of ignition key.
After having turned the ignition key to STOP, the
sound system will stay on for 20 minutes max.
IMPORTANT When the sound system is switched off
automatically after turning the ignition key to OFF
(for both immediate or 20-minute delayed power off),
it will switch on automatically turning the ignition key
to ON. If the sound system has been switched off
pressing the knob/button 19 (ON/OFF VOLUME),
when turning the key to ON it will stay off.

73
RADIO WITH COMPACT DISC
AND MP3 CD PLAYERRADIO WITH
COMPACT DISC PLAYER
TECHNICAL INFORMATION
Radio
Maximum power: 4x40W
Sound system
The system includes:
❒2 tweeters (A), 40W max. power, set on front doors as shown in the
figure;
❒2 mid-woofers (B), 165 mm diameter, 40W max. power, set on front
doors;
❒2 rear full-range speakers (C), 165 mm diameter, 40W max. power,
set on rear doors.
F0L0165m
F0L0167m
F0L0169m

74
RADIO WITH COMPACT DISC
AND MP3 CD PLAYERRADIO WITH
COMPACT DISC PLAYER
CD Changer (where provided)
The car can be equipped with a CD Changer for 5 discs set in the glove
compartment.
Protection fuse
The radio has a 10A fuse.
Hi-Fi system (where provided)
The system includes:
❒2 tweeters (D), 40W power, set on front doors as shown in the figure;
❒2 woofers (E), 165 mm diameter, 40W power, set on front doors;
❒2 tweeters (F), 40W power, set on front doors;
❒2 woofers (G), 165 mm diameter, 40W power, set on rear doors;
❒1 subwoofer, 100 W power set on the right side of the boot.
Subwoofer is protected by a fuse
F0L0166m
F0L0168m
F0L0170m
