2004 FIAT CROMA Radio CD Manual

RADIO WITH
COMPACT DISC PLAYER
RADIO WITH COMPACT DISC
AND MP3 CD PLAYER
F0L0055m
F0L0056m

INTRODUCTION ................................................................. 4
ADVICE ..................................................................................... 4
- Road safety ............................................................................ 4
- Reception conditions .......................................................... 4
- Care and maintenance ........................................................ 5
- Compact Disc ....................................................................... 5
RADIO WITH COMPACT DISC PLAYER
CONTROL DESCRIPTION ................................................. 7
GENERAL ................................................................................. 12
- Radio section ......................................................................... 12
- Compact Disc section ......................................................... 13
- Audio section ........................................................................ 13
- Antitheft protection ............................................................ 13
GLOSSARY .............................................................................. 15
OPERATION ........................................................................... 18Controls on steering wheel .................................................. 18
Functions and adjustments ................................................... 20
Telephone provision .............................................................. 24
Radio (Tuner) .......................................................................... 25
Menu .......................................................................................... 38
Compact Disc player ............................................................. 43
CD Changer ............................................................................. 48
Technical information ............................................................ 53
RADIO WITH COMPACT DISC
AND MP3 CD PLAYER
CONTROL DESCRIPTION ................................................. 55
INTRODUCTION ................................................................. 60
MP3 mode ................................................................................ 60
Menu .......................................................................................... 67
Technical information ............................................................ 73
C C C C
O O O O
N N N N
T T T T
E E E E
N N N N
T T T T
S S S S

4
INTRODUCTION
Sound system, fitted with CD player (radio
with Compact Disc player) or MP3 CD player (radio
with MP3 CD player) has been designed in accordance
with the special features of the passenger
compartment, with a personalised design that blends
with the style of the dashboard. The sound system
cannot be adapted to other vehicles and for this
reason it cannot be removed.
The radio is installed in a user-friendly position for the
driver and passenger and the graphics on the front
panel make location of the controls quick, facilitating
use.
The CD Changer for 10 discs (if provided), is housed
in the boot.
In the following pages you will find the instructions for
use, which you are advised to read through carefully.
The instructions also contain the procedure for
controlling the CD Changer (if provided) through the
radio. For the instructions for use of the CD Changer
refer to the specific manual.
ADVICE
Road Safety
You are advised to learn how to use the various radio
functions (e.g.: storing stations) before starting to
drive.
Reception conditions
Reception conditions change constantly when driving.
Reception may be disturbed by the presence of
mountains, buildings or bridges particularly when far
away from the station being listened to.
IMPORTANT When receiving traffic information, the
volume may be higher than normal.
WARNINGToo high a volume when driving can put the driver’s life at risk and that of other
people. Therefore the volume should always be adjusted in such a way that it is
always possible to hear the noises of the surrounding environment (e.g.: horns,
ambulance, police sirens, etc.).

5
Care and maintenance
The radio structure ensures long operation with no
need for particular maintenance.In the event of a fault,
contact a Fiat Dealership.
To clean the front panel only use a soft, antistatic
cloth. Cleaning and polishing products might spoil the
surface.
Compact Disc
Remember that dirt,marks or distortion on Compact
Disc can cause skipping. To obtain optimum playing
conditions we give the following advice:
❒only use Compact Discs which have the following
brand:
❒carefully clean all Compact Discs of fingerprints and
dust using a soft cloth. Support Compact Discs from
the outer circumference and clean from the centre
outwards;❒never use chemical products for cleaning (e.g.: spray
cans,antistatic or thinners) as they might damage
the surface of Compact Discs;
❒after use, put Compact Discs back in their
container, to avoid marks or scratches that may
cause skipping when playing;
❒do not expose Compact Discs to direct sunlight,
high temperatures or damp for prolonged lengths of
time to prevent them from bending;
❒do not stick labels or write on the recorded surface
of Compact Discs with pens or pencils.
To remove a Compact Disc from its container, press
the centre and raise the disc carefully, holding it by the
outer circumference.
Always hold Compact Discs by the outer
circumference. Never touch the surface.
To remove fingerprints and dust, use a soft cloth
starting from the centre of the Compact Disc
outwards.

6
Do not use highly scratched, cracked, or distorted
discs, etc. The use of these discs will involve
malfunctioning or damage to the player.
For best playing use only original CDs. Proper
operation is not guaranteed when using R/RW CDs
not properly mastered and/or with max. capacity
exceeding 650 MB.
IMPORTANT Do not use the protective sheets fo
CD in commerce or discs with stabilisers, etc.as they
might get stuck in the internal mechanism and damage
the disc.IMPORTANT Should copy-protected CDs be used,
then, few seconds may be required for playing them.
IMPORTANT The CD player can read most of the
compression systems currently on sale (e.g.: LAME,
BLADE,XING, FRAUNHOFER); however, due to the
evolution of these systems, reading of all compression
formats is not guaranteed.
WARNING When loading a multi-session CD, only
the first session will be played.
New discs may be rough around the edges. When
these discs are used, the player might not work or the
sound might skip. To remove the roughness from the
edge of the disc use a ball-point pen, etc.

RADIO WITH COMPACT DISC
AND MP3 CD PLAYER
RADIO WITH
COMPACT DISC PLAYER
7
R R R R
A A A A
D D D D
I I I I
O O O O

W W W W
I I I I
T T T T
H H H H

C C C C
O O O O
M M M M
P P P P
A A A A
C C C C
T T T T

D D D D
I I I I
S S S S
C C C C

P P P P
L L L L
A A A A
Y Y Y Y
E E E E
R R R R
CONTROL DESCRIPTIONF0L0057m

8
RADIO WITH COMPACT DISC
AND MP3 CD PLAYER
RADIO WITH
COMPACT DISC PLAYER
1
2
3
4
5
6
7
8
9
10
SOURCE-SCAN
Display
N
˚
˜
O
÷
6
AUDIO-LOUDNESS
5-MIXSelect audio source/Scan function
Automatic station tuning
Eject CD
Manual station tuning
Automatic station tuning
Manual station tuning
Preset station 6
Audio settings/Loudness
Preset station 5/MIX functionSelect CD,CD Changer
(if installed) or Radio
Manual station tuning
TP: seek +
PTY: seek +
AF: seek +
Eject CD
Manual station tuning
TP: seek +
PTY: seek +
AF: seek +
Automatic station tuning
TP: seek -
PTY: seek -
AF: seek -
Manual station tuning
TP: seek -
PTY: seek -
AF: seek -
FM/AM:call preset
station 6
Bass (B)
Treble (T)
Fader (F)
Balance (B)
FM/AM: call preset
station 5FM/AM station scan
Fast manual station tuning
TP: seek +
PTY: seek +
AF: seek +
Fast manual station tuning
TP: seek +
PTY: seek +
AF: seek +
Fast automatic station tuning
TP: seek -
PTY: seek -
AF: seek -
Fast manual station tuning
TP: seek -
PTY: seek -
AF: seek -
FM/AM:call preset
station 6
Loudness on/off
FM/AM: call preset
station 5
ButtonButtons and front panel
Letters or symbol FunctionRADIO mode
Short-push function (less than 2 sec.) Long-push function (over 2 sec.)
